Model Whirlpool 106.72132100 Refrigerator (Kenmore 10672132100) – Common Parts &amp; Diagrams

1

W11023679 Whirlpool Refrigerator Door Assembl Backorder WPL W11023679 $471.91

1

Refrigerator Housing WPL 2210500 Contact Us For Availability

1

Outer Shelf Support WPL 2210522 Contact Us For Availability

1A

W11023688 Whirlpool Refrigerator Door Assembl Backorder WPL W11023688 $450.46

2

WP2201061 Whirlpool Refrigerator Door Trim In Stock WPL WP2201061 $35.91

2

Ladder WPL 2202821 Contact Us For Availability

3

WP488878 Whirlpool Refrigerator Tube Clamp Backorder WPL WP488878 $4.81

3

Refrigerator Door Trim Screw WPL 489487 Contact Us For Availability

3

Refrigerator Pan Trim WPL 2176357 Contact Us For Availability

4

4387491 Whirlpool Refrigerator Insert In Stock WPL 4387491 $3.70

4

W11745278 Whirlpool Bracket In Stock WPL W11745278 $5.18

4

WP2166108 Whirlpool Refrigerator Cabinet Roll In Stock WPL WP2166108 $13.54

4

WP2195341 Whirlpool Refrigerator Pan Trim Backorder WPL WP2195341 $30.18

4

Refrigerator Water Tubing Clip WPL 2210523 Contact Us For Availability

5

WP488921 Whirlpool Refrigerator Screw Backorder WPL WP488921 $2.51

5

WP628379 Whirlpool Refrigerator Clip Backorder WPL WP628379 $4.61

6

8281197 Whirlpool Refrigerator Screw Backorder WPL 8281197 $5.38

6

WP2162361 Whirlpool Switch In Stock WPL WP2162361 $8.80

6

WP8281206 Whirlpool Refrigerator Screw Backorder WPL WP8281206 $2.51

6

WP941839 Whirlpool Refrigerator Button Plug In Stock WPL WP941839 $3.70

6

Refrigerator Crisper Drawer Humidity Control WPL 2176222 Contact Us For Availability

7

W10823511 Whirlpool Refrigerator Water Tube In Stock WPL W10823511 $13.36

7

WP2156007 Whirlpool Refrigerator Endcap Trim In Stock WPL WP2156007 $3.70

7

WP2212446 Whirlpool Refrigerator Control Body In Stock WPL WP2212446 $34.50

7

WP2212648 Whirlpool Refrigerator Hinge Sleeve Backorder WPL WP2212648 $3.70

7A

WP2212649 Whirlpool Refrigerator Button Plug Backorder WPL WP2212649 $3.70

8

2159060 Whirlpool Refrigerator Gasket In Stock WPL 2159060 $120.49

8

2159061 Whirlpool Refrigerator Door Gasket In Stock WPL 2159061 $98.99

8

W11544659 Whirlpool Refrigerator Screw Backorder WPL W11544659 $9.59

WP2183003 Whirlpool Thimble In Stock WPL WP2183003 $3.70

WP2314549 Whirlpool Refrigerator Cover In Stock WPL WP2314549 $113.65

WP3400504 Whirlpool Refrigerator Screw Backorder WPL WP3400504 $3.70

WPW10498990 Whirlpool Refrigerator Inlet Valv In Stock WPL WPW10498990 $97.16

11

WP2176225 Whirlpool Glass Shelf Backorder WPL WP2176225 $134.44

11

WP2204812 Whirlpool Refrigerator Door Bin In Stock WPL WP2204812 $50.01

11

WP245183 Whirlpool Nut Backorder WPL WP245183 $2.51

12

WP2254533W Whirlpool Refrigerator Handle In Stock WPL WP2254533W $66.77

12

Refrigerator Cantilever Shelf WPL 2210444 Contact Us For Availability

12

Refrigerator Door Handle (White) WPL 2195276W Contact Us For Availability

12A

Refrigerator Handle (Off-White) WPL 2195276T Contact Us For Availability

12A

Refrigerator Handle (Off-White) WPL 2195248T Contact Us For Availability

13

Refrigerator Temperature Control Thermostat WPL 2210491 Contact Us For Availability

