Model Whirlpool 8VET20NKHW01 REFRIGERATOR – Common Parts &amp; Diagrams

2

WP2193353W Whirlpool Refrigerator Trim Handle In Stock WPL WP2193353W $3.70

2

Shelf (2) WPL 2163856 Contact Us For Availability

3

WP2166108 Whirlpool Refrigerator Cabinet Roll In Stock WPL WP2166108 $13.54

3

WP2314548 Whirlpool Refrigerator Cover Backorder WPL WP2314548 $101.54

3

WP8281206 Whirlpool Refrigerator Screw Backorder WPL WP8281206 $2.51

4

W10854037 Whirlpool Refrigerator Crisper Pan In Stock WPL W10854037 $93.60

5

2163762 Whirlpool Refrigerator Cup Assembly Backorder WPL 2163762 $4.32

6

WP2172748 Whirlpool Drawer Support Backorder WPL WP2172748 $53.36

6

WP3400504 Whirlpool Refrigerator Screw Backorder WPL WP3400504 $3.70

6

WP489357 Whirlpool Recessed Screw In Stock WPL WP489357 $2.51

6

WP941839 Whirlpool Refrigerator Button Plug In Stock WPL WP941839 $3.70

7

W11594405 Whirlpool Axle In Stock WPL W11594405 $6.90

7

WP2163835 Whirlpool Track Assembly In Stock WPL WP2163835 $11.91

8

WP2176275 Whirlpool Refrigerator Wire Shelf Backorder WPL WP2176275 $73.09

9

2159057 Whirlpool Refrigerator Fresh Food Doo In Stock WPL 2159057 $84.60

9

W10856580 Whirlpool Crisper Pan In Stock WPL W10856580 $97.55

10

WP2169921 Whirlpool Refrigerator Glass Shelf Backorder WPL WP2169921 $130.50

11

Support Block WPL 2201184 Contact Us For Availability

11

Trim, Door Shelf WPL 2195941 Contact Us For Availability

11

Shelf, Ladder (2) WPL 2210522 Contact Us For Availability

12

Shelf, Ladder WPL 2202821 Contact Us For Availability

14

WP2195943 Whirlpool Shelf Retainer Bar In Stock WPL WP2195943 $28.05

14

Meat Pan WPL 2200920K Contact Us For Availability

15

Cover, Meat Pan WPL 2163848 Contact Us For Availability

16

WP2201061 Whirlpool Refrigerator Door Trim In Stock WPL WP2201061 $44.74

16

WP489478 Whirlpool Refrigerator Screw Backorder WPL WP489478 $2.51

17

W10136387A Whirlpool Refrigerator Egg Contain In Stock WPL W10136387A $5.98

17

WP2183854 Whirlpool Refrigerator Shim Backorder WPL WP2183854 $4.54

17

WP8281146 Whirlpool Screw Backorder WPL WP8281146 $2.51

18

WP489464 Whirlpool Refrigerator Screw Backorder WPL WP489464 $3.70

18

Trim, Door WPL 2195942 Contact Us For Availability

19

W11384469 Whirlpool Door Switch In Stock WPL W11384469 $13.32

19

WP489497 Whirlpool Screw In Stock WPL WP489497 $4.58

19

Clip, Heater WPL 2182338 Contact Us For Availability

20

WP2189000 Whirlpool Refrigerator Handle Plug Backorder WPL WP2189000 $3.70

212643 Whirlpool Refrigerator Permagum Sealer In Stock WPL 212643 $28.53

2254352A Whirlpool Refrigerator Ice Container In Stock WPL 2254352A $15.66

285006 Whirlpool Spray In Stock WPL 285006 $28.82

350930 Whirlpool White Spray Paint In Stock WPL 350930 $13.12

350942 Whirlpool Spray Paint Backorder WPL 350942 $32.57

350956 Whirlpool Spray Assembly In Stock WPL 350956 $19.22

511873 Whirlpool Refrigerator Paint Backorder WPL 511873 $19.22

606755 Whirlpool Refrigerator Bag Backorder WPL 606755 $27.52

72017 Whirlpool Appliance Touch-Up Paint Whit In Stock WPL 72017 $3.51

72032 Whirlpool Touch Up Paint Black In Stock WPL 72032 $15.46

833938 Whirlpool Refrigerator Terminal Backorder WPL 833938 $3.70

876370 Whirlpool Refrigerator Insulation Backorder WPL 876370 $100.80

W11729596 Whirlpool Ice Maker Field Install K In Stock WPL W11729596 $105.37

WP503695 Whirlpool Refrigerator Sealer Backorder WPL WP503695 $41.14

WP505587 Whirlpool Refrigerator Sealer Backorder WPL WP505587 $60.73

WP542638 Whirlpool Refrigerator Grease In Stock WPL WP542638 $23.17

WP72107 Whirlpool Touchup In Stock WPL WP72107 $5.80

Cover, Air Diffuser WPL 2176281 Contact Us For Availability

KIT, FOAM SLAB (30`` X 32 1/2`` X 1 1/2``) WPL 876029 Contact Us For Availability

