Model Whirlpool RM988PXVN0 – Common Parts &amp; Diagrams

Screw, 10-32 x 5/8 (2) WPL 246127 Contact Us For Availability

1

Trim, Shelf (Front) WPL 313614 Contact Us For Availability

1

Bracket, Mounting (2) WPL 307981 Contact Us For Availability

1

Transformer WPL 3148101 Contact Us For Availability

1

bracket, catch WPL 3113654 Contact Us For Availability

1

Bracket, Stop R.H. WPL 3147486 Contact Us For Availability

1

Bracket, Stop L.H. WPL 3147487 Contact Us For Availability

1

Wiring Harness Control (Microwave) WPL 3147559 Contact Us For Availability

1

Latch Assembly (Pyro) WPL 3171148 Contact Us For Availability

1

Liner, Door WPL 3170706 Contact Us For Availability

1

Frame, Control Panel WPL 3148090 Contact Us For Availability

1

Harness, Wiring (Oven) WPL 3147970 Contact Us For Availability

2

238614 Whirlpool Bumper Hinge Backorder WPL 238614 $71.57

2

WP488729 Whirlpool Refrigerator Door Screw In Stock WPL WP488729 $2.64

2

Trim, Shelf (Rear) WPL 313615 Contact Us For Availability

2

Rail R.H. (Includes Illus. 3) WPL 307982 Contact Us For Availability

2

rail L.H. (includes illus. 3) WPL 307987 Contact Us For Availability

2

Catch (2) WPL 311795 Contact Us For Availability

2

Bumper (4) WPL 312783 Contact Us For Availability

2

Panel, Bottom WPL 314216 Contact Us For Availability

2

Seal, Foam WPL 3147593 Contact Us For Availability

2

Cover, Side WPL 3147004 Contact Us For Availability

2

Wiring Harness Main (Microwave) WPL 3147554 Contact Us For Availability

2

Safety Switch WPL 308185 Contact Us For Availability

2

Screw (2) WPL 98106 Contact Us For Availability

2

Module, Control WPL 3148982 Contact Us For Availability

2

Wiring Harness (Infinite Switch) WPL 3147549 Contact Us For Availability

3

Shelf, Microwave (Install with Silastic 30757 WPL 313639 Contact Us For Availability

3

Glide, Front (2) WPL 307979 Contact Us For Availability

3

Screw, 8-32 x 3/16 (4) WPL 313818 Contact Us For Availability

3

Switch (Alt.) WPL 313075 Contact Us For Availability

3

Switch (Alt.) WPL 313123 Contact Us For Availability

3

Switch WPL 661144 Contact Us For Availability

3

Deflector, Air WPL 3148435 Contact Us For Availability

3

Harness Wiring Vent Motor WPL 3147556 Contact Us For Availability

3

Insulator, Switch WPL 309245 Contact Us For Availability

3

Seal, Flange (2) WPL 3148441 Contact Us For Availability

3

bracket, control (mounting) WPL 3147280 Contact Us For Availability

3

Harness, Wiring Surface Unit WPL 3149254 Contact Us For Availability

4

814037 Whirlpool Microwave Switch Backorder WPL 814037 $30.52

4

WP308180 Whirlpool Range Bake Element 2600W 2 In Stock WPL WP308180 $24.28

4

Snap-In Socket WPL 330514 Contact Us For Availability

4

unit, bake (alt.) WPL 308140 Contact Us For Availability

4

screw, 10-32 x 1/2 (4) WPL 312185 Contact Us For Availability

4

Filter, Mesh (2) WPL 3147606 Contact Us For Availability

4

Nut (3) WPL 3147378 Contact Us For Availability

4

Harness Wiring Switch, Rocker WPL 3147567 Contact Us For Availability

4

Screw, 6 x 3/8B (2) WPL 309258 Contact Us For Availability

4

Shield, Latch Terminal WPL 313035 Contact Us For Availability

4

Glass, Reflective WPL 3148178 Contact Us For Availability

4

Skirt, Dail (4) WPL 3147032 Contact Us For Availability

4

Wiring Harness (Select/Therm) WPL 3147917 Contact Us For Availability

5

WP313808 Whirlpool Screw Backorder WPL WP313808 $2.51

5

WP3395618 Whirlpool Light Bulb Backorder WPL WP3395618 $26.21

5

WP660579 Whirlpool Range Wall Oven Broil Elem In Stock WPL WP660579 $66.17

5

seal, liner WPL 3148183 Contact Us For Availability

5

Bracket, Capacitor WPL 312619 Contact Us For Availability

5

Screw, 4-40 x 5/8 Pan Head Thread Form (6) WPL 312717 Contact Us For Availability