13

Shim WPL 2172743 Contact Us For Availability

14

WP2156006 Whirlpool Refrigerator Shelf Trim E In Stock WPL WP2156006 $4.10

14

WP2188785 Whirlpool Water Inlet Valve Backorder WPL WP2188785 $105.79

WP2172748 Whirlpool Drawer Support Backorder WPL WP2172748 $55.95

WP2188236 Whirlpool Refrigerator Shelf Door In Stock WPL WP2188236 $29.42

WP489497 Whirlpool Screw In Stock WPL WP489497 $4.58

WP627018 Whirlpool Refrigerator Nut In Stock WPL WP627018 $4.59

16

WP488366 Whirlpool Refrigerator Clamp Backorder WPL WP488366 $4.81

16

WP489357 Whirlpool Recessed Screw In Stock WPL WP489357 $2.51

16

Refrigerator Cantilever Shelf WPL 2214907 Contact Us For Availability

WP2183854 Whirlpool Refrigerator Shim Backorder WPL WP2183854 $4.54

WP8281146 Whirlpool Screw Backorder WPL WP8281146 $2.51

Refrigerator Freezer Door Shelf Trim WPL 2195947 Contact Us For Availability

Refrigerator Glass Shelf WPL 2184667 Contact Us For Availability

Refrigerator Nut WPL 1129179 Contact Us For Availability

18

WPW10289690 Whirlpool Ice Maker Cover Backorder WPL WPW10289690 $2.64

18

Refrigerator Nameplate WPL 2193145W Contact Us For Availability

18A

Refrigerator Nameplate WPL 2193145T Contact Us For Availability

2163762 Whirlpool Refrigerator Cup Assembly Backorder WPL 2163762 $4.32

W11384469 Whirlpool Door Switch In Stock WPL W11384469 $15.76

WP489464 Whirlpool Refrigerator Screw Backorder WPL WP489464 $3.70

Refrigerator Defrost Heater Bracket WPL 2182338 Contact Us For Availability

Refrigerator Door Trim (White) WPL 2193144W Contact Us For Availability

19A

Refrigerator Extension WPL 2193144T Contact Us For Availability

20

WP2218132K Whirlpool Crisper Meat Pan In Stock WPL WP2218132K $88.62

20

WPW10190929 Whirlpool Refrigerator Ice Maker Backorder WPL WPW10190929 $153.49

W11594405 Whirlpool Axle In Stock WPL W11594405 $6.90

WPW10421486 Whirlpool Refrigerator Door Trim In Stock WPL WPW10421486 $44.25

Refrigerator Air Damper Cover WPL 2176281 Contact Us For Availability

Refrigerator Drawer Slide Rail WPL 2214892 Contact Us For Availability

22

WP2195916K Whirlpool End Cap In Stock WPL WP2195916K $7.08

22

WP628356 Whirlpool Refrigerator Fill Cup Backorder WPL WP628356 $17.55

22

Refrigerator Evaporator Support Block WPL 2201185 Contact Us For Availability

2254352A Whirlpool Refrigerator Ice Container In Stock WPL 2254352A $16.93

WP2218118 Whirlpool Refrigerator Door Compres Backorder WPL WP2218118 $48.99

WP627843 Whirlpool Refrigerator Ejector Arm In Stock WPL WP627843 $32.06

Refrigerator Freezer Air Tower WPL 2182340 Contact Us For Availability

W10854037 Whirlpool Refrigerator Crisper Pan In Stock WPL W10854037 $99.21

WP2182124 Whirlpool Refrigerator Stripper Arm Backorder WPL WP2182124 $29.83

WP2189000 Whirlpool Refrigerator Handle Plug Backorder WPL WP2189000 $3.70

WP2189452 Whirlpool Refrigerator Diffuser Backorder WPL WP2189452 $47.43

24A

WP2200936 Whirlpool Refrigerator Handle Plug Backorder WPL WP2200936 $2.51

25

WP2195914 Whirlpool Refrigerator Ice Maker Ho Backorder WPL WP2195914 $41.30

26

2212996 Whirlpool Refrigerator Retainer Backorder WPL 2212996 $7.52

26

WP2315522 Whirlpool Refrigerator Clip Backorder WPL WP2315522 $4.59

26

Refrigerator Diffuser WPL 2204690 Contact Us For Availability

27

WP627985 Whirlpool Icemaker Cycling Thermosta In Stock WPL WP627985 $46.67

28

8533917 Whirlpool Refrigerator Screw In Stock WPL 8533917 $9.59

30

WP681249 Whirlpool Screw Assembly In Stock WPL WP681249 $2.51

31

WP627792 Whirlpool Refrigerator Shut Off Arm In Stock WPL WP627792 $39.24

