Model Whirlpool KEHC309JBT3 COOKTOP – Common Parts &amp; Diagrams

1

Glass, Middle WPL 4448937 Contact Us For Availability

1

Panel, Control Stainless Steel WPL 4451791 Contact Us For Availability

1

Safer Cooking Tips WPL LIT3191638 Contact Us For Availability

1

Literature Parts (Easy Set Guide) WPL LIT4449264 Contact Us For Availability

1

Literature Parts (Installation Instructions) WPL LIT4450412 Contact Us For Availability

1

Literature Parts (Chart, High Speed Cooking) WPL LIT4452967 Contact Us For Availability

1

Literature Parts (Use & Care Guide (Microwave WPL LIT4453217 Contact Us For Availability

1

Literature Parts (Use & Care Guide (Oven)) WPL LIT4453218 Contact Us For Availability

1

Literature Parts (Tech Sheet (Oven)) WPL LIT4453233 Contact Us For Availability

1

Literature Parts (Cooking Guide (Lable)) WPL LIT4453330 Contact Us For Availability

1

Panel, Control (Black) WPL 4452604 Contact Us For Availability

1

Panel, Control (White) WPL 4452605 Contact Us For Availability

1

Panel, Control (Biscuit) WPL 4452974 Contact Us For Availability

2

4455178 Whirlpool Oven Top Elbow Backorder WPL 4455178 $9.48

2

WP4449743 Whirlpool Screw Backorder WPL WP4449743 $2.51

2

WP4455526 Whirlpool Door Hinge In Stock WPL WP4455526 $49.56

2

WP8303556 Whirlpool Microwave Door Frame In Stock WPL WP8303556 $114.92

2

Switch, Membrane (Black) WPL 4453170 Contact Us For Availability

2

Switch, Membrane (White) WPL 4453172 Contact Us For Availability

2

Switch, Membrane (Stainless Steel) WPL 4453174 Contact Us For Availability

2

Switch, Membrane (Biscuit) WPL 4453176 Contact Us For Availability

3

WP4449259 Whirlpool Glass Window In Stock WPL WP4449259 $79.44

3

Rubber Ring WPL 4375252 Contact Us For Availability

3

Hinge Receiver (Right Hand) WPL 4455521 Contact Us For Availability

3

Hinge Receiver (Left Hand) WPL 4455520 Contact Us For Availability

3

Insulator, Board WPL 4452248 Contact Us For Availability

4

4448520 Whirlpool Oven Bumper Backorder WPL 4448520 $10.76

4

WP3400832 Whirlpool Screw In Stock WPL WP3400832 $2.51

4

WP4451722 Whirlpool Door Insulation Assembly Backorder WPL WP4451722 $65.32

4

Bracket, Mounting (Right Side) WPL 4449141 Contact Us For Availability

4

Bracket, Mounting (Left Side) WPL 4449142 Contact Us For Availability

4

Insulator, Board Support WPL 4452249 Contact Us For Availability

5

4455177 Whirlpool Oven Bottom Elbow Backorder WPL 4455177 $7.05

5

WP8281236 Whirlpool Screw In Stock WPL WP8281236 $2.51

5

(Trim, Side Left Hand) (Black) WPL 4455431 Contact Us For Availability

5

Filler, Side (Right Side) WPL 4449083 Contact Us For Availability

5

Filler, Side (Left Side) WPL 4449086 Contact Us For Availability

5

Support Rails (Right Side) WPL 4452551 Contact Us For Availability

5

Support Rails (Left Side) WPL 4452552 Contact Us For Availability

5

Trim, Side Right Hand (Screw) (White) WPL 4449041 Contact Us For Availability

5

Trim, Side Right Hand (Stainless Steel) WPL 4452083 Contact Us For Availability

5

(Trim, Side Left Hand) (Stainless Steel) WPL 4452084 Contact Us For Availability

5

Trim, Side Right Hand (Black) WPL 4455430 Contact Us For Availability

5

