Model Whirlpool 5KSM156EFP4 5 QT. STAND MIXER - EUROPE AND BRITAIN ARTISAN - T – Common Parts &amp; Diagrams

1

HOUSING Backorder WPL W10477204 $69.76

1

WP110679 Whirlpool Screw Backorder WPL WP110679 $2.91

1

MOTOR HOUSING (ELECTRIC BLUE) WPL W10342527 Contact Us For Availability

1

MOTOR HOUSING (BLACK STORM) WPL W10382712 Contact Us For Availability

2

W11188411 Whirlpool Trim Band Backorder WPL W11188411 $13.73

2

WP116241 Whirlpool Washer Backorder WPL WP116241 $2.91

2

TRIM BAND (WEDDING EDITION) WPL W10474765 Contact Us For Availability

3

W10342506 Whirlpool Cover Assembly Backorder WPL W10342506 $33.38

3

COVER Backorder WPL W10382849 $33.38

3

W10477198 Whirlpool Cover Assembly Backorder WPL W10477198 $33.38

3

WP9709194 Whirlpool Black Thumb Screw In Stock WPL WP9709194 $12.61

3

WP9709276 Whirlpool Speed Control Lever In Stock WPL WP9709276 $3.50

3

WPW10239110 Whirlpool Cover Backorder WPL WPW10239110 $19.34

4

W10239112 Whirlpool Planetary Mixer Backorder WPL W10239112 $31.48

4

PLANETARY Backorder WPL W10382847 $31.48

4

WP3183680 Whirlpool Spring Backorder WPL WP3183680 $3.06

4

PLANETARY (ELECTRIC BLUE) WPL W10342513 Contact Us For Availability

4

PLANETARY (FROSTED PEARL) WPL W10477206 Contact Us For Availability

5

W10245786 Whirlpool Gearcase Backorder WPL W10245786 $43.92

5

GEARCASE Backorder WPL W10382395 $45.16

5

GEARCASE Backorder WPL W10477200 $45.16

5

WP9704324 Whirlpool Washer In Stock WPL WP9704324 $2.91

5

LOWER GEARCASE (ELECTRIC BLUE) WPL W10342533 Contact Us For Availability

6

PEDESTL Backorder WPL W10381782 $64.94

6

PEDESTL Backorder WPL W10477199 $64.94

6

W10900799 Whirlpool Armature Backorder WPL W10900799 $51.40

6

WPW10112253 Whirlpool Gear Assembly In Stock WPL WPW10112253 $8.38

6

WPW10191926 Whirlpool Cap Screw In Stock WPL WPW10191926 $11.42

6

PEDESTAL W/FEET & HEADLOCK (CANDY APPLE) WPL W10245720 Contact Us For Availability

6

PEDESTAL W/FEET & HEADLOCK (BLACK STORM) WPL W10382325 Contact Us For Availability

