Model Whirlpool KEMS377GBL0 – Common Parts &amp; Diagrams

1

WP8281236 Whirlpool Screw Backorder WPL WP8281236 $2.51

1

Door Liner WPL 4451718 Contact Us For Availability

1

Trim, Side (Screw White) WPL 4449041 Contact Us For Availability

1

Trim, Side (RH Black) WPL 4450856 Contact Us For Availability

1

Trim, Side (RH White) WPL 4450857 Contact Us For Availability

1

Trim, Side (RH Almond) WPL 4450858 Contact Us For Availability

1

Trim, Side (LH Black) WPL 4450859 Contact Us For Availability

1

Trim, Side (LH White) WPL 4450860 Contact Us For Availability

1

Trim, Side (LH Almond) WPL 4450861 Contact Us For Availability

1

Trim, Side (RH Biscuit) WPL 4452124 Contact Us For Availability

1

Trim, Side (LH Biscuit) WPL 4452125 Contact Us For Availability

1

Cover, Top WPL 4450377 Contact Us For Availability

2

4455178 Whirlpool Oven Top Elbow Backorder WPL 4455178 $9.48

2

WP4449743 Whirlpool Screw Backorder WPL WP4449743 $2.51

2

WP4455523 Whirlpool Oven Door Hinge In Stock WPL WP4455523 $31.90

2

WP4455525 Whirlpool Oven Door Hinge In Stock WPL WP4455525 $43.32

2

Baffle, Blower WPL 4448935 Contact Us For Availability

3

4455177 Whirlpool Oven Bottom Elbow Backorder WPL 4455177 $7.05

3

WP4449253 Whirlpool Glass Window In Stock WPL WP4449253 $74.43

3

WP4449745 Whirlpool Screw Backorder WPL WP4449745 $2.51

3

Blower WPL 4450920 Contact Us For Availability

4

4448520 Whirlpool Oven Bumper In Stock WPL 4448520 $10.76

4

Insulation, Door WPL 4451721 Contact Us For Availability

4

Plate, Mounting Transformer WPL 4451789 Contact Us For Availability

5

W10491987 Whirlpool Foam Seal Backorder WPL W10491987 $3.70

5

WP9760588 Whirlpool Transformer In Stock WPL WP9760588 $95.80

5

Retainer, Glass WPL 4451670 Contact Us For Availability

6

Rack, Oven WPL 4448715 Contact Us For Availability

6

Exhaust Duct WPL 4450366 Contact Us For Availability

7

WP4449257 Whirlpool Door Glass Backorder WPL WP4449257 $96.15

7

Top, Chassis WPL 4452236 Contact Us For Availability

7

Bracket, Duct WPL 4450027 Contact Us For Availability

8

WP112432 Whirlpool Nut Assembly Backorder WPL WP112432 $2.51

8

Grommet WPL 4449964 Contact Us For Availability

9

4454949 Whirlpool Oven Fuse Block Backorder WPL 4454949 $30.25

9

W10861715 Whirlpool Vent Tube Backorder WPL W10861715 $40.00

9

Convection Motor WPL 4451583 Contact Us For Availability

9

Glass, Middle WPL 4448937 Contact Us For Availability

9

Baffle, Rear WPL 4450407 Contact Us For Availability

WP4452226 Whirlpool Convection Fan Backorder WPL WP4452226 $28.29

WPW10017410 Whirlpool Fuse In Stock WPL WPW10017410 $6.79

Latch Assembly WPL 4451424 Contact Us For Availability

Lens, Light WPL 4452163 Contact Us For Availability

4449748 Whirlpool Oven Screw Backorder WPL 4449748 $7.01

WP3387230 Whirlpool Screw In Stock WPL WP3387230 $2.64

WP4448972 Whirlpool Oven Light In Stock WPL WP4448972 $50.93

WP8203546 Whirlpool Terminal Block In Stock WPL WP8203546 $10.98

Solenoid WPL 4451663 Contact Us For Availability

WP4452164 Whirlpool 12V 5W Halogen Light Bulb In Stock WPL WP4452164 $49.89

Duct, Inlet WPL 4375260 Contact Us For Availability

Door Glass, Assy (Black Model) WPL 4452071 Contact Us For Availability