Trim, Side Right Hand (White) WPL 4455432 Contact Us For Availability

5

(Trim, Side Left Hand) (White) WPL 4455433 Contact Us For Availability

5

Trim, Side Right Hand (Biscuit) WPL 4455434 Contact Us For Availability

5

(Trim, Side Left Hand) (Biscuit) WPL 4455435 Contact Us For Availability

5

Spacer, Foam WPL 4452260 Contact Us For Availability

6

W10491987 Whirlpool Foam Seal Backorder WPL W10491987 $3.70

6

Insulator, Dialectric WPL 4452345 Contact Us For Availability

6

Handle, Door (Stainless Steel) WPL 4452088 Contact Us For Availability

6

Handle, Door (Black) WPL 4452502 Contact Us For Availability

6

Handle, Door (White) WPL 4452503 Contact Us For Availability

6

Handle, Door (Biscuit) WPL 4452871 Contact Us For Availability

7

WP4449263 Whirlpool Inner Door Glass Backorder WPL WP4449263 $80.64

7

WP4452259 Whirlpool Door Glass In Stock WPL WP4452259 $201.52

7

Microcomputer WPL 4452953 Contact Us For Availability

7

Glass, Outer (Black) WPL 4452211 Contact Us For Availability

7

Glass, Outer (White) WPL 4452789 Contact Us For Availability

7

Top, Chassis WPL 4455286 Contact Us For Availability

7

Screw WPL 3400406 Contact Us For Availability

7

Glass, Outer (Biscuit) WPL 4452995 Contact Us For Availability

8

WP112432 Whirlpool Nut Assembly Backorder WPL WP112432 $2.51

8

Insulation, Top WPL 4452492 Contact Us For Availability

9

4454949 Whirlpool Oven Fuse Block Backorder WPL 4454949 $28.80

9

W10861715 Whirlpool Vent Tube Backorder WPL W10861715 $38.10

9

W11233072 Whirlpool Screw In Stock WPL W11233072 $9.59

9

Convection Motor WPL 4451583 Contact Us For Availability

9

Bracket, Handle WPL 4452331 Contact Us For Availability

9

Baffle, Rear WPL 4450408 Contact Us For Availability

9

Screw WPL 4451040 Contact Us For Availability

WP4452226 Whirlpool Convection Fan Backorder WPL WP4452226 $26.94

Latch Assy. WPL 4451424 Contact Us For Availability

Lens, Light WPL 4452163 Contact Us For Availability

RETAINER, GLASS CLIP (BLACK) WPL 4450863 Contact Us For Availability

RETAINER,GLASS CLIP (WHITE) WPL 4450864 Contact Us For Availability

4449748 Whirlpool Oven Screw Backorder WPL 4449748 $7.01

WP4448972 Whirlpool Oven Light Backorder WPL WP4448972 $50.93

Screw WPL 3400080 Contact Us For Availability

Rear Channel WPL 4452548 Contact Us For Availability

Solenoid WPL 4451663 Contact Us For Availability

Door, Plate WPL 4375339 Contact Us For Availability

12

WP4452164 Whirlpool 12V 5W Halogen Light Bulb In Stock WPL WP4452164 $35.14

12

Microswitch N.C. WPL 4452312 Contact Us For Availability

12

Frame, Inner WPL 4375414 Contact Us For Availability

WP4450038 Whirlpool Screw Backorder WPL WP4450038 $2.51

Insulation, Grill WPL 4452491 Contact Us For Availability

Microswitch WPL 4451426 Contact Us For Availability

Strap, Door WPL 4375330 Contact Us For Availability

4455803 Whirlpool Oven Bracket Backorder WPL 4455803 $12.39

WP4450118 Whirlpool Nut Backorder WPL WP4450118 $2.51

Bracket, Handle (Left Hand) WPL 4455804 Contact Us For Availability

Screw WPL 4449040 Contact Us For Availability

Frame, Front WPL 4455612 Contact Us For Availability

Spring, Latch WPL 4451537 Contact Us For Availability

Screw WPL 4375313 Contact Us For Availability

