Model Whirlpool JBRFL24IGX10 REFRIGERATOR, ALL – Common Parts &amp; Diagrams

1

W11245156 Whirlpool Refrigerator Glass Shelf Backorder WPL W11245156 $230.40

1

W11245215 Whirlpool Refrigerator Cover Backorder WPL W11245215 $91.75

1

W11247667 Whirlpool Refrigerator Cover Backorder WPL W11247667 $39.18

1

ASSEMBLY, REFRIGERATOR/FREEZER DOOR WPL W10823674 Contact Us For Availability

2

W10370680 Whirlpool Refrigerator Fitting Backorder WPL W10370680 $13.10

2

W11245159 Whirlpool Refrigerator Glass Shelf Backorder WPL W11245159 $133.64

2

W11245201 Whirlpool Refrigerator Cantilever B Backorder WPL W11245201 $150.07

2

W11679634 Whirlpool Filter Cap Backorder WPL W11679634 $8.11

2

PAN, BASE WPL W10761666 Contact Us For Availability

3

EDR2RXD1 Whirlpool Everydrop® Water Filter 2 In Stock WPL EDR2RXD1 $55.44

3

W11038431 Whirlpool Refrigerator Gasket Finis Backorder WPL W11038431 $107.74

3

WPW10141625 Whirlpool Refrigerator Screw Asse Backorder WPL WPW10141625 $9.59

3

COVER, LED SIDE WPL W10816886 Contact Us For Availability

3

ASSEMBLY, UPPER CRISPER SLIDE SUPPORT WPL W10824120 Contact Us For Availability

4

W11233381 Whirlpool Module Backorder WPL W11233381 $109.58

4

W11235096 Whirlpool Refrigerator Bracket Backorder WPL W11235096 $25.27

4

ASSEMBLY, LOWER CRISPER SLIDE SUPPORT WPL W10821601 Contact Us For Availability

4

CLIP WPL 2223913 Contact Us For Availability

4

GROMMET, EVAPORATOR TRAY WPL W10886557 Contact Us For Availability

4A

W11233382 Whirlpool Module Backorder WPL W11233382 $145.76

5

W11233377 Whirlpool Refrigerator Divider Backorder WPL W11233377 $26.44

5

ASSEMBLY, EVAPORATOR AND HEATER (ALSO ORDER T WPL W11351163 Contact Us For Availability

5

ASSEMBLY, BOTTOM CRISPER PAN WPL W11022752 Contact Us For Availability

5

HARNESS, VALVE (ALSO ORDER 2300868 - 5/16" WA WPL W10831294 Contact Us For Availability

5

TUBE, SUCTION WPL W11495450 Contact Us For Availability

5A

W11504451 Whirlpool Coupler Backorder WPL W11504451 $24.87

5B

W11506619 Whirlpool Refrigerator Coupler In Stock WPL W11506619 $13.58

6

W10225833 Whirlpool Grommet Backorder WPL W10225833 $24.54

6

W11235097 Whirlpool Adapter Backorder WPL W11235097 $38.47

6

W11299812 Whirlpool Refrigerator Latch Backorder WPL W11299812 $30.96

6

ASSEMBLY, TOP CRISPER PAN WPL W10816839 Contact Us For Availability

6

TRAY, EVAPORATOR DRAIN WPL W10801047 Contact Us For Availability

6A

W11235098 Whirlpool Refrigerator Adapter Backorder WPL W11235098 $38.47

7

67006425 Whirlpool Refrigerator Screw In Stock WPL 67006425 $2.51

7

W11194438 Whirlpool Water Filter Housing In Stock WPL W11194438 $80.20

7

W11302040 Whirlpool Refrigerator Bracket Backorder WPL W11302040 $134.28

7

ASSEMBLY, DELI WPL W10816762 Contact Us For Availability

7

PLATE, BOTTOM WPL W10834246 Contact Us For Availability

8

W11302061 Whirlpool Refrigerator Trim Backorder WPL W11302061 $30.62

8

W11642201 Whirlpool Inverter Box Backorder WPL W11642201 $225.84

8

COVER, LED TOP WPL W10816890 Contact Us For Availability

8

CLIP, RETAINER (LEFT HAND) WPL W10856559 Contact Us For Availability

8

VALVE, PILOT (ALSO ORDER 2300868 - 5/16" WATE WPL W10870856 Contact Us For Availability

8A

CLIP, RETAINER (RIGHT HAND) WPL W10856558 Contact Us For Availability

9

W11245199 Whirlpool Support Bracket Backorder WPL W11245199 $141.78

9

W11299811 Whirlpool Refrigerator Door Trim Backorder WPL W11299811 $59.59

9

WPW10624574-includeCORE Whirlpool WPW10624574 Backorder WPL WPW10624574-includeCORE $196.64

