Model GE JB553GM3 Electric Range – Common Parts & Diagrams
0
1
2
3
4
Common parts from model GE JB553GM3 Electric Range
1
GEN WB36M0002 GEN WB36M0002 Contact Us For Availability
2
GEN WB07X1838 GEN WB07X1838 Contact Us For Availability
2
GEN WB07X1839 GEN WB07X1839 Contact Us For Availability
6
GEN WB36M0001 GEN WB36M0001 Contact Us For Availability
7
GEN WB06X0127 GEN WB06X0127 Contact Us For Availability
7
GEN WB06X0128 GEN WB06X0128 Contact Us For Availability
8
GEN WB02X9884 GEN WB02X9884 Contact Us For Availability
9
GEN WB02X9415 GEN WB02X9415 Contact Us For Availability
10
GEN WB06X0134 GEN WB06X0134 Contact Us For Availability
14
GEN WB02X9873 GEN WB02X9873 Contact Us For Availability
16
GEN WB19X0268 GEN WB19X0268 Contact Us For Availability
17
GEN WB25M0004 GEN WB25M0004 Contact Us For Availability
18
GEN WB02X9664 GEN WB02X9664 Contact Us For Availability
19
ELEMENT CONTROL 2000W GEN WB23K5029 Contact Us For Availability
21
GEN WB24X0479 GEN WB24X0479 Contact Us For Availability
24
GEN WB02X9874 GEN WB02X9874 Contact Us For Availability
25
GEN WB07X1790 GEN WB07X1790 Contact Us For Availability
26
GEN WB02X9756 GEN WB02X9756 Contact Us For Availability
29
GEN WB03M0002 GEN WB03M0002 Contact Us For Availability
30
GEN WB03X0770 GEN WB03X0770 Contact Us For Availability
31
GEN WB27X0609 GEN WB27X0609 Contact Us For Availability
36
GEN WB08M0002 GEN WB08M0002 Contact Us For Availability
37
GEN WB02X9390 GEN WB02X9390 Contact Us For Availability
38
GEN WB08X0291 GEN WB08X0291 Contact Us For Availability
39
BASE STARTER ASM GEN WB08X0290 Contact Us For Availability
42
GEN WB34K5092 GEN WB34K5092 Contact Us For Availability
43
PC BOARD SPACER GEN WB02X9158 Contact Us For Availability
44
GEN WB06X0125 GEN WB06X0125 Contact Us For Availability
51
GEN WB62M0008 GEN WB62M0008 Contact Us For Availability
51
GEN WB62M0009 GEN WB62M0009 Contact Us For Availability
56
GEN WB30X0261 GEN WB30X0261 Contact Us For Availability
57
GEN WB30X0260 GEN WB30X0260 Contact Us For Availability
58
7" HOB ELEMENT GEN WB30X0263 Contact Us For Availability
61
GEN WB64M0017 GEN WB64M0017 Contact Us For Availability
63
GEN WB02X9519 GEN WB02X9519 Contact Us For Availability
64
GEN WB02M0002 GEN WB02M0002 Contact Us For Availability
66
GEN WB02X9523 GEN WB02X9523 Contact Us For Availability
71
GEN WB02X9525 GEN WB02X9525 Contact Us For Availability
72
GEN WB06X0129 GEN WB06X0129 Contact Us For Availability
76
GEN WB02X9526 GEN WB02X9526 Contact Us For Availability
77
GEN WB06X0130 GEN WB06X0130 Contact Us For Availability
79
BURN BOX BTM BAFFLE-LT GEN WB34M0045 Contact Us For Availability
79
BURN BOX BTM BAFFLE-RT GEN WB34M0046 Contact Us For Availability
86
GEN WB20X0116 GEN WB20X0116 Contact Us For Availability
91
HINGE MT LT GEN WB14X0126 Contact Us For Availability
91
HINGE MT RT GEN WB14X0127 Contact Us For Availability
92
GEN WB17M0001 GEN WB17M0001 Contact Us For Availability
96
REINFORCEMENT PLATE GEN WB02X9418 Contact Us For Availability
97
GEN WB06X0131 GEN WB06X0131 Contact Us For Availability
111
GEN WB55M0010 GEN WB55M0010 Contact Us For Availability
112
GEN WB56M0001 GEN WB56M0001 Contact Us For Availability
113
OV DR INS RETAINER GEN WB02X9372 Contact Us For Availability
114
GEN WB02M0001 GEN WB02M0001 Contact Us For Availability
116
GLASS MOUNTING PLATE GEN WB02X9178 Contact Us For Availability
117
GLASS RETAINER GEN WB02X9384 Contact Us For Availability
122
INTERMEDIATE GLASS GEN WB56X1906 Contact Us For Availability
123
CENTER GLASS GEN WB56X1907 Contact Us For Availability
124
GEN WB57M0001 GEN WB57M0001 Contact Us For Availability
133
FELT WASHER GEN WB01X1159 Contact Us For Availability
136
OV DOOR HANDLE GEN WB15X0272 Contact Us For Availability
140
GEN WB56M0004 GEN WB56M0004 Contact Us For Availability
143
DOOR GLASS SPACER GEN WB02X9039 Contact Us For Availability
146
DOOR HANDLE SPACER GEN WB02X9037 Contact Us For Availability
147
FIBER WASHER GEN WB01X1138 Contact Us For Availability
151
LATCH ASM GEN WB14X0128 Contact Us For Availability
160
GEN WB02X9882 GEN WB02X9882 Contact Us For Availability
