Model Samsung DV328AEW/XAA-00 Dryer – Common Parts & Diagrams

Common parts from model Samsung DV328AEW/XAA-00 Dryer

Control Panel

Print

• This Diagram
• All Diagrams

1

DC97-14486A Samsung Dryer Heating Element Duc In Stock SMG DC97-14486A View Details $174.27

View on Model

1

Dryer motor and blower assembly SMG DC96-01112E Contact Us For Availability

View on Model

1

Dryer electronic control board SMG MFS-DV318A-S0 Contact Us For Availability

View on Model

1-1

6002-000239 Samsung Air Conditioner Tapping S Backorder SMG 6002-000239 View Details $0.92

View on Model

1-1

6021-001201 Samsung Dryer Left Turn Nut 3/8"- In Stock SMG 6021-001201 View Details $2.07

View on Model

1-2

Dryer heater box, upper SMG DC67-00132A Contact Us For Availability

View on Model

1-3

DC47-00019A Samsung Dryer Heating Element Ass In Stock SMG DC47-00019A View Details $63.35

View on Model

1-4

DC67-00133A Samsung Heater Lower Duct Assembl Backorder SMG DC67-00133A View Details $45.75

View on Model

1-5

DC96-00887C Samsung Dryer Thermal Cut-Off Fus In Stock SMG DC96-00887C View Details $43.37

View on Model

1-6

DC47-00015A Samsung Dryer 250V Thermostat In Stock SMG DC47-00015A View Details $23.22

View on Model

1-6

DC61-01214A Samsung Spring Plate Assembly Backorder SMG DC61-01214A View Details $3.50

View on Model

1-7

DC31-00055D Samsung Clothes Dryer Induction M In Stock SMG DC31-00055D View Details $236.07

View on Model

1-7

DC61-01204A Samsung Dryer Thermostat Bracket Backorder SMG DC61-01204A View Details $2.07

View on Model

1-8

6002-001306 Samsung Washer Tapping Screw Backorder SMG 6002-001306 View Details $0.92

View on Model

1-8

DC32-00007A Samsung Dryer Thermistor Sensor In Stock SMG DC32-00007A View Details $18.25

View on Model

1-9

DC47-00016A Samsung Thermostat In Stock SMG DC47-00016A View Details $10.73

View on Model

1-9

DC47-00018A Samsung Thermostat In Stock SMG DC47-00018A View Details $21.75

View on Model

1-10

DC61-01240A Samsung Thermistor Bracket Backorder SMG DC61-01240A View Details $6.62

View on Model

1-13

3405-001077 Samsung Micro Switch Backorder SMG 3405-001077 View Details $17.40

View on Model

1-15

DC61-01213A Samsung Motor Bracket Assembly In Stock SMG DC61-01213A View Details $97.45

View on Model

1-16

6009-001342 Samsung Dryer Special Puller Scre In Stock SMG 6009-001342 View Details $1.24

View on Model

1-17

DC61-01215B Samsung Dryer Idler Tension Sprin In Stock SMG DC61-01215B View Details $4.98

View on Model

1-18

DC93-00634A Samsung Dryer Idler Pulley Assemb In Stock SMG DC93-00634A View Details $40.64

View on Model

1-20

Dryer idler pulley SMG DC97-07509B Contact Us For Availability

View on Model

1-21

Dryer idler pulley SMG DC66-00402A Contact Us For Availability

View on Model

1-22

DC61-01228A Samsung Dryer Drum Support Roller In Stock SMG DC61-01228A View Details $1.67

View on Model

2

6602-001655 Samsung Dryer Drive Belt In Stock SMG 6602-001655 View Details $35.36

View on Model

3

DC97-07895A Samsung Dryer Connector Duct Asse Backorder SMG DC97-07895A View Details $43.70

View on Model

3

Dryer electronic control board SMG MFS-DV327L-00 Contact Us For Availability

View on Model

11

DC97-07519A Samsung Dryer Exhaust Duct Assemb Backorder SMG DC97-07519A View Details $54.92

View on Model

15

DC63-00534B Samsung Back Cover Assembly Backorder SMG DC63-00534B View Details $41.07

View on Model

16

DC61-01428A Samsung Power Holder Assembly Backorder SMG DC61-01428A View Details $1.24

View on Model

NI

Dryer motor bracket SMG DC96-00790C Contact Us For Availability

View on Model

×
