Model Electrolux 253.55694400 Refrigerator (Kenmore 25355694400) – Common Parts &amp; Diagrams

1

241786014 Frigidaire Refrigerator Door Gasket In Stock WCI 241786014 $57.30

1

5304526057 Frigidaire Refrigerator Condenser Backorder WCI 5304526057 $88.09

2

241786013 Frigidaire Refrigerator Door Gasket In Stock WCI 241786013 $57.76

2

Refrigerator Spring WCI 5304436616 Contact Us For Availability

3

218679614 Frigidaire Refrigerator Evaporator Backorder WCI 218679614 $12.67

4

240323002 Frigidaire Bottom Clear Door Bin In Stock WCI 240323002 $42.94

4

5303305677 Frigidaire Replacement Filters Fil In Stock WCI 5303305677 $16.79

4

5304469403 Frigidaire Gear Backorder WCI 5304469403 $12.74

4

Refrigerator Dispenser Cover (Black) WCI 5304421643 Contact Us For Availability

4

Refrigerator Module Cover WCI 5304421641 Contact Us For Availability

4

Refrigerator Module Cover WCI 5304421642 Contact Us For Availability

4A

240334202 Frigidaire Refrigerator Door Bin Up In Stock WCI 240334202 $40.45

4C

Refrigerator Freezer Door Bin WCI 240351702 Contact Us For Availability

4D

Tilt Support WCI 241571702 Contact Us For Availability

5

5308000010 Frigidaire Refrigerator Evaporator In Stock WCI 5308000010 $31.93

5

Bin Wire WCI 241571602 Contact Us For Availability

5

Refrigerator Mounting Plate WCI 5304436604 Contact Us For Availability

6

218359202 Frigidaire Refrigerator Screw Backorder WCI 218359202 $6.79

6

Refrigerator Wire Harness WCI 240346402 No Longer Available

7

241561402 Frigidaire Refrigerator Front Ice C Backorder WCI 241561402 $50.64

7

5304469407 Frigidaire Refrigerator Ice Maker Backorder WCI 5304469407 $97.46

7

Refrigerator Dairy Door WCI 240326210 Contact Us For Availability

8

Spacer WCI 3206312 Contact Us For Availability

8

Dispenser Module WCI 5304433616 Contact Us For Availability

8

Dispenser Module WCI 5304433617 Contact Us For Availability

8

Dispenser Module WCI 5304433618 Contact Us For Availability

9

Refrigerator Evaporator Fan Motor Bracket, Fr WCI 5303292396 Contact Us For Availability

9

Refrigerator Detent WCI 5304436610 Contact Us For Availability

10

241688901 Frigidaire Refrigerator Torsion Spr Backorder WCI 241688901 $13.57

10

Clamp WCI 3206315 Contact Us For Availability

10

Cover-air Du WCI 240435908 Contact Us For Availability

10A

Refrigerator Control Cover Evaporator WCI 240475907 Contact Us For Availability

5303208309 Frigidaire Refrigerator Plug Hole In Stock WCI 5303208309 $27.18

Refrigerator Freezer Door WCI 240554241 Contact Us For Availability

Refrigerator Freezer Door WCI 240554242 Contact Us For Availability

Refrigerator Freezer Door WCI 240554243 Contact Us For Availability

Refrigerator Ice Maker Thermal Cut-Off WCI 5304436618 Contact Us For Availability

