Model Whirlpool WFG530S0EB0 RANGE/OVEN, GAS, FREESTANDING, 30 INCH – Common Parts &amp; Diagrams

1

W10817433 Whirlpool Vent Trim In Stock WPL W10817433 $52.39

1

W11219365 Whirlpool Panel Endcap Backorder WPL W11219365 $14.25

1

W11457094 Whirlpool Range Flue Backorder WPL W11457094 $95.90

1

WP3196814 Whirlpool Rivet Backorder WPL WP3196814 $4.60

1A

W11219664 Whirlpool Endcap Panel In Stock WPL W11219664 $94.64

1A

WP3196813 Whirlpool Rivet Backorder WPL WP3196813 $4.60

1A

WPW10310922 Whirlpool Air Grille In Stock WPL WPW10310922 $105.84

1B

W11219370 Whirlpool Endcap Panel Backorder WPL W11219370 $36.71

1C

W11219665 Whirlpool Panel Endcap Backorder WPL W11219665 $14.25

2

8053505 Whirlpool Range Shield Backorder WPL 8053505 $62.83

2

W10949105 Whirlpool Mounting Bracket Backorder WPL W10949105 $11.97

2

WPW10183374 Whirlpool Burner Cap In Stock WPL WPW10183374 $111.78

2

WPW10200660 Whirlpool Range Oven Door Handle In Stock WPL WPW10200660 $2.60

3

W10300489 Whirlpool Door Handle Backorder WPL W10300489 $102.84

3

W10462911 Whirlpool Bracket Mounting Backorder WPL W10462911 $98.53

3

W11197500 Whirlpool Orifice Holder Backorder WPL W11197500 $47.67

3

W11252094 Whirlpool Control Panel Backorder WPL W11252094 $221.92

3

WPW10515455 Whirlpool Burner Head In Stock WPL WPW10515455 $55.31

W10300490 Whirlpool Door Handle In Stock WPL W10300490 $75.94

W11252095 Whirlpool Control Panel Backorder WPL W11252095 $156.88

W11700294 Whirlpool Range Orifice Holder Backorder WPL W11700294 $34.39

W11759228 Whirlpool Mounting Bracket Backorder WPL W11759228 $11.44

WPW10515454 Whirlpool Burner Head In Stock WPL WPW10515454 $45.94

W11234417 Whirlpool Surface Burner Orifice Ho Backorder WPL W11234417 $42.64

W11250166 Whirlpool Control Panel Backorder WPL W11250166 $156.88

WPW10515453 Whirlpool Burner Head In Stock WPL WPW10515453 $40.87

WPW10618239 Whirlpool Door Handle In Stock WPL WPW10618239 $104.77

3C

W11700304 Whirlpool Orifice Holder Backorder WPL W11700304 $34.39

3D

W10474170 Whirlpool Orifice Holder Backorder WPL W10474170 $30.13

4

W11680399 Whirlpool Gas Tubing Backorder WPL W11680399 $65.10

4

WP9761344 Whirlpool Door Liner In Stock WPL WP9761344 $118.41

4

WPW10575396 Whirlpool Side Panel Backorder WPL WPW10575396 $87.63

4A

W11730303 Whirlpool Side Panel In Stock WPL W11730303 $64.43

4B

W11256444 Whirlpool Drawer Panel Backorder WPL W11256444 $82.06

5

W10137382 Whirlpool Clip Backorder WPL W10137382 $31.33

5

W10444452 Whirlpool Manifold Panel Backorder WPL W10444452 $130.48

5

WP3196175 Whirlpool Screw In Stock WPL WP3196175 $2.60

5

WPW10031790 Whirlpool Screw In Stock WPL WPW10031790 $2.60

5

WPW10413868 Whirlpool Wire Harness Backorder WPL WPW10413868 $84.96

5

WPW10511278 Whirlpool Spark Module In Stock WPL WPW10511278 $143.47

5A

W10444453 Whirlpool Manifold Panel Backorder WPL W10444453 $129.85

6

8523249 Whirlpool Range Support Bracket Backorder WPL 8523249 $28.60

6

W10516123 Whirlpool Mounting Bracket Backorder WPL W10516123 $59.75

6

W10909673 Whirlpool Knob Assembly Backorder WPL W10909673 $35.25

