Model GE JCK3000DF4WW Electric Range – Common Parts & Diagrams

18
OVERLAY
OVERLAY GEN WB27T11462 Contact Us For Availability
View on Model
32
COOLING FAN
COOLING FAN GEN WB26X24020 Contact Us For Availability
View on Model
102
INSULATION DR SIDE
INSULATION DR SIDE GEN WB35X21672 Contact Us For Availability
View on Model
113
RETAINER INSLN OVEN DOOR
RETAINER INSLN OVEN DOOR GEN WB34T10152 Contact Us For Availability
View on Model
133
BUMPER DOOR
BUMPER DOOR GEN WB03T10341 Contact Us For Availability
View on Model
136
HANDLE WHITE
HANDLE WHITE GEN WB15T10211 Contact Us For Availability
View on Model
144
SUPPORT HANDLE
SUPPORT HANDLE GEN WB02T10603 Contact Us For Availability
View on Model
145
DEFLECTOR OVEN DOOR 27
DEFLECTOR OVEN DOOR 27 GEN WB34T10143 Contact Us For Availability
View on Model
150
LATCH ASM
LATCH ASM GEN WB10X23814 Contact Us For Availability
View on Model
209
CHANNEL REAR LT
CHANNEL REAR LT GEN WB34X21910 Contact Us For Availability
View on Model
253
SENSOR ASM
SENSOR ASM GEN WB21X10165 Contact Us For Availability
View on Model
257
LAMP HALOGEN BULB G9
LAMP HALOGEN BULB G9 GEN WB25T10102 Contact Us For Availability
View on Model
261
LENS OVEN LIGHT
LENS OVEN LIGHT GEN WB34T10145 Contact Us For Availability
View on Model
265
TRIM VENT LOWER BLACK
TRIM VENT LOWER BLACK GEN WB07T10807 Contact Us For Availability
View on Model
268
TRIM BOTTOM CABINET WH
TRIM BOTTOM CABINET WH GEN WB07T10780 Contact Us For Availability
View on Model
277
BRACE VERTICAL RIGHT BLK
BRACE VERTICAL RIGHT BLK GEN WB07T10750 Contact Us For Availability
View on Model
277
BRACE VERTICAL LEFT BLK
BRACE VERTICAL LEFT BLK GEN WB07T10751 Contact Us For Availability
View on Model
300
HINGE BRACKET ASM KIT
HINGE BRACKET ASM KIT GEN WB49X21652 Contact Us For Availability
View on Model
338
WINDOW PACK ASM
WINDOW PACK ASM GEN WB56X27502 Contact Us For Availability
View on Model
402
COVER TOP LEFT EDGE
COVER TOP LEFT EDGE GEN WB44T10126 Contact Us For Availability
View on Model
424
COVER BOTTOM AIR DUCT
COVER BOTTOM AIR DUCT GEN WB34T10155 Contact Us For Availability
View on Model
578
SWITCH SPDT HIGH AMP
SWITCH SPDT HIGH AMP GEN WB24T10147 Contact Us For Availability
View on Model
599
BOARD FAN SENSOR
BOARD FAN SENSOR GEN WB27T11463 Contact Us For Availability
View on Model
605
HARNESS WIRE MAIN
HARNESS WIRE MAIN GEN WB18X24022 Contact Us For Availability
View on Model
801
6-19 X 1/4 TORX PAN HEAD
6-19 X 1/4 TORX PAN HEAD GEN WD02X10129 Contact Us For Availability
View on Model
936
SCREW 10-16 2 1/2 IN T20
SCREW 10-16 2 1/2 IN T20 GEN WB01T10129 Contact Us For Availability
View on Model
937
SCREW HANDLE SUPPORT
SCREW HANDLE SUPPORT GEN WB01T10135 Contact Us For Availability
View on Model
962
STANDOFF PCB
STANDOFF PCB GEN WB02T10093 Contact Us For Availability
View on Model
1005
SCREW 10-32 TR T
SCREW 10-32 TR T GEN WB01T10008 Contact Us For Availability
View on Model
