Model Whirlpool GU980SCGT3 UNDERCOUNTER DISHWASHER – Common Parts &amp; Diagrams

1

350942 Whirlpool Spray Paint Backorder WPL 350942 $32.57

1

350956 Whirlpool Spray Assembly In Stock WPL 350956 $19.22

1

675679 Whirlpool Dishwasher White Tip Tines In Stock WPL 675679 $11.01

1

676458 Whirlpool Dishwasher Tine Tip Backorder WPL 676458 $15.56

1

72017 Whirlpool Appliance Touch-Up Paint Whit In Stock WPL 72017 $3.51

1

72032 Whirlpool Touch Up Paint Black In Stock WPL 72032 $15.46

1

W10840471 Whirlpool Dishwasher Touch Up In Stock WPL W10840471 $15.23

1

W10841140 Whirlpool Dishwasher Adhesive In Stock WPL W10841140 $8.16

1

WP676453 Whirlpool Dishwasher Touch-Up In Stock WPL WP676453 $15.77

1

WP676455 Whirlpool Dishwasher Touch-Up In Stock WPL WP676455 $15.43

1

WP72107 Whirlpool Touchup In Stock WPL WP72107 $5.80

1

DOOR SPRING KIT: (HEAVY DUTY) WPL 4318050 Contact Us For Availability

1

Seal, Tube WPL 9742953 Contact Us For Availability

2

Tub, Wheel Assembly (8) WPL 3380371 Contact Us For Availability

3

WP9741232 Whirlpool Dishwasher Screw In Stock WPL WP9741232 $2.51

4

WP302710 Whirlpool Dishwasher Ring Seal Backorder WPL WP302710 $4.26

4

WP3369505 Whirlpool Dishwasher Actuator Backorder WPL WP3369505 $17.06

4

WP8268816 Whirlpool Tine Row Clip In Stock WPL WP8268816 $4.27

4

Tinerow, Folding WPL 8268869 Contact Us For Availability

5

WP8052028 Whirlpool Dishwasher Dispenser Backorder WPL WP8052028 $46.99

5

WP8268523 Whirlpool Dishwasher Pivot Tine Backorder WPL WP8268523 $38.81

6

WP3379673 Whirlpool Dishwasher Seal Backorder WPL WP3379673 $4.89

6

WP8268522 Whirlpool Dishwasher Retainer Backorder WPL WP8268522 $3.70

6

Console (Includes Insert) (Black) WPL 8051710 Contact Us For Availability

6

Wheel (2) WPL 302819 Contact Us For Availability

7

WP719929 Whirlpool Dishwasher Check Ball Backorder WPL WP719929 $4.43

7

Silverware Basket Assembly WPL 8268884 Contact Us For Availability

7

Draw Bar, Electronic WPL 3369448 Contact Us For Availability

8

WP3368999 Whirlpool Dishwasher Spring In Stock WPL WP3368999 $2.51

8

WP8268843 Whirlpool Dishwasher Holder In Stock WPL WP8268843 $31.49

8

Plate, Latch WPL 3378149 Contact Us For Availability

8

Door Frame (Black) WPL 9743028 Contact Us For Availability

8

Door, Silverware Basket WPL 8519540 Contact Us For Availability

9

WP3380854 Whirlpool Door Latch Bolt In Stock WPL WP3380854 $51.51

9

Filter Assembly (Includes Items 12, 13 & 22) WPL 8519553 Contact Us For Availability

