Model Whirlpool GT1SHTXMQ02 REFRIGERATOR – Common Parts &amp; Diagrams

350930 Whirlpool White Spray Paint In Stock WPL 350930 $13.12

350942 Whirlpool Spray Paint Backorder WPL 350942 $32.57

4392899 Whirlpool Biscuit Touch-Up Paint In Stock WPL 4392899 $7.21

4392901 Whirlpool Biscuit Spray Paint In Stock WPL 4392901 $27.58

511873 Whirlpool Refrigerator Paint Backorder WPL 511873 $19.22

606755 Whirlpool Refrigerator Bag Backorder WPL 606755 $27.52

72017 Whirlpool Appliance Touch-Up Paint Whit In Stock WPL 72017 $3.51

72032 Whirlpool Touch Up Paint Black In Stock WPL 72032 $15.46

833938 Whirlpool Refrigerator Terminal Backorder WPL 833938 $3.70

WP503695 Whirlpool Refrigerator Sealer Backorder WPL WP503695 $41.14

WP505587 Whirlpool Refrigerator Sealer Backorder WPL WP505587 $60.73

WP542638 Whirlpool Refrigerator Grease In Stock WPL WP542638 $23.17

KIT, FOAM SLAB (30`` X 32 1/2`` X 1 1/2``) WPL 876029 Contact Us For Availability

TAPE, VINYL (3/4 X 108``) WPL 479502 Contact Us For Availability

PAINT, BULK (1 QT.) (WHITE (UNCUT)) WPL 799344 Contact Us For Availability

Torx Key WPL 1117510 Contact Us For Availability

1

WP488878 Whirlpool Refrigerator Tube Clamp Backorder WPL WP488878 $4.81

1

Housing, Dispenser WPL 2210500 Contact Us For Availability

1

Customer Instructions WPL 2225413 Contact Us For Availability

1

Modular Icemaker Service Sheet WPL 2225623 Contact Us For Availability

1

Service & Wiring Sheet WPL 2301816 Contact Us For Availability

1

Use & Care Guide WPL 2301880 Contact Us For Availability

1

Energy Label WPL 2302185 Contact Us For Availability

1

Customer Instruct Sheet, Wtr Filter WPL 2302485 Contact Us For Availability

1

DO-IT-YOURSELF MANUAL, REF./ FZR. WPL 677969 Contact Us For Availability

1

Following May Be Purchased DO-IT-YOURSELF REP WPL ARI72457A6 Contact Us For Availability