9

STRIP, TOP LED WPL W10826248 Contact Us For Availability

9

TUBE, DISCHARGE WPL W11297133 Contact Us For Availability

W11234290 Whirlpool Electronic Control Board Backorder WPL W11234290 $75.33

W11234857 Whirlpool Housing Backorder WPL W11234857 $88.56

W11302041 Whirlpool Refrigerator Screw Backorder WPL W11302041 $9.59

SCREW WPL 489473 Contact Us For Availability

W11233637 Whirlpool Fan Backorder WPL W11233637 $103.19

W11234859 Whirlpool Refrigerator Wire Harness Backorder WPL W11234859 $51.86

W11235114 Whirlpool Gasket Backorder WPL W11235114 $48.71

W11380825 Whirlpool Refrigerator Power Cord Backorder WPL W11380825 $58.66

W11235115 Whirlpool Refrigerator Damper Backorder WPL W11235115 $70.37

W11690161 Whirlpool Support In Stock WPL W11690161 $18.28

WP2203075 Whirlpool Refrigerator Spacer Backorder WPL WP2203075 $6.59

TUBE, PROCESS WPL W11517921 Contact Us For Availability

W11036131 Whirlpool Bracket Backorder WPL W11036131 $50.62

W11557671 Whirlpool Refrigerator Compressor In Stock WPL W11557671 $445.05

PANEL, MULLION WPL W11024695 Contact Us For Availability

SCREW WPL W11168732 Contact Us For Availability

13A

W11504415 Whirlpool Refrigerator Coupler In Stock WPL W11504415 $13.69

13A

ASSEMBLY, AIR TOWER BRACKET (INCLUDES RUBBER WPL W11036132 Contact Us For Availability

13B

W11504421 Whirlpool Refrigerator Coupler Backorder WPL W11504421 $13.58

13C

W11504416 Whirlpool Refrigerator Coupler In Stock WPL W11504416 $14.57

W11248063 Whirlpool Mounting Kit Backorder WPL W11248063 $191.49

WALL, FALSE WPL W10816929 Contact Us For Availability

BRACKET, SUPPORT WPL W11045476 Contact Us For Availability

GROMMET WPL W10587113 Contact Us For Availability

W11233371 Whirlpool Water Tube Backorder WPL W11233371 $43.54

W11661108 Whirlpool Grommet Backorder WPL W11661108 $5.51

DUCT, DELI WPL W10816934 Contact Us For Availability

PLATE, CRISPER SUPPORT LED WPL W10902248 Contact Us For Availability

W11109499 Whirlpool Refrigerator Tube In Stock WPL W11109499 $20.17

W11235118 Whirlpool Gasket Assembly Backorder WPL W11235118 $9.85

W11247540 Whirlpool Refrigerator Housing Backorder WPL W11247540 $77.16

THERMISTOR (INCLUDES COVER) WPL W11265008 Contact Us For Availability

16B

W11504447 Whirlpool Refrigerator Coupler In Stock WPL W11504447 $23.61

17

W11247543 Whirlpool Refrigerator Filter Cover Backorder WPL W11247543 $37.70

17

ASSEMBLY, DUCT (INCLUDES DAMPER) WPL W10863616 Contact Us For Availability

17

ASSEMBLY, DRAIN TUBE WPL W10781987 Contact Us For Availability

W11233384 Whirlpool Module Assembly Backorder WPL W11233384 $70.97

W11247538 Whirlpool Screw Backorder WPL W11247538 $9.59

W11247700 Whirlpool Wire Harness Assembly Backorder WPL W11247700 $51.86

CLIP, WIRE WPL W10604160 Contact Us For Availability

HARNESS, COMPRESSOR WPL W11411189 Contact Us For Availability

W11404243-includeCORE Whirlpool W11404243 Ref Backorder WPL W11404243-includeCORE $254.34

W11645578-includeCORE Whirlpool W11645578 Ref Backorder WPL W11645578-includeCORE $188.43

SCREW WPL W10141645 Contact Us For Availability

HARNESS, MULLION WPL W10818566 Contact Us For Availability

BRACKET, INVERTER MOUNTING WPL W10663674 Contact Us For Availability

W11233378 Whirlpool Trim Assembly Backorder WPL W11233378 $93.56

W11233634 Whirlpool Condenser Backorder WPL W11233634 $108.31

W11233638-includeCORE Whirlpool W11233638 Ref Backorder WPL W11233638-includeCORE $229.25