7

W11082541 Whirlpool Bearing In Stock WPL W11082541 $8.84

7

W11233557 Whirlpool Washer Backorder WPL W11233557 $2.43

7

WP9709707 Whirlpool Foot In Stock WPL WP9709707 $2.91

8

WP16998 Whirlpool Drive Stud Backorder WPL WP16998 $2.91

8

WP9704329 Whirlpool Wire Whip In Stock WPL WP9704329 $18.85

8

WP9705444 Whirlpool Pin Groove In Stock WPL WP9705444 $3.06

9

WP3180526 Whirlpool Bearing Bracket In Stock WPL WP3180526 $13.12

10

W11192794 Whirlpool HUB Gear In Stock WPL W11192794 $30.38

10

WP240775-1 Whirlpool Endcap Seal In Stock WPL WP240775-1 $3.06

11

WPW10131078 Whirlpool Nut Assembly Backorder WPL WPW10131078 $2.91

12

Washer, Felt WPL 3180238 Contact Us For Availability

13

W10851015 Whirlpool Stat Screw Backorder WPL W10851015 $2.91

14

W11170663 Whirlpool Washer Backorder WPL W11170663 $2.91

14

W11218705 Whirlpool Washer Assembly Backorder WPL W11218705 $2.91

14

WP9705443 Whirlpool Pin Groove Backorder WPL WP9705443 $3.06

15

103993 Whirlpool Screw Backorder WPL 103993 $17.77

15

GASKET Backorder WPL W11805888 $0.00

15

Speed Link & Cam WPL 3184176 Contact Us For Availability

16

W11232016 Whirlpool Latch Link Backorder WPL W11232016 $2.43

16

WP240205 Whirlpool Spring In Stock WPL WP240205 $2.91

17

WP9709267 Whirlpool Latch Lever Backorder WPL WP9709267 $2.91

17

WPW10417246 Whirlpool Field Assembly Backorder WPL WPW10417246 $34.70

18

W11210996 Whirlpool Sleeve Backorder WPL W11210996 $2.91

18

WP16910 Whirlpool Dowel Pin In Stock WPL WP16910 $2.91

19

WPW10380496 Whirlpool Stand Mixer Motor Brush In Stock WPL WPW10380496 $3.93

19

PEDESTAL WPL NP Contact Us For Availability

20

W11176201 Whirlpool Screw Backorder WPL W11176201 $2.91

20

WP3184264 Whirlpool Headlock Assembly Backorder WPL WP3184264 $5.05

21

4162546 Whirlpool Brush Holder In Stock WPL 4162546 $15.46

21

W11188450 Whirlpool Spring Backorder WPL W11188450 $2.91

21

WP9703438 Whirlpool Snap Retaining Ring In Stock WPL WP9703438 $2.05

22

WP3179908 Whirlpool Brush Holder Backorder WPL WP3179908 $3.06

23

W11656718 Whirlpool Insert In Stock WPL W11656718 $3.59

24

WP116286 Whirlpool Spring Cap Backorder WPL WP116286 $2.91

25

WP116287 Whirlpool Spring Cap Backorder WPL WP116287 $2.91

26

WP3184211 Whirlpool Brush Cap Backorder WPL WP3184211 $2.91

26

WP3184212 Whirlpool Stand Mixer Black Brush H Backorder WPL WP3184212 $3.06

27

W11084238 Whirlpool Screw Assembly Backorder WPL W11084238 $2.91

28

4160474 Whirlpool Control Shaft Backorder WPL 4160474 $18.94

28

WPW10119326 Whirlpool Speed Control In Stock WPL WPW10119326 $10.94

29

WPW10330804 Whirlpool Speed Governor In Stock WPL WPW10330804 $9.70

30

W11174552 Whirlpool Stand Mixer Phase Board In Stock WPL W11174552 $11.49

30

WP3400025 Whirlpool Screw Backorder WPL WP3400025 $2.91

W10706734 Whirlpool Power Cord Backorder WPL W10706734 $28.68

W10908276 Whirlpool Power Cord Backorder WPL W10908276 $22.38

W11112762 Whirlpool Power Cord Backorder WPL W11112762 $11.88

WP3400203 Whirlpool Screw Backorder WPL WP3400203 $2.91

32

W11133645 Whirlpool Pinion Gear Backorder WPL W11133645 $3.11

32

WP4159193 Whirlpool Screw In Stock WPL WP4159193 $2.91

33

WP9706090 Whirlpool Washer In Stock WPL WP9706090 $2.91

35

WP240285 Whirlpool Drip Ring In Stock WPL WP240285 $5.64

W11200218 Whirlpool Grease Filter In Stock WPL W11200218 $57.21

WPW10223140 Whirlpool Bowl Cover Backorder WPL WPW10223140 $15.76

FOOD TRAY (FT) WPL 241675 Contact Us For Availability

JUICER (JE) WPL 4164748 Contact Us For Availability

FOOD GRINDER (FG-A) WPL 4164749 Contact Us For Availability

ROTOR SLICER/ SHREDDER(WITH4 STANDARD CONES) WPL 4164750 Contact Us For Availability

FRUIT/VEGETABLE STRAINER AND FOOD GRINDER (FV WPL 4164774 Contact Us For Availability

FRUIT/VEGETABLE STRAINER PARTS (USE WITH FG-A WPL 4164775 Contact Us For Availability

MIXER ATTACHMENT PAK (INCLUDES FOOD GRINDER ( WPL 4164778 Contact Us For Availability

SAUSAGE STUFFER KIT (SSA) WPL 4164803 Contact Us For Availability

Speed Disc (Service Tool) WPL 4164839 Contact Us For Availability

COVER, QUILTED (KMCC1WH) WPL 4396709 Contact Us For Availability

PASTA EXTRUDER W/6 DISCS WPL KPEXTA Contact Us For Availability
