Model Electrolux FGFU19F6QFD FREEZER, UPRIGHT, W/ICE MAKER – Common Parts &amp; Diagrams

1

5300083897 Frigidaire Refrigerator Condenser In Stock WCI 5300083897 $389.21

1

5304505782 Frigidaire Refrigerator Door Gaske In Stock WCI 5304505782 $123.27

2

5308000110 Frigidaire Refrigerator Evaporator In Stock WCI 5308000110 $39.44

3

216503100 Frigidaire Refrigerator Drain Scree Backorder WCI 216503100 $38.53

6

297200900 Frigidaire Refrigerator Breaker Kit Backorder WCI 297200900 $43.91

8

BUSHING, MOTOR MTG., (2) WCI 5304495760 Contact Us For Availability

9

297200100 Frigidaire Refrigerator W/Corner Br In Stock WCI 297200100 $36.75

9

297280800 Frigidaire Refrigerator Inner Door Backorder WCI 297280800 $133.94

11

297329309 Frigidaire Freezer Outer Door Panel In Stock WCI 297329309 $529.22

12

242015201 Frigidaire Nameplate In Stock WCI 242015201 $4.38

13

5304456665 Frigidaire Refrigerator Thermostat Backorder WCI 5304456665 $79.31

13

5304504914 Frigidaire Freezer Motor In Stock WCI 5304504914 $85.83

13

DOOR STOP, LH WCI 297302801 Contact Us For Availability

14

216730700 Frigidaire Refrigerator Defrost Hea In Stock WCI 216730700 $79.93

14

216822900 Frigidaire Refrigerator Switch In Stock WCI 216822900 $44.37

15

297414901 Frigidaire Refrigerator Evaporator In Stock WCI 297414901 $97.49

15

5304456667 Frigidaire Refrigerator Micro Swit Backorder WCI 5304456667 $54.68

15

5304517886 Frigidaire Refrigerator Light In Stock WCI 5304517886 $43.41

15A

297217900 Frigidaire Refrigerator Suction Tub In Stock WCI 297217900 $49.52

16

241622802 Frigidaire Refrigerator Light Socke Backorder WCI 241622802 $37.63

17

BOX-CONTROL WCI 297269000 No Longer Available

18

241930101 Frigidaire Refrigerator Stainless S In Stock WCI 241930101 $71.81

18

297078701 Frigidaire Refrigerator Evaporator Backorder WCI 297078701 $2.26

19

216204902 Frigidaire Refrigerator Evaporator Backorder WCI 216204902 $21.74

19

INSULATOR-EVAP, STYROFOAM, LH WCI 297078801 Contact Us For Availability

20

297216600 Frigidaire Refrigerator Defrost The In Stock WCI 297216600 $13.53

21A

297197500 Frigidaire Refrigerator Screw Backorder WCI 297197500 $9.04

22

216970802 Frigidaire Refrigerator/Freezer Top In Stock WCI 216970802 $6.79

24

5304456675 Frigidaire Refrigerator Lever Arm Backorder WCI 5304456675 $42.12

25

COVER-EVAPORATOR WCI 297099255 Contact Us For Availability

26

216524201 Frigidaire Refrigerator Gasket In Stock WCI 216524201 $31.69

27

5303212828 Frigidaire Refrigerator Primary Cl In Stock WCI 5303212828 $10.41

28

297302513 Frigidaire Freezer Lower Hinge Backorder WCI 297302513 $19.91

29

5304494536 Frigidaire Compressor In Stock WCI 5304494536 $510.77

29

5304510353 Frigidaire Refrigerator Hose In Stock WCI 5304510353 $8.73

30

297237702 Frigidaire Refrigerator Start Relay In Stock WCI 297237702 $62.75

31

297165800 Frigidaire Refrigerator Drain Pan Backorder WCI 297165800 $53.66

32

5304511843 Frigidaire Refrigerator Sleeve In Stock WCI 5304511843 $8.62

35

216273000 Frigidaire Refrigerator Strap Backorder WCI 216273000 $14.03

37

297273906 Frigidaire Refrigerator Corner Trim Backorder WCI 297273906 $4.51

38

HINGE-UPPER, LH WCI 297303901 Contact Us For Availability

40

COVER-HINGE, GRAY, LH WCI 297304001 Contact Us For Availability

41

240578902 Frigidaire Screw Mounting Hinge In Stock WCI 240578902 $9.04

42

297265900 Frigidaire Refrigerator Glass Shelf Backorder WCI 297265900 $94.18

45

5304455650 Frigidaire Refrigerator Screw Backorder WCI 5304455650 $9.06

47

297192903 Frigidaire Refrigerator Baffle Backorder WCI 297192903 $15.85

47A

297102705 Frigidaire Glass Cover Crisper In Stock WCI 297102705 $94.98

47B

297102704 Frigidaire Glass Crisper Cover In Stock WCI 297102704 $99.35

48

BRACKET-FAN MOTOR WCI 297436400 Contact Us For Availability

48C

297350101 Frigidaire Freezer Door Bin In Stock WCI 297350101 $80.13

49

297291700 Frigidaire Refrigerator Door Bin Backorder WCI 297291700 $58.76

