Model Whirlpool 4PLGC8647JT1 29``GAS DRYER – Common Parts &amp; Diagrams

1

Following May Be Purchased DO-IT-YOURSELF REP WPL ARI140753A Contact Us For Availability

1

Literature Parts (Installation Instructions ( WPL LIT3405338 Contact Us For Availability

1

Literature Parts (Dryer) WPL LIT677818 Contact Us For Availability

1

Literature Parts (Installation Instructions ( WPL LIT8318357 Contact Us For Availability

1

Literature Parts (Guide, Use & Care) WPL LIT8318359 Contact Us For Availability

1

Literature Parts (Wiring Diagram) WPL LIT8533211 Contact Us For Availability

2

W10103406 Whirlpool Rear Panel Backorder WPL W10103406 $42.99

2

WP489463 Whirlpool Refrigerator Screw In Stock WPL WP489463 $2.51

3

WP3394427 Whirlpool Clip In Stock WPL WP3394427 $3.70

3

WP3404162 Whirlpool Clamp In Stock WPL WP3404162 $3.70

4

279311 Whirlpool Dryer Flat Igniter Assembly In Stock WPL 279311 $15.72

4

W11415783 Whirlpool Seal In Stock WPL W11415783 $6.81

4

Cap, End (L.H.) WPL 8271368 Contact Us For Availability

5

3401144 Whirlpool Connector Backorder WPL 3401144 $7.89

5

W11539855 Whirlpool Refrigerator Pump In Stock WPL W11539855 $338.82

5

WP90767 Whirlpool Screw In Stock WPL WP90767 $2.51

5

WPW10366705 Whirlpool Screw In Stock WPL WPW10366705 $2.51

6

WP681414 Whirlpool Screw In Stock WPL WP681414 $2.51

6

Wire, Jumper (Black) WPL 3401684 Contact Us For Availability

6

Wire Jumper (Yellow/Black) WPL 3401666 Contact Us For Availability

7

WP3392519 Whirlpool Dryer Thermal Fuse In Stock WPL WP3392519 $7.30

7

Base, Burner WPL 693986 Contact Us For Availability

8

WP693995 Whirlpool Screw In Stock WPL WP693995 $1.92

8

Cap, End (R.H.) WPL 8271362 Contact Us For Availability

9

3952439 Whirlpool Buzzer Backorder WPL 3952439 $29.43

9

WP229742 Whirlpool Gas Orifice Backorder WPL WP229742 $12.08

9

WP234826 Whirlpool Gas Orifice In Stock WPL WP234826 $12.08

9

WP234868 Whirlpool Gas Orifice Backorder WPL WP234868 $12.08

9

WP3387137 Whirlpool Thermostat In Stock WPL WP3387137 $43.24

9

Orifice, Burner (Type 3) WPL 15419 Contact Us For Availability

9

Orifice, Burner (Type 2) WPL 15775 Contact Us For Availability

10

279923 Whirlpool Gas Valve In Stock WPL 279923 $150.52

10

WP349639 Whirlpool Lint Filter In Stock WPL WP349639 $19.80

10

WP694089 Whirlpool Dryer Blower Wheel In Stock WPL WP694089 $16.56

11

694421 Whirlpool Screw Assembly Backorder WPL 694421 $7.58

11

Cover, Lint Screen WPL 8283380 Contact Us For Availability

12

694538 Whirlpool Bracket Backorder WPL 694538 $40.00

12

WPW10044470 Whirlpool Hinge Assembly In Stock WPL WPW10044470 $3.70

12

WPW10044480 Whirlpool Hinge Assembly In Stock WPL WPW10044480 $3.70

13

W11693756 Whirlpool Screw Assembly Backorder WPL W11693756 $8.11

279834 Whirlpool Dryer Gas Valve Solenoid Coi In Stock WPL 279834 $12.01

Wire, Jumper (Violet) WPL 3393811 Contact Us For Availability

Wire, Jumper (Light Blue) WPL 3393812 Contact Us For Availability

Wire, Jumper (White) WPL 3401667 Contact Us For Availability

16

49621 Whirlpool Leveling Feet In Stock WPL 49621 $2.29

16

W11398682 Whirlpool Bracket Backorder WPL W11398682 $19.91

16

Top WPL 8271392 Contact Us For Availability

18

3400859 Whirlpool Screw Backorder WPL 3400859 $9.13

19

WP98234 Whirlpool Nut In Stock WPL WP98234 $4.78

19

Switch, Clean Touch WPL 8316078 Contact Us For Availability

20

W10295523 Whirlpool Plug Backorder WPL W10295523 $10.76

