Model Whirlpool KEMS377DAL6 – Common Parts &amp; Diagrams

1

WP8281236 Whirlpool Screw In Stock WPL WP8281236 $2.51

1

Cover, Top WPL 4450377 Contact Us For Availability

1

Trim, Side (Screw White) WPL 4449041 Contact Us For Availability

1

Trim, Side (RH Black) WPL 4450856 Contact Us For Availability

1

Trim, Side (RH White) WPL 4450857 Contact Us For Availability

1

Trim, Side (RH Almond) WPL 4450858 Contact Us For Availability

1

Trim, Side (LH Black) WPL 4450859 Contact Us For Availability

1

Trim, Side (LH White) WPL 4450860 Contact Us For Availability

1

Trim, Side (LH Almond) WPL 4450861 Contact Us For Availability

1

Trim, Side (RH Biscuit) WPL 4452124 Contact Us For Availability

1

Trim, Side (LH Biscuit) WPL 4452125 Contact Us For Availability

1

Bracket, Capacitor WPL 4375299 Contact Us For Availability

2

WP4449743 Whirlpool Screw Backorder WPL WP4449743 $2.51

2

WPW10207400 Whirlpool Broil Element In Stock WPL WPW10207400 $118.34

2

Baffle, Blower WPL 4448935 Contact Us For Availability

2

Screw WPL 4375313 Contact Us For Availability

3

4396923 Whirlpool Broil Pan Set Gray Porcelai In Stock WPL 4396923 $18.48

3

WP4449253 Whirlpool Glass Window In Stock WPL WP4449253 $70.88

3

WP4449745 Whirlpool Screw Backorder WPL WP4449745 $2.51

3

Microcomputer WPL 4448869 Contact Us For Availability

3

Blower WPL 4450920 Contact Us For Availability

3

Rubber Ring WPL 4375037 Contact Us For Availability

4

4448520 Whirlpool Oven Bumper Backorder WPL 4448520 $10.76

4

Insulation, Door WPL 4451721 Contact Us For Availability

4

Plate, Mounting Transformer WPL 4451789 Contact Us For Availability

4

Screw WPL 4375038 Contact Us For Availability

5

WP9760588 Whirlpool Transformer In Stock WPL WP9760588 $116.84

5

Rack, Roasting WPL 3181534 Contact Us For Availability

5

Air Duct, Magnetron WPL 4375314 Contact Us For Availability

5

Support Rails (Right Side) WPL 4450404 Contact Us For Availability

5

Support Rails (Left Side) WPL 4450405 Contact Us For Availability

6

Rack, Oven WPL 4448715 Contact Us For Availability

6

Exhaust Duct WPL 4450366 Contact Us For Availability

6

Support, Tube WPL 4375253 Contact Us For Availability

7

4451175 Whirlpool Bake Element Backorder WPL 4451175 $96.47

7

WP4449257 Whirlpool Door Glass Backorder WPL WP4449257 $91.57

7

Bracket, Duct WPL 4450027 Contact Us For Availability

7

Top, Chassis WPL 4452236 Contact Us For Availability

7

Plug, Ceramic WPL 4375254 Contact Us For Availability

8

WP112432 Whirlpool Nut Assembly Backorder WPL WP112432 $2.51

8

WP9755546 Whirlpool Locknut Backorder WPL WP9755546 $2.51

8

Grommet WPL 4449964 Contact Us For Availability

8

Bushing WPL 4375255 Contact Us For Availability

9

4454949 Whirlpool Oven Fuse Block Backorder WPL 4454949 $28.80

9

W10861715 Whirlpool Vent Tube Backorder WPL W10861715 $38.10

9

Convection Motor WPL 4451583 Contact Us For Availability

9

Glass, Middle WPL 4448937 Contact Us For Availability

9

Reflector WPL 4375256 Contact Us For Availability

WP4452226 Whirlpool Convection Fan Backorder WPL WP4452226 $26.94

WPW10017410 Whirlpool Fuse In Stock WPL WPW10017410 $6.79

Latch Assembly WPL 4451424 Contact Us For Availability

Lens, Light WPL 4452163 Contact Us For Availability

Chamber, Reflector WPL 4375257 Contact Us For Availability

4449748 Whirlpool Oven Screw Backorder WPL 4449748 $7.01

WP3387230 Whirlpool Screw In Stock WPL WP3387230 $2.51

WP4448972 Whirlpool Oven Light Backorder WPL WP4448972 $50.93

WP8203546 Whirlpool Terminal Block In Stock WPL WP8203546 $10.45

WP9755547 Whirlpool Lockwasher Backorder WPL WP9755547 $3.51

Damper WPL 4375315 Contact Us For Availability

Rear Channel WPL 4451753 Contact Us For Availability

WP4452164 Whirlpool 12V 5W Halogen Light Bulb In Stock WPL WP4452164 $35.14

Duct, Inlet WPL 4375260 Contact Us For Availability

Door Glass, Assy (Almond) WPL 4452073 Contact Us For Availability