166
GEN WB24X0454 GEN WB24X0454 Contact Us For Availability
171
GEN WB02X9880 GEN WB02X9880 Contact Us For Availability
176
GEN WB02X9881 GEN WB02X9881 Contact Us For Availability
178
GEN WB35K5027 GEN WB35K5027 Contact Us For Availability
181
GEN WB02K5097 GEN WB02K5097 Contact Us For Availability
191
GEN WB02X9720 GEN WB02X9720 Contact Us For Availability
192
LOCK HANDLE GEN WB03X0782 Contact Us For Availability
193
KNOB CLIP GEN WB02X9404 Contact Us For Availability
195
LOCK SPRING GEN WB09X0251 Contact Us For Availability
201
GEN WB63M0040 GEN WB63M0040 Contact Us For Availability
202
GEN WB63X0438 GEN WB63X0438 Contact Us For Availability
203
GEN WB63M0039 GEN WB63M0039 Contact Us For Availability
204
GEN WB58X0065 GEN WB58X0065 Contact Us For Availability
211
GEN WB02M0038 GEN WB02M0038 Contact Us For Availability
212
GEN WB02K5093 GEN WB02K5093 Contact Us For Availability
216
GEN WB34M0020 GEN WB34M0020 Contact Us For Availability
217
GEN WB34K5093 GEN WB34K5093 Contact Us For Availability
221
BODY SIDE-WHITE GEN WB63X0326 Contact Us For Availability
221
BODY SIDE-ALMOND GEN WB63X0327 Contact Us For Availability
222
PANEL FRT LWR ASM GEN WB56X1969 Contact Us For Availability
226
GEN WB15X0270 GEN WB15X0270 Contact Us For Availability
231
GEN WB35M0022 GEN WB35M0022 Contact Us For Availability
232
GEN WB35K5029 GEN WB35K5029 Contact Us For Availability
233
INSULATION-TOP & SIDES GEN WB02X9430 Contact Us For Availability
241
GEN WB48X0210 GEN WB48X0210 Contact Us For Availability
256
GEN WB08M0003 GEN WB08M0003 Contact Us For Availability
257
OVEN LIGHT BULB GEN BUY LOCAL Contact Us For Availability
259
GEN WB25M0010 GEN WB25M0010 Contact Us For Availability
261
GEN WB24X0795 GEN WB24X0795 Contact Us For Availability
266
BASE ASM W/LEVELER GEN WB02X9187 Contact Us For Availability
267
GEN WB56M0003 GEN WB56M0003 Contact Us For Availability
269
RANGE SERVIVE MTG PLATE GEN WB02X9427 Contact Us For Availability
282
GEN WB38M0001 GEN WB38M0001 Contact Us For Availability
286
GEN WB09X0273 GEN WB09X0273 Contact Us For Availability
291
GEN WB02X9152 GEN WB02X9152 Contact Us For Availability
292
GEN WB02X9146 GEN WB02X9146 Contact Us For Availability
293
GEN WB02X9148 GEN WB02X9148 Contact Us For Availability
296
GEN WB02X9188 GEN WB02X9188 Contact Us For Availability
805
GEN WB01X1113 GEN WB01X1113 Contact Us For Availability
811
GEN WB01X1172 GEN WB01X1172 Contact Us For Availability
815
SCREW GEN WB01X1176 Contact Us For Availability
816
GEN WB01X1125 GEN WB01X1125 Contact Us For Availability
817
GEN WB01X1346 GEN WB01X1346 Contact Us For Availability
818
SCREW 10-32X3/4" GEN WB01X1250 Contact Us For Availability
827
GEN WB01X1395 GEN WB01X1395 Contact Us For Availability
848
GEN WB01X1394 GEN WB01X1394 Contact Us For Availability
854
GEN WB01X1328 GEN WB01X1328 Contact Us For Availability
926
WASHER GROUND GEN WB01X1260 Contact Us For Availability
928
GEN WB01X1310 GEN WB01X1310 Contact Us For Availability
936
GEN WB02X9447 GEN WB02X9447 Contact Us For Availability
950
GEN WB01M0003 GEN WB01M0003 Contact Us For Availability
951
BACKGUARD CLIP GEN WB02X9443 Contact Us For Availability
976
GEN WB01X1251 GEN WB01X1251 Contact Us For Availability
977
PW NUT "M6" GEN WB01X1305 Contact Us For Availability
979
EXPANSION NUT SPACER GEN WB01X1177 Contact Us For Availability
985
NUT M4 GEN WB01X1304 Contact Us For Availability
999
GEN 31-0926 GEN 31-0926 Contact Us For Availability
999
GEN 31-13026 GEN 31-13026 Contact Us For Availability
999
GEN 49-8148 GEN 49-8148 Contact Us For Availability
999
GEN WB06M0001 GEN WB06M0001 Contact Us For Availability
999
GEN WB18K5132 GEN WB18K5132 Contact Us For Availability
999
GEN WB18K5232 GEN WB18K5232 Contact Us For Availability
999
GEN WB18K5292 GEN WB18K5292 Contact Us For Availability
999
GEN WB18K5381 GEN WB18K5381 Contact Us For Availability
999
GEN WB18M0061 GEN WB18M0061 Contact Us For Availability
999
GEN WB18X0414 GEN WB18X0414 Contact Us For Availability
999
GEN WB18X0417 GEN WB18X0417 Contact Us For Availability
× ![]()
