Model Whirlpool KFDC558JAV00 RANGE/OVEN, DUAL FUEL, COMMERCIAL-STYLE, 48 INCH – Common Parts &amp; Diagrams

1

W11318335 Whirlpool Glass Frame Backorder WPL W11318335 $122.09

1

W11318831 Whirlpool Glass Frame Backorder WPL W11318831 $122.09

1

WP4449751 Whirlpool Range Oven Thermostat Fix In Stock WPL WP4449751 $76.71

1

KICKPLATE WPL W11394822 Contact Us For Availability

1

GUIDE, USE AND CARE WPL W11114331 Contact Us For Availability

1A

INSTRUCTIONS, INSTALLATION WPL W11114334 Contact Us For Availability

1B

GUIDE, INTERNET CONNECTIVITY WPL W11184759 Contact Us For Availability

1C

GUIDE, QUICK START WPL W11114332 Contact Us For Availability

1D

DIAGRAM, WIRING WPL W11202393 Contact Us For Availability

1E

DIAGRAM, WIRING (OVEN) WPL W11202387 Contact Us For Availability

1F

SHEET, TECH WPL W11202289 Contact Us For Availability

2

W10859573 Whirlpool Range Oven Temperature Se In Stock WPL W10859573 $68.99

2

W11029221 Whirlpool Door Latch In Stock WPL W11029221 $116.09

2

W11381267 Whirlpool Manifold Assembly Backorder WPL W11381267 $119.92

2

W11688507 Whirlpool Insulation In Stock WPL W11688507 $9.10

2

INSULATION, DOOR WPL W10321285 Contact Us For Availability

2

BACK, CHASSIS WPL W11324987 Contact Us For Availability

2

INSULATION, DOOR WPL W10884821 Contact Us For Availability

2A

W11381269 Whirlpool Manifold Assembly Backorder WPL W11381269 $119.92

2B

W11378578 Whirlpool Manifold Backorder WPL W11378578 $120.72

3

W10570879 Whirlpool Range Rack Assembly Backorder WPL W10570879 $71.02

3

W11317951 Whirlpool Glass Door Backorder WPL W11317951 $60.54

3

W11318823 Whirlpool Door Glass Backorder WPL W11318823 $60.54

3

W11344433 Whirlpool Wire Harness Backorder WPL W11344433 $70.03

3

W11550107 Whirlpool Oven Rack Backorder WPL W11550107 $59.22

3

WPW10138054 Whirlpool Refrigerator Cabinet Ro In Stock WPL WPW10138054 $17.40

3

WPW10351278 Whirlpool Bumper Backorder WPL WPW10351278 $3.70

4

W11320153 Whirlpool Mounting Bracket Backorder WPL W11320153 $41.34

4

W11320536 Whirlpool Duct Backorder WPL W11320536 $122.73

4

W11496977 Whirlpool Range Rack Backorder WPL W11496977 $210.16

4

W11573760 Whirlpool Surface Igniter In Stock WPL W11573760 $8.44

4

SCREW WPL 7101P42660 Contact Us For Availability

4

RETAINER, GLASS WPL W11194821 Contact Us For Availability

4

RETAINER, GLASS WPL W11194818 Contact Us For Availability

4B

W11628654 Whirlpool Surface Igniter Backorder WPL W11628654 $19.62

5

SHIELD-HT Backorder WPL W10160856 $68.91

5

W11319687 Whirlpool Spark Module In Stock WPL W11319687 $90.36

5

W11643630 Whirlpool Door Hinge Backorder WPL W11643630 $79.55

5

W11643896 Whirlpool Appliance Door Hinge In Stock WPL W11643896 $74.14

5

WP9759118 Whirlpool Mounting Plate Backorder WPL WP9759118 $31.49

5

TUBE, VENT WPL W11290663 Contact Us For Availability

5