4455191 Whirlpool Oven Mounting Plate Backorder WPL 4455191 $8.69

W11675844 Whirlpool Oven Gasket In Stock WPL W11675844 $25.44

WP4375323 Whirlpool Microwave Door Hinge Backorder WPL WP4375323 $52.87

WP4375324 Whirlpool Microwave Door Hinge Backorder WPL WP4375324 $52.70

Tray, Bake WPL 4455037 Contact Us For Availability

16515 Whirlpool Clip Backorder WPL 16515 $11.62

242831 Whirlpool Oven Wire Backorder WPL 242831 $261.62

261900 Whirlpool Microwave Spray Backorder WPL 261900 $27.45

285006 Whirlpool Spray In Stock WPL 285006 $27.45

350930 Whirlpool White Spray Paint In Stock WPL 350930 $12.50

4450800 Whirlpool Oven Screw Backorder WPL 4450800 $9.59

4450950 Whirlpool Oven Conduit Backorder WPL 4450950 $109.51

4452400 Whirlpool Microwave Wire Harness Backorder WPL 4452400 $27.03

72017 Whirlpool Appliance Touch-Up Paint Whit In Stock WPL 72017 $3.35

72032 Whirlpool Touch Up Paint Black In Stock WPL 72032 $5.60

814381 Whirlpool Pin Backorder WPL 814381 $3.70

WP261869 Whirlpool Microwave Paint In Stock WPL WP261869 $9.88

WP4448950 Whirlpool Screw Backorder WPL WP4448950 $2.51

WP4451009 Whirlpool Microwave Spring In Stock WPL WP4451009 $47.54

WP482338 Whirlpool Refrigerator Adhesive In Stock WPL WP482338 $24.89

WPW10016550 Whirlpool Blower Cooling Fan In Stock WPL WPW10016550 $150.94

WPW10339879 Whirlpool Wire Tie In Stock WPL WPW10339879 $2.51

Spacer, Foam WPL 4452490 Contact Us For Availability

Wire (14 Ga. 150 c Black) WPL 242820 Contact Us For Availability

Wire (14 Ga. 150 c Blue) WPL 242821 Contact Us For Availability

Wire (14 Ga. 150 c Brown) WPL 242822 Contact Us For Availability

Wire (14 Ga. 150 c Green) WPL 242823 Contact Us For Availability

Wire (14 Ga. 150 c Orange) WPL 242824 Contact Us For Availability

Wire (14 Ga. 150 c Red) WPL 242825 Contact Us For Availability

Wire (14 Ga. 150 c White) WPL 242826 Contact Us For Availability

Wire (14 Ga. 150 c Yellow) WPL 242827 Contact Us For Availability

Wire (12 Ga. 150 c Black) WPL 242828 Contact Us For Availability

Wire (12 Ga. 150 c Red) WPL 242829 Contact Us For Availability

Wire (14 Ga. 200 c Brown) WPL 242830 Contact Us For Availability

Wire (14 Ga. 200 c Yellow) WPL 242832 Contact Us For Availability

G WPL 4450831 Contact Us For Availability

WPL 4452222 WPL 4452222 Contact Us For Availability

WPL 4452239 WPL 4452239 Contact Us For Availability

WPL 4455744 WPL 4455744 Contact Us For Availability

WPL 591014 WPL 591014 Contact Us For Availability

17

Insulation Bottom Vent WPL 4452337 Contact Us For Availability

19

W11193483 Whirlpool Microwave Lamp Lens In Stock WPL W11193483 $38.25

19

Support, Insulation WPL 4451478 Contact Us For Availability

19

EXT Filler WPL 4449906 Contact Us For Availability

20

Retainer, Glass WPL 4451668 Contact Us For Availability

20

Cap, Spacer WPL 4451605 Contact Us For Availability

423107022541 Whirlpool Microwave Reflector Backorder WPL 423107022541 $32.79

814375 Whirlpool Oven Rail Mount Backorder WPL 814375 $81.00

814376 Whirlpool Oven Rail Mount Backorder WPL 814376 $74.37

WP4448444 Whirlpool Grommet Backorder WPL WP4448444 $3.18

Suppressor WPL 4451934 Contact Us For Availability

23

4452220 Whirlpool Microwave Rack In Stock WPL 4452220 $60.64