2

WP2193353W Whirlpool Refrigerator Trim Handle In Stock WPL WP2193353W $3.70

2

WP2261963 Whirlpool Refrigerator Door Hinge In Stock WPL WP2261963 $43.15

3

2163762 Whirlpool Refrigerator Cup Assembly Backorder WPL 2163762 $4.32

3

WP2166108 Whirlpool Refrigerator Cabinet Roll In Stock WPL WP2166108 $13.54

3

WP2254360 Whirlpool Refrigerator Gasket Backorder WPL WP2254360 $8.67

3

WP488921 Whirlpool Refrigerator Screw Backorder WPL WP488921 $2.51

3

WP8281146 Whirlpool Screw Backorder WPL WP8281146 $2.51

3

Condenser WPL 2214960 Contact Us For Availability

4

EDR6D1 Whirlpool EveryDrop® Ice and Water Re In Stock WPL EDR6D1 $43.40

4

Flange, Tube WPL 2210523 Contact Us For Availability

5

WP2189000 Whirlpool Refrigerator Handle Plug Backorder WPL WP2189000 $3.70

5

WP2189009 Whirlpool Refrigerator Handle Plug Backorder WPL WP2189009 $3.51

5

WP488366 Whirlpool Refrigerator Clamp Backorder WPL WP488366 $4.81

5

WP628379 Whirlpool Refrigerator Clip Backorder WPL WP628379 $4.61

5

WP939101 Whirlpool Refrigerator Plate Backorder WPL WP939101 $3.70

6

WP2162361 Whirlpool Switch In Stock WPL WP2162361 $8.80

6

WP489427 Whirlpool Refrigerator Screw Backorder WPL WP489427 $3.70

6

WP8281206 Whirlpool Refrigerator Screw Backorder WPL WP8281206 $2.51

7

WP2186494B Whirlpool Refrigerator Filter Cap In Stock WPL WP2186494B $20.14

7

WP2186494T Whirlpool Water Filter Cap In Stock WPL WP2186494T $6.15

7

WP2186494W Whirlpool Water Filter Cap Backorder WPL WP2186494W $31.24

7

WP2212648 Whirlpool Refrigerator Hinge Sleeve In Stock WPL WP2212648 $3.70

7

WP2212651 Whirlpool Refrigerator Button Plug Backorder WPL WP2212651 $10.27

7

Drain Pan WPL 2254295 Contact Us For Availability

8

WP488787 Whirlpool Refrigerator Screw Backorder WPL WP488787 $4.56

9

WP2225521 Whirlpool Water Filter Housing In Stock WPL WP2225521 $97.38

9

WP489357 Whirlpool Recessed Screw In Stock WPL WP489357 $2.51

10

W10833053 Whirlpool Refrigerator Plate Backorder WPL W10833053 $6.31

11

WP2163777 Whirlpool Refrigerator Fan Blade In Stock WPL WP2163777 $37.19

11

WP2176225 Whirlpool Glass Shelf In Stock WPL WP2176225 $126.83

11

WP3400504 Whirlpool Refrigerator Screw Backorder WPL WP3400504 $3.70

12

549193 Whirlpool Refrigerator Power Clamp Backorder WPL 549193 $6.94

12

WP2183003 Whirlpool Thimble In Stock WPL WP2183003 $3.70

W11594405 Whirlpool Axle In Stock WPL W11594405 $6.90

WP2188236 Whirlpool Refrigerator Shelf Door In Stock WPL WP2188236 $51.39

WP2188808 Whirlpool Refrigerator Inlet Valve In Stock WPL WP2188808 $101.31

Thermostat Assembly (Includes Illus. 5 & 18) WPL 2210491 Contact Us For Availability