W11245152 Whirlpool Refrigerator Grille Backorder WPL W11245152 $42.99

20A

W11504445 Whirlpool Refrigerator Coupler In Stock WPL W11504445 $15.56

20A

TRIM, CABINET SIDE (EBONY (LEFT HAND)) WPL W11111408 Contact Us For Availability

20B

W11506623 Whirlpool Refrigerator Coupler In Stock WPL W11506623 $11.51

21

W11234285 Whirlpool Electronic Control Board Backorder WPL W11234285 $78.34

21

HARNESS, HV WPL W10890822 Contact Us For Availability

22

W10848725 Whirlpool Front Grille Backorder WPL W10848725 $41.32

22

WP489069 Whirlpool Compactor Screw In Stock WPL WP489069 $2.51

22

HARNESS, LV WPL W11319311 Contact Us For Availability

22A

W10848724 Whirlpool Front Grille Backorder WPL W10848724 $42.99

23

W11247672 Whirlpool Refrigerator Water Tube Backorder WPL W11247672 $43.54

23

W11302064 Whirlpool Tray Mount Backorder WPL W11302064 $9.42

23

ASSEMBLY, AIR TOWER PANEL WPL W10816938 Contact Us For Availability

24

W11603843 Whirlpool Refrigerator Water Reserv Backorder WPL W11603843 $70.75

24

TRIM, HINGE (CHARCOAL SPARKLE) WPL W10900023 Contact Us For Availability

24

LID, COVER WPL W10822213 Contact Us For Availability

25

W11247958 Whirlpool Cover Assembly Backorder WPL W11247958 $59.80

25

W11618049 Whirlpool Back Cover Backorder WPL W11618049 $54.08

26

WP12575502 Whirlpool Refrigerator Switch Backorder WPL WP12575502 $26.90

27

W11247961 Whirlpool Refrigerator Valve Backorder WPL W11247961 $72.49

27

COVER, POWER SWITCH WPL W11415331 Contact Us For Availability

28

W11248065 Whirlpool Water Tube Backorder WPL W11248065 $43.54

28

COVER, SAFETY SWITCH WPL W11356980 Contact Us For Availability

29

LADDER, SHELF (INCLUDES SCREW GUIDE) (LEFT HA WPL W10905671 Contact Us For Availability

29A

LADDER, SHELF (INCLUDES SCREW GUIDE) (RIGHT H WPL W10905672 Contact Us For Availability

30

W11234826 Whirlpool Refrigerator Thermistor Backorder WPL W11234826 $44.05

31

W11235125 Whirlpool Cover Backorder WPL W11235125 $39.18

32

WPL W11288606 WPL W11288606 Contact Us For Availability

33

W11642296 Whirlpool Heater Backorder WPL W11642296 $37.62

34

W11553819 Whirlpool Refrigerator Insulation In Stock WPL W11553819 $9.59

35

W11579165 Whirlpool Water Tube Backorder WPL W11579165 $33.34

36

WPL W11216534 WPL W11216534 Contact Us For Availability

36A

WPL W11216533 WPL W11216533 Contact Us For Availability

37

WPL W10816924 WPL W10816924 Contact Us For Availability

37A

WPL W10887668 WPL W10887668 Contact Us For Availability

38

W11642297 Whirlpool Wire Harness Backorder WPL W11642297 $39.77

39

WPL W11441794 WPL W11441794 Contact Us For Availability

40

WPL W10895218 WPL W10895218 Contact Us For Availability

41

WPL W10780861 WPL W10780861 Contact Us For Availability

42

WPL W10895214 WPL W10895214 Contact Us For Availability

43

WPL W10816945 WPL W10816945 Contact Us For Availability

44

WPL W10876967 WPL W10876967 Contact Us For Availability

212643 Whirlpool Refrigerator Permagum Sealer In Stock WPL 212643 $27.18

8003RP Whirlpool Refrigerator 25' 1/4" Copper In Stock WPL 8003RP $21.98

833938 Whirlpool Refrigerator Terminal Backorder WPL 833938 $3.70

876370 Whirlpool Refrigerator Insulation Backorder WPL 876370 $96.00

W10756744 Whirlpool Refrigerator Touch-Up Pai Backorder WPL W10756744 $10.07

W10756745 Whirlpool Touch-Up Backorder WPL W10756745 $21.05

W11234308 Whirlpool Spacer Backorder WPL W11234308 $6.19

W11247578 Whirlpool Installation Kit Backorder WPL W11247578 $388.08

WP503695 Whirlpool Refrigerator Sealer Backorder WPL WP503695 $39.18

WP505587 Whirlpool Refrigerator Sealer Backorder WPL WP505587 $57.83

WP542638 Whirlpool Refrigerator Grease In Stock WPL WP542638 $22.07

KIT, FOAM SLAB (30" X 32 1/2" X 1 1/2") WPL 876029 Contact Us For Availability

TAPE, VINYL (3/4 X 108") WPL 479502 Contact Us For Availability

TORX SCREW WRENCH, TORX KEY WPL 1117510 Contact Us For Availability

PEDESTAL (REFER TO COLOR VARIATION PARTS PAGE WPL NP Contact Us For Availability

MISCELLANEOUS, CLEANER, STAINLESS STEEL WPL 20000008 Contact Us For Availability

CEMENT, ALUMILASTIC (1 1/4 OZ.) WPL 542639 Contact Us For Availability

JOIN KIT, HINGE - LEFT HAND / NON HINGE - RIG WPL W11103738 Contact Us For Availability

JOIN KIT, NON HINGE - LEFT HAND / HINGE - RIG WPL W11103740 Contact Us For Availability

BEZEL TRIM KIT, NON HINGE - LEFT HAND / HINGE WPL W11227384 Contact Us For Availability

BEZEL TRIM KIT, HINGE - LEFT HAND / HINGE - R WPL W11227385 Contact Us For Availability

BEZEL TRIM KIT, HINGE - LEFT HAND / NON HINGE WPL W11227386 Contact Us For Availability
