Model Whirlpool WFG374LVD0 30`` GAS FREESTANDING SELF CLEAN RANGE SEALED BURN – Common Parts &amp; Diagrams

1

W11219370 Whirlpool Endcap Panel Backorder WPL W11219370 $33.36

1

W11219664 Whirlpool Endcap Panel In Stock WPL W11219664 $86.77

1

W11219665 Whirlpool Panel Endcap Backorder WPL W11219665 $13.73

1

W11457094 Whirlpool Range Flue Backorder WPL W11457094 $87.10

1

Screw, Valve WPL 8273096 Contact Us For Availability

2

8053505 Whirlpool Range Shield Backorder WPL 8053505 $57.07

2

W10169973 Whirlpool Burner Cap Backorder WPL W10169973 $50.54

2

WPW10169975 Whirlpool Burner Cap Backorder WPL WPW10169975 $33.38

2

WPW10183368 Whirlpool Burner Cap In Stock WPL WPW10183368 $45.91

2

WPW10183369 Whirlpool Burner Cap In Stock WPL WPW10183369 $35.28

2

WPW10183370 Whirlpool Burner Cap In Stock WPL WPW10183370 $49.70

2

Harness (Includes Center Switch) WPL W10170130 Contact Us For Availability

2

Cap, Burner Left Rear & Center (Grey) WPL W10169974 Contact Us For Availability

3

WPW10144883 Whirlpool Door Handle Backorder WPL WPW10144883 $105.69

3

Tubing, Burner W/Orifice (Left Front) WPL W10216417 Contact Us For Availability

3

Tubing, Burner W/Orifice (Right Rear) WPL W10170842 Contact Us For Availability

3

Tubing, Burner W/Orifice (Center) WPL W10170838 Contact Us For Availability

3

Panel, Console (Black) WPL W10184044 Contact Us For Availability

3

Panel, Console (Universal Silver) WPL W10184045 Contact Us For Availability

4

WP3196813 Whirlpool Rivet Backorder WPL WP3196813 $4.43

4

WP3196814 Whirlpool Rivet Backorder WPL WP3196814 $4.43

4

WP9761344 Whirlpool Door Liner In Stock WPL WP9761344 $118.41

4

Tubing (Manifold to Regulator) WPL W10157928 Contact Us For Availability

5

8523249 Whirlpool Range Support Bracket Backorder WPL 8523249 $25.99

5

W11230490 Whirlpool Drawer Panel Backorder WPL W11230490 $74.54

5

WPW10031790 Whirlpool Screw In Stock WPL WPW10031790 $3.33

5

WPW10295998 Whirlpool Wire Harness In Stock WPL WPW10295998 $86.45

6

WP8053334 Whirlpool Drawer Glide In Stock WPL WP8053334 $4.70

6

WPW10134130 Whirlpool Knob Backorder WPL WPW10134130 $12.50

6

WPW10134131 Whirlpool Knob In Stock WPL WPW10134131 $13.14

6

WPW10134134 Whirlpool Knob In Stock WPL WPW10134134 $13.32

6

WPW10160648 Whirlpool Knob Backorder WPL WPW10160648 $13.47

6

WPW10160649 Whirlpool Knob In Stock WPL WPW10160649 $12.94

6

WPW10216419 Whirlpool Surface Igniter In Stock WPL WPW10216419 $13.73

6

Knob (White, Pwr Burner) WPL W10134133 Contact Us For Availability

7

W10198745 Whirlpool Rear Cover Backorder WPL W10198745 $91.95

7

WP3196037 Whirlpool Leveling Foot In Stock WPL WP3196037 $28.64

7

GRATE, BURNER (BLACK) WPL W10165288 Contact Us For Availability

8

W10192841 Whirlpool Heat Shield Backorder WPL W10192841 $55.10

8

WPW10058460 Whirlpool Appliance Levelling Leg In Stock WPL WPW10058460 $4.52

8

WPW10170204 Whirlpool Burner Valve In Stock WPL WPW10170204 $101.32

8

Valve (Left Rear) WPL 8273004 Contact Us For Availability

9

WP3195097 Whirlpool Range Bottom In Stock WPL WP3195097 $86.28

9

WP3196557 Whirlpool Screw In Stock WPL WP3196557 $3.33

9

Cover, Back WPL W10184370 Contact Us For Availability

10

WP8273062 Whirlpool Screw In Stock WPL WP8273062 $3.33

10

WPW10181986 Whirlpool Range Sensor In Stock WPL WPW10181986 $66.20

8053967 Whirlpool Range Heat Baffle Backorder WPL 8053967 $112.34

WP9781235 Whirlpool Clip Backorder WPL WP9781235 $5.22

WPW10118454 Whirlpool Range Outer Door Glass In Stock WPL WPW10118454 $198.84

WPW10118455 Whirlpool Door Glass Assembly In Stock WPL WPW10118455 $205.92

12