10

WP8268874 Whirlpool Dishwasher Spray Arm Backorder WPL WP8268874 $57.52

10

Lever, Latch (Black) WPL 3369457 Contact Us For Availability

10

Lever, Latch White WPL 3372231 Contact Us For Availability

11

WP3372028 Whirlpool Hinge Pin In Stock WPL WP3372028 $4.43

11

Barrier, Lower Vent WPL 8283179 Contact Us For Availability

WP3371710 Whirlpool Dishwasher Screen Backorder WPL WP3371710 $3.70

WP3376846 Whirlpool Seal In Stock WPL WP3376846 $12.16

WP8268873 Whirlpool Dishwasher Nut In Stock WPL WP8268873 $3.88

Pin, Switch (2) WPL 3368955 Contact Us For Availability

WP302711 Whirlpool Dishwasher Ring Seal In Stock WPL WP302711 $11.66

WP3378134 Whirlpool Dishwasher Cap In Stock WPL WP3378134 $3.88

WP8268840 Whirlpool Dishwasher Spray Arm Backorder WPL WP8268840 $25.91

WP9742946 Whirlpool Dishwasher Spray Arm Bear In Stock WPL WP9742946 $11.42

14

3376405 Whirlpool Dishwasher Elbow Backorder WPL 3376405 $5.33

14

8268867 Whirlpool Dishwasher Clip Backorder WPL 8268867 $30.91

14

WP717273 Whirlpool Dishwasher Rubber Washer In Stock WPL WP717273 $2.64

15

WP3400892 Whirlpool Dishwasher Screw Backorder WPL WP3400892 $2.51

15

WP8268812 Whirlpool Dishwasher Mounting Assem In Stock WPL WP8268812 $6.35

15

Clip, Silverware Basket (Right) WPL 8268868 Contact Us For Availability

16

Cover, Drip WPL 3371569 Contact Us For Availability

17

Motor, Dual WPL 3374501 Contact Us For Availability

17

Stop, Track WPL 3379941 Contact Us For Availability

18

WP3385089 Whirlpool Track In Stock WPL WP3385089 $33.27

18

WP661566 Whirlpool High Limit Thermostat In Stock WPL WP661566 $14.44

WP3379674 Whirlpool Dishwasher Vent Assembly Backorder WPL WP3379674 $42.29

WP8268807 Whirlpool Dishwasher Upper Wheel In Stock WPL WP8268807 $5.36

Panel Front (White) WPL 3379376 Contact Us For Availability

Panel Front (Black) WPL 3379375 Contact Us For Availability

Panel, Front (Biscuit) WPL 8054178 Contact Us For Availability

23

Clip, Cupshelf WPL 8268817 No Longer Available

23

Cover, Drain (Also Order Item 30) See Note A. WPL 3376845 Contact Us For Availability

24

WP8274950 Whirlpool Dishwasher Impeller Backorder WPL WP8274950 $32.72

24

Tube, Feed WPL 9743958 Contact Us For Availability

25

WP3379369 Whirlpool Dishwasher Wash Assembly In Stock WPL WP3379369 $30.25

26

WP3373234 Whirlpool Dishwasher Bearing Backorder WPL WP3373234 $4.43

28

WP3379383 Whirlpool Dishwasher Spring In Stock WPL WP3379383 $10.47

29

Housing, Float Switch WPL 3369048 Contact Us For Availability

31

Tool, Pump Centering WPL 303918 Contact Us For Availability

32

WP3376397 Whirlpool Dishwasher Float Assembly In Stock WPL WP3376397 $53.89

32

WP356138 Whirlpool Hose Clamp In Stock WPL WP356138 $3.70

33

WP3374077 Whirlpool Dishwasher Drain Hose In Stock WPL WP3374077 $50.11

33

Nut WPL 717488 Contact Us For Availability

34

3371748 Whirlpool Dishwasher Cap Backorder WPL 3371748 $4.41

35

Panel, Access (White) WPL 3384262 Contact Us For Availability

35

Panel, Access (Biscuit) WPL 3384264 Contact Us For Availability

36

WP302868 Whirlpool Screw In Stock WPL WP302868 $2.51

37

Hose, Inlet WPL 3369414 Contact Us For Availability

38

Seal, O-Rin WPL 3376723 Contact Us For Availability

39

Clip, Grounding WPL 3378123 Contact Us For Availability

40

W11086533 Whirlpool Dishwasher Shield In Stock WPL W11086533 $14.15

40

WP9740674 Whirlpool Dishwasher Gasket Backorder WPL WP9740674 $3.70

41

Terminal Box WPL 3378131 Contact Us For Availability

42

COVER ASSEMBLY TERMINAL BOX WPL 300068 Contact Us For Availability

46

Switch, Pressure WPL 3380871 Contact Us For Availability

47

Hose, Pressure Switch WPL 3380785 Contact Us For Availability

48

Clamp, Hose WPL 3380943 Contact Us For Availability

50

W10539489 Whirlpool Dishwasher Bracket-Stat Backorder WPL W10539489 $7.32

52

Damper, Tub side (6) WPL 3374773 Contact Us For Availability

53

3379740 Whirlpool Dishwasher Heater Support Backorder WPL 3379740 $33.69

54

WP3400014 Whirlpool Dishwasher Screw Backorder WPL WP3400014 $2.51

55

WP3378128 Whirlpool Dishwasher Washer Backorder WPL WP3378128 $2.51

56

Relief, Strain WPL 3370307 Contact Us For Availability

57

Screw, 8-18 WPL 3369138 Contact Us For Availability

58

WP304666 Whirlpool Dishwasher Retainer In Stock WPL WP304666 $9.37

59

Seal, Side (2) WPL 3380884 Contact Us For Availability

60

Seal, Top WPL 3380885 Contact Us For Availability

61

Friction Pad WPL 8520838 Contact Us For Availability