20

Bumper, Lint Lid WPL 297535 Contact Us For Availability

21

WP3406282 Whirlpool Timer Backorder WPL WP3406282 $207.59

21

Seal, Blower WPL 3394196 Contact Us For Availability

21

Pipe, Gas Supply WPL 233273 Contact Us For Availability

22

8066086 Whirlpool Plug Backorder WPL 8066086 $4.76

22

WP3403499 Whirlpool Connector Backorder WPL WP3403499 $3.51

22

Elbow Union Assembly WPL 3406052 Contact Us For Availability

23

3393767 Whirlpool Pipe Backorder WPL 3393767 $57.12

23

WP3403498 Whirlpool Connector Backorder WPL WP3403498 $3.70

24

WPW10139210 Whirlpool Screw In Stock WPL WPW10139210 $2.51

24

Nut, Compression WPL 233076 Contact Us For Availability

341029 Whirlpool Clamp Backorder WPL 341029 $7.58

49572A Whirlpool Dryer Propane Gas Conversion In Stock WPL 49572A $15.98

W10861521 Whirlpool Dryer Door Seal In Stock WPL W10861521 $38.69

WP357213 Whirlpool Hinge Stopper Backorder WPL WP357213 $3.70

26

Harness, Wiring WPL 8283172 Contact Us For Availability

27

WP348197 Whirlpool Washer Assembly Backorder WPL WP348197 $2.51

27

WPW10112633 Whirlpool Relay Parts Backorder WPL WPW10112633 $39.84

28

WP3359452 Whirlpool Nut In Stock WPL WP3359452 $2.51

28

WP3957755 Whirlpool Knob Backorder WPL WP3957755 $1.68

29

3957797 Whirlpool Knob Backorder WPL 3957797 $29.43

29

W10854425 Whirlpool Dryer Front Panel Bottom In Stock WPL W10854425 $6.19

29

W11178668 Whirlpool Bulkhead Backorder WPL W11178668 $104.56

30

WP338906 Whirlpool Dryer Gas Sensor In Stock WPL WP338906 $17.97

30

Receptacle, 2 Way WPL 717252 Contact Us For Availability

32

WP94614 Whirlpool Terminal Backorder WPL WP94614 $2.51

33

W11429589 Whirlpool Strike In Stock WPL W11429589 $9.48

33

Bracket, Control WPL 8271426 Contact Us For Availability

34

Panel, Control WPL 8318390 Contact Us For Availability

35

3936144 Whirlpool Connector Backorder WPL 3936144 $10.76

35

WP692490 Whirlpool Drum Baffle In Stock WPL WP692490 $49.76

36

W11684613 Whirlpool Bracket Backorder WPL W11684613 $7.96

36

Door, Front WPL 3402337 Contact Us For Availability

3406839 Whirlpool Drying Rack In Stock WPL 3406839 $42.42

350938 Whirlpool Spray Gun In Stock WPL 350938 $32.57

4392065 Whirlpool Dryer Maintenance Kit In Stock WPL 4392065 $16.88

4392899 Whirlpool Biscuit Touch-Up Paint In Stock WPL 4392899 $6.86

4392901 Whirlpool Biscuit Spray Paint In Stock WPL 4392901 $26.26

W11224254 Whirlpool Test Kit In Stock WPL W11224254 $4.76

WP3405189 Whirlpool Handle Backorder WPL WP3405189 $28.80

WP388326 Whirlpool Screw Backorder WPL WP388326 $2.51

WP90296 Whirlpool Clip Backorder WPL WP90296 $2.51

WPL 4392900 WPL 4392900 Contact Us For Availability

WPL ARI140754A WPL ARI140754A Contact Us For Availability

38

WP3403636 Whirlpool Drum Baffle Backorder WPL WP3403636 $45.29

39

WP339956 Whirlpool Foam Seal In Stock WPL WP339956 $3.70

40

W11233063 Whirlpool Shield Assembly Backorder WPL W11233063 $10.76

53

WP691366 Whirlpool Dryer Idler Pulley Assembl In Stock WPL WP691366 $5.69

57

WP348780 Whirlpool Base In Stock WPL WP348780 $36.31

58

3400500 Whirlpool Screw Backorder WPL 3400500 $9.59

59

W11233559 Whirlpool Motor Pulley Backorder WPL W11233559 $40.37

63

WP660658 Whirlpool Clamp In Stock WPL WP660658 $3.70

74

WP694424 Whirlpool Limiter In Stock WPL WP694424 $12.57

75

WP694423 Whirlpool Regulator Backorder WPL WP694423 $3.70

76

WP694422 Whirlpool Spring Backorder WPL WP694422 $9.42