TUBE, VENT WPL W10288078 Contact Us For Availability

6

W10859931 Whirlpool Foot Level Backorder WPL W10859931 $46.17

6

COVER Backorder WPL W11211948 $51.46

6

W11233684 Whirlpool Range Light Assembly Backorder WPL W11233684 $36.75

6

TRAY-INSUL Backorder WPL W11330430 $74.79

6

W11643898 Whirlpool Door Hinge Backorder WPL W11643898 $48.57

6

W11643900 Whirlpool Door Hinge In Stock WPL W11643900 $48.57

6

W11662207 Whirlpool Convection Baffle Backorder WPL W11662207 $60.04

7

W10169756 Whirlpool Light Lens Backorder WPL W10169756 $27.80

7

W10860984 Whirlpool Fan Motor In Stock WPL W10860984 $74.69

7

W10908710 Whirlpool Mounting Bracket Backorder WPL W10908710 $79.35

7

W11712404 Whirlpool Screw Backorder WPL W11712404 $8.11

7

WPW10272594 Whirlpool Window Frame Backorder WPL WPW10272594 $69.70

7

BRACKET, GRIDDLE-RTD WPL W11121384 Contact Us For Availability

8

W10162096 Whirlpool Screw Backorder WPL W10162096 $9.59

8

W10819914 Whirlpool Convection Fan In Stock WPL W10819914 $35.67

8

WP4449743 Whirlpool Screw Backorder WPL WP4449743 $2.51

8

WPW10169757 Whirlpool Light Bulb In Stock WPL WPW10169757 $29.94

8

TUBE, MANIFOLD SUPPLY (LEFT) WPL W10892809 Contact Us For Availability

8A

TUBE, MANIFOLD SUPPLY (LEFT CENTER) WPL W10892804 Contact Us For Availability

8B

TUBE, MANIFOLD SUPPLY (RIGHT CENTER) WPL W10892805 Contact Us For Availability

9

W10270397 Whirlpool Vent Seal Backorder WPL W10270397 $12.11

9

W11602621 Whirlpool Module Backorder WPL W11602621 $825.77

9

WP9759117 Whirlpool Leveling Foot Backorder WPL WP9759117 $63.64

9

TRAY, HIDDEN BAKE WPL W11110223 Contact Us For Availability

9

BRACKET, HANDLE WPL W11197830 Contact Us For Availability

9

RECEIVER, HINGE (LEFT) WPL W11096294 Contact Us For Availability

W10115869 Whirlpool Shaft Backorder WPL W10115869 $43.57

W10160858 Whirlpool Lid Cover Backorder WPL W10160858 $27.52

W10491985 Whirlpool Screw Backorder WPL W10491985 $3.33

W10794042 Whirlpool Nut Backorder WPL W10794042 $5.29

W11400571 Whirlpool Door Glass Backorder WPL W11400571 $486.07

ELEMENT, HIDDEN BAKE WPL W11045324 Contact Us For Availability

ASSEMBLY, OUTER DOOR (INCLUDES HANDLE) WPL W11389278 Contact Us For Availability

W10115793 Whirlpool Shaft Backorder WPL W10115793 $33.69

W10115843 Whirlpool Access Cover Backorder WPL W10115843 $6.62

W10116010 Whirlpool Broil Element Backorder WPL W10116010 $55.15

W11380863 Whirlpool Door Handle Backorder WPL W11380863 $191.68

W11643125 Whirlpool Element Backorder WPL W11643125 $46.65

WP9761958 Whirlpool Range Terminal Block In Stock WPL WP9761958 $14.49

HANDLE, DOOR WPL W11221413 Contact Us For Availability

489504 Whirlpool Range Ring Backorder WPL 489504 $4.85

W10160855 Whirlpool Heat Shield Backorder WPL W10160855 $58.73

W11320145 Whirlpool Cabinet Panel Backorder WPL W11320145 $124.37

WP112432 Whirlpool Nut Assembly Backorder WPL WP112432 $2.51