Door Glass, Assy (White Model) WPL 4452072 Contact Us For Availability

Door Glass, Assy (Almond) WPL 4452073 Contact Us For Availability

Door Glass, Assy (Biscuit) WPL 4452146 Contact Us For Availability

Door Glass, Assy (Black-Stainless) WPL 4452476 Contact Us For Availability

Micro Switch N.C. WPL 4451422 Contact Us For Availability

Side, Combo WPL 4450401 Contact Us For Availability

Tape, Foam WPL 4450265 Contact Us For Availability

Door Handle (Black) WPL 4448411 Contact Us For Availability

Door Handle (White) WPL 4448412 Contact Us For Availability

Door Handle (Almond) WPL 4448413 Contact Us For Availability

Door Handle (Biscuit) WPL 4452128 Contact Us For Availability

Microswitch WPL 4451426 Contact Us For Availability

Vent, (Control Panel) WPL 4449764 Contact Us For Availability

W10755214 Whirlpool Side Complete Backorder WPL W10755214 $35.63

W10790240 Whirlpool Side Assembly Complete Backorder WPL W10790240 $30.23

Bracket, Mounting (Right Side) WPL 4449141 Contact Us For Availability

Bracket, Mounting (Left Side) WPL 4449142 Contact Us For Availability

Bracket, Handle WPL 4450813 Contact Us For Availability

Screw WPL 4449040 Contact Us For Availability

Screw WPL 4451040 Contact Us For Availability

Spring, Latch WPL 4451537 Contact Us For Availability

Frame, Front WPL 4451739 Contact Us For Availability

15

WP4455381 Whirlpool Door Gasket In Stock WPL WP4455381 $71.22

15

Filler, Side WPL 4449083 Contact Us For Availability

15

Back, Control WPL 4452244 Contact Us For Availability

16

WPW10016550 Whirlpool Blower Cooling Fan In Stock WPL WPW10016550 $165.64

16

Cover, Top Rear WPL 4450550 Contact Us For Availability

4448664 Whirlpool Oven Mounting Bracket Backorder WPL 4448664 $10.25

Glass, Outer (Black Model) WPL 4449133 Contact Us For Availability

Glass, Outer (White Model) WPL 4449134 Contact Us For Availability

Glass, Outer (Almond Model) WPL 4449135 Contact Us For Availability

Glass, Outer (Biscuit) WPL 4452148 Contact Us For Availability

Glass, Outer (Black-Stainless) WPL 4452466 Contact Us For Availability

18

8206180 Whirlpool Microwave Screw Backorder WPL 8206180 $9.59

18

Cover, Top Front WPL 4450553 Contact Us For Availability

W11193483 Whirlpool Microwave Lamp Lens In Stock WPL W11193483 $38.25

Shield, Heat WPL 4450361 Contact Us For Availability

Support, Insulation WPL 4451477 Contact Us For Availability

Transformer, Control Panel WPL 4455038 Contact Us For Availability

20

Retainer, Glass WPL 4451668 Contact Us For Availability

20

Cap, Spacer WPL 4451605 Contact Us For Availability

20

Plate, Cover WPL 4452247 Contact Us For Availability

21

423107022541 Whirlpool Microwave Reflector Backorder WPL 423107022541 $34.44

21

WP4448444 Whirlpool Grommet Backorder WPL WP4448444 $3.18

21

Seal, Door Top WPL 4451673 Contact Us For Availability

RETAINER, GLASS CLIP (BLACK) WPL 4450863 Contact Us For Availability

RETAINER,GLASS CLIP (WHITE) WPL 4450864 Contact Us For Availability

Retainer, Glass-Clip (Almond) WPL 4450865 Contact Us For Availability

RETAINER,GLASS CLIP (BISCUIT) WPL 4452119 Contact Us For Availability

24

Bracket, Handle (Black, White, Almond, Biscui WPL 4452330 Contact Us For Availability