TAPE, VINYL (3/4 X 108``) WPL 479502 Contact Us For Availability

PAINT, BULK (1 QT.) (WHITE (UNCUT)) WPL 799344 Contact Us For Availability

Torx Key WPL 1117510 Contact Us For Availability

CEMENT, ALUMILASTIC (1 1/4 OZ.) WPL 542639 Contact Us For Availability

KIT, PORCELAIN REPAIR (WHITE) WPL 799832 Contact Us For Availability

KIT, EVAPORATOR REPAIR (ALUMINUM EPOXY) WPL 799833 Contact Us For Availability

Enamel, Almond (1 Qt. Uncut) WPL 978883 Contact Us For Availability

22

WP2183003 Whirlpool Thimble In Stock WPL WP2183003 $3.70

23

2159327 Whirlpool Refrigerator Door Gasket In Stock WPL 2159327 $82.03

23

Shim, Bottom Hinge WPL 2172743 Contact Us For Availability

23

Air Tower WPL 2182340 Contact Us For Availability

24

WP2189452 Whirlpool Refrigerator Diffuser Backorder WPL WP2189452 $44.74

24

WP2195915 Whirlpool Door Shelf Support In Stock WPL WP2195915 $6.24

27

WP488921 Whirlpool Refrigerator Screw Backorder WPL WP488921 $2.51

27

Cover, Hole WPL 2205003 Contact Us For Availability

28

876765 Whirlpool Primary Mounting Kit Refrige In Stock WPL 876765 $25.97

28

Installation Kit WPL 482801 Contact Us For Availability

29

WP2156007 Whirlpool Refrigerator Endcap Trim In Stock WPL WP2156007 $3.70

30

WP2156006 Whirlpool Refrigerator Shelf Trim E In Stock WPL WP2156006 $4.10

30

WP2254360 Whirlpool Refrigerator Gasket Backorder WPL WP2254360 $8.67

31

Shield, heat WPL 2204639 Contact Us For Availability

32

WP487996 Whirlpool Refrigerator Cap Tube Backorder WPL WP487996 $4.48

33

Clip, Defrost Timer WPL 2176341 Contact Us For Availability

34

Knob, Damper WPL 2176297 Contact Us For Availability

35

WPW10283959 Whirlpool Refrigerator Filler In Stock WPL WPW10283959 $3.70

35

Bracket, Damper Knob WPL 2163810 Contact Us For Availability

36

WP2205079 Whirlpool Refrigerator Seal Backorder WPL WP2205079 $4.14

37

CLIP, GRILLE (2) WPL 2189356 Contact Us For Availability

38

WP2210509 Whirlpool Refrigerator Tub Valve Backorder WPL WP2210509 $28.80

38

WP487576 Whirlpool Washer In Stock WPL WP487576 $4.58

39

Wire Assembly, Freezer Compartment WPL 2187301 Contact Us For Availability

43

Blade, Fan WPL 2190685 Contact Us For Availability

44

WP486692 Whirlpool Refrigerator Nut Backorder WPL WP486692 $3.70

44

Sleeve WPL 2179712 Contact Us For Availability

45

Shield WPL 2201082 Contact Us For Availability

46

Tube, Discharge WPL 2205294 Contact Us For Availability

48

W11676464 Whirlpool Tube Backorder WPL W11676464 $39.69

876764 Whirlpool Refrigerator Primary Valve In Stock WPL 876764 $23.44

978026 Whirlpool Refrigerator Primary Valve In Stock WPL 978026 $33.93

978027 Whirlpool Refrigerator Primary Valve Backorder WPL 978027 $35.65

978030 Whirlpool Refrigerator Valve Backorder WPL 978030 $37.30

WP978025 Whirlpool Refrigerator Valve In Stock WPL WP978025 $27.19

Evap. Tray WPL 2210451 Contact Us For Availability

VALVE, ACCESS (5/8``) WPL 978029 Contact Us For Availability
