Model Whirlpool KTRC19MKSS02 REFRIGERATOR – Common Parts &amp; Diagrams

1

Liner (Not A Serviceable Part) WPL ARI109468A Contact Us For Availability

1

Refrigerator Door (White) WPL 2205403 Contact Us For Availability

1

Refrigerator Door (Biscuit) WPL 2205404 Contact Us For Availability

1

Refrigerator Door (Black) WPL 2205406 Contact Us For Availability

1

Refrigerator Door (Stainless Steel (Includes WPL 2212494 Contact Us For Availability

1

Freezer Door (White) WPL 2205399 Contact Us For Availability

1

Freezer Door (Biscuit) WPL 2205400 Contact Us For Availability

1

Freezer Door (Black) WPL 2205402 Contact Us For Availability

1

Freezer Door (Stainless Steel (Includes No.6 WPL 2212495 Contact Us For Availability

2

WP2212649 Whirlpool Refrigerator Button Plug Backorder WPL WP2212649 $3.70

2

WP2264462 Whirlpool Refrigerator Grommet In Stock WPL WP2264462 $17.06

3

2210495 Whirlpool Refrigerator Clip Backorder WPL 2210495 $33.49

3

WP2166108 Whirlpool Refrigerator Cabinet Roll In Stock WPL WP2166108 $13.54

3

WP2254360 Whirlpool Refrigerator Gasket Backorder WPL WP2254360 $8.67

3

Beverage Holder WPL 2193409 Contact Us For Availability

3

Handle (White) WPL 2205459 Contact Us For Availability

3

Handle (Biscuit) WPL 2205460 Contact Us For Availability

3

Handle (Black) WPL 2221632 Contact Us For Availability

4

W11745278 Whirlpool Bracket In Stock WPL W11745278 $5.18

4

WP2304099-includeCORE Whirlpool WP2304099 Ref Backorder WPL WP2304099-includeCORE $191.35