24

Bracket, Handle (Black Stainless Model) WPL 4450960 Contact Us For Availability

16515 Whirlpool Clip Backorder WPL 16515 $11.62

242831 Whirlpool Oven Wire Backorder WPL 242831 $249.73

261900 Whirlpool Microwave Spray Backorder WPL 261900 $27.45

285006 Whirlpool Spray In Stock WPL 285006 $28.82

350930 Whirlpool White Spray Paint In Stock WPL 350930 $13.12

4392899 Whirlpool Biscuit Touch-Up Paint In Stock WPL 4392899 $7.21

4392901 Whirlpool Biscuit Spray Paint In Stock WPL 4392901 $27.58

4450800 Whirlpool Oven Screw Backorder WPL 4450800 $9.59

4450950 Whirlpool Oven Conduit Backorder WPL 4450950 $114.99

72017 Whirlpool Appliance Touch-Up Paint Whit In Stock WPL 72017 $3.51

72032 Whirlpool Touch Up Paint Black In Stock WPL 72032 $15.46

814381 Whirlpool Pin In Stock WPL 814381 $3.70

WP261869 Whirlpool Microwave Paint Backorder WPL WP261869 $9.88

WP4375020 Whirlpool High Voltage Capacitor In Stock WPL WP4375020 $98.72

WP4448950 Whirlpool Screw Backorder WPL WP4448950 $2.51

WP482338 Whirlpool Refrigerator Adhesive In Stock WPL WP482338 $24.89

WPW10339879 Whirlpool Wire Tie In Stock WPL WPW10339879 $2.51

Wire (14 Ga. 150 c Black) WPL 242820 Contact Us For Availability

Wire (14 Ga. 150 c Blue) WPL 242821 Contact Us For Availability

Wire (14 Ga. 150 c Brown) WPL 242822 Contact Us For Availability

Wire (14 Ga. 150 c Green) WPL 242823 Contact Us For Availability

Wire (14 Ga. 150 c Orange) WPL 242824 Contact Us For Availability

Wire (14 Ga. 150 c Red) WPL 242825 Contact Us For Availability

Wire (14 Ga. 150 c White) WPL 242826 Contact Us For Availability

Wire (14 Ga. 150 c Yellow) WPL 242827 Contact Us For Availability

Wire (12 Ga. 150 c Black) WPL 242828 Contact Us For Availability

Wire (12 Ga. 150 c Red) WPL 242829 Contact Us For Availability

Wire (14 Ga. 200 c Brown) WPL 242830 Contact Us For Availability

Wire (14 Ga. 200 c Yellow) WPL 242832 Contact Us For Availability

Filler Kit (BL) WPL 4378950 Contact Us For Availability

Filler Kit (WH) WPL 4378951 Contact Us For Availability

Filler Kit (AL) WPL 4378952 Contact Us For Availability

WPL 4450831 WPL 4450831 Contact Us For Availability

WPL 4452222 WPL 4452222 Contact Us For Availability

WPL 4452239 WPL 4452239 Contact Us For Availability

WPL 4454929 WPL 4454929 Contact Us For Availability

WPL 591014 WPL 591014 Contact Us For Availability

Side, Chassis (R.H. & L.H.) WPL 4454691 Contact Us For Availability

26

Back, Chassis WPL 4452233 Contact Us For Availability

27

WP4375321 Whirlpool Microwave Fuse In Stock WPL WP4375321 $10.36

27

Liner, Oven (Not a Serviceable Part) WPL ARI86164A3 Contact Us For Availability

28

W10245194 Whirlpool Microwave Fuse Block Backorder WPL W10245194 $29.77

29

4375278 Whirlpool Microwave Primary Fan Motor Backorder WPL 4375278 $143.25

29

Sensor WPL 4451665 Contact Us For Availability

30

Thermostat WPL 4375279 Contact Us For Availability

30

BRACKET-SUPPORT WPL 4449845 Contact Us For Availability

31

WP4375079 Whirlpool Microwave Thermostat In Stock WPL WP4375079 $35.04

32

Thermostat WPL 4375281 Contact Us For Availability

33

Deflector, Vent WPL 4450280 Contact Us For Availability

34

WP4375286 Whirlpool Microwave Transformer In Stock WPL WP4375286 $159.20

34

WP4450038 Whirlpool Screw In Stock WPL WP4450038 $2.51

34

Vent, Center WPL 4451666 Contact Us For Availability

36

WP4375323 Whirlpool Microwave Door Hinge In Stock WPL WP4375323 $54.90

36

WP4375324 Whirlpool Microwave Door Hinge In Stock WPL WP4375324 $54.73

37

WP9759243 Whirlpool Thermostat In Stock WPL WP9759243 $33.45

38

WP4451008 Whirlpool Microwave Spring In Stock WPL WP4451008 $50.89

40

Inlet WPL 4375329 Contact Us For Availability

43

Base, Chassis WPL 4451397 Contact Us For Availability

46

W10727408 Whirlpool Microwave Switch In Stock WPL W10727408 $95.69

48

Cover Plate (Lower) WPL 4375338 Contact Us For Availability

49

WP4448933 Whirlpool Retainer Backorder WPL WP4448933 $2.51

49

WP4449154 Whirlpool Screw In Stock WPL WP4449154 $2.51

50

WP4449809 Whirlpool Screw In Stock WPL WP4449809 $2.64

50

WP4451747 Whirlpool Rear Cover Backorder WPL WP4451747 $51.94

50

Inner Frame WPL 4375340 Contact Us For Availability

Trim, Bottom (Screw) WPL 4159465 Contact Us For Availability

Trim, Bottom (Black) WPL 4448475 Contact Us For Availability

Trim, Bottom (White Model) WPL 4448476 Contact Us For Availability

Trim, Bottom (Almond) WPL 4448861 Contact Us For Availability

Trim, Bottom (Biscuit Model) WPL 4452414 Contact Us For Availability

52

Insulation, Wrap WPL 4449315 Contact Us For Availability

52

Insulation, Back WPL 4450364 Contact Us For Availability

52

Chassis, Back WPL 4451755 Contact Us For Availability

53

W10211972 Whirlpool Microwave Switch In Stock WPL W10211972 $32.67

57

Cable WPL 4375350 Contact Us For Availability