49A

BIN-DOOR, GALLON, W/TRIM WCI 297295401 Contact Us For Availability

50

216394050 Frigidaire Refrigerator Bracket Backorder WCI 216394050 $13.59

51

TUBE, WATER, ICE MAKER WCI 216887500 Contact Us For Availability

55

242252603 Frigidaire Refrigerator Water Inlet In Stock WCI 242252603 $31.75

55

297286812 Frigidaire Run Capacitor Assembly In Stock WCI 297286812 $7.03

57

297269405 Frigidaire Refrigerator Overlay Backorder WCI 297269405 $39.94

59

BEARING, DOOR STOP WCI 297302900 Contact Us For Availability

59B

BASKET, ASSY-MID LEVEL WCI 297269700 Contact Us For Availability

61

241639502 Frigidaire Refrigerator Condenser F In Stock WCI 241639502 $11.41

63

216396900 Frigidaire Dryer Adjustable Levelin In Stock WCI 216396900 $14.92

64

5304455846 Frigidaire Refrigerator Clamp In Stock WCI 5304455846 $6.79

64

PLUG-BUTTON, HOLE FILLER, DOOR BASE WCI 216403701 Contact Us For Availability

65

240385201 Frigidaire Refrigerator Ice Contain In Stock WCI 240385201 $67.44

71A

SCREW, 8-18AB X.470 QX WCI 297146820 Contact Us For Availability

72

297036907 Frigidaire Refrigerator Kickplate G Backorder WCI 297036907 $23.45

79

218755401 Frigidaire Refrigerator Screw Set In Stock WCI 218755401 $14.94

80

218755504 Frigidaire Refrigerator Shoulder Sc In Stock WCI 218755504 $8.60

100

297366805 Frigidaire Refrigerator Cord Backorder WCI 297366805 $42.57

107

ACCESS COVER, MACHINE COMPT. WCI 297165400 Contact Us For Availability

130

297244700 Frigidaire Refrigerator Support Backorder WCI 297244700 $2.72

136

240405201 Frigidaire Refrigerator Grommet Backorder WCI 240405201 $12.67

137

297050600 Frigidaire Refrigerator Shelf Frame Backorder WCI 297050600 $108.14

138

TRIM-SHELF, FRONT WCI 297261400 Contact Us For Availability

139

TRIM-SHELF, REAR WCI 297261500 Contact Us For Availability

146

SHROUD-FAN ORFICE WCI 297164000 Contact Us For Availability

148

FRAME, CRISPER-COVER, BTM WCI 297271703 Contact Us For Availability

148B

297142600 Frigidaire Refrigerator/Freezer Scr Backorder WCI 297142600 $8.15

151

5304497788 Frigidaire Freezer Controller In Stock WCI 5304497788 $225.42

151A

5304495182 Frigidaire Refrigerator Jumper Har Backorder WCI 5304495182 $81.11

169

216912401 Frigidaire Refrigerator Screw Backorder WCI 216912401 $8.14

170

297280403 Frigidaire Refrigerator Valve Backorder WCI 297280403 $13.59

171

297092700 Frigidaire Refrigerator Bracket In Stock WCI 297092700 $33.06

172

297092701 Frigidaire Refrigerator Bracket In Stock WCI 297092701 $33.97

173

5304517648 Frigidaire Freezer Basket-Slide Backorder WCI 5304517648 $44.82

174

5304517649 Frigidaire Freezer Basket-Slide Backorder WCI 5304517649 $48.41

175

297099500 Frigidaire Refrigerator Support In Stock WCI 297099500 $28.07

205

HOLDER, AIR FILTER WCI 297294301 Contact Us For Availability

207

SHIELD-LIGHT, CLEAR WCI 297294500 Contact Us For Availability

216858001 Frigidaire Refrigerator Screw In Stock WCI 216858001 $6.80

216905301 Frigidaire Refrigerator Screw Backorder WCI 216905301 $9.06

218362501 Frigidaire Refrigerator Screw Backorder WCI 218362501 $7.71

240537301 Frigidaire Refrigerator Anchor Nut Backorder WCI 240537301 $7.23

240555002 Frigidaire Refrigerator Screw #8-32 In Stock WCI 240555002 $8.58

241853202 Frigidaire Refrigerator Screw Backorder WCI 241853202 $6.32

297110400 Frigidaire Refrigerator Thermistor In Stock WCI 297110400 $49.29

5304485759 Frigidaire Refrigerator Tape Backorder WCI 5304485759 $0.46

WCI 297001704 WCI 297001704 Contact Us For Availability

WCI 297305500 WCI 297305500 Contact Us For Availability

WCI 297048000 WCI 297048000 Contact Us For Availability

216337701 Frigidaire Refrigerator Screw Backorder WCI 216337701 $8.58

240561701 Frigidaire Refrigerator Seal Backorder WCI 240561701 $13.13

5304406520 Frigidaire Refrigerator Clip 40 Pa In Stock WCI 5304406520 $81.17

WCI 297164650 WCI 297164650 Contact Us For Availability

NIB

WCI 297164651 WCI 297164651 Contact Us For Availability
