Model Whirlpool GB6526FEAW1 REFRIGERATOR – Common Parts &amp; Diagrams

1

W10251969 Whirlpool Refrigerator Ladder Backorder WPL W10251969 $11.95

1

WP2256087 Whirlpool Refrigerator Bracket Backorder WPL WP2256087 $33.29

1

LINER (NOT A SEVICEABLE PART) WPL NP Contact Us For Availability

1

Refrigerator Door (w/ Insulation) (White) WPL 12658530WQ Contact Us For Availability

1

Refrigerator Door (w/ Insulation) (Stainless) WPL 13023841SQ Contact Us For Availability

2

67006425 Whirlpool Refrigerator Screw In Stock WPL 67006425 $2.60

2

W10856123 Whirlpool Refrigerator Gasket Backorder WPL W10856123 $3.84

2

W11120581 Whirlpool Refrigerator Water Tube Backorder WPL W11120581 $50.31

2

WP12825803 Whirlpool Refrigerator Fan Blade In Stock WPL WP12825803 $40.95

3

W10273463 Whirlpool Refrigerator Ladder Backorder WPL W10273463 $11.82

3

W11448709 Whirlpool Refrigerator Bracket Backorder WPL W11448709 $12.14

3

WP67003637 Whirlpool Dairy Door Backorder WPL WP67003637 $48.32

3

BASEPAN WPL W10210832 Contact Us For Availability

4

W10001240 Whirlpool Refrigerator Screw Backorder WPL W10001240 $5.87

4

W10208592 Whirlpool Refrigerator Valve Cover Backorder WPL W10208592 $36.90

4

W10709795 Whirlpool Refrigerator Screw Backorder WPL W10709795 $8.11

4

WP67001279 Whirlpool Refrigerator Dairy Tray Backorder WPL WP67001279 $53.90

4

Cover, Light WPL 12804901 Contact Us For Availability

5

67004040 Whirlpool Refrigerator Bucket Door Backorder WPL 67004040 $59.16

5

W10157765 Whirlpool Refrigerator Deflector Backorder WPL W10157765 $33.29

5

WPW10328329 Whirlpool Crisper Pan Backorder WPL WPW10328329 $96.33

5

WPW10708492-includeCORE Whirlpool WPW10708492 Backorder WPL WPW10708492-includeCORE $216.69

5

Roller Assembly WPL 12580304 Contact Us For Availability

5

VALVE-INLET WPL W10158153 Contact Us For Availability

6

12647901S Whirlpool Refrigerator Handle Space Backorder WPL 12647901S $9.22

6

W11402521 Whirlpool Refrigerator Glass Shelf Backorder WPL W11402521 $136.66

6

W11447232 Whirlpool Refrigerator Socket In Stock WPL W11447232 $4.75

6

WP67004028 Whirlpool Refrigerator Shut-Off Ar In Stock WPL WP67004028 $36.35

7

12991101 Whirlpool Refrigerator Screw Backorder WPL 12991101 $9.96

7

WP67006878 Whirlpool Refrigerator Crisper Gla In Stock WPL WP67006878 $133.53

7

WPW10289690 Whirlpool Ice Maker Cover Backorder WPL WPW10289690 $2.74

8

W10443313 Whirlpool Door Gasket In Stock WPL W10443313 $139.14

8

WPA3223101 Whirlpool Refrigerator Insert PL Backorder WPL WPA3223101 $3.84

8

WPW10436248 Whirlpool Door Gasket In Stock WPL WPW10436248 $114.94

8

WPW10568041 Whirlpool Refrigerator Crisper Sh In Stock WPL WPW10568041 $72.04

9

12846204S Whirlpool Refrigerator Handle Backorder WPL 12846204S $267.99

9

W10656985 Whirlpool Refrigerator Trim Backorder WPL W10656985 $54.51

9

W10829281 Whirlpool Refrigerator Screw Backorder WPL W10829281 $5.21

9

WP67002552 Whirlpool Refrigerator Light Bulb In Stock WPL WP67002552 $6.65

9

MOLD & HEATER ASSEMBLY (ALSO ORDER 542638) WPL W10122523 Contact Us For Availability