WPW10276043 Whirlpool Screw Backorder WPL WPW10276043 $2.51

TRAY, HIDDEN BAKE WPL W11109421 Contact Us For Availability

RECEIVER, HINGE (RIGHT) WPL W11096293 Contact Us For Availability

12A

CHASSIS, SIDE (RIGHT) WPL W11102296 Contact Us For Availability

W10261523 Whirlpool Plate Backorder WPL W10261523 $27.12

W10839793 Whirlpool Refrigerator Nameplate In Stock WPL W10839793 $23.59

W11193480 Whirlpool Screw In Stock WPL W11193480 $9.59

W11319618 Whirlpool Sensor Backorder WPL W11319618 $86.72

W11320154 Whirlpool Range Gas Tubing Backorder WPL W11320154 $66.79

WP9755542 Whirlpool Oven Meat Probe In Stock WPL WP9755542 $59.04

14

W11368841SI Whirlpool Range Medallion Backorder WPL W11368841SI $134.94

14

SUPPORT Backorder WPL W11369238 $66.48

14

WP4449154 Whirlpool Screw In Stock WPL WP4449154 $2.51

8186589 Whirlpool Jack Probe Backorder WPL 8186589 $64.26

W11643628 Whirlpool Screw In Stock WPL W11643628 $9.59

W11675844 Whirlpool Oven Gasket In Stock WPL W11675844 $44.23

INSULATION, GRIDDLE WPL W11121383 Contact Us For Availability

15A

W11115326 Whirlpool Gasket Backorder WPL W11115326 $111.80

16

4453116 Whirlpool Range Adapter Backorder WPL 4453116 $72.36

16

W11050145 Whirlpool HVAC Air Duct Backorder WPL W11050145 $61.68

16

W11231343 Whirlpool Lock Nut In Stock WPL W11231343 $9.59

W10115819 Whirlpool Brace Backorder WPL W10115819 $27.52

W10276497 Whirlpool Drip Tray Backorder WPL W10276497 $189.27

SCREW Backorder WPL W10739592 $6.28

W10850807 Whirlpool Screw Backorder WPL W10850807 $2.51

W10920281 Whirlpool Screw Backorder WPL W10920281 $2.95

18

W11319602 Whirlpool Grille Element Backorder WPL W11319602 $123.09

18

W11362015 Whirlpool Retainer Backorder WPL W11362015 $60.35

18

ELEMENT, HIDDEN BAKE WPL W10115995 Contact Us For Availability

19

W11233072 Whirlpool Screw In Stock WPL W11233072 $10.41

19

TOP, CHASSIS WPL W11324984 Contact Us For Availability

20

CHASSIS, BOTTOM WPL W11040800 Contact Us For Availability

21

W10130760 Whirlpool Bracket Mounting Backorder WPL W10130760 $27.52

21

PANEL, BACK TOP WPL W11103335 Contact Us For Availability

21A

W10130759 Whirlpool Mounting Bracket Backorder WPL W10130759 $27.52

22

PANEL, BACK BOTTOM WPL W11034123 Contact Us For Availability

23

W11320155 Whirlpool Mounting Bracket Backorder WPL W11320155 $41.34

24

W11106948 Whirlpool Pressure Regulator In Stock WPL W11106948 $112.73

25

3400518 Whirlpool Oven Foot Mount Screw Backorder WPL 3400518 $9.13

25

W10271524 Whirlpool Trim Top Backorder WPL W10271524 $88.85

26

DRAWER, APPLIANCE MANAGER WPL W11106341 Contact Us For Availability

28

COVER-CNTL Backorder WPL W11369237 $55.78

29

CHANNEL, WIRE WPL W11368831 Contact Us For Availability

30

W10116114 Whirlpool Indicator Light Backorder WPL W10116114 $33.25

30

W11318207 Whirlpool Clip Assembly Backorder WPL W11318207 $4.61