6

WP9758079 Whirlpool Range Igniter In Stock WPL WP9758079 $28.03

7

W11394363 Whirlpool Grate Kit In Stock WPL W11394363 $159.39

7

WPW10316950 Whirlpool Window Frame Backorder WPL WPW10316950 $33.29

7

WPW10413870 Whirlpool Manifold Assembly Backorder WPL WPW10413870 $190.47

8

W10198745 Whirlpool Rear Cover Backorder WPL W10198745 $101.24

8

WPW10278991 Whirlpool Insulation Backorder WPL WPW10278991 $46.78

8

WPW10279614 Whirlpool Burner Valve Backorder WPL WPW10279614 $131.92

8A

WPW10247744 Whirlpool Burner Valve Backorder WPL WPW10247744 $132.03

8B

WPW10279615 Whirlpool Burner Valve In Stock WPL WPW10279615 $123.10

9

W10192841 Whirlpool Heat Shield Backorder WPL W10192841 $60.67

9

W10224921 Whirlpool Bracket Mounting Backorder WPL W10224921 $30.29

9

WP3196557 Whirlpool Screw In Stock WPL WP3196557 $2.60

9

WPW10341186 Whirlpool Range Front Levelling L In Stock WPL WPW10341186 $11.21

W11447673 Whirlpool Range Tip Anchor In Stock WPL W11447673 $13.07

W11684507 Whirlpool Screw In Stock WPL W11684507 $8.42

WPW10058460 Whirlpool Appliance Levelling Leg In Stock WPL WPW10058460 $3.84

WPW10299224 Whirlpool Range Door Hinge Assemb In Stock WPL WPW10299224 $44.04

11

WP3195097 Whirlpool Range Bottom In Stock WPL WP3195097 $94.09

11

WP3400016 Whirlpool Screw Assembly Backorder WPL WP3400016 $2.60

11

WPW10409945 Whirlpool Glass Door In Stock WPL WPW10409945 $141.10

11A

WPW10409946 Whirlpool Door Glass In Stock WPL WPW10409946 $105.71

W10833885 Whirlpool Temperature Sensor In Stock WPL W10833885 $70.18

WP8054078 Whirlpool Broiler Burner Backorder WPL WP8054078 $108.04

WP8523172 Whirlpool Left Door Trim In Stock WPL WP8523172 $41.93

WPW10515459 Whirlpool Surface Igniter In Stock WPL WPW10515459 $19.96

12B

WP8523166 Whirlpool Door Trim In Stock WPL WP8523166 $42.03

13

8053967 Whirlpool Range Heat Baffle Backorder WPL 8053967 $123.77

13

WP8273062 Whirlpool Screw In Stock WPL WP8273062 $2.60

13

WPW10184491 Whirlpool Burner Baffle Backorder WPL WPW10184491 $98.93

14

W11230932 Whirlpool Bracket Mounting Backorder WPL W11230932 $47.35

14

W11502236 Whirlpool Door Trim Backorder WPL W11502236 $9.63

14

WP9758078 Whirlpool Range Burner In Stock WPL WP9758078 $109.81

15

W11594186 Whirlpool Door Trim In Stock WPL W11594186 $24.38

15

WPW10475149 Whirlpool Spark Module In Stock WPL WPW10475149 $130.17

15

WPW10602001 Whirlpool Gas Valve In Stock WPL WPW10602001 $159.88

15A

WP8523177 Whirlpool Door Trim Assembly In Stock WPL WP8523177 $51.77

16

WPW10333842 Whirlpool Range Igniter In Stock WPL WPW10333842 $63.43

16

GLASS ASSEMBLY, OUTER DOOR (STAINLESS) WPL W10330077 Contact Us For Availability

16

SWITCH, ROCKER (WHITE) WPL 3149360 Contact Us For Availability

17

9757239 Whirlpool Oven Door Rod Backorder WPL 9757239 $36.50

17

W10420040 Whirlpool Gas Tubing Backorder WPL W10420040 $155.05

17

WPW10410341 Whirlpool Spacer In Stock WPL WPW10410341 $29.83

18

W10592836 Whirlpool Fitting Backorder WPL W10592836 $47.35

18

WPW10299227 Whirlpool Range Door Hinge In Stock WPL WPW10299227 $28.99