5

Edge, Protector (2) WPL 3147756 Contact Us For Availability

5

Relay, Vent (24V, Clear) WPL 314125 Contact Us For Availability

5

Connector, Housing WPL 308565 Contact Us For Availability

5

Screw, 10-24 x 1/2 (2) WPL 308422 Contact Us For Availability

5

Screw (2) WPL 311056 Contact Us For Availability

5

Handle, Latch WPL 3147065 Contact Us For Availability

5

thermostat WPL 3148930 Contact Us For Availability

5

Disconnect Block WPL 309408 Contact Us For Availability

6

WP112432 Whirlpool Nut Assembly Backorder WPL WP112432 $2.51

6

WP3149478 Whirlpool Microwave Support In Stock WPL WP3149478 $2.73

6

WP8203546 Whirlpool Terminal Block In Stock WPL WP8203546 $10.98

6

Knob, Latch WPL 3148684 Contact Us For Availability

6

Screw, 10-16 x 3/4 (2) WPL 98884 Contact Us For Availability

6

Switch, Light Monitor (Alt.) WPL 313076 Contact Us For Availability

6

Switch, Light Monitor (Alt.) WPL 313124 Contact Us For Availability

6

Switch, Light/ Monitor WPL 661145 Contact Us For Availability

6

Socket, Assembly L.H. WPL 3147244 Contact Us For Availability

6

Socket, Assembly R.H. WPL 3147245 Contact Us For Availability

6

Screw, 6AB x 3/8 (2) WPL 246231 Contact Us For Availability

6

Thermostat WPL 3147274 Contact Us For Availability

6

Disconnect Block WPL 3147362 Contact Us For Availability

6

Retainer, Insulation WPL 3148159 Contact Us For Availability

6

Switch, Selector WPL 3147234 Contact Us For Availability

6

Disconnect Block WPL 309409 Contact Us For Availability

7

WP3169203 Whirlpool Door Glass Backorder WPL WP3169203 $61.02

7

WP3390631 Whirlpool Screw In Stock WPL WP3390631 $2.51

7

rack, wire WPL 313663 Contact Us For Availability

7

Ground Strap WPL 308498 Contact Us For Availability

7

Clip WPL 313660 Contact Us For Availability

7

Screw, 8-32 x 3/8 Pan Head Phillips WPL 312713 Contact Us For Availability

7

Insulator WPL 313126 Contact Us For Availability

7

Support, Frame WPL 330677 Contact Us For Availability

7

Disconnect Block, Female WPL 310960 Contact Us For Availability

7

Box, Burner WPL 3149194 Contact Us For Availability

7

Screw, 8-32 x 3/16 (8) WPL 308119 Contact Us For Availability

7

switch, infinite (4) WPL 308477 Contact Us For Availability

7

Disconnect Block WPL 309406 Contact Us For Availability

8

Bracket, Service WPL 307970 Contact Us For Availability

8

capacitor (alt.) WPL 312631 Contact Us For Availability

8

capacitor (alt.) WPL 313632 Contact Us For Availability

8

Capacitor WPL 661004 Contact Us For Availability

8

Screw, 4-40 x 10 (2) WPL 310211 Contact Us For Availability

8

Side Panel, L.H. (White) WPL 3147142 Contact Us For Availability

8

Side Panel L.H. (White) WPL 3147143 Contact Us For Availability

8

Side Panel, L.H. (Almond) WPL 3147144 Contact Us For Availability

8

Side Panel L.H. (Almond) WPL 3147145 Contact Us For Availability

8

Side Panel L.H. (Seal, Foam (2)) WPL 3147591 Contact Us For Availability

8

Side Panel, L.H. (Seal, Foam (2) Side Panel, WPL 3147592 Contact Us For Availability

