Model Whirlpool 8ED2FHKXVA01 REFRIGERATOR – Common Parts &amp; Diagrams

1

LINER (NOT A SERVICEABLE PART) WPL NP Contact Us For Availability

1

Control Box WPL W10167079 Contact Us For Availability

2

2311611 Whirlpool Refrigerator Bracket Backorder WPL 2311611 $8.73

2

W10175967 Whirlpool Refrigerator Escutcheon Backorder WPL W10175967 $30.25

2

W10864399 Whirlpool Glass Shelf In Stock WPL W10864399 $123.54

2

Fan, Blade WPL 2190685 Contact Us For Availability

2

RETAINER, FAN MOTOR WPL 2155590 Contact Us For Availability

3

W10803597 Whirlpool Refrigerator Air Scoop Backorder WPL W10803597 $34.51

3

WP2256101 Whirlpool Dairy Door In Stock WPL WP2256101 $69.06

3

WP2309717 Whirlpool Refrigerator Door Trim Backorder WPL WP2309717 $36.45

3

WP3196557 Whirlpool Screw In Stock WPL WP3196557 $3.33

3

SLIDE MEAT PAN CONTROL WPL 2182757 Contact Us For Availability

4

WP2149705 Whirlpool Refrigerator Door Switch In Stock WPL WP2149705 $24.28

4

WP2309941 Whirlpool Refrigerator Door Bar Tri In Stock WPL WP2309941 $54.65

4

WP489464 Whirlpool Refrigerator Screw Backorder WPL WP489464 $4.52

4

WPW10225581 Whirlpool Refrigerator Defrost Th In Stock WPL WPW10225581 $20.33

4

WPW10250570 Whirlpool Refrigerator Cabinet Ro Backorder WPL WPW10250570 $14.49

4

Louver WPL 2257741 Contact Us For Availability

5

WP2175210 Whirlpool Refrigerator Shroud Backorder WPL WP2175210 $27.52

5

WP2196003 Whirlpool Refrigerator Bar Riser Backorder WPL WP2196003 $3.70

5

WP489491 Whirlpool Refrigerator Screw Backorder WPL WP489491 $2.51

5

WP941839 Whirlpool Refrigerator Button Plug In Stock WPL WP941839 $4.52

5

Air Duct Freezer WPL 2203592 Contact Us For Availability

6

2179350 Whirlpool Refrigerator Deflector Backorder WPL 2179350 $28.49

6

W10822278 Whirlpool Defrost Timer In Stock WPL W10822278 $18.14

6

W11239891 Whirlpool Refrigerator Light Lens Backorder WPL W11239891 $38.12

6

WP2155013 Whirlpool Refrigerator Clip In Stock WPL WP2155013 $4.52

6

WPW10339879 Whirlpool Wire Tie In Stock WPL WPW10339879 $3.33

7

4389144 Whirlpool Refrigerator Evaporator Fan In Stock WPL 4389144 $38.71

7

489392 Whirlpool Refrigerator Screw Backorder WPL 489392 $9.59

7

W10759522 Whirlpool Screw Backorder WPL W10759522 $2.51

7

WP3400012 Whirlpool Refrigerator Screw In Stock WPL WP3400012 $2.51

7

WPW10194474 Whirlpool Refrigerator Shield Backorder WPL WPW10194474 $54.79

7

ENDCAP, HANDLE WPL 2194272T Contact Us For Availability

8

2203407T Whirlpool Refrigerator Cover Backorder WPL 2203407T $13.83

8

940014 Whirlpool Refrigerator Primary Button Backorder WPL 940014 $10.25

8

WP2169142 Whirlpool Fan Blade In Stock WPL WP2169142 $27.11

8

WPW10151374 Whirlpool Refrigerator Diffuser In Stock WPL WPW10151374 $50.99

9

2152019 Whirlpool Refrigerator Cover Backorder WPL 2152019 $34.62

9

WP2176759 Whirlpool Refrigerator Grommet In Stock WPL WP2176759 $4.52

9

WP2179342 Whirlpool Refrigerator Slide Backorder WPL WP2179342 $10.08

9

WP2198202 Whirlpool Refrigerator Temperature In Stock WPL WP2198202 $46.16

9

Shim WPL 2209697 Contact Us For Availability

9

Handle, Center (White) WPL 2186649W Contact Us For Availability

10

W10252495 Whirlpool Refrigerator Wire Cover Backorder WPL W10252495 $28.82

10

W11234406 Whirlpool Refrigerator Wire Harness Backorder WPL W11234406 $60.47

10

WP965173 Whirlpool Dishwasher Screw Backorder WPL WP965173 $2.64

WP2155789 Whirlpool Refrigerator Gasket Backorder WPL WP2155789 $3.70

WP2182195 Whirlpool Refrigerator Cam Backorder WPL WP2182195 $5.14

WP2203771 Whirlpool Refrigerator Door Hinge In Stock WPL WP2203771 $34.57

WP2309758 Whirlpool Refrigerator Freezer Bin Backorder WPL WP2309758 $58.93

WP489427 Whirlpool Refrigerator Screw Backorder WPL WP489427 $3.70

12

1110560 Whirlpool Refrigerator Bearing Backorder WPL 1110560 $4.72

12

4388500 Whirlpool Refrigerator Gasket Backorder WPL 4388500 $28.09

12

WP2203770 Whirlpool Refrigerator Door Hinge Backorder WPL WP2203770 $31.66

13

WP2196062 Whirlpool Refrigerator Clip Backorder WPL WP2196062 $4.59