5

WP2196003 Whirlpool Refrigerator Bar Riser Backorder WPL WP2196003 $3.70

5

WP628379 Whirlpool Refrigerator Clip Backorder WPL WP628379 $4.61

6

WP2183003 Whirlpool Thimble In Stock WPL WP2183003 $3.70

6

WP941839 Whirlpool Refrigerator Button Plug In Stock WPL WP941839 $3.70

7

WP2212648 Whirlpool Refrigerator Hinge Sleeve In Stock WPL WP2212648 $3.70

7

WP2212651 Whirlpool Refrigerator Button Plug Backorder WPL WP2212651 $10.27

7

Wire Assy. Control Box WPL 2187352 Contact Us For Availability

7

Hole Plug (White) WPL 2204837 Contact Us For Availability

7

Hole Plug (Biscuit) WPL 2204838 Contact Us For Availability

7

Hole Plug (Black) WPL 2204840 Contact Us For Availability

8

2159057 Whirlpool Refrigerator Fresh Food Doo In Stock WPL 2159057 $84.60

8

2159327 Whirlpool Refrigerator Door Gasket In Stock WPL 2159327 $82.03

8

2177304 Whirlpool Refrigerator FIP Gasket In Stock WPL 2177304 $130.47

8

2177305 Whirlpool Refrigerator Door FIP Gaske In Stock WPL 2177305 $145.16

8

4387478 Whirlpool Refrigerator Light Socket In Stock WPL 4387478 $32.34

8

W11594405 Whirlpool Axle In Stock WPL W11594405 $6.90

10

WP2315576 Whirlpool Water Inlet Valve In Stock WPL WP2315576 $42.13

10

WPW10189703 Whirlpool Refrigerator Evaporator In Stock WPL WPW10189703 $35.77

10

Eyelet, Roller WPL 2174478 Contact Us For Availability

2212996 Whirlpool Refrigerator Retainer Backorder WPL 2212996 $7.52

WP2163777 Whirlpool Refrigerator Fan Blade In Stock WPL WP2163777 $37.19

WP3400504 Whirlpool Refrigerator Screw Backorder WPL WP3400504 $3.70

WP627018 Whirlpool Refrigerator Nut In Stock WPL WP627018 $4.59

12

Control Box WPL 2213193 Contact Us For Availability

13

Thermostat Assembly (Includes Item 5) WPL 2204984 Contact Us For Availability

13

Butter, Dish WPL 2165792 Contact Us For Availability

14

Handle (White) WPL 2205463 Contact Us For Availability

14

Handle (Biscuit) WPL 2205464 Contact Us For Availability

14

Handle (Black) WPL 2221636 Contact Us For Availability

15

WP489497 Whirlpool Screw In Stock WPL WP489497 $4.58

15

WP693995 Whirlpool Screw In Stock WPL WP693995 $1.92

16

WP681249 Whirlpool Screw Assembly In Stock WPL WP681249 $2.51

16

Cover-Evaporator WPL 2201173 Contact Us For Availability

8009 Whirlpool 40W 120V Light Bulb In Stock WPL 8009 $6.89

WP2176275 Whirlpool Refrigerator Wire Shelf Backorder WPL WP2176275 $73.09

WP2183854 Whirlpool Refrigerator Shim Backorder WPL WP2183854 $4.54

Trim, Door (2) WPL 2159291 Contact Us For Availability

212643 Whirlpool Refrigerator Permagum Sealer In Stock WPL 212643 $28.53

285006 Whirlpool Spray In Stock WPL 285006 $28.82

350930 Whirlpool White Spray Paint In Stock WPL 350930 $13.12

350942 Whirlpool Spray Paint Backorder WPL 350942 $32.57

350956 Whirlpool Spray Assembly In Stock WPL 350956 $19.22

4392899 Whirlpool Biscuit Touch-Up Paint In Stock WPL 4392899 $7.21

4392901 Whirlpool Biscuit Spray Paint In Stock WPL 4392901 $27.58

511873 Whirlpool Refrigerator Paint Backorder WPL 511873 $19.22

606755 Whirlpool Refrigerator Bag Backorder WPL 606755 $27.52

72017 Whirlpool Appliance Touch-Up Paint Whit In Stock WPL 72017 $3.51

72032 Whirlpool Touch Up Paint Black In Stock WPL 72032 $15.46

833938 Whirlpool Refrigerator Terminal Backorder WPL 833938 $3.70

876370 Whirlpool Refrigerator Insulation Backorder WPL 876370 $100.80

W11729596 Whirlpool Ice Maker Field Install K In Stock WPL W11729596 $105.37

WP503695 Whirlpool Refrigerator Sealer Backorder WPL WP503695 $41.14

WP505587 Whirlpool Refrigerator Sealer Backorder WPL WP505587 $60.73

WP72107 Whirlpool Touchup In Stock WPL WP72107 $5.80

WPW10272364 Whirlpool Refrigerator Screw In Stock WPL WPW10272364 $4.56

WPW10289690 Whirlpool Ice Maker Cover Backorder WPL WPW10289690 $2.64

WPL 876029 WPL 876029 Contact Us For Availability

TAPE, VINYL (3/4 X 108``) WPL 479502 Contact Us For Availability

WPL 799344 WPL 799344 Contact Us For Availability

Torx Key WPL 1117510 Contact Us For Availability

Weight, Thermal WPL 2200831 Contact Us For Availability

Nameplate (White) WPL 2212760 Contact Us For Availability

Nameplate (Biscuit) WPL 2212761 Contact Us For Availability

Nameplate (Black) WPL 2212762 Contact Us For Availability

PAINT, BULK (1 QT.) (BISCUIT (UNCUT)) WPL 4392900 Contact Us For Availability

CEMENT, ALUMILASTIC (1 1/4 OZ.) WPL 542639 Contact Us For Availability

WPL 799340 WPL 799340 Contact Us For Availability

WPL 799832 WPL 799832 Contact Us For Availability

WPL 799833 WPL 799833 Contact Us For Availability

WPL 978883 WPL 978883 Contact Us For Availability

19

W11384469 Whirlpool Door Switch In Stock WPL W11384469 $13.32

19

WP489464 Whirlpool Refrigerator Screw Backorder WPL WP489464 $3.70

19

Clip, Heater WPL 2182338 Contact Us For Availability

WP542638 Whirlpool Refrigerator Grease In Stock WPL WP542638 $23.17

WPW10190929 Whirlpool Refrigerator Ice Maker Backorder WPL WPW10190929 $144.80

Wire Assembly, Freezer Compartment WPL 2187568 Contact Us For Availability

