Samsung DV520AEW/XAA-00 Dryer Parts List

1

DC93-00187A Samsung Assembly Duct Outlet Backorder SMG DC93-00187A $87.39

View on Model

1

DC97-07895A Samsung Dryer Connector Duct Asse Backorder SMG DC97-07895A $43.70

View on Model

1-1

DC64-02144A Samsung Washer and Dryer Safety D Backorder SMG DC64-02144A $108.14

View on Model

1-1

DC65-00028A Samsung Block Terminal Backorder SMG DC65-00028A $12.02

View on Model

1-2

Dryer door outer frame SMG DC63-01141A Contact Us For Availability

View on Model

1-3

6002-001306 Samsung Washer Tapping Screw Backorder SMG 6002-001306 $0.92

View on Model

1-4

DC47-00018A Samsung Thermostat In Stock SMG DC47-00018A $21.75

View on Model

1-5

DC96-00887C Samsung Dryer Thermal Cut-Off Fus In Stock SMG DC96-00887C $43.37

View on Model

1-6

Dryer heater box, upper SMG DC67-00132A Contact Us For Availability

View on Model

1-6

Dryer door window frame SMG DC61-02596A Contact Us For Availability

View on Model

1-8

Laundry appliance screw, m4-18 x 22 SMG 6002-000445 Contact Us For Availability

View on Model

1-9

Dryer screw SMG 6001-001668 Contact Us For Availability

View on Model

1-10

Door hinge SMG DC61-02597A Contact Us For Availability

View on Model

1-11

DC61-00891A Samsung Washer Dryer Hinge Guide In Stock SMG DC61-00891A $32.08

View on Model

1-12

Washer screw, m5 x 12 SMG 6002-000241 Contact Us For Availability

View on Model

1-13

DC62-00262A Samsung Dryer Door Seal Assembly Backorder SMG DC62-00262A $51.59

View on Model

2

DC93-00101B Samsung Motor Assembly Backorder SMG DC93-00101B $225.54

View on Model

2

Dryer power control board SMG DC92-00322A Contact Us For Availability

View on Model

2

Dryer heater housing bracket SMG DC61-02016A Contact Us For Availability

View on Model

2-2

Dryer blower wheel nut SMG 6021-001201 Contact Us For Availability

View on Model

2-3

DC97-07510B Samsung Dryer Door Lever Holder C In Stock SMG DC97-07510B $14.09

View on Model

2-4

DC32-00007A Samsung Dryer Thermistor Sensor In Stock SMG DC32-00007A $18.25

View on Model

2-5

DC47-00016A Samsung Thermostat In Stock SMG DC47-00016A $10.73

View on Model

2-5

DC64-00828B Samsung Washer Dryer Door Switch In Stock SMG DC64-00828B $32.45

View on Model

2-6

DC61-01214A Samsung Spring Plate Assembly Backorder SMG DC61-01214A $3.50

View on Model

2-7

DC31-00055D Samsung Clothes Dryer Induction M In Stock SMG DC31-00055D $236.07

View on Model

2-9

DC61-01213A Samsung Motor Bracket Assembly In Stock SMG DC61-01213A $97.45

View on Model

2-10

Dryer belt switch housing SMG DC63-00919A Contact Us For Availability

View on Model

2-11

3405-001077 Samsung Micro Switch Backorder SMG 3405-001077 $17.40

View on Model

2-13

6009-001342 Samsung Dryer Special Puller Scre In Stock SMG 6009-001342 $1.24

View on Model

2-14

DC93-00634A Samsung Dryer Idler Pulley Assemb In Stock SMG DC93-00634A $40.64

View on Model

2-15

DC61-01215B Samsung Dryer Idler Tension Sprin In Stock SMG DC61-01215B $4.98

View on Model

3

6602-001655 Samsung Dryer Drive Belt In Stock SMG 6602-001655 $35.36

View on Model

3

DC97-16782A Samsung Dryer Plastic Roller Whee In Stock SMG DC97-16782A $33.38

View on Model

3

Dryer encoder board SMG DC92-00320A Contact Us For Availability

View on Model

4

Dryer user interface SMG DC92-00319B Contact Us For Availability

View on Model

5

Frame plate SMG DC61-02600A Contact Us For Availability

View on Model

5

Dryer roller wheel nut SMG DC60-50145A Contact Us For Availability

View on Model

6

Dryer drum light lens SMG DC63-00531A Contact Us For Availability

View on Model

7

DC61-01428A Samsung Power Holder Assembly Backorder SMG DC61-01428A $1.24

View on Model

8

4713-001199 Samsung Dryer Drum Incandescent L Backorder SMG 4713-001199 $8.71

View on Model

8

DC63-00534B Samsung Back Cover Assembly Backorder SMG DC63-00534B $41.07

View on Model

9

DC97-12150A Samsung Dryer Leg Assembly In Stock SMG DC97-12150A $15.76

View on Model

9

Lamp socket SMG DC47-00021A Contact Us For Availability

View on Model

10

DC61-02627A Samsung Dryer Moisture Sensor Pla In Stock SMG DC61-02627A $6.22

View on Model

10

DC97-07519A Samsung Dryer Exhaust Duct Assemb Backorder SMG DC97-07519A $54.92

View on Model

11

DC93-00154A Samsung Dryer Duct Heater Assembl In Stock SMG DC93-00154A $220.25

View on Model

11

DC96-00766A Samsung Dryer Wire Harness Assemb In Stock SMG DC96-00766A $9.96

View on Model

12

DC61-02740A Samsung Dryer Lint Screen Filter In Stock SMG DC61-02740A $0.92

View on Model

12

DC93-00153A Samsung Main Wire Harness Assembl Backorder SMG DC93-00153A $170.97

View on Model

13

DC63-01140A Samsung Dryer Lint Filter Screen In Stock SMG DC63-01140A $16.16

View on Model

14

Dryer lint screen cover SMG DC63-01139A Contact Us For Availability

View on Model

15

DC63-01143A Samsung Cover Filter Assembly Backorder SMG DC63-01143A $87.01

View on Model

15

DC97-15249A Samsung Hose Connector Assembly Backorder SMG DC97-15249A $79.97

View on Model

16

Dryer drum SMG DC97-14849A Contact Us For Availability

View on Model

18

DC61-02063A Samsung Nozzle Guide Assembly Backorder SMG DC61-02063A $3.88

View on Model

20

DC97-16919A Samsung Steam Kit Assembly Backorder SMG DC97-16919A $136.76

View on Model

26

Dryer retainer clip SMG DC61-00133A Contact Us For Availability

View on Model

NI

6002-000239 Samsung Air Conditioner Tapping S Backorder SMG 6002-000239 $0.92

View on Model