9

HANDLE, DOOR (WHITE) WPL 12658751W Contact Us For Availability

W10122561 Whirlpool Refrigerator Cup Fill In Stock WPL W10122561 $10.60

W11702858 Whirlpool Housing Backorder WPL W11702858 $37.30

WP67005864 Whirlpool Humidity Control In Stock WPL WP67005864 $3.84

SCREW WPL 12992801 Contact Us For Availability

11

WP627843 Whirlpool Refrigerator Ejector Arm Backorder WPL WP627843 $33.29

11

WP67004041 Whirlpool Refrigerator Bucket In Stock WPL WP67004041 $59.93

11

Cover, Evaporator WPL 12226113 Contact Us For Availability

67004978 Whirlpool Refrigerator Black Door Bu Backorder WPL 67004978 $11.17

WP489349 Whirlpool Refrigerator Screw In Stock WPL WP489349 $2.60

WP67004977 Whirlpool Refrigerator Door Hinge Backorder WPL WP67004977 $3.84

WPW10122563 Whirlpool Refrigerator Stripper A Backorder WPL WPW10122563 $37.77

WPW10671238 Whirlpool Drawer Slide Rail In Stock WPL WPW10671238 $45.51

WP12227303WD Whirlpool Refrigerator Crisper B Backorder WPL WP12227303WD $48.93

WP12806701 Whirlpool Refrigerator Box Cover Backorder WPL WP12806701 $43.72

WP2195914 Whirlpool Refrigerator Ice Maker Ho Backorder WPL WP2195914 $42.88

RETAINER, DOOR WPL 12690502 Contact Us For Availability

W11750607 Whirlpool Insulation Backorder WPL W11750607 $21.15

WP2315522 Whirlpool Refrigerator Clip Backorder WPL WP2315522 $4.77

WP98165 Whirlpool Screw In Stock WPL WP98165 $2.60

TRIM, CRISPER WPL W10231341 Contact Us For Availability

CLIP, EVAP. MOTOR WPL 13058002 No Longer Available

W11689473 Whirlpool Door Hinge Backorder WPL W11689473 $29.07

WP12607104ED Whirlpool Refrigerator Door Hing Backorder WPL WP12607104ED $54.89

WP2321258 Whirlpool Refrigerator Bimetallic D Backorder WPL WP2321258 $39.18

WP67002633 Whirlpool Crisper Pan In Stock WPL WP67002633 $79.71

BIN, UTILITY WPL 10423131SP Contact Us For Availability

12968202W Whirlpool Refrigerator Door Stop Backorder WPL 12968202W $32.02

W10001280 Whirlpool Refrigerator Screw Backorder WPL W10001280 $5.87

W11396033 Whirlpool Refrigerator Rocker Switc In Stock WPL W11396033 $16.36

W11708403 Whirlpool Door Stop Backorder WPL W11708403 $5.26

SHELF, GLIDE (UPPER) WPL 12694605 Contact Us For Availability

17

12587703W Whirlpool Refrigerator Cover Backorder WPL 12587703W $11.17

17

WP489464 Whirlpool Refrigerator Screw Backorder WPL WP489464 $3.84

17

TRAY, EGG WPL 10436506S Contact Us For Availability

12975112 Whirlpool Wire Harness Backorder WPL 12975112 $56.55

WP12566606ED Whirlpool Refrigerator Door Hing Backorder WPL WP12566606ED $18.70

LID, UTILITY WPL 10436404S Contact Us For Availability

DIVIDER, UPPER BASKET WPL 12690802N Contact Us For Availability

19

WPM0114003 Whirlpool Microwave Speed Clip Cla Backorder WPL WPM0114003 $4.77

20

WPW10292802 Whirlpool Refrigerator Drip Tray Backorder WPL WPW10292802 $76.69

20

Basket, Freezer (Lower) WPL 12754804 Contact Us For Availability

20

Gasket, Bottom WPL 12739112 Contact Us For Availability

21

WP33001882 Whirlpool Screw Backorder WPL WP33001882 $30.29

22

12001919 Whirlpool Refrigerator Evaporator Re Backorder WPL 12001919 $214.88

22

489136 Whirlpool Refrigerator Screw Backorder WPL 489136 $4.73

22

WPW10175909 Whirlpool Grille Assembly In Stock WPL WPW10175909 $31.88

W11176463 Whirlpool Refrigerator Water Tube In Stock WPL W11176463 $48.36

WPW10167023 Whirlpool Refrigerator Shroud Backorder WPL WPW10167023 $39.43

DAM (LEFT SIDE) WPL 12225602 Contact Us For Availability

Dam (Right Side) WPL 12225702 Contact Us For Availability

24

12918001 Whirlpool Refrigerator Funnel Backorder WPL 12918001 $7.98

24

