Model Whirlpool RS20EKXFW01 – Common Parts & Diagrams

WPL  1117510
WPL 1117510 WPL 1117510 Contact Us For Availability
View on Model
1
Freezer Door Panel (Also Order Item 11)
Freezer Door Panel (Also Order Item 11) WPL 2194610W Contact Us For Availability
View on Model
1
Refrigerator Door Panel (Also Order Item 4)
Refrigerator Door Panel (Also Order Item 4) WPL 2194611W Contact Us For Availability
View on Model
1
Cabinet (Not A Serviceable Part)
Cabinet (Not A Serviceable Part) WPL ARI123878A Contact Us For Availability
View on Model
1
Liner (Not A Serviceable Part)
Liner (Not A Serviceable Part) WPL ARI123879A Contact Us For Availability
View on Model
2
Fan, Blade
Fan, Blade WPL 1108179 Contact Us For Availability
View on Model
2
Mounting Bracket
Mounting Bracket WPL 1110629 Contact Us For Availability
View on Model
2
Front Roller (2)
Front Roller (2) WPL 2174748 Contact Us For Availability
View on Model
3
SLIDE MEAT PAN CONTROL
SLIDE MEAT PAN CONTROL WPL 2182757 Contact Us For Availability
View on Model
3
Trim, Shelf
Trim, Shelf WPL 2177862 Contact Us For Availability
View on Model
4
Cap, Hinge Sleeve
Cap, Hinge Sleeve WPL 509929 Contact Us For Availability
View on Model
4
Saddle Stud (Right Side)
Saddle Stud (Right Side) WPL 1118133 Contact Us For Availability
View on Model
6
Shelf, Door
Shelf, Door WPL 2177863 Contact Us For Availability
View on Model
6
Shelf Ladder (2)
Shelf Ladder (2) WPL 2181796 Contact Us For Availability
View on Model
7
Shelf, Door
Shelf, Door WPL 2177864 Contact Us For Availability
View on Model
9
Cover, Unit Compartment
Cover, Unit Compartment WPL 2182057 Contact Us For Availability
View on Model
10
Grommet (10)
Grommet (10) WPL 2176134 Contact Us For Availability
View on Model
10
Handle, Insert
Handle, Insert WPL 2198036 Contact Us For Availability
View on Model
10
Shim, Hinge (2)
Shim, Hinge (2) WPL 2196048 Contact Us For Availability
View on Model
10
Louver
Louver WPL 2182147 Contact Us For Availability
View on Model
11
Screw
Screw WPL 489284 Contact Us For Availability
View on Model
12
Screw Anchor (2)
Screw Anchor (2) WPL 941242 Contact Us For Availability
View on Model
13
Panel, Interior Door
Panel, Interior Door WPL 1129243 Contact Us For Availability
View on Model
13
Shelf, Wire (2)
Shelf, Wire (2) WPL 2163617 Contact Us For Availability
View on Model
14
Endcap
Endcap WPL 2194778B Contact Us For Availability
View on Model
14
Trim, Shelf (5)
Trim, Shelf (5) WPL 2177865 Contact Us For Availability
View on Model
14
Saddle Stud (Left Side)
Saddle Stud (Left Side) WPL 1118134 Contact Us For Availability
View on Model
15
Pivot Arm
Pivot Arm WPL 1110559 Contact Us For Availability
View on Model
15
Insert, Handle
Insert, Handle WPL 2198037 Contact Us For Availability
View on Model
15
Shelf, Wire
Shelf, Wire WPL 2173378 Contact Us For Availability
View on Model
16
Filler, Wrapper
Filler, Wrapper WPL 2196094 Contact Us For Availability
View on Model
16
Retainer, Gasket
Retainer, Gasket WPL 1117767 Contact Us For Availability
View on Model
17
Grille
Grille WPL 2155476 Contact Us For Availability
View on Model
17
Panel, Interior
Panel, Interior WPL 2177858 Contact Us For Availability
View on Model
18
Clip, Defrost Heater
Clip, Defrost Heater WPL 2161324 Contact Us For Availability
View on Model
18
Tap, Plate
Tap, Plate WPL 2196135 Contact Us For Availability
View on Model
20
Retainer, Gasket
Retainer, Gasket WPL 1118301 Contact Us For Availability
View on Model
20
Meat Pan
Meat Pan WPL 2174418 Contact Us For Availability
View on Model
21
Retainer, Gasket
Retainer, Gasket WPL 1117766 Contact Us For Availability
View on Model
24
Fastener, Push-On
Fastener, Push-On WPL 489285 Contact Us For Availability
View on Model
25
Bracket, Door Stop
Bracket, Door Stop WPL 2195950 Contact Us For Availability
View on Model
26
Nameplate
Nameplate WPL 2163676 Contact Us For Availability
View on Model
26
Cover, Conduit
Cover, Conduit WPL 2150330 Contact Us For Availability
View on Model
27
Knob, Air Control
Knob, Air Control WPL 2197871 Contact Us For Availability
View on Model
29
WPL  876029
WPL 876029 WPL 876029 Contact Us For Availability
View on Model
29
TAPE, VINYL (3/4 X 108``)
TAPE, VINYL (3/4 X 108``) WPL 479502 Contact Us For Availability
View on Model
55
VALVE, ACCESS (5/8``)
VALVE, ACCESS (5/8``) WPL 978029 Contact Us For Availability
View on Model