Door Glass, Assy (Black-Stainless) WPL 4452077 Contact Us For Availability

Door Glass, Assy (Biscuit) WPL 4452146 Contact Us For Availability

Nut WPL 4452227 Contact Us For Availability

Side, Combo WPL 4450401 Contact Us For Availability

8186589 Whirlpool Jack Probe In Stock WPL 8186589 $60.42

Door Handle (Black) WPL 4448411 Contact Us For Availability

Door Handle (White) WPL 4448412 Contact Us For Availability

Door Handle (Almond) WPL 4448413 Contact Us For Availability

Door Handle (Biscuit) WPL 4452128 Contact Us For Availability

Vent, (Control Panel) WPL 4449764 Contact Us For Availability

Insulation, Switch WPL 4375316 Contact Us For Availability

W10755214 Whirlpool Side Complete Backorder WPL W10755214 $33.93

W10790240 Whirlpool Side Assembly Complete Backorder WPL W10790240 $28.79

WP9755542 Whirlpool Oven Meat Probe In Stock WPL WP9755542 $55.46

Bracket, Mounting (Right Side) WPL 4449141 Contact Us For Availability

Bracket, Mounting (Left Side) WPL 4449142 Contact Us For Availability

Bracket, Handle WPL 4450813 Contact Us For Availability

Screw WPL 4449040 Contact Us For Availability

Screw WPL 4451040 Contact Us For Availability

Frame, Front WPL 4451739 Contact Us For Availability

Fan Wheel WPL 4375322 Contact Us For Availability

WP4455381 Whirlpool Door Gasket In Stock WPL WP4455381 $67.84

Filler, Side WPL 4449083 Contact Us For Availability

Tray, Bake WPL 4448722 Contact Us For Availability

Back, Control WPL 4452244 Contact Us For Availability

Duct, Air WPL 4375317 Contact Us For Availability

16

Cover, Top Rear WPL 4450550 Contact Us For Availability

16

Block, Slide WPL 4375264 Contact Us For Availability

17

4448664 Whirlpool Oven Mounting Bracket Backorder WPL 4448664 $10.25

17

4450039 Whirlpool Oven Access Cover Backorder WPL 4450039 $28.80

17

Cover Plate, Upper WPL 4375248 Contact Us For Availability

18

8206180 Whirlpool Microwave Screw Backorder WPL 8206180 $9.59

18

Cover, Top Front WPL 4450553 Contact Us For Availability

W11193483 Whirlpool Microwave Lamp Lens In Stock WPL W11193483 $38.25

Shield, Heat WPL 4450361 Contact Us For Availability

Transformer, Control Panel WPL 4451658 Contact Us For Availability

Support, Insulation WPL 4451477 Contact Us For Availability

W10465869 Whirlpool Microwave Spring Backorder WPL W10465869 $36.67

WP9760769 Whirlpool Element Assembly In Stock WPL WP9760769 $133.70

Retainer, Glass WPL 4451668 Contact Us For Availability

Cap, Spacer WPL 4451605 Contact Us For Availability

423107022541 Whirlpool Microwave Reflector Backorder WPL 423107022541 $32.79

814375 Whirlpool Oven Rail Mount Backorder WPL 814375 $81.00

814376 Whirlpool Oven Rail Mount Backorder WPL 814376 $74.37

WP4448444 Whirlpool Grommet Backorder WPL WP4448444 $3.18

WPW10160821 Whirlpool Fan Cover Backorder WPL WPW10160821 $101.81

Seal, Door Top WPL 4451673 Contact Us For Availability

22

W10851464 Whirlpool Microwave Handle Panel In Stock WPL W10851464 $8.45

RETAINER, GLASS CLIP (BLACK) WPL 4450863 Contact Us For Availability

RETAINER,GLASS CLIP (WHITE) WPL 4450864 Contact Us For Availability

Retainer, Glass-Clip (Almond) WPL 4450865 Contact Us For Availability

RETAINER,GLASS CLIP (BISCUIT) WPL 4452119 Contact Us For Availability

Rack WPL 4375276 Contact Us For Availability

24

WPW10120480 Whirlpool Crisper Pan Backorder WPL WPW10120480 $41.30

261900 Whirlpool Microwave Spray Backorder WPL 261900 $27.45

350930 Whirlpool White Spray Paint In Stock WPL 350930 $12.50

4392899 Whirlpool Biscuit Touch-Up Paint In Stock WPL 4392899 $6.86

4392901 Whirlpool Biscuit Spray Paint In Stock WPL 4392901 $26.26

4450950 Whirlpool Oven Conduit Backorder WPL 4450950 $109.51

72017 Whirlpool Appliance Touch-Up Paint Whit In Stock WPL 72017 $3.35

72032 Whirlpool Touch Up Paint Black In Stock WPL 72032 $5.60

814381 Whirlpool Pin Backorder WPL 814381 $3.70

WP261869 Whirlpool Microwave Paint In Stock WPL WP261869 $9.88