19

W10379120 Whirlpool Screw In Stock WPL W10379120 $30.29

19

WPW10347414 Whirlpool Orifice Spud Backorder WPL WPW10347414 $36.33

19A

WPW10170508 Whirlpool Orifice Spud Backorder WPL WPW10170508 $44.86

19B

WPW10170506 Whirlpool Orifice Spud Backorder WPL WPW10170506 $37.62

19C

WPW10170507 Whirlpool Orifice Backorder WPL WPW10170507 $37.64

20

W10137062 Whirlpool Burner Baffle Backorder WPL W10137062 $178.38

20

MAIN, BACK WPL W10416099 Contact Us For Availability

21

3196265 Whirlpool Range Screw Backorder WPL 3196265 $9.96

21

W11542153 Whirlpool Door Gasket In Stock WPL W11542153 $23.77

22

W10435470 Whirlpool Brace Backorder WPL W10435470 $30.29

23

9761449 Whirlpool Range Retainer Backorder WPL 9761449 $143.89

23A

9761448 Whirlpool Range Retainer Backorder WPL 9761448 $143.89

24

W11169708 Whirlpool Screw Backorder WPL W11169708 $9.96

25

W11582239 Whirlpool Range Power Cord Backorder WPL W11582239 $9.39

26

W10647259 Whirlpool Hinge Receiver In Stock WPL W10647259 $2.60

28

W11594027 Whirlpool Range Oven Light Socket In Stock WPL W11594027 $39.14

30

WP9761013 Whirlpool Door Latch Backorder WPL WP9761013 $100.19

31

W10078370 Whirlpool Latch Rod Backorder WPL W10078370 $33.29

32

WPW10107830 Whirlpool Stove Door Lock Latch A Backorder WPL WPW10107830 $133.35

35

W11676354 Whirlpool Range Convection Fan Backorder WPL W11676354 $106.14

39

W10158780 Whirlpool Rear Cover Backorder WPL W10158780 $54.49

285006 Whirlpool Spray In Stock WPL 285006 $46.08

350930 Whirlpool White Spray Paint In Stock WPL 350930 $22.23

4392899 Whirlpool Biscuit Touch-Up Paint In Stock WPL 4392899 $10.93

4396096RB Whirlpool Griddle Backorder WPL 4396096RB $219.60

4396923 Whirlpool Broil Pan Set Gray Porcelai In Stock WPL 4396923 $32.66

511873 Whirlpool Refrigerator Paint Backorder WPL 511873 $19.95

72017 Whirlpool Appliance Touch-Up Paint Whit In Stock WPL 72017 $10.93

W10123240 Whirlpool Broil Pan and Roasting Ra Backorder WPL W10123240 $75.20

W10334923 Whirlpool Clip Backorder WPL W10334923 $5.49

W10519920 Whirlpool Wire Harness Backorder WPL W10519920 $8.38

W10683155 Whirlpool Wire Harness Backorder WPL W10683155 $141.80

W10738993 Whirlpool Wire Harness Backorder WPL W10738993 $78.26

W11126051 Whirlpool Conversion Kit In Stock WPL W11126051 $100.92

W11161843 Whirlpool Wire Harness In Stock WPL W11161843 $122.53

W11520287 Whirlpool Rack Assembly In Stock WPL W11520287 $33.88

W11684915 Whirlpool Insulation Backorder WPL W11684915 $52.36

WPW10170516 Whirlpool Conversion Kit In Stock WPL WPW10170516 $41.88

WPW10208653 Whirlpool Insulation Backorder WPL WPW10208653 $33.29

ACCESSORY PARTS, CLEANER, STAINLESS STEEL WPL W10355016 Contact Us For Availability

ACCESSORY PARTS, WIPES, STAINLESS STEEL CLEAN WPL W10355049 Contact Us For Availability

ACCESSORY PARTS, CLEANER, GRATE & DRIP PAN WPL 31617A Contact Us For Availability

ACCESSORY PARTS, CLEANER, GRANITE WPL W10275756 Contact Us For Availability

PAINT, BULK (1 QT. WHITE (UNCUT)) WPL 799344 Contact Us For Availability