WP8054078 Whirlpool Broiler Burner Backorder WPL WP8054078 $98.14

12

WP8523166 Whirlpool Door Trim In Stock WPL WP8523166 $48.93

12

WP8523172 Whirlpool Left Door Trim In Stock WPL WP8523172 $40.98

13

WPW10184491 Whirlpool Burner Baffle Backorder WPL WPW10184491 $89.85

14

WP3196175 Whirlpool Screw In Stock WPL WP3196175 $3.33

14

WP9758078 Whirlpool Range Burner In Stock WPL WP9758078 $100.55

15

Seal, Oven Flange WPL W10008830 Contact Us For Availability

16

W10877054 Whirlpool Spacer Assembly Backorder WPL W10877054 $28.09

16

WP8054129 Whirlpool Range Igniter In Stock WPL WP8054129 $78.63

16

WP9758079 Whirlpool Range Igniter In Stock WPL WP9758079 $27.82

WP8523175 Whirlpool Door Trim Assembly In Stock WPL WP8523175 $52.13

WP8523177 Whirlpool Door Trim Assembly In Stock WPL WP8523177 $55.08

Spark Module (Filtered) WPL 8522425 Contact Us For Availability

Tubing (Broiler Fitting To Valve) WPL 8272222 Contact Us For Availability

Trim, Bottom (Universal Silver) WPL W10067550 Contact Us For Availability

18

Fitting, Broiler WPL 3186489 Contact Us For Availability

19

WP3400016 Whirlpool Screw Assembly Backorder WPL WP3400016 $2.51

9761448 Whirlpool Range Retainer Backorder WPL 9761448 $130.62

9761449 Whirlpool Range Retainer Backorder WPL 9761449 $130.62

WPW10170506 Whirlpool Orifice Spud Backorder WPL WPW10170506 $34.18

WPW10170507 Whirlpool Orifice Backorder WPL WPW10170507 $34.20

WPW10170508 Whirlpool Orifice Spud Backorder WPL WPW10170508 $40.75

WPW10170509 Whirlpool Spud Orifice Backorder WPL WPW10170509 $39.05

WPW10200660 Whirlpool Range Oven Door Handle In Stock WPL WPW10200660 $3.33

21

W10137062 Whirlpool Burner Baffle Backorder WPL W10137062 $161.91

21

W10137382 Whirlpool Clip Backorder WPL W10137382 $28.47

22

3196265 Whirlpool Range Screw Backorder WPL 3196265 $9.59

22

WP9757891 Whirlpool Power Cord Backorder WPL WP9757891 $50.80

24

W11684507 Whirlpool Screw In Stock WPL W11684507 $8.93

24

WP9757262 Whirlpool Light Switch In Stock WPL WP9757262 $62.28

27

WP9761013 Whirlpool Door Latch Backorder WPL WP9761013 $90.99

28

W10078370 Whirlpool Latch Rod Backorder WPL W10078370 $30.25

29

WPW10107820 Whirlpool Door Latch In Stock WPL WPW10107820 $98.24

30

WPW10114344 Whirlpool Drawer Glide In Stock WPL WPW10114344 $4.70

32

W11169708 Whirlpool Screw Backorder WPL W11169708 $9.59

34

Screw WPL 3196152 Contact Us For Availability

35

3196166 Whirlpool Screw Backorder WPL 3196166 $4.85

40

9757239 Whirlpool Oven Door Rod Backorder WPL 9757239 $33.16

285006 Whirlpool Spray In Stock WPL 285006 $29.65

3400964 Whirlpool Range Clip Backorder WPL 3400964 $34.20

350930 Whirlpool White Spray Paint In Stock WPL 350930 $13.94

4396923 Whirlpool Broil Pan Set Gray Porcelai In Stock WPL 4396923 $36.18

511873 Whirlpool Refrigerator Paint Backorder WPL 511873 $19.22

72017 Whirlpool Appliance Touch-Up Paint Whit In Stock WPL 72017 $4.25

72032 Whirlpool Touch Up Paint Black In Stock WPL 72032 $15.46

W10170249 Whirlpool Wire Harness Backorder WPL W10170249 $53.51

W10170251 Whirlpool Wire Harness Backorder WPL W10170251 $7.19

W11244557 Whirlpool Screw Backorder WPL W11244557 $9.59

W11447673 Whirlpool Range Tip Anchor In Stock WPL W11447673 $13.41

W11684915 Whirlpool Insulation Backorder WPL W11684915 $47.58

WP3196174 Whirlpool Screw Backorder WPL WP3196174 $2.51

WPW10170516 Whirlpool Conversion Kit In Stock WPL WPW10170516 $38.87

WPW10208653 Whirlpool Insulation Backorder WPL WPW10208653 $30.25

FOIL, ALUMINUM OVEN (18`` X 25 ) WPL 241430 Contact Us For Availability

PAINT, BULK (1 QT.) (WHITE (UNCUT)) WPL 799344 Contact Us For Availability