WP4375020 Whirlpool High Voltage Capacitor In Stock WPL WP4375020 $94.01

WP482338 Whirlpool Refrigerator Adhesive In Stock WPL WP482338 $24.89

Side, Chassis (R.H. & L.H.) WPL 4454691 Contact Us For Availability

26

W10245183 Whirlpool Microwave Magnetron In Stock WPL W10245183 $135.56

26

Back, Chassis WPL 4452233 Contact Us For Availability

27

WP4375321 Whirlpool Microwave Fuse In Stock WPL WP4375321 $10.36

27

Liner, Oven (Not a Serviceable Part) WPL ARI86136A8 Contact Us For Availability

28

W10245194 Whirlpool Microwave Fuse Block Backorder WPL W10245194 $29.77

29

4375278 Whirlpool Microwave Primary Fan Motor Backorder WPL 4375278 $143.25

29

Sensor WPL 4451665 Contact Us For Availability

30

Thermostat WPL 4375279 Contact Us For Availability

30

BRACKET-SUPPORT WPL 4449845 Contact Us For Availability

31

WP4375079 Whirlpool Microwave Thermostat In Stock WPL WP4375079 $33.38

32

Thermostat WPL 4375281 Contact Us For Availability

33

Deflector, Vent WPL 4450280 Contact Us For Availability

33

Q Tube Assembly WPL 4375282 Contact Us For Availability

34

WP4375286 Whirlpool Microwave Transformer In Stock WPL WP4375286 $200.87

34

WP4450038 Whirlpool Screw Backorder WPL WP4450038 $2.51

34

WP8304106 Whirlpool Oven Vent Backorder WPL WP8304106 $86.52

35

Ring Assembly WPL 4375344 Contact Us For Availability

WP4375323 Whirlpool Microwave Door Hinge Backorder WPL WP4375323 $52.87

WP4375324 Whirlpool Microwave Door Hinge Backorder WPL WP4375324 $52.70

WP8183788 Whirlpool Microwave Turn Shaft Backorder WPL WP8183788 $17.33

Cabinet Parts WPL ARI86137A8 Contact Us For Availability

37

WP9759243 Whirlpool Thermostat In Stock WPL WP9759243 $33.45

38

WP4451008 Whirlpool Microwave Spring In Stock WPL WP4451008 $41.08

39

Bracket, Hinge (Left) WPL 4375327 Contact Us For Availability

39

Bracket, Hinge (Right) WPL 4375328 Contact Us For Availability

40

Inlet WPL 4375329 Contact Us For Availability

41

Strap, Door WPL 4375330 Contact Us For Availability

42

Grill Plate WPL 4375331 Contact Us For Availability

43

Base, Chassis WPL 4451397 Contact Us For Availability

43

Bracket, Thermostat WPL 4375332 Contact Us For Availability

44

Fan Cap WPL 4375333 Contact Us For Availability

45

Fan Cap Bottom WPL 4375334 Contact Us For Availability

46

W10727408 Whirlpool Microwave Switch In Stock WPL W10727408 $87.50

47

Isolation Plate WPL 4375337 Contact Us For Availability

48

Cover Plate (Lower) WPL 4375338 Contact Us For Availability

49

WP4448933 Whirlpool Retainer Backorder WPL WP4448933 $2.51

49

WP4449154 Whirlpool Screw Backorder WPL WP4449154 $2.51

49

Plate, Door WPL 4375339 Contact Us For Availability

50

WP4449809 Whirlpool Screw In Stock WPL WP4449809 $2.51

50

WP4451747 Whirlpool Rear Cover Backorder WPL WP4451747 $49.46

50

Inner Frame WPL 4375340 Contact Us For Availability

Trim, Bottom (Screw) WPL 4159465 Contact Us For Availability

Trim, Bottom (Black) WPL 4448475 Contact Us For Availability

Trim, Bottom (White Model) WPL 4448476 Contact Us For Availability

Trim, Bottom (Almond) WPL 4448861 Contact Us For Availability

Trim, Bottom (Biscuit Model) WPL 4452414 Contact Us For Availability

Plate, Side (Right) WPL 4375341 Contact Us For Availability

Plate, Side (Left) WPL 4375342 Contact Us For Availability

W11373838 Whirlpool Glass Tray In Stock WPL W11373838 $43.52

Insulation, Wrap WPL 4449315 Contact Us For Availability

Insulation, Back WPL 4450364 Contact Us For Availability

Chassis, Back WPL 4451755 Contact Us For Availability

53

W10211972 Whirlpool Microwave Switch In Stock WPL W10211972 $28.44

54

W10642989 Whirlpool Microwave Oven Turntable In Stock WPL W10642989 $72.24

55

WPW10440740 Whirlpool Microwave Light Bulb In Stock WPL WPW10440740 $12.94

56

WPW10687786 Whirlpool Microwave Diode In Stock WPL WPW10687786 $11.69

57

Cable WPL 4375350 Contact Us For Availability

58

Holder, Lamp WPL 4375351 Contact Us For Availability