32

WP2187464 Whirlpool Refrigerator Wire Harness Backorder WPL WP2187464 $48.79

32

WP4387764 Whirlpool Run Capacitor Backorder WPL WP4387764 $90.19

33

W11500948 Whirlpool Refrigerator Bracket In Stock WPL W11500948 $12.32

33

WP489478 Whirlpool Refrigerator Screw Backorder WPL WP489478 $2.51

35

W10190935 Whirlpool Refrigerator Icemaker Mot In Stock WPL W10190935 $49.38

35

WPW10283959 Whirlpool Refrigerator Filler In Stock WPL WPW10283959 $3.70

37

WP8281196 Whirlpool Screw Backorder WPL WP8281196 $3.70

37

Refrigerator Toe Grille Clip WPL 2189356 Contact Us For Availability

38

489136 Whirlpool Refrigerator Screw Backorder WPL 489136 $4.56

38

WP487576 Whirlpool Washer In Stock WPL WP487576 $4.58

39

WP488163 Whirlpool Refrigerator Screw In Stock WPL WP488163 $3.70

40

WP2213360 Whirlpool Refrigerator Cover Backorder WPL WP2213360 $11.95

40

WP488787 Whirlpool Refrigerator Screw Backorder WPL WP488787 $4.56

40A

2213364 Whirlpool Refrigerator Cover Backorder WPL 2213364 $9.48

43

Refrigerator Condenser Fan WPL 2190685 Contact Us For Availability

44

WP486692 Whirlpool Refrigerator Nut Backorder WPL WP486692 $3.70

46

WP489442 Whirlpool Refrigerator Screw Backorder WPL WP489442 $4.56

47

W10777924 Whirlpool Refrigerator Wine Rack Backorder WPL W10777924 $8.47

58

Refrigerator Drain Pan WPL 2210451 Contact Us For Availability

60

WP3400065 Whirlpool Refrigerator Screw Backorder WPL WP3400065 $2.51

NI02

212643 Whirlpool Refrigerator Permagum Sealer In Stock WPL 212643 $30.25

NI03

Refrigerator Vinyl Tape WPL 479502 Contact Us For Availability

NI04

876370 Whirlpool Refrigerator Insulation Backorder WPL 876370 $106.84

NI06

Foam Slab WPL 876029 Contact Us For Availability

NI07

WP505587 Whirlpool Refrigerator Sealer Backorder WPL WP505587 $64.36

NI08

511873 Whirlpool Refrigerator Paint Backorder WPL 511873 $19.22

NI09

WP542638 Whirlpool Refrigerator Grease In Stock WPL WP542638 $24.56

NI10

Adhesive WPL 542639 Contact Us For Availability

NI11

606755 Whirlpool Refrigerator Bag Backorder WPL 606755 $29.17

NI12

Epoxy WPL 799833 Contact Us For Availability

NI13

Epoxy WPL 799832 Contact Us For Availability

NI14

WP503695 Whirlpool Refrigerator Sealer Backorder WPL WP503695 $43.61

NI15

350942 Whirlpool Spray Paint Backorder WPL 350942 $50.33

NI16

285006 Whirlpool Spray In Stock WPL 285006 $44.38

NI17

350930 Whirlpool White Spray Paint In Stock WPL 350930 $21.41

NI18

4392901 Whirlpool Biscuit Spray Paint In Stock WPL 4392901 $43.92

NI19

72017 Whirlpool Appliance Touch-Up Paint Whit In Stock WPL 72017 $4.92

NI20

72032 Whirlpool Touch Up Paint Black In Stock WPL 72032 $7.21

NI21

4392899 Whirlpool Biscuit Touch-Up Paint In Stock WPL 4392899 $7.21

NI22

Appliance Porcelain Touch-Up Paint, 1-qt (Whi WPL 799344 Contact Us For Availability

NI23

Paint, Bsq WPL 4392900 Contact Us For Availability

NI24

833938 Whirlpool Refrigerator Terminal Backorder WPL 833938 $3.70

NI25

Refrigerator Ice Maker Torx Key Wrench WPL 1117510 Contact Us For Availability

NI26

WP978025 Whirlpool Refrigerator Valve In Stock WPL WP978025 $28.82

NI27

978026 Whirlpool Refrigerator Primary Valve In Stock WPL 978026 $35.96

NI28

978027 Whirlpool Refrigerator Primary Valve Backorder WPL 978027 $37.79

NI29

Refrigerator Service Valve WPL 978028 Contact Us For Availability

NI30

Refrigerator Service Valve WPL 978029 Contact Us For Availability

NI31

978030 Whirlpool Refrigerator Valve Backorder WPL 978030 $39.53

NI32

876764 Whirlpool Refrigerator Primary Valve In Stock WPL 876764 $23.44