14

W11233072 Whirlpool Screw In Stock WPL W11233072 $9.59

15

W10853646 Whirlpool Indicator Light In Stock WPL W10853646 $48.75

15

WP2225929 Whirlpool Refrigerator Start Device Backorder WPL WP2225929 $54.64

15

WP489497 Whirlpool Screw In Stock WPL WP489497 $4.58

16

WP2254618 Whirlpool Center Door Hinge In Stock WPL WP2254618 $35.16

17

WP2183854 Whirlpool Refrigerator Shim Backorder WPL WP2183854 $4.54

17

Trim, Door Shelf (2) WPL 2195947 Contact Us For Availability

18

WP489464 Whirlpool Refrigerator Screw Backorder WPL WP489464 $3.70

18

Nameplate WPL 2220214 Contact Us For Availability

19

W11384469 Whirlpool Door Switch In Stock WPL W11384469 $13.32

19

Clip, Heater WPL 2182338 Contact Us For Availability

20

WP2204812 Whirlpool Refrigerator Door Bin In Stock WPL WP2204812 $47.18

20

WP2254473 Whirlpool Refrigerator Door Hinge In Stock WPL WP2254473 $3.70

21

Cover, Air Diffuser WPL 2176281 Contact Us For Availability

21

Nut (Not Serviced) WPL ARI72462A3 Contact Us For Availability

22

WP2218118 Whirlpool Refrigerator Door Compres Backorder WPL WP2218118 $46.21

22

WP628356 Whirlpool Refrigerator Fill Cup Backorder WPL WP628356 $16.56

22

Support Block WPL 2201185 Contact Us For Availability

23

WP2201061 Whirlpool Refrigerator Door Trim In Stock WPL WP2201061 $44.74

23

WP2254354 Whirlpool Refrigerator Air Tower Backorder WPL WP2254354 $54.06

23

Cover, Water Valve WPL 2166251 Contact Us For Availability

WP2182124 Whirlpool Refrigerator Stripper Arm Backorder WPL WP2182124 $28.15

WP2189452 Whirlpool Refrigerator Diffuser Backorder WPL WP2189452 $44.74

Relay (Service Only) WPL 2183454 Contact Us For Availability

Fitting, Water Tube (Not Serviced) WPL ARI72458A2 Contact Us For Availability

WP2151652 Whirlpool Refrigerator Button Plug In Stock WPL WP2151652 $8.20

WP2183998 Whirlpool Refrigerator Button Plug Backorder WPL WP2183998 $6.68

WP627985 Whirlpool Icemaker Cycling Thermosta In Stock WPL WP627985 $44.03

Hole Plug (6) (Biscuit) WPL 2200924 Contact Us For Availability

28

2254454 Whirlpool Refrigerator Bracket Backorder WPL 2254454 $33.38

28

8533917 Whirlpool Refrigerator Screw In Stock WPL 8533917 $9.59

28

W10309988 Whirlpool Refrigerator Compressor In Stock WPL W10309988 $284.26

29

W10843121 Whirlpool Refrigerator Tube In Stock WPL W10843121 $38.32

29

BRACKET, FAN MOTOR WPL 2254453 Contact Us For Availability

30

WPW10339879 Whirlpool Wire Tie In Stock WPL WPW10339879 $2.51

31

WP627792 Whirlpool Refrigerator Shut Off Arm Backorder WPL WP627792 $37.02

32

WPW10662129 Whirlpool Refrigerator Run Capaci In Stock WPL WPW10662129 $28.24

32

Slide, Crisper WPL 2176222 Contact Us For Availability

33

W11500948 Whirlpool Refrigerator Bracket In Stock WPL W11500948 $12.32

33

WP2172890 Whirlpool Refrigerator Wire Backorder WPL WP2172890 $2.51

34

Knob, Damper WPL 2302536 Contact Us For Availability

35

W10283958 Whirlpool Refrigerator Filler Backorder WPL W10283958 $14.60

35

W11252732 Whirlpool Refrigerator Filler Backorder WPL W11252732 $7.16

35

WPW10283959 Whirlpool Refrigerator Filler In Stock WPL WPW10283959 $3.70

WP2212446 Whirlpool Refrigerator Control Body In Stock WPL WP2212446 $33.15

WP489478 Whirlpool Refrigerator Screw Backorder WPL WP489478 $2.51

Grille (Includes Illus. 39) (White) WPL 2301618W Contact Us For Availability

Grille (Includes Illus. 39) (Black) WPL 2301618B Contact Us For Availability

Grille (Includes Illus. 39) (Biscuit) WPL 2301618T Contact Us For Availability

37

WP2210509 Whirlpool Refrigerator Tub Valve Backorder WPL WP2210509 $28.80

37

WP489467 Whirlpool Hinge Shim In Stock WPL WP489467 $4.59

38

489136 Whirlpool Refrigerator Screw Backorder WPL 489136 $4.56

38

WP2156007 Whirlpool Refrigerator Endcap Trim In Stock WPL WP2156007 $3.70

38

WP487576 Whirlpool Washer In Stock WPL WP487576 $4.58

WP2156006 Whirlpool Refrigerator Shelf Trim E In Stock WPL WP2156006 $4.10

CLIP, GRILLE (2) WPL 2189356 Contact Us For Availability

Housing Base WPL 2300418 Contact Us For Availability

Air Baffle WPL 2302249 Contact Us For Availability

2213364 Whirlpool Refrigerator Cover Backorder WPL 2213364 $9.48

WP2188874 Whirlpool Refrigerator Condenser Mo In Stock WPL WP2188874 $59.32

WP2213360 Whirlpool Refrigerator Cover Backorder WPL WP2213360 $11.95

WP2213363 Whirlpool Refrigerator Cover Backorder WPL WP2213363 $11.29

WP489442 Whirlpool Refrigerator Screw Backorder WPL WP489442 $4.56

41

Rail Center (Not Serviced) WPL ARI72459A6 Contact Us For Availability

42

2187916 Whirlpool Refrigerator Wire Harness Backorder WPL 2187916 $91.12

43

W11458267 Whirlpool Refrigerator Fan Blade In Stock WPL W11458267 $7.16

43

WP2195341 Whirlpool Refrigerator Pan Trim Backorder WPL WP2195341 $28.47

44

Cover, Unit WPL 2302358 Contact Us For Availability

45

Cabinet (Not A Serviceable Part) WPL ARI72460A2 Contact Us For Availability

46

Tube, Discharge WPL 2205384 Contact Us For Availability

47

Tube, Suction WPL 2225237 Contact Us For Availability

48

2154109 Whirlpool Refrigerator Tube Backorder WPL 2154109 $35.59

57

3400518 Whirlpool Oven Foot Mount Screw Backorder WPL 3400518 $9.13

8201826 Whirlpool Refrigerator Evaporator Tra Backorder WPL 8201826 $45.05

876764 Whirlpool Refrigerator Primary Valve In Stock WPL 876764 $23.44

978026 Whirlpool Refrigerator Primary Valve In Stock WPL 978026 $33.93

978027 Whirlpool Refrigerator Primary Valve Backorder WPL 978027 $35.65

978030 Whirlpool Refrigerator Valve Backorder WPL 978030 $37.30

WP978025 Whirlpool Refrigerator Valve In Stock WPL WP978025 $27.19

VALVE, ACCESS (5/8``) WPL 978029 Contact Us For Availability

Tube, Water WPL 2301621 Contact Us For Availability

VALVE, ACCESS (1/2``) WPL 978028 Contact Us For Availability

Following Parts Not Illustrated and Optional WPL ARI72463A2 Contact Us For Availability

REFRIGERANT CHARGE 4.0 Ozs. (R134A) WPL ARI72464A9 Contact Us For Availability

100

4317943 Whirlpool Refrigerator Ice Maker Asse In Stock WPL 4317943 $89.62