Bin, Door Shelf (3) WPL 2171065 Contact Us For Availability

21

WP2156006 Whirlpool Refrigerator Shelf Trim E In Stock WPL WP2156006 $4.10

21

Cover, Air Diffuser WPL 2176281 Contact Us For Availability

2163762 Whirlpool Refrigerator Cup Assembly Backorder WPL 2163762 $4.32

WP628356 Whirlpool Refrigerator Fill Cup Backorder WPL WP628356 $16.56

Knob, Thermostat WPL 2205094 Contact Us For Availability

Door, Compartment WPL 2218122 Contact Us For Availability

WP627843 Whirlpool Refrigerator Ejector Arm In Stock WPL WP627843 $30.25

Shim WPL 2172743 Contact Us For Availability

Air Tower WPL 2182340 Contact Us For Availability

Support Block WPL 2201184 Contact Us For Availability

24

WP2182124 Whirlpool Refrigerator Stripper Arm Backorder WPL WP2182124 $28.15

24

WP2189452 Whirlpool Refrigerator Diffuser Backorder WPL WP2189452 $44.74

25

WP2195914 Whirlpool Refrigerator Ice Maker Ho Backorder WPL WP2195914 $38.96

25

Freezer Floor WPL 2204746 Contact Us For Availability

26

WP2315522 Whirlpool Refrigerator Clip Backorder WPL WP2315522 $4.59

26

Air Diffuser, Top WPL 2179877 Contact Us For Availability

26

Gasket, Door Compartment WPL 2159124 Contact Us For Availability

27

WP627985 Whirlpool Icemaker Cycling Thermosta In Stock WPL WP627985 $44.03

27

Bin, Door WPL 2171062 Contact Us For Availability

27

Cement Alumilastic) WPL 542369 Contact Us For Availability

28

8533917 Whirlpool Refrigerator Screw In Stock WPL 8533917 $9.59

28

WPW10421484 Whirlpool Refrigerator Door Trim In Stock WPL WPW10421484 $49.65

29

WP489427 Whirlpool Refrigerator Screw Backorder WPL WP489427 $3.70

29

Bracket, Fan Motor WPL 2218696 Contact Us For Availability

30

Bracket, Evap. Fan, Front WPL 2214979 Contact Us For Availability

31

WP627792 Whirlpool Refrigerator Shut Off Arm Backorder WPL WP627792 $37.02

31

WP98129 Whirlpool Screw Backorder WPL WP98129 $2.51

32

WP2187464 Whirlpool Refrigerator Wire Harness Backorder WPL WP2187464 $46.02

32

WP4387764 Whirlpool Run Capacitor Backorder WPL WP4387764 $85.09

33

W11500948 Whirlpool Refrigerator Bracket In Stock WPL W11500948 $12.32

34

Air Damper WPL 2212413 Contact Us For Availability

35

W10190935 Whirlpool Refrigerator Icemaker Mot In Stock WPL W10190935 $54.86

35

WPW10283959 Whirlpool Refrigerator Filler In Stock WPL WPW10283959 $3.70

35

Shield, heat WPL 2204639 Contact Us For Availability

36

WP2205079 Whirlpool Refrigerator Seal Backorder WPL WP2205079 $4.14

36

WP489478 Whirlpool Refrigerator Screw Backorder WPL WP489478 $2.51

37

WP2184574 Whirlpool Refrigerator Gear Wheel Backorder WPL WP2184574 $27.52

37

CLIP, GRILLE WPL 2189356 Contact Us For Availability

38

489136 Whirlpool Refrigerator Screw Backorder WPL 489136 $4.56

38

WP487576 Whirlpool Washer In Stock WPL WP487576 $4.58

38

Knob, Damper WPL 2204951 Contact Us For Availability

39

WP488163 Whirlpool Refrigerator Screw In Stock WPL WP488163 $3.70

39

Housing Base WPL 2201152 Contact Us For Availability

2213364 Whirlpool Refrigerator Cover Backorder WPL 2213364 $9.48

WP2213360 Whirlpool Refrigerator Cover Backorder WPL WP2213360 $11.95

WP488787 Whirlpool Refrigerator Screw Backorder WPL WP488787 $4.56

Air Seal, Foam WPL 2205055 Contact Us For Availability

41

W10777924 Whirlpool Refrigerator Wine Rack Backorder WPL W10777924 $8.47

41

Wiring Harness, Freezer Light WPL 2221682 Contact Us For Availability

42

WP489442 Whirlpool Refrigerator Screw Backorder WPL WP489442 $4.56

42

Electrical Shield, Freezer Light WPL 2193491 Contact Us For Availability

43

4396822 Whirlpool Refrigerator Light Bulb In Stock WPL 4396822 $6.28

43

Fan, Blade WPL 2190685 Contact Us For Availability

44

WP486692 Whirlpool Refrigerator Nut Backorder WPL WP486692 $3.70

44

Control, Freezer WPL 2204991 Contact Us For Availability

45

Gear Wheel, Freezer Control WPL 2204992 Contact Us For Availability

47

Barrier, Freezer Control WPL 2212485 Contact Us For Availability

48

Gasket, Rear WPL 2166284 Contact Us For Availability

49

Pullout, Freezer Floor WPL 2189429 Contact Us For Availability

50

REAR FENCE PULL-OUT FREEZER FLOOR WPL 2198768 Contact Us For Availability

51

Roller, Slide WPL 2176246 Contact Us For Availability

52

Side Support, Floor Assembly WPL 2179713 Contact Us For Availability

53

Center Support, Floor Assembly WPL 2179714 Contact Us For Availability

57

Bracket, Evap. Fan, Rear WPL 2214976 Contact Us For Availability

876764 Whirlpool Refrigerator Primary Valve In Stock WPL 876764 $23.44

978026 Whirlpool Refrigerator Primary Valve In Stock WPL 978026 $33.93

978027 Whirlpool Refrigerator Primary Valve Backorder WPL 978027 $35.65

978030 Whirlpool Refrigerator Valve Backorder WPL 978030 $37.30

WP2210509 Whirlpool Refrigerator Tub Valve Backorder WPL WP2210509 $28.80

WP978025 Whirlpool Refrigerator Valve In Stock WPL WP978025 $27.19

Evaporator Tray WPL 2210451 Contact Us For Availability

VALVE, ACCESS (5/8``) WPL 978029 Contact Us For Availability

100

4317943 Whirlpool Refrigerator Ice Maker Asse In Stock WPL 4317943 $89.62