8

Bushing, Stirrer WPL 312023 Contact Us For Availability

8

Housing, Plug WPL 310241 Contact Us For Availability

8

Shield, Wiring WPL 307973 Contact Us For Availability

8

Retainer, Glass (2) WPL 3148187 Contact Us For Availability

8

light, indicator (3) WPL 3147862 Contact Us For Availability

8

Disconnect Block WPL 309405 Contact Us For Availability

9

WPW10339879 Whirlpool Wire Tie In Stock WPL WPW10339879 $2.51

9

Screw, 8-32 x 3/8 Slot Hex Washer Head Self-T WPL 309080 Contact Us For Availability

9

Seal, Foam WPL 3147599 Contact Us For Availability

9

Rod, Cooktop WPL 3148659 Contact Us For Availability

9

Bumper (4) WPL 3148182 Contact Us For Availability

9

Knob, Control (4) WPL 3147030 Contact Us For Availability

330031 Whirlpool Range Surface Element Recept In Stock WPL 330031 $9.81

Cover, Rear WPL 3148975 Contact Us For Availability

shield WPL 311360 Contact Us For Availability

Top Panel WPL 3170318 Contact Us For Availability

Shaft, Stirrer WPL 312026 Contact Us For Availability

Connector, Housing WPL 311574 Contact Us For Availability

Glass, Panel WPL 3148185 Contact Us For Availability

knob, selector (2) WPL 3147888 Contact Us For Availability

4454949 Whirlpool Oven Fuse Block Backorder WPL 4454949 $30.25

WP681414 Whirlpool Screw In Stock WPL WP681414 $2.51

Cover, Service WPL 307972 Contact Us For Availability

Panel, Backguard WPL 3147589 Contact Us For Availability

Stirrer Blade WPL 313595 Contact Us For Availability

Pin, Housing WPL 3147361 Contact Us For Availability

Bracket (2) WPL 307965 Contact Us For Availability

Foil, Door WPL 3148184 Contact Us For Availability

light, indicator WPL 3149036 Contact Us For Availability

WP355515 Whirlpool Screw Backorder WPL WP355515 $2.51

Rivet, Pop (3) WPL 311928 Contact Us For Availability

socket, fluorescent WPL 3147224 Contact Us For Availability

Washer, Nylon WPL 312025 Contact Us For Availability

Handle, Door WPL 3148228 Contact Us For Availability

16515 Whirlpool Clip Backorder WPL 16515 $11.62

242831 Whirlpool Oven Wire Backorder WPL 242831 $249.73

261900 Whirlpool Microwave Spray Backorder WPL 261900 $27.45

285006 Whirlpool Spray In Stock WPL 285006 $28.82

350930 Whirlpool White Spray Paint In Stock WPL 350930 $13.12

350942 Whirlpool Spray Paint Backorder WPL 350942 $32.57

350956 Whirlpool Spray Assembly In Stock WPL 350956 $19.22

4396923 Whirlpool Broil Pan Set Gray Porcelai In Stock WPL 4396923 $36.18

511873 Whirlpool Refrigerator Paint Backorder WPL 511873 $19.22

72017 Whirlpool Appliance Touch-Up Paint Whit In Stock WPL 72017 $3.51

72032 Whirlpool Touch Up Paint Black In Stock WPL 72032 $15.46

72110 Whirlpool Dryer Touch-Up Paint, Golden In Stock WPL 72110 $10.07

72113 Whirlpool Touch-Up Paint Backorder WPL 72113 $10.07

WP261869 Whirlpool Microwave Paint Backorder WPL WP261869 $9.88

WP482338 Whirlpool Refrigerator Adhesive In Stock WPL WP482338 $24.89

WP72107 Whirlpool Touchup In Stock WPL WP72107 $5.80

WP75614 Whirlpool Connector Backorder WPL WP75614 $2.51

WPW10208653 Whirlpool Insulation Backorder WPL WPW10208653 $30.25

Starter, Lamp WPL 387695 Contact Us For Availability

WPL 799344 WPL 799344 Contact Us For Availability

Switch, Miniature WPL 313120 Contact Us For Availability