24

Glass, Inner WPL 4455257 Contact Us For Availability

25

W10782197 Whirlpool Side Panel Backorder WPL W10782197 $54.63

26

WP4375424 Whirlpool Microwave Magnetron In Stock WPL WP4375424 $273.49

26

WPL 4452234 WPL 4452234 Contact Us For Availability

27

WP4375321 Whirlpool Microwave Fuse In Stock WPL WP4375321 $10.36

27

WPL ARI84881A7 WPL ARI84881A7 Contact Us For Availability

28

W10245194 Whirlpool Microwave Fuse Block Backorder WPL W10245194 $29.77

29

4375278 Whirlpool Microwave Primary Fan Motor Backorder WPL 4375278 $143.25

29

WPW10131825 Whirlpool Oven Temperature Sensor In Stock WPL WPW10131825 $54.84

30

Thermostat WPL 4375279 Contact Us For Availability

30

WPL 4449845 WPL 4449845 Contact Us For Availability

31

WPL 4455510 WPL 4455510 Contact Us For Availability

32

Thermostat WPL 4375281 Contact Us For Availability

33

9760677 Whirlpool Oven Vent Deflector Backorder WPL 9760677 $61.70

34

WPL 4450289 WPL 4450289 Contact Us For Availability

34

WPL 4451667 WPL 4451667 Contact Us For Availability

37

WP9759243 Whirlpool Thermostat In Stock WPL WP9759243 $33.45

43

WPL 4455530 WPL 4455530 Contact Us For Availability

49

WP4448933 Whirlpool Retainer Backorder WPL WP4448933 $2.51

49

WP4449154 Whirlpool Screw Backorder WPL WP4449154 $2.51

50

WP4449809 Whirlpool Screw In Stock WPL WP4449809 $2.51

50

WP4451747 Whirlpool Rear Cover Backorder WPL WP4451747 $49.46

4452152 Whirlpool Oven Mounting Bracket Backorder WPL 4452152 $13.12

WPL 4455147 WPL 4455147 Contact Us For Availability

WPL 4159465 WPL 4159465 Contact Us For Availability

WPL 4455443 WPL 4455443 Contact Us For Availability

WPL 4455445 WPL 4455445 Contact Us For Availability

WPL 4455447 WPL 4455447 Contact Us For Availability

461967842541 Whirlpool Microwave Actuator Backorder WPL 461967842541 $27.87

W11684730 Whirlpool Insulation Backorder WPL W11684730 $45.31

WPL 4450365 WPL 4450365 Contact Us For Availability

WPL 4451756 WPL 4451756 Contact Us For Availability

55

Sensor, Temp. WPL 4375422 Contact Us For Availability

59

Element, Heater WPL 4375417 Contact Us For Availability

60

W11512064 Whirlpool Microwave Fan Backorder WPL W11512064 $60.85

61

Motor, Fan WPL 4375429 Contact Us For Availability

62

Left-Threaded Nut (Serviced With Motor Item 6 WPL ARI84882A9 Contact Us For Availability

63

W11607085 Whirlpool Microwave Thermostat Fix In Stock WPL W11607085 $16.05

64

Shield, Heat WPL 4375431 Contact Us For Availability

65

Insulation WPL 4375432 Contact Us For Availability

66

Chamber, Heat Cabinet WPL 4375433 Contact Us For Availability

67

Isolation Plate WPL 4375437 Contact Us For Availability

68

Cover Plate WPL 4375338 Contact Us For Availability

71

Side Plate (Left) WPL 4375341 Contact Us For Availability

71

Side Plate (Right) WPL 4375342 Contact Us For Availability

72

W11373838 Whirlpool Glass Tray In Stock WPL W11373838 $43.52

73

W10211972 Whirlpool Microwave Switch In Stock WPL W10211972 $28.44

74

W10642989 Whirlpool Microwave Oven Turntable In Stock WPL W10642989 $72.24

75

WPW10440740 Whirlpool Microwave Light Bulb In Stock WPL WPW10440740 $12.94

76

WPW10687786 Whirlpool Microwave Diode In Stock WPL WPW10687786 $11.69