11C

240324101 Frigidaire Refrigerator Pizza Shelf Backorder WCI 240324101 $35.78

12

Refrigerator Wiring Harness WCI 5304436614 Contact Us For Availability

13

Refrigerator Thermostat WCI 5304436613 Contact Us For Availability

240418319 Frigidaire Black Facade Label Backorder WCI 240418319 $2.26

240438003 Frigidaire Refrigerator Bracket and Backorder WCI 240438003 $10.41

240505801 Frigidaire Light Switch In Stock WCI 240505801 $42.13

5303918255 Frigidaire Refrigerator Defrost He In Stock WCI 5303918255 $65.42

Screw WCI 5304420652 Contact Us For Availability

Refrigerator Label Module WCI 240418317 Contact Us For Availability

Refrigerator Label Module WCI 240418318 Contact Us For Availability

14A

241547902 Frigidaire Refrigerator Light Switc In Stock WCI 241547902 $15.92

5303918284 Frigidaire Refrigerator Evaporator In Stock WCI 5303918284 $330.62

5304456667 Frigidaire Refrigerator Micro Swit Backorder WCI 5304456667 $54.68

Refrigerator Complete Door WCI 240451986 Contact Us For Availability

Refrigerator Door Assembly (Bisque) WCI 240451987 Contact Us For Availability

Refrigerator Door Assembly (Black) WCI 240451988 Contact Us For Availability

15A

316538904 Frigidaire Oven Light Lamp In Stock WCI 316538904 $10.61

16

5308000110 Frigidaire Refrigerator Evaporator In Stock WCI 5308000110 $39.44

16

Refrigerator Housing WCI 5304436609 Contact Us For Availability

17

241679801 Frigidaire Screw Backorder WCI 241679801 $9.06

297272500 Frigidaire Refrigerator Door Handle In Stock WCI 297272500 $49.74

Refrigerator Temperature Control Knob WCI 240360801 Contact Us For Availability

Refrigerator Door Handle (Gray) WCI 218803903 Contact Us For Availability

Handle Ff &f WCI 218803904 Contact Us For Availability

Refrigerator Ice Ejector WCI 5304436607 Contact Us For Availability

19

Refrigerator Ice Maker Fill Cup WCI 5304436606 Contact Us For Availability

20

Refrigerator Screw WCI 5304408581 Contact Us For Availability

21

5303918214 Frigidaire Refrigerator Defrost Th In Stock WCI 5303918214 $16.38

21

5304473031 Frigidaire Refrigerator Ice Stripp Backorder WCI 5304473031 $17.68

21C

218252201 Frigidaire Refrigerator Screw Backorder WCI 218252201 $9.04

21C

Refrigerator Freezer Door Handle Screw WCI 240521302 Contact Us For Availability

240328201 Frigidaire Refrigerator Hinge Beari In Stock WCI 240328201 $11.32

240328203 Frigidaire Refrigerator Door Hinge In Stock WCI 240328203 $13.57

240457701 Frigidaire Refrigerator Freezer Doo In Stock WCI 240457701 $36.22

Refrigerator Compressor Base WCI 240330008 Contact Us For Availability

Refrigerator Shut-Off Arm WCI 5304436602 Contact Us For Availability

22A

242000501 Frigidaire Refrigerator Hinge Beari Backorder WCI 242000501 $4.57

22A

242000502 Frigidaire Hinge Bearing Backorder WCI 242000502 $4.59

22B

Refrigerator Door Hinge Bushing, Upper WCI 240328401 Contact Us For Availability

22C

240328402 Frigidaire Refrigerator Bearing Hin Backorder WCI 240328402 $12.67

22C

240328404 Frigidaire Refrigerator Upper Door In Stock WCI 240328404 $14.61

218513300 Frigidaire Refrigerator Compressor In Stock WCI 218513300 $27.16

241659103 Frigidaire Refrigerator Drip Tray Backorder WCI 241659103 $41.68

Refrigerator Screw, #10-32 x 1/4-in WCI 240402701 Contact Us For Availability

Refrigerator Ice Maker Mounting Screw WCI 5304408582 Contact Us For Availability

Refrigerator Drip Tray WCI 240411701 Contact Us For Availability

Refrigerator Drip Tray WCI 240411702 Contact Us For Availability

241685701 Frigidaire Refrigerator White Water In Stock WCI 241685701 $121.20

241685703 Frigidaire Refrigerator Lighted Wat In Stock WCI 241685703 $84.51

5304456675 Frigidaire Refrigerator Lever Arm Backorder WCI 5304456675 $42.12

Refrigerator Actuator WCI 5304433614 Contact Us For Availability

24A

241682303 Frigidaire Refrigerator Actuator Backorder WCI 241682303 $133.50

24A

Refrigerator Actuator WCI 5304433611 Contact Us For Availability

24A

Refrigerator Actuator WCI 5304433612 Contact Us For Availability

25

240350702 Frigidaire Refrigerator Upper Crisp In Stock WCI 240350702 $26.27