screw, 8-32 x 1/2 (3) WPL 313816 Contact Us For Availability

Leveler, Enamel WPL 206925 Contact Us For Availability

Wire (14 Ga. 150 c Black) WPL 242820 Contact Us For Availability

Wire (14 Ga. 150 c Blue) WPL 242821 Contact Us For Availability

Wire (14 Ga. 150 c Brown) WPL 242822 Contact Us For Availability

Wire (14 Ga. 150 c Green) WPL 242823 Contact Us For Availability

Wire (14 Ga. 150 c Orange) WPL 242824 Contact Us For Availability

Wire (14 Ga. 150 c Red) WPL 242825 Contact Us For Availability

Wire, White 14 Ga. 150 oC WPL 242826 Contact Us For Availability

Wire (14 Ga. 150 c Yellow) WPL 242827 Contact Us For Availability

Wire (12 Ga. 150 c Black) WPL 242828 Contact Us For Availability

Wire, Red 12 Ga. 150 oC WPL 242829 Contact Us For Availability

Wire (14 Ga. 200 c Brown) WPL 242830 Contact Us For Availability

Rotisserie Kit WPL 242985 Contact Us For Availability

wire, yellow 14 ga. 200 o c WPL 243832 Contact Us For Availability

Touch-Up, Oven WPL 254323 Contact Us For Availability

Grease WPL 261582 Contact Us For Availability

Harvest Gold WPL 261890 Contact Us For Availability

Harvest Gold (Uncut) WPL 261891 Contact Us For Availability

Toast WPL 285365 Contact Us For Availability

Paint, Spray (13 Oz.) (Platinum) WPL 285366 Contact Us For Availability

Enamal, Toast (1 Qt. Uncut) WPL 285367 Contact Us For Availability

Platinum (Uncut) WPL 285368 Contact Us For Availability

WPL 591014 WPL 591014 Contact Us For Availability

WPL 72112 WPL 72112 Contact Us For Availability

WPL 799340 WPL 799340 Contact Us For Availability

WPL 799832 WPL 799832 Contact Us For Availability

WPL 814023 WPL 814023 Contact Us For Availability

WPL 978883 WPL 978883 Contact Us For Availability

cooktop (almond 10-32 x 1/2) WPL 307871 Contact Us For Availability

Cooktop (White) WPL 3170981 Contact Us For Availability

screw (2) WPL 254225 Contact Us For Availability

Shield, Door WPL 3148680 Contact Us For Availability

Rack, Oven (Straight) WPL 308173 Contact Us For Availability

End Trim R.H. (Screw, 10-12 x 7/8 (2)) WPL 308043 Contact Us For Availability

End Trim R.H. (Almond) WPL 314198 Contact Us For Availability

End Trim R.H. (Almond) WPL 314199 Contact Us For Availability

End Trim R.H. (White) WPL 314203 Contact Us For Availability

end trim R.H. (almond) WPL 314204 Contact Us For Availability

Pulley, Stirrer Blade WPL 311923 Contact Us For Availability

Trim, Panel WPL 3148223 Contact Us For Availability

WP308605 Whirlpool Refrigerator Clamp Backorder WPL WP308605 $4.81

WP965173 Whirlpool Dishwasher Screw Backorder WPL WP965173 $2.64

Clip, Mtg (2) WPL 3148282 Contact Us For Availability

Rack, Oven (Offset) WPL 308172 Contact Us For Availability

Rectifier, High Voltage WPL 313830 Contact Us For Availability

``E`` Ring WPL 311999 Contact Us For Availability

WP4332752 Whirlpool Clip Backorder WPL WP4332752 $3.70

Coverplate (2) WPL 311982 Contact Us For Availability

Fastener (4) WPL 313740 Contact Us For Availability

Trim, Glass (Top) WPL 313320 Contact Us For Availability

screw (6) WPL 3148443 Contact Us For Availability

Frame, Glass WPL 3148234 Contact Us For Availability

W10854470 Whirlpool Trim Ring Backorder WPL W10854470 $31.49