31

W10294500 Whirlpool Light Lens Backorder WPL W10294500 $4.85

31

W11199181 Whirlpool Foot Cover Backorder WPL W11199181 $57.09

31A

W11199178 Whirlpool Foot Cover Assembly Backorder WPL W11199178 $57.09

32

W10291193 Whirlpool Trim Top Backorder WPL W10291193 $57.11

32

W11169708 Whirlpool Screw Backorder WPL W11169708 $9.59

35

WP3400814 Whirlpool Screw Backorder WPL WP3400814 $2.91

42

W11398684-includeCORE Whirlpool W11398684 Ran Backorder WPL W11398684-includeCORE $238.39

43

W11234290 Whirlpool Electronic Control Board Backorder WPL W11234290 $75.33

44

WPL 7101P62460 WPL 7101P62460 Contact Us For Availability

4450800 Whirlpool Oven Screw Backorder WPL 4450800 $9.59

W10123240 Whirlpool Broil Pan and Roasting Ra Backorder WPL W10123240 $72.40

W10160195 Whirlpool Cover Backorder WPL W10160195 $160.20

W10216179 Whirlpool Wok Ring In Stock WPL W10216179 $26.90

W10282812 Whirlpool Insulation Assembly Backorder WPL W10282812 $43.77

W10285449 Whirlpool Backsplash Backorder WPL W10285449 $484.00

W10780278 Whirlpool Wire Harness Backorder WPL W10780278 $43.72

W11200302 Whirlpool Wire Harness Backorder WPL W11200302 $164.01

W11317786 Whirlpool Wire Harness Backorder WPL W11317786 $87.44

W11317787 Whirlpool Wire Harness Backorder WPL W11317787 $79.55

W11317788 Whirlpool Wire Harness Backorder WPL W11317788 $70.03

W11317789 Whirlpool Wire Harness In Stock WPL W11317789 $113.37

W11317791 Whirlpool Wire Harness Backorder WPL W11317791 $79.55

W11368841BN Whirlpool Medallion Backorder WPL W11368841BN $88.69

MEDALLION Backorder WPL W11368841MP $75.12

W11368841NE Whirlpool Medallion Backorder WPL W11368841NE $131.86

W11368841RE Whirlpool Range Commercial-Style Backorder WPL W11368841RE $83.26

W11502161 Whirlpool Conversion Kit In Stock WPL W11502161 $26.97

W11544575 Whirlpool Anti-Tip Bracket Backorder WPL W11544575 $19.47

WP3400968 Whirlpool Nut Backorder WPL WP3400968 $3.70

WP9759877 Whirlpool Retainer Backorder WPL WP9759877 $6.51

ACCESSORY PARTS, CLEANER, COOKTOP WPL 31464 Contact Us For Availability

ACCESSORY PARTS, STAINLESS STEEL CLEANER & PO WPL 4396920 Contact Us For Availability

ACCESSORY PARTS, BACKSPLASH (ADJUSTABLE) WPL 8284755 Contact Us For Availability

ACCESSORY PARTS, KIT, HIGH ALTITUDE WPL W11238043 Contact Us For Availability

ACCESSORY PARTS, MEDALLION, HANDLE (BLACK ANO WPL W11368841BO Contact Us For Availability

ACCESSORY PARTS, MEDALLION, HANDLE (DARK BLUE WPL W11368841DD Contact Us For Availability

FOLLOWING PARTS NOT ILLUSTRATED WPL NP Contact Us For Availability

SCREW, ANTI-TIP KIT WPL 7101P48560 Contact Us For Availability

CORD, POWER WPL W11212216 Contact Us For Availability

INSULATION, WRAP, 30" WPL W10282810 Contact Us For Availability

INSULATION, BACK, 30" WPL W10282818 Contact Us For Availability

INSULATION, WRAP, 18" WPL W10282820 Contact Us For Availability