25

Compressor Screw WCI 240491501 Contact Us For Availability

25

Screw WCI 3206336 Contact Us For Availability

26

241697603 Frigidaire Defrost Pan Backorder WCI 241697603 $47.70

26

Screw-ther WCI 5304420654 Contact Us For Availability

26

Container-eg WCI 5303288969 Contact Us For Availability

27

Screw WCI 3206338 Contact Us For Availability

27A

240362201 Frigidaire Refrigerator Humidity Co Backorder WCI 240362201 $43.91

28

Screw WCI 3206339 Contact Us For Availability

29

5304475102 Frigidaire Refrigerator Compressor In Stock WCI 5304475102 $297.55

29

Refrigerator Ice Maker Motor Screw WCI 3206323 Contact Us For Availability

241688401 Frigidaire Ice Door Bracket In Stock WCI 241688401 $31.71

297237702 Frigidaire Refrigerator Start Relay In Stock WCI 297237702 $62.75

5303918455 Frigidaire Refrigerator Adjustable In Stock WCI 5303918455 $87.38

Screw WCI 3206341 Contact Us For Availability

30A

241688501 Frigidaire Refrigerator Door Center In Stock WCI 241688501 $33.84

30B

241688601 Frigidaire Refrigerator Door Insula In Stock WCI 241688601 $39.94

30C

241688701 Frigidaire Refrigerator Door Seal In Stock WCI 241688701 $24.59

31

Insulator WCI 3206342 Contact Us For Availability

32

241544101 Frigidaire Refrigerator Clamp In Stock WCI 241544101 $5.49

32

Refrigerator Ice Maker Fill Switch Bracket WCI 3206343 Contact Us For Availability

33

Thermostat Spring WCI 5304436615 Contact Us For Availability

34

240405201 Frigidaire Refrigerator Grommet Backorder WCI 240405201 $12.67

34

Screw WCI 5304420655 Contact Us For Availability

35

Screw WCI 5304408585 Contact Us For Availability

35

Damper-rot WCI 5304421620 Contact Us For Availability

36

Refrigerator Ice Maker Cover WCI 5304436605 Contact Us For Availability

242161201 Frigidaire Refrigerator Cabinet Cor In Stock WCI 242161201 $1.89

242161203 Frigidaire Refrigerator Corner Cabi In Stock WCI 242161203 $4.53

Refrigerator Door Handle Trim, Lower (Black) WCI 218779320 Contact Us For Availability

Freezer Door Handle Trim, Lower WCI 218779318 Contact Us For Availability

Refrigerator Corner Trim (Black) WCI 240337603 Contact Us For Availability

Refrigerator Freezer Door Handle Trim, Lower WCI 218779321 Contact Us For Availability

241684107 Frigidaire Refrigerator Ice Crusher Backorder WCI 241684107 $13.13

Refrigerator Hand Trim WCI 218779309 Contact Us For Availability

Refrigerator Door Handle Trim, Upper (White) WCI 218779307 Contact Us For Availability

Tri Snap WCI 218776600 Contact Us For Availability

Refrigerator Handle Trim WCI 218779315 Contact Us For Availability

38

240327207 Frigidaire Refrigerator Upper Hinge Backorder WCI 240327207 $36.72

38

Refrigerator Door Hinge, Upper WCI 240327206 Contact Us For Availability

38

Refrigerator Electronic Control Board WCI 5304433619 Contact Us For Availability

38A

241689106 Frigidaire Refrigerator Micro Switc In Stock WCI 241689106 $5.10

38C

241708307 Frigidaire Refrigerator Control Boa In Stock WCI 241708307 $152.59

38C

Harness Ring WCI 5304430811 Contact Us For Availability

39

240367602 Frigidaire Refrigerator Shelf Trim In Stock WCI 240367602 $28.99

39

241688801 Frigidaire Refrigerator Hinge Pin Backorder WCI 241688801 $27.62

40

240327005 Frigidaire Refrigerator Upper P-1 H In Stock WCI 240327005 $37.47

40

240327007 Frigidaire Refrigerator Upper Hinge Backorder WCI 240327007 $34.43

40

Cover-uppe WCI 240327006 Contact Us For Availability

41

240555002 Frigidaire Refrigerator Screw #8-32 In Stock WCI 240555002 $8.58

41

241550801 Frigidaire Refrigerator Shelf Mount In Stock WCI 241550801 $37.63

41

241689001 Frigidaire Refrigerator Actuator Sp Backorder WCI 241689001 $14.03

42

240356501 Frigidaire Tray Hanger Pan In Stock WCI 240356501 $36.26

42

240578902 Frigidaire Screw Mounting Hinge Backorder WCI 240578902 $9.04

42A

240349701 Frigidaire Refrigerator Left Hand M Backorder WCI 240349701 $36.75

42A

Refrigerator Deli Drawer Hanger WCI 240349901 Contact Us For Availability

42A

Refrigerator Deli Drawer Slide Rail Spring WCI 240350001 Contact Us For Availability