W10858781 Whirlpool Trim Ring Backorder WPL W10858781 $32.67

WP487939 Whirlpool Refrigerator Nut In Stock WPL WP487939 $2.51

WP95292 Whirlpool Fluorescent Light Bulb Backorder WPL WP95292 $51.08

cover WPL 314790 Contact Us For Availability

303776 Whirlpool Dishwasher Screw Backorder WPL 303776 $4.65

W10291024 Whirlpool Range Cooktop Gray Porcel In Stock WPL W10291024 $49.86

WP313646 Whirlpool Microwave Drive Belt Backorder WPL WP313646 $28.99

Panel, Glass WPL 313322 Contact Us For Availability

SCREW Backorder WPL 246131 $8.20

697811 Whirlpool Relay Backorder WPL 697811 $32.79

WP660532 Whirlpool Oven Surface Element In Stock WPL WP660532 $25.31

WP90767 Whirlpool Screw In Stock WPL WP90767 $3.08

Frame, Door WPL 3170441 Contact Us For Availability

Trim, Glass (Bottom) WPL 313321 Contact Us For Availability

Frame, Panel WPL 3148235 Contact Us For Availability

98005642 Whirlpool Clip Backorder WPL 98005642 $30.25

screw (6) WPL 307748 Contact Us For Availability

Door, Inner WPL 3171012 Contact Us For Availability

Stirrer Cover WPL 313563 Contact Us For Availability

Medallion (4) WPL 309195 Contact Us For Availability

Glide, Rear (2) WPL 307980 Contact Us For Availability

WP307986 Whirlpool Hinge Pin Backorder WPL WP307986 $5.23

WP488787 Whirlpool Refrigerator Screw Backorder WPL WP488787 $4.56

Panel Drawer (White) WPL 307935 Contact Us For Availability

Panel, Drawer (Almond) WPL 307939 Contact Us For Availability

WP488627 Whirlpool Refrigerator Screw In Stock WPL WP488627 $4.26

WPW10017410 Whirlpool Fuse In Stock WPL WPW10017410 $6.79

WPW10068250 Whirlpool Dishwasher Screw Backorder WPL WPW10068250 $2.91

Trim, End (Glass) (2) WPL 313319 Contact Us For Availability

Shield, Insulation WPL 312320 Contact Us For Availability

Handle, Drawer WPL 313337 Contact Us For Availability

WP308126 Whirlpool Door Spring In Stock WPL WP308126 $12.59

Air Duct (Horizontal) WPL 313578 Contact Us For Availability

Plate, Tuning WPL 313735 Contact Us For Availability

Clamp, Tube WPL 313570 Contact Us For Availability

24

WP308125 Whirlpool Microwave Range/Cooktop An Backorder WPL WP308125 $5.29

24

Blower, Exhaust WPL 3147817 Contact Us For Availability

24

Support (4) WPL 313739 Contact Us For Availability

814103 Whirlpool Clip In Stock WPL 814103 $3.95

Switch, Door WPL 310345 Contact Us For Availability

Cover, Access WPL 3147798 Contact Us For Availability

Nut (6) WPL 3147866 Contact Us For Availability

Support, Tubing R.H. WPL 314195 Contact Us For Availability

support, tubing L.H. WPL 314197 Contact Us For Availability

Magnetron (Alt.) WPL 311992 Contact Us For Availability

Magnetron (Alt.) WPL 311993 Contact Us For Availability

Magnetron (Alt.) WPL 311994 Contact Us For Availability

Magnetron (Alt.) WPL 311995 Contact Us For Availability

Magnetron (Alt.) WPL 313034 Contact Us For Availability

Magnetron WPL 660595 Contact Us For Availability

Screw, 8-32 x 1/2 (4) WPL 311945 Contact Us For Availability

Frame WPL 3170129 Contact Us For Availability

Switch, Safety WPL 3148669 Contact Us For Availability

Rack, Literature WPL 357645 Contact Us For Availability

Seal, Door WPL 3148284 Contact Us For Availability

Panel, Vent Door WPL 3147712 Contact Us For Availability