13

WP8281227 Whirlpool Screw In Stock WPL WP8281227 $4.58

13

BRACKET, DOOR STOP WPL W10185570 Contact Us For Availability

4389654 Whirlpool Screw Backorder WPL 4389654 $9.59

WP2179343 Whirlpool Refrigerator Control Body Backorder WPL WP2179343 $13.98

Nameplate WPL 2220214 Contact Us For Availability

Clip, Defrost Heater WPL 2161324 Contact Us For Availability

Pivot Arm WPL 1110559 Contact Us For Availability

627068 Whirlpool Refrigerator Screw Backorder WPL 627068 $7.52

W11384469 Whirlpool Door Switch In Stock WPL W11384469 $14.06

WP2188831 Whirlpool Refrigerator Start Device In Stock WPL WP2188831 $64.15

WP489478 Whirlpool Refrigerator Screw Backorder WPL WP489478 $2.51

4387478 Whirlpool Refrigerator Light Socket In Stock WPL 4387478 $33.16

4388358 Whirlpool Refrigerator Support Bracke Backorder WPL 4388358 $12.65

WP2196483 Whirlpool Refrigerator Shelf Stud In Stock WPL WP2196483 $4.34

WPW10170540 Whirlpool Screw In Stock WPL WPW10170540 $5.40

Screw WPL W10191952 Contact Us For Availability

17

8009 Whirlpool 40W 120V Light Bulb In Stock WPL 8009 $7.63

489203 Whirlpool Refrigerator Washer Backorder WPL 489203 $4.36

W11366418 Whirlpool Screw In Stock WPL W11366418 $10.41

W11544659 Whirlpool Refrigerator Screw Backorder WPL W11544659 $9.59

WPW10130299 Whirlpool Refrigerator Cup In Stock WPL WPW10130299 $9.50

19

2311636 Whirlpool Refrigerator Wire Harness Backorder WPL 2311636 $130.51

19

W11566763 Whirlpool Fitting In Stock WPL W11566763 $20.64

20

W11512417 Whirlpool Drain Connector In Stock WPL W11512417 $13.85

20

WP1115374 Whirlpool Refrigerator Clip Backorder WPL WP1115374 $2.51

21

489396 Whirlpool Refrigerator Clip Backorder WPL 489396 $4.72

21

CLIP, WIRING WPL 1115375 Contact Us For Availability

22

2311631 Whirlpool Refrigerator Rod Backorder WPL 2311631 $9.81

22

WP2188822 Whirlpool Refrigerator Evaporator In Stock WPL WP2188822 $195.78

23

Fastener, Push-On WPL 489285 Contact Us For Availability

24

489348 Whirlpool Refrigerator Tube Clamp Backorder WPL 489348 $5.38

24

W10723843 Whirlpool Refrigerator Thermostat K Backorder WPL W10723843 $11.14

25

2311615 Whirlpool Refrigerator Knob In Stock WPL 2311615 $32.26

27

WP489483 Whirlpool Screw In Stock WPL WP489483 $5.40

27

WPW10143759 Whirlpool Dryer Filter In Stock WPL WPW10143759 $15.50

30

WP2181929 Whirlpool Refrigerator Bracket Backorder WPL WP2181929 $5.67

36

Air Baffle WPL W10163483 Contact Us For Availability

212643 Whirlpool Refrigerator Permagum Sealer In Stock WPL 212643 $29.35

350930 Whirlpool White Spray Paint In Stock WPL 350930 $13.94

350942 Whirlpool Spray Paint Backorder WPL 350942 $32.57

4392899 Whirlpool Biscuit Touch-Up Paint In Stock WPL 4392899 $8.03

4392901 Whirlpool Biscuit Spray Paint In Stock WPL 4392901 $28.40

511873 Whirlpool Refrigerator Paint Backorder WPL 511873 $19.22

606755 Whirlpool Refrigerator Bag Backorder WPL 606755 $27.52

72017 Whirlpool Appliance Touch-Up Paint Whit In Stock WPL 72017 $4.25

72032 Whirlpool Touch Up Paint Black In Stock WPL 72032 $15.46

833938 Whirlpool Refrigerator Terminal Backorder WPL 833938 $3.70

876764 Whirlpool Refrigerator Primary Valve In Stock WPL 876764 $23.44

978026 Whirlpool Refrigerator Primary Valve In Stock WPL 978026 $34.75

978027 Whirlpool Refrigerator Primary Valve Backorder WPL 978027 $35.65

978030 Whirlpool Refrigerator Valve Backorder WPL 978030 $37.30

WP503695 Whirlpool Refrigerator Sealer Backorder WPL WP503695 $41.14

WP505587 Whirlpool Refrigerator Sealer Backorder WPL WP505587 $60.73

WP542638 Whirlpool Refrigerator Grease In Stock WPL WP542638 $23.99

WP978025 Whirlpool Refrigerator Valve In Stock WPL WP978025 $28.02

VALVE, ACCESS (5/8``) WPL 978029 Contact Us For Availability

KIT, FOAM SLAB (30`` X 32 1/2`` X 1 1/2``) WPL 876029 Contact Us For Availability

TAPE, VINYL (3/4 X 108``) WPL 479502 Contact Us For Availability

REFINISHING MATERIAL (ENAMEL, WHITE (1 QT. UN WPL 799344 Contact Us For Availability

Torx Key WPL 1117510 Contact Us For Availability
