Model GE JTP45BW1BB – Common Parts & Diagrams
CONTROL PANEL
DOOR
DOOR LOCK
LOWER BODY PARTS
SPACER
UPPER BODY PARTS
Common parts from model GE JTP45BW1BB
2
GEN WB07K5286 GEN WB07K5286 Contact Us For Availability
2
VENT END CAP-LT-BLK GEN WB07K5287 Contact Us For Availability
2
CAP END FLR RT (BLK) GEN WB07K5469 Contact Us For Availability
2
CAP END FLR LT (BLK) GEN WB07K5470 Contact Us For Availability
2
END CAP-LT-BLK-CONTROL GEN WB36K5519 Contact Us For Availability
2
END CAP-RT-BLK-CONTROL GEN WB36K5520 Contact Us For Availability
8
GEN WB02K5355 GEN WB02K5355 Contact Us For Availability
11
GEN WB37K5037 GEN WB37K5037 Contact Us For Availability
11
GEN WB37K5038 GEN WB37K5038 Contact Us For Availability
103
GEN WB02K5321 GEN WB02K5321 Contact Us For Availability
106
GEN WB07K5300 GEN WB07K5300 Contact Us For Availability
112
GEN WB55K5035 GEN WB55K5035 Contact Us For Availability
113
GEN WB02K5322 GEN WB02K5322 Contact Us For Availability
119
GEN WB07K5288 GEN WB07K5288 Contact Us For Availability
121
GEN WB57K5212 GEN WB57K5212 Contact Us For Availability
127
GEN WB34K5197 GEN WB34K5197 Contact Us For Availability
132
OVEN DOOR GASKET GEN WB32K5039 Contact Us For Availability
133
FELT PAD GEN WB01K5115 Contact Us For Availability
134
GEN WB07K5299 GEN WB07K5299 Contact Us For Availability
136
GEN WB15T10030 GEN WB15T10030 Contact Us For Availability
140
GEN WB56K5129 GEN WB56K5129 Contact Us For Availability
157
GEN WB24K5125 GEN WB24K5125 Contact Us For Availability
158
GEN WB24K5127 GEN WB24K5127 Contact Us For Availability
159
SWITCH LIMIT GEN WB24K5126 Contact Us For Availability
184
GEN WB34K5200 GEN WB34K5200 Contact Us For Availability
185
GEN WB15K5075 GEN WB15K5075 Contact Us For Availability
201
GEN WB63K5171 GEN WB63K5171 Contact Us For Availability
202
GEN WB63K5172 GEN WB63K5172 Contact Us For Availability
205
SCREEN FAN HOUSING GEN WB06K5041 Contact Us For Availability
211
SIDE INSULATION RETAINER GEN WB02K5306 Contact Us For Availability
212
GEN WB02K5305 GEN WB02K5305 Contact Us For Availability
215
WIRE COVER-MIDDLE REAR GEN WB34K5224 Contact Us For Availability
217
WIRE COVER-UPR RR GEN WB34K5193 Contact Us For Availability
218
WIRE COVER-LWR RR GEN WB34K5192 Contact Us For Availability
219
GEN WB02K5307 GEN WB02K5307 Contact Us For Availability
220
SHIELD BTM TRIM GEN NCN Contact Us For Availability
227
GEN WB02K5387 GEN WB02K5387 Contact Us For Availability
230
GEN WB35K5118 GEN WB35K5118 Contact Us For Availability
231
GEN WB35K5119 GEN WB35K5119 Contact Us For Availability
246
BROILER PAN GEN WB48K5021 Contact Us For Availability
247
GEN WB48K5020 GEN WB48K5020 Contact Us For Availability
256
GEN WB08K5042 GEN WB08K5042 Contact Us For Availability
257
GEN BUY LOCAL GEN BUY LOCAL Contact Us For Availability
259
GEN WB25K5025 GEN WB25K5025 Contact Us For Availability
262
GEN WB07K5368 GEN WB07K5368 Contact Us For Availability
263
GEN WB07K5435 GEN WB07K5435 Contact Us For Availability
264
GEN WB07K5308 GEN WB07K5308 Contact Us For Availability
265
GEN WB07K5371 GEN WB07K5371 Contact Us For Availability
268
GEN WB07K5467 GEN WB07K5467 Contact Us For Availability
273
COVER HOLE GEN WB02K5365 Contact Us For Availability
279
GEN WB38K5028 GEN WB38K5028 Contact Us For Availability
281
GEN WB14K5014 GEN WB14K5014 Contact Us For Availability
291
COVER ENAM WIPE GEN WB02X9152 Contact Us For Availability
338
GEN WB56K0020 GEN WB56K0020 Contact Us For Availability
416
GEN WB34K5217 GEN WB34K5217 Contact Us For Availability
513
GEN WB26K5063 GEN WB26K5063 Contact Us For Availability
600
GEN WB18K5540 GEN WB18K5540 Contact Us For Availability
602
SCREW COUPLE CLAMP GEN WH02X0941 Contact Us For Availability
692
SCR 8-18 HXW 3/4S GEN WZ04X0416 Contact Us For Availability
832
GEN WB01X1317 GEN WB01X1317 Contact Us For Availability
862
SCREW TC6-32X.250HEXNI GEN WB01X1178 Contact Us For Availability
888
GEN WB01M0005 GEN WB01M0005 Contact Us For Availability
926
WASHER GROUND GEN WB01X1260 Contact Us For Availability
937
GEN WB01X1140 GEN WB01X1140 Contact Us For Availability
941
GEN WB01X1399 GEN WB01X1399 Contact Us For Availability
999
GEN 31-10125 GEN 31-10125 Contact Us For Availability
999
GEN 31-13266 GEN 31-13266 Contact Us For Availability
999
GEN 49-8719 GEN 49-8719 Contact Us For Availability
999
GEN WB18K5491 GEN WB18K5491 Contact Us For Availability
999
GEN WB18K5552 GEN WB18K5552 Contact Us For Availability
999
GEN WB18K5626 GEN WB18K5626 Contact Us For Availability
× ![]()