43

5304453707 Frigidaire Oven Screw In Stock WCI 5304453707 $9.50

43

5304499445 Frigidaire Refrigerator Roller Ass Backorder WCI 5304499445 $19.99

44

5303001199 Frigidaire Refrigerator Wiring Har Backorder WCI 5303001199 $41.66

45

241500303 Frigidaire Refrigerator Screw Backorder WCI 241500303 $2.72

45

5304455651 Frigidaire Refrigerator Screw In Stock WCI 5304455651 $8.58

46

5303001193 Frigidaire Refrigerator Clamp Backorder WCI 5303001193 $10.41

47

Refrigerator Shelf Bracket WCI 240349402 Contact Us For Availability

47A

240350603 Frigidaire Glass Shelf Backorder WCI 240350603 $73.07

49

240356402 Frigidaire Refrigerator Gallon Door In Stock WCI 240356402 $61.71

49B

Refrigerator Freezer Basket WCI 240530504 Contact Us For Availability

51

240343002 Frigidaire Hanger Basket Backorder WCI 240343002 $38.55

51

241796407 Frigidaire Refrigerator Fill Water Backorder WCI 241796407 $12.67

51A

240395502 Frigidaire Refrigerator Basket Hang Backorder WCI 240395502 $46.16

52

240343102 Frigidaire Basket Hanger Backorder WCI 240343102 $41.24

52A

240395602 Frigidaire Refrigerator Basket Hang Backorder WCI 240395602 $38.97

53

240369501 Frigidaire Refrigerator Control Box Backorder WCI 240369501 $46.30

55

242252702 Frigidaire Refrigerator Water Inlet In Stock WCI 242252702 $45.74

55

297286803 Frigidaire Refrigerator Run Capacit In Stock WCI 297286803 $21.04

56

Refrigerator Dispenser Micro-Switch Screw WCI 5304421830 Contact Us For Availability

57

240542601 Frigidaire Wiring Harness Clip Backorder WCI 240542601 $57.37

58

218781101 Frigidaire Handle Screw In Stock WCI 218781101 $9.97

58

240569202 Frigidaire Refrigerator Screw In Stock WCI 240569202 $1.35

59

Shroud Control WCI 240315501 Contact Us For Availability

59A

Refrigerator Condenser Fan Motor Bracket WCI 240346501 Contact Us For Availability

59B

Grommet Bracket WCI 240346601 Contact Us For Availability

60

5304448483 Frigidaire Refrigerator Condenser Backorder WCI 5304448483 $162.29

60

5304455852 Frigidaire Refrigerator Screw Backorder WCI 5304455852 $8.14

61

241639502 Frigidaire Refrigerator Condenser F In Stock WCI 241639502 $11.41

61B

Refrigerator Bracket Support WCI 240564001 Contact Us For Availability

62

5304481642 Frigidaire Refrigerator Trough Backorder WCI 5304481642 $189.92

64

5304455846 Frigidaire Refrigerator Clamp In Stock WCI 5304455846 $6.79

66

Ice Bracket WCI 5304436611 Contact Us For Availability

66

Refrigerator Pantry Drawer Temperature Contro WCI 5304424968 Contact Us For Availability

67

5304465210 Frigidaire Refrigerator Switch Kit Backorder WCI 5304465210 $134.77

68

241525101 Frigidaire Refrigerator Ice Chute Backorder WCI 241525101 $48.59

70

218990801 Frigidaire Refrigerator Evaporator/ Backorder WCI 218990801 $40.32

72

240324409 Frigidaire Refrigerator Grille Kick Backorder WCI 240324409 $37.63

72

240324411 Frigidaire Grille Kickplate Backorder WCI 240324411 $43.01

72

Kick Grille WCI 240324404 Contact Us For Availability

73

218396700 Frigidaire Door Handle Mounting Blo In Stock WCI 218396700 $28.99

74

215503203 Frigidaire Refrigerator Door Handle In Stock WCI 215503203 $4.51

81

5304455650 Frigidaire Refrigerator Screw Backorder WCI 5304455650 $9.06

82

5304418225 Frigidaire Refrigerator Roller P-1 In Stock WCI 5304418225 $30.80

83

5304455655 Frigidaire Refrigerator Rivet Backorder WCI 5304455655 $23.04

84

241957901 Frigidaire Refrigerator Drain Tube Backorder WCI 241957901 $38.55

85

241856901 Frigidaire Refrigerator Connector T Backorder WCI 241856901 $46.16

86

240409302 Frigidaire Refrigerator Condenser T Backorder WCI 240409302 $39.88

87

241688302 Frigidaire Refrigerator Bearing Pla Backorder WCI 241688302 $12.67

87A

241688301 Frigidaire Refrigerator Bearing Pla Backorder WCI 241688301 $12.67

89

5304520905 Frigidaire Assembly Cover Refriger Backorder WCI 5304520905 $44.58

90

218249808 Frigidaire Refrigerator Coil Cover Backorder WCI 218249808 $5.40

91

240380101 Frigidaire Refrigerator Ice Maker D Backorder WCI 240380101 $44.37

92

241710601 Frigidaire Refrigerator Screw In Stock WCI 241710601 $8.60

97

240545302 Frigidaire Water Reservoir Assembly Backorder WCI 240545302 $167.84

100

241993001 Frigidaire Refrigerator Left Crispe In Stock WCI 241993001 $5.55

100

241993101 Frigidaire Refrigerator Right Crisp In Stock WCI 241993101 $3.46

121

Refrigerator Freezer Ice Cream Shelf Slide Ra WCI 241561001 Contact Us For Availability

