Model Whirlpool RF3020XGN1 – Common Parts &amp; Diagrams

1

Endcap (Left Hand) WPL 3186188 Contact Us For Availability

1

Endcap (Right Hand) WPL 3186189 Contact Us For Availability

2

W11699791 Whirlpool Burner Box In Stock WPL W11699791 $107.87

2

WP3195996 Whirlpool Pan Grid Backorder WPL WP3195996 $41.94

2

Support, Endcap (Left Hand) WPL 3186198 Contact Us For Availability

2

Support, Endcap (Right Hand) WPL 3186199 Contact Us For Availability

3

WP3196076 Whirlpool Broil Pan Backorder WPL WP3196076 $167.94

3

WPW10575396 Whirlpool Side Panel Backorder WPL WPW10575396 $75.80

3

Panel, Side (2) (Almond-Textured) WPL 8053831 Contact Us For Availability

3

Panel, Backguard WPL 3186160 Contact Us For Availability

4

98005642 Whirlpool Clip Backorder WPL 98005642 $28.80

4

WP3148953 Whirlpool Oven Infinite Switch In Stock WPL WP3148953 $34.61

4

WP3149404 Whirlpool Oven Surface Element Swit In Stock WPL WP3149404 $28.08

4

WP3195060 Whirlpool Cooktop Pin Backorder WPL WP3195060 $4.23

5

W11542153 Whirlpool Door Gasket In Stock WPL W11542153 $21.59

5

Indicator, Surface WPL 8273303 Contact Us For Availability

6

W10856603 Whirlpool Broil Element In Stock WPL W10856603 $87.56

6

WP3188987 Whirlpool Oven Switch In Stock WPL WP3188987 $57.92

6

WP3196814 Whirlpool Rivet Backorder WPL WP3196814 $4.43

7

W11219377 Whirlpool Drawer Panel Backorder WPL W11219377 $70.99

7

WP3195812 Whirlpool Cooktop Rod In Stock WPL WP3195812 $2.51

7

WP3196163 Whirlpool Screw In Stock WPL WP3196163 $2.51

7

WP3196803 Whirlpool Oven Thermostat In Stock WPL WP3196803 $101.85

7

WPW10308477 Whirlpool Bake Element In Stock WPL WPW10308477 $36.86

8

W10903447 Whirlpool Door Panel Assembly In Stock WPL W10903447 $113.65

8

WP3195917 Whirlpool Clip Assembly In Stock WPL WP3195917 $3.70

8

Indicator, Oven WPL 314031 Contact Us For Availability

8

Plug, Frame WPL 3196072 Contact Us For Availability

9

814399 Whirlpool Receptacle Kit In Stock WPL 814399 $15.52

9

WP3196143 Whirlpool Spacer Assembly In Stock WPL WP3196143 $3.70

9

WP8053334 Whirlpool Drawer Glide In Stock WPL WP8053334 $3.70

9

Spacer, Handle (Almond) WPL 3196209 Contact Us For Availability

9

Plug Button WPL 308535 Contact Us For Availability

10

3196200 Whirlpool Clip In Stock WPL 3196200 $5.05

10

WP3195263 Whirlpool Door Handle In Stock WPL WP3195263 $68.83

10

WP3195546 Whirlpool Drawer Glide In Stock WPL WP3195546 $3.70

3196558 Whirlpool Oven Screw Backorder WPL 3196558 $9.59

WP3196037 Whirlpool Leveling Foot Backorder WPL WP3196037 $26.50

WP3196231 Whirlpool Knob In Stock WPL WP3196231 $11.02

Screw, Top (Almond) WPL 3196559 Contact Us For Availability

12

Frame, Front WPL 3186156 Contact Us For Availability

13

WP3196068 Whirlpool Light Lens In Stock WPL WP3196068 $2.85

13

WP3196925 Whirlpool Clip Assembly Backorder WPL WP3196925 $5.16

13

WP8054068 Whirlpool Retainer Backorder WPL WP8054068 $28.80

285006 Whirlpool Spray In Stock WPL 285006 $27.45

350930 Whirlpool White Spray Paint In Stock WPL 350930 $12.50

350956 Whirlpool Spray Assembly In Stock WPL 350956 $19.22

511873 Whirlpool Refrigerator Paint Backorder WPL 511873 $19.22

72017 Whirlpool Appliance Touch-Up Paint Whit In Stock WPL 72017 $3.35

799344 Whirlpool Refrigerator Paint Backorder WPL 799344 $93.22

814381 Whirlpool Pin Backorder WPL 814381 $3.70

WP72107 Whirlpool Touchup In Stock WPL WP72107 $5.80

WPW10208653 Whirlpool Insulation Backorder WPL WPW10208653 $28.80

Knob, Thermostat WPL 3196213 Contact Us For Availability

FOIL, ALUMINUM OVEN (18`` X 25 ) WPL 241430 Contact Us For Availability

Grease WPL 261582 Contact Us For Availability

Clip, Ground Wire WPL 313660 Contact Us For Availability

WPL 799832 WPL 799832 Contact Us For Availability

WPL 8273272 WPL 8273272 Contact Us For Availability

WPL 978883 WPL 978883 Contact Us For Availability

Clip, Panel (6) WPL 3196576 Contact Us For Availability

15

WPW10306546 Whirlpool Base Rail Backorder WPL WPW10306546 $50.64

15

Shield, Heat WPL 8053912 Contact Us For Availability

16

WPW10058460 Whirlpool Appliance Levelling Leg In Stock WPL WPW10058460 $3.70

16

Screw WPL 4449746 Contact Us For Availability

17

WP8272473 Whirlpool Rear Cover Backorder WPL WP8272473 $112.03

18

238614 Whirlpool Bumper Hinge Backorder WPL 238614 $68.16

18

WPW10326122 Whirlpool Black Cover Backorder WPL WPW10326122 $46.85

19

W10404688 Whirlpool Bracket Support Backorder WPL W10404688 $7.69

19

W11233072 Whirlpool Screw In Stock WPL W11233072 $9.59

20

W11728255 Whirlpool Service Bracket Backorder WPL W11728255 $28.68

20

WP3400882 Whirlpool Screw In Stock WPL WP3400882 $2.51

21

WP112432 Whirlpool Nut Assembly Backorder WPL WP112432 $2.51

21

WP3196170 Whirlpool Screw Backorder WPL WP3196170 $2.51

21

WP8203546 Whirlpool Terminal Block In Stock WPL WP8203546 $10.45

22

Back, Main WPL 8053508 Contact Us For Availability

24

Strap, Ground WPL 3169573 Contact Us For Availability

25

WP3196567 Whirlpool Screw Backorder WPL WP3196567 $2.51

26

WP3400832 Whirlpool Screw In Stock WPL WP3400832 $2.51

27

WP3196174 Whirlpool Screw Backorder WPL WP3196174 $2.51

28

WP3196175 Whirlpool Screw In Stock WPL WP3196175 $2.51

29

Screw WPL 3196179 Contact Us For Availability

31

WP3400016 Whirlpool Screw Assembly Backorder WPL WP3400016 $2.51

33

W11244557 Whirlpool Screw Backorder WPL W11244557 $9.59

34

W11311894 Whirlpool Insulation Backorder WPL W11311894 $37.17

34

WP7101P246-60 Whirlpool Screw Backorder WPL WP7101P246-60 $2.51