WP2169142 Whirlpool Fan Blade In Stock WPL WP2169142 $14.17

24

WPW10246191 Whirlpool Refrigerator Motor Backorder WPL WPW10246191 $151.09

25

W10121318 Whirlpool Refrigerator Grommet Backorder WPL W10121318 $31.54

25

W11673433 Whirlpool Clip Backorder WPL W11673433 $69.09

25

WP67001255 Whirlpool Ice Bucket Backorder WPL WP67001255 $94.92

26

WP67005023 Whirlpool Refrigerator Evaporator Backorder WPL WP67005023 $155.29

26

Hinge, Bottom (White) WPL 12465002WD Contact Us For Availability

26

HARNESS, UNIT WPL W10273559 Contact Us For Availability

27

12726003 Whirlpool Refrigerator Water Cover Backorder WPL 12726003 $7.43

27

W10815413 Whirlpool Refrigerator Funnel Backorder WPL W10815413 $32.00

27

WPW10143759 Whirlpool Dryer Filter In Stock WPL WPW10143759 $15.24

28

W10183407 Whirlpool Refrigerator Compressor Backorder WPL W10183407 $345.09

28

WPM0500703 Whirlpool Refrigerator O-Ring Seal Backorder WPL WPM0500703 $4.90

29

2321245 Whirlpool Refrigerator Capacitor Backorder WPL 2321245 $54.15

29

WPB8381501 Whirlpool Refrigerator Door Gasket In Stock WPL WPB8381501 $3.84

29

Insulation, Sound WPL 12820505 Contact Us For Availability

30

12002355 Whirlpool Refrigerator Thermistor Ki In Stock WPL 12002355 $27.89

30

67006434 Whirlpool Axle Pin Backorder WPL 67006434 $3.84

31

W11556315 Whirlpool Shroud Backorder WPL W11556315 $32.13

31

WP67003924 Whirlpool Refrigerator Cover Backorder WPL WP67003924 $3.84

33

B5759655 Whirlpool Refrigerator Gasket Backorder WPL B5759655 $7.98

33

WP90767 Whirlpool Screw In Stock WPL WP90767 $2.60

34

10547003 Whirlpool Refrigerator Dryer Clip Backorder WPL 10547003 $4.77

35

WP67005149 Whirlpool Roller Backorder WPL WP67005149 $11.17

36

Clip, Evap (2) WPL 10623002 Contact Us For Availability

37

WPW10137529 Whirlpool Refrigerator Grommet Backorder WPL WPW10137529 $3.84

100

WPW10190972 Whirlpool Refrigerator Icemaker Backorder WPL WPW10190972 $84.60

212643 Whirlpool Refrigerator Permagum Sealer In Stock WPL 212643 $31.41

285006 Whirlpool Spray In Stock WPL 285006 $46.08

350930 Whirlpool White Spray Paint In Stock WPL 350930 $22.23

350942 Whirlpool Spray Paint Backorder WPL 350942 $52.25

72017 Whirlpool Appliance Touch-Up Paint Whit In Stock WPL 72017 $10.93

72032 Whirlpool Touch Up Paint Black In Stock WPL 72032 $10.93

833938 Whirlpool Refrigerator Terminal Backorder WPL 833938 $3.84

876764 Whirlpool Refrigerator Primary Valve In Stock WPL 876764 $23.44

978026 Whirlpool Refrigerator Primary Valve In Stock WPL 978026 $37.34

978027 Whirlpool Refrigerator Primary Valve Backorder WPL 978027 $39.24

978030 Whirlpool Refrigerator Valve Backorder WPL 978030 $41.04

WP503695 Whirlpool Refrigerator Sealer Backorder WPL WP503695 $45.28

WP505587 Whirlpool Refrigerator Sealer Backorder WPL WP505587 $66.85

WP542638 Whirlpool Refrigerator Grease In Stock WPL WP542638 $25.50

WP978025 Whirlpool Refrigerator Valve In Stock WPL WP978025 $29.93

Valve, Access (5/8``) WPL 978029 Contact Us For Availability

TAPE, VINYL (3/4 X 108``) WPL 479502 Contact Us For Availability

PAINT, BULK (1 QT.) (WHITE UNCUT) WPL 799344 Contact Us For Availability

Torx Key WPL 1117510 Contact Us For Availability

Valve, Access (1/2``) WPL 978028 Contact Us For Availability

Cleaner, Stainless Steel WPL 4396920 Contact Us For Availability

CEMENT, ALUMILASTIC (1 1/4 OZ.) WPL 542639 Contact Us For Availability

PAINT, BULK (1 QT.) (BLACK (UNCUT)) WPL 799340 Contact Us For Availability

Kit, Evaporator Repair (Aluminum Epoxy) WPL 799833 Contact Us For Availability

Harness, Lights (Freezer) WPL 13065802 Contact Us For Availability