Scr WPL 3147724 Contact Us For Availability

WPL 3147764 WPL 3147764 Contact Us For Availability

WPL 3147858 WPL 3147858 Contact Us For Availability

WPL 3148294 WPL 3148294 Contact Us For Availability

Insulator, Switch WPL 3147864 Contact Us For Availability

Drawer, Utility WPL 327887 Contact Us For Availability

Thermal Protector (Alt.) WPL 312800 Contact Us For Availability

Thermal Protector (Alt.) WPL 313521 Contact Us For Availability

Thermal Protector WPL 661165 Contact Us For Availability

WPL 3147525 WPL 3147525 Contact Us For Availability

WPL 3147607 WPL 3147607 Contact Us For Availability

Protector, Drawer Slide (2) WPL 309329 Contact Us For Availability

29

WPL 3147710 WPL 3147710 Contact Us For Availability

29

Baffle, Air Exhaust WPL 3147003 Contact Us For Availability

30

Latch Assembly WPL 329066 Contact Us For Availability

30

WPL 3170269 WPL 3170269 Contact Us For Availability

31

WP3147265 Whirlpool Rocker Switch In Stock WPL WP3147265 $52.76

31

Spring, Torsion (2) WPL 311352 Contact Us For Availability

32

WP4314961 Whirlpool Lite Switch Backorder WPL WP4314961 $31.90

32

Handle, Door WPL 314169 Contact Us For Availability

313611 Whirlpool Microwave Door Button Backorder WPL 313611 $15.98

Ballast (Alt.) WPL 346772 Contact Us For Availability

Ballast WPL 660001 Contact Us For Availability

Ballast (Alt.) WPL 685591 Contact Us For Availability

WPL 3147726 WPL 3147726 Contact Us For Availability

Screw, 8-32 x 5/16 (2) WPL 307537 Contact Us For Availability

locator, cooktop WPL 311909 Contact Us For Availability

Screw, 11-16 x 1/2 Double Load Space Thread ( WPL 346893 Contact Us For Availability

Spring, Compression WPL 310197 Contact Us For Availability

WPL 3147843 WPL 3147843 Contact Us For Availability

35

Screw (2) WPL 313820 Contact Us For Availability

35

WPL 3147250 WPL 3147250 Contact Us For Availability

35

WPL 3147590 WPL 3147590 Contact Us For Availability

36

Transmotor WPL 313641 Contact Us For Availability

36

WPL 3148158 WPL 3148158 Contact Us For Availability

37

Pulley, Motor WPL 311922 Contact Us For Availability

37

WPL 3147595 WPL 3147595 Contact Us For Availability

38

End Cap WPL 3148297 Contact Us For Availability

38

WPL 3147596 WPL 3147596 Contact Us For Availability

38

Jack, Probe WPL 3147071 Contact Us For Availability

39

WPL 3147751 WPL 3147751 Contact Us For Availability

39

Washer, Internal Lock WPL 313105 Contact Us For Availability

40

Bracket, Motor WPL 313601 Contact Us For Availability

40

Screw, 8-22 (5) WPL 313823 Contact Us For Availability

41

Nut WPL 313104 Contact Us For Availability

42

WP486579 Whirlpool Air Conditioner Screw Backorder WPL WP486579 $3.11

43

Wheel, Blower WPL 3147223 Contact Us For Availability

43

Probe, Temperature WPL 313527 Contact Us For Availability

44

Jumper, High Voltage Red (6-5/16``) WPL 313130 Contact Us For Availability

44

Fuse, Thermal WPL 313855 Contact Us For Availability

45

Sensor, Gas WPL 3147060 Contact Us For Availability

46

High Voltage Lead, Gray 6-3/4`` (2) WPL 3147863 Contact Us For Availability

47

Clip WPL 311311 Contact Us For Availability

48

Extension, Air Duct WPL 3147262 Contact Us For Availability

49

Fuse, Thermal WPL 3147275 Contact Us For Availability
