Model Electrolux WGF355BADA RANGE – Common Parts &amp; Diagrams

*61363

HARNESS-WIRING, MAIN WCI 5303292880 Contact Us For Availability

*61364

WCI 5303281584 WCI 5303281584 Contact Us For Availability

*61365

WCI 316065300 WCI 316065300 Contact Us For Availability

*61366

RIVET-POP, WARING-PLATE WCI 3203618 Contact Us For Availability

*61367

WCI 5303212671 WCI 5303212671 Contact Us For Availability

*61368

WCI 5303269859 WCI 5303269859 Contact Us For Availability

*61369

WCI 5303280311 WCI 5303280311 Contact Us For Availability

*61370

5303285179 Frigidaire Oven Door Screw Backorder WCI 5303285179 $8.60

*61371

Plug-button,glide ,(4) WCI 3018702 Contact Us For Availability

*61372

WCI 5303305325 WCI 5303305325 Contact Us For Availability

*61374

WCI 08067961 WCI 08067961 Contact Us For Availability

*61375

WCI 3200846 WCI 3200846 Contact Us For Availability

1

WCI 3203082 WCI 3203082 Contact Us For Availability

1

DRAWER-UTILITY WCI 316011501 Contact Us For Availability

2

316137003 Frigidaire Range End Cap Backorder WCI 316137003 $28.99

2

WCI 3131975 WCI 3131975 Contact Us For Availability

3

PANEL, BODYSIDE, ALMOND, LH (NON-ILLUSTRATED WCI 316081007 Contact Us For Availability

3

Trim,oven door ,black WCI 316067802 Contact Us For Availability

3A

SWITCH-IGNITER, (4) WCI 316032000 Contact Us For Availability

3A

SHIELD-HEAT, BODY SIDE (NON-ILLUSTRATED) WCI 3200834 Contact Us For Availability

3B

SHIELD-INSULATION, GALV STEEL (NON-ILLUSTRATE WCI 08067992 Contact Us For Availability

3C

WCI 316081006 WCI 316081006 Contact Us For Availability

4

WCI 316011905 WCI 316011905 Contact Us For Availability

4

WCI 316056206 WCI 316056206 Contact Us For Availability

4

GLASS-OVEN DOOR, BLACK, OUTER WCI 3051152 Contact Us For Availability

4A

WCI 08067785 WCI 08067785 Contact Us For Availability

5

ANTI-TIP KIT (NON-ILLUSTRATED) WCI 3934056 Contact Us For Availability

5

FASTENER-SPACER, PUSH-IN NUT, NYLON WCI 3131387 Contact Us For Availability

5

GLASS-OVEN DOOR, INNER WCI 5303209513 Contact Us For Availability

5A

316116000 Frigidaire Screw Backorder WCI 316116000 $7.67

5B

WCI 5303288460 WCI 5303288460 Contact Us For Availability

5C

SCREW-LEVELING WCI 5303203397 Contact Us For Availability

6

316067902 Frigidaire Oven Rack Backorder WCI 316067902 $65.19

6

SHIELD-INSULATION WCI 5303211084 Contact Us For Availability

7

3051163 Frigidaire Oven Range Rear Broiler Dr In Stock WCI 3051163 $2.37

7

WCI 316007002 WCI 316007002 Contact Us For Availability

7

INSULATION-OVEN DOOR WCI 5303209514 Contact Us For Availability

8

316064600 Frigidaire Oven Support Backorder WCI 316064600 $11.32

8A

PANEL-OVEN BOTTOM WCI 5303212540 Contact Us For Availability

9

PAN-BROILER WCI 5303013568 Contact Us For Availability

9

WCI 316066603 WCI 316066603 Contact Us For Availability

10

SCREW-HANDLE MTG, WAFER HEAD, 10-24(F) X 3 WCI 5303281378 Contact Us For Availability