137

Frigidaire WF2CB PureSource Water Filter In Stock WCI WF2CB $42.87

138

Refrigerator Water Filter Release Button WCI 240397301 Contact Us For Availability

140

240430501 Frigidaire Refrigerator Channel Backorder WCI 240430501 $61.86

150

Guide Control WCI 240368701 Contact Us For Availability

198

240397401 Frigidaire Refrigerator Retainer As Backorder WCI 240397401 $37.63

199

240398401 Frigidaire Refrigerator Filter Rele Backorder WCI 240398401 $35.32

199

Refrigerator Water Filter Bypass Valve WCI 240397501 Contact Us For Availability

215474201 Frigidaire Refrigerator Washer Backorder WCI 215474201 $11.78

218709101 Frigidaire Refrigerator Handle Moun Backorder WCI 218709101 $4.09

218976901 Frigidaire Refrigerator P1 Water In Backorder WCI 218976901 $51.52

218976903 Frigidaire Refrigerator Water Inlet Backorder WCI 218976903 $44.38

240346701 Frigidaire Refrigerator Foam Seal T Backorder WCI 240346701 $19.01

240349801 Frigidaire Refrigerator Clip In Stock WCI 240349801 $12.24

240359403 Frigidaire Refrigerator Fan Shroud Backorder WCI 240359403 $2.26

240362101 Frigidaire Refrigerator Crisper Cov In Stock WCI 240362101 $28.07

240363602 Frigidaire Refrigerator Shoulder Sc Backorder WCI 240363602 $8.14

240396801 Frigidaire Refrigerator Tube Clamp Backorder WCI 240396801 $12.24

240494001 Frigidaire Refrigerator Plug Button In Stock WCI 240494001 $10.85

240542901 Frigidaire Water Valve Cap Backorder WCI 240542901 $11.33

240545201 Frigidaire Refrigerator Elbow P-1 In Stock WCI 240545201 $46.62

240561701 Frigidaire Refrigerator Seal Backorder WCI 240561701 $13.13

241550701 Frigidaire Refrigerator Shelf Mount Backorder WCI 241550701 $10.85

241583301 Frigidaire Refrigerator Air Deflect Backorder WCI 241583301 $29.88

5303321319 Frigidaire Refrigerator White Touc In Stock WCI 5303321319 $9.23

5303321321 Frigidaire Refrigerator Black Touc In Stock WCI 5303321321 $13.61

5303918256 Frigidaire Refrigerator Heater Kit In Stock WCI 5303918256 $342.79

5303918328 Frigidaire Refrigerator OS1 Heat E In Stock WCI 5303918328 $213.23

5303918344 Frigidaire Refrigerator Kit Ice Ma In Stock WCI 5303918344 $105.39

5308000133 Frigidaire Refrigerator Clamp Backorder WCI 5308000133 $7.25

Refrigerator Hot Tube Repair Kit WCI 5303918222 Contact Us For Availability

Appliance Touch-Up Paint, 0.6-oz (Bisque) WCI 5304414035 Contact Us For Availability

Refrigerator Water Tubing WCI 218976907 Contact Us For Availability

Refrigerator Wire Harness WCI 240449601 Contact Us For Availability

Refrigerator Ice and Water Dispenser Cover Cl WCI 240411501 Contact Us For Availability

Refrigerator Connector WCI 240470401 Contact Us For Availability

Refrigerator Freezer Door Wire Harness WCI 240552102 Contact Us For Availability

Refrigerator Screw WCI 240569501 Contact Us For Availability

Refrigerator Control Box Wire Harness WCI 241537801 Contact Us For Availability

Refrigerator Water Tubing Clip WCI 218515402 Contact Us For Availability

Refrigerator Wiring Harness WCI 240352601 Contact Us For Availability

Refrigerator Insulator WCI 5304426535 Contact Us For Availability

Lower Shim WCI 240481601 Contact Us For Availability