10

WCI 5303131356 WCI 5303131356 Contact Us For Availability

11

316011200 Frigidaire Oven Top Burner Igniter In Stock WCI 316011200 $9.10

11

BRACKET-LIGHT SWITCH WCI 5303131289 Contact Us For Availability

12

5303131601 Frigidaire Oven Seal Backorder WCI 5303131601 $203.31

12

SWITCH-OVEN LIGHT, DOOR FRAME WCI 5303202622 Contact Us For Availability

13

WCI 316065005 WCI 316065005 Contact Us For Availability

13

WCI 5303269501 WCI 5303269501 Contact Us For Availability

14

316021104 Frigidaire Oven Screw Assembly Backorder WCI 316021104 $4.97

14

316116400 Frigidaire Oven Light Socket In Stock WCI 316116400 $40.25

14

REFLECTOR, ALUMINUM FOIL WCI 5303208656 Contact Us For Availability

14A

316022500 Frigidaire Oven Warmer Drawer Zone In Stock WCI 316022500 $36.24

14A

5303208655 Frigidaire Reflector Assembly Backorder WCI 5303208655 $36.74

15

316538904 Frigidaire Oven Light Lamp In Stock WCI 316538904 $10.61

15

BRACKET-GLASS MTG WCI 5303209510 Contact Us For Availability

5304524341 Frigidaire Lens In Stock WCI 5304524341 $9.87

GLASS-OVEN DOOR, HEAT BARRIER, (2) WCI 5303209512 Contact Us For Availability

WCI 5303271891 WCI 5303271891 Contact Us For Availability

WCI 5303271892 WCI 5303271892 Contact Us For Availability

16A

WCI 316010409 WCI 316010409 Contact Us For Availability

17

5303208499 Frigidaire Gas Safety Valve In Stock WCI 5303208499 $359.54

17

RETAINER-GLASS WCI 3204585 Contact Us For Availability

17

WCI 5303209517 WCI 5303209517 Contact Us For Availability

131243700 Frigidaire Screw In Stock WCI 131243700 $2.16

SHIELD-LATCH, TOP (NON-ILLUSTRATED) WCI 3131593 Contact Us For Availability

BRACKET-HINGE,MAIN TOP RH WCI 08067747 Contact Us For Availability

SEAL-ROPE, 0.25 DIA WCI 5303211085 Contact Us For Availability

18A

BRACKET-HINGE,MAIN TOP LH WCI 08067746 Contact Us For Availability

18A

WCI 5303015453 WCI 5303015453 Contact Us For Availability

19

WCI 5303131357 WCI 5303131357 Contact Us For Availability

19

WCI 316011400 WCI 316011400 Contact Us For Availability

19

WCI 316067600 WCI 316067600 Contact Us For Availability

20

BAFFLE-OVEN BURNER WCI 3131284 Contact Us For Availability

20

WCI 08013188 WCI 08013188 Contact Us For Availability

20

WCI 5303269632 WCI 5303269632 Contact Us For Availability

20A

WCI 3203218 WCI 3203218 Contact Us For Availability

21

Backorder WCI 154079601 $0.28

21

SPACER-BODYSIDE, (8) WCI 3014099 Contact Us For Availability

21

WCI 316035101 WCI 316035101 Contact Us For Availability

22

316010901 Frigidaire Burner Cap P1 Backorder WCI 316010901 $40.78

22

WCI 316065002 WCI 316065002 Contact Us For Availability

22

WCI 08067978 WCI 08067978 Contact Us For Availability

22A

SWITCH-LATCH WCI 5303269499 Contact Us For Availability

23

WCI 08067935 WCI 08067935 Contact Us For Availability

23

WCI 08067776 WCI 08067776 Contact Us For Availability

24

WCI 5303208640 WCI 5303208640 Contact Us For Availability

24

SHIELD-LATCH WCI 3051413 Contact Us For Availability

25

BAFFLE-BROILER WCI 5303210379 Contact Us For Availability

25

WCI 3131313 WCI 3131313 Contact Us For Availability

26

5303935068 Frigidaire Flat Igniter In Stock WCI 5303935068 $89.52

26

WCI 08067757 WCI 08067757 Contact Us For Availability

27

5303284616 Frigidaire Range Bulb Clip Thermos In Stock WCI 5303284616 $5.88

28

CLIP-WIRE WCI 3011813 Contact Us For Availability

29

3051162 Frigidaire Oven Range Front Broiler D In Stock WCI 3051162 $1.76

33

SHIELD, REAR WALL WCI 316014401 Contact Us For Availability

35

316542102 Frigidaire Flue Gasket Backorder WCI 316542102 $7.23

36

WCI 316009010 WCI 316009010 Contact Us For Availability

36

WCI 3131931 WCI 3131931 Contact Us For Availability

37

316069301 Frigidaire Oven Burner Mounting Pri In Stock WCI 316069301 $1.79

38

WCI 316014301 WCI 316014301 Contact Us For Availability

39

5304534377 Frigidaire Cord Backorder WCI 5304534377 $16.03

39

HANDLE-DRAWER, ALMOND WCI 316019502 Contact Us For Availability

39

HANDLE-DOOR, BLACK, OVEN WCI 5303273127 Contact Us For Availability

40

WCI 5303288570 WCI 5303288570 Contact Us For Availability

40A

WCI 3200836 WCI 3200836 Contact Us For Availability

41

WCI 3131570 WCI 3131570 Contact Us For Availability

42

WCI 5303270104 WCI 5303270104 Contact Us For Availability

43

316282700 Frigidaire Oven Screw Backorder WCI 316282700 $6.32

44

3131903 Frigidaire Door/Drawer Bumper Backorder WCI 3131903 $33.06

44

ORIFICE-TOP BURNER, (4) WCI 5303210090 No Longer Available

45

WCI 316011100 WCI 316011100 Contact Us For Availability

45

SHIELD-WIRE WCI 08068018 Contact Us For Availability

46

WCI 5303269491 WCI 5303269491 Contact Us For Availability

47

WCI 5303286386 WCI 5303286386 Contact Us For Availability

49

3205821 Frigidaire Clip Backorder WCI 3205821 $22.65

50

BURNER-TOP, (4), INCLUDES 37 WCI 5303935026 Contact Us For Availability

53

08067973 Frigidaire 0 Insulation Backorder WCI 08067973 $33.06

53A

WCI 5303271047 WCI 5303271047 Contact Us For Availability

58A

INSULATION, OVEN WRAPPER WCI 3200833 Contact Us For Availability

58B

WCI 316054200 WCI 316054200 Contact Us For Availability

58C

INSULATION, OVEN TOP WCI 3131304 Contact Us For Availability

60

SCREW-DRAWER HANDLE, 8 TRUSS HEAD, 10-16 X 1/ WCI 5303281651 Contact Us For Availability

72

COVER-LIGHT/SWITCH ROD WCI 5303285692 Contact Us For Availability
