Model Whirlpool RS22AMXVL00 – Common Parts &amp; Diagrams

350930 Whirlpool White Spray Paint In Stock WPL 350930 $13.12

350942 Whirlpool Spray Paint Backorder WPL 350942 $32.57

350956 Whirlpool Spray Assembly In Stock WPL 350956 $19.22

WPL 1117510 WPL 1117510 Contact Us For Availability

WPL 350941 WPL 350941 Contact Us For Availability

WPL LIT1123779 WPL LIT1123779 Contact Us For Availability

WPL LIT1124442 WPL LIT1124442 Contact Us For Availability

WPL LIT1124444 WPL LIT1124444 Contact Us For Availability

WPL LIT4315824 WPL LIT4315824 Contact Us For Availability

WPL LIT628107 WPL LIT628107 Contact Us For Availability

1

NLA:SCREW Backorder WPL WPW10141645 $3.70

1

Control Box WPL 1123962 Contact Us For Availability

1

Refrigerator Door (White) WPL 1124427 Contact Us For Availability

1

Refrigerator Door (Almond) WPL 1124428 Contact Us For Availability

1

Liner (Not A Serviceable Part) WPL ARI123898A Contact Us For Availability

1

Freezer, Door Panel (White) WPL 1124439 Contact Us For Availability

1

Freezer, Door Panel (Almond (Also Order Item WPL 1124440 Contact Us For Availability

1

Fan Scroll WPL 1108414 Contact Us For Availability

1

Liner (Not A Serviceable Part) WPL ARI123897A Contact Us For Availability

2

819091 Whirlpool Refrigerator Shelf Stud In Stock WPL 819091 $13.89

2

W11624204 Whirlpool Screw Backorder WPL W11624204 $9.59

2

WP2196157 Whirlpool Fill Tube In Stock WPL WP2196157 $4.83

2

Mounting Bracket WPL 1110629 Contact Us For Availability

2

Hole Plug (White) WPL 534927 Contact Us For Availability

2

Overload Spring WPL 943320 Contact Us For Availability

2

Hole Plug (Almond) WPL 989197 Contact Us For Availability

2

Escutcheon, Meat Pan Control WPL 985468 Contact Us For Availability

3

WP488878 Whirlpool Refrigerator Tube Clamp Backorder WPL WP488878 $4.81

3

Screw (2) WPL 489190 Contact Us For Availability

3

Tap Plate WPL 988402 Contact Us For Availability

3

Condenser Assembly WPL 1105640 Contact Us For Availability

3

Air Scoop WPL 1110798 Contact Us For Availability

3

Slide, Meat Pan Control WPL 984102 Contact Us For Availability

4

4387491 Whirlpool Refrigerator Insert In Stock WPL 4387491 $3.70

4

WP2149705 Whirlpool Refrigerator Door Switch In Stock WPL WP2149705 $23.46

4

Cap, Hinge Sleeve WPL 509929 Contact Us For Availability

4

Evaporator, Support WPL 1108436 Contact Us For Availability

4

Pad, Foam WPL 992358 Contact Us For Availability

5

WP628379 Whirlpool Refrigerator Clip Backorder WPL WP628379 $4.61

5

Air Duct Freezer WPL 1108434 Contact Us For Availability

5

Screw 8-15 x 1/2 WPL 486214 Contact Us For Availability

6

WP2158826 Whirlpool Refrigerator Dampener In Stock WPL WP2158826 $0.90

6

Defrost Timer (10 Hr.) WPL 945486 Contact Us For Availability

6

Screw Anchor WPL 941242 Contact Us For Availability

6

Clip (2) WPL 548744 Contact Us For Availability

6

Grommet (2) WPL 216446 Contact Us For Availability

6

Diffuser Air Duct WPL 1118245 Contact Us For Availability

6

Ladder, Shelf (2) WPL 1108433 Contact Us For Availability

7

4318165 Whirlpool Refrigerator Door Closure C In Stock WPL 4318165 $9.42

7

482469 Whirlpool Refrigerator Evaporator Fan In Stock WPL 482469 $88.24

7

489392 Whirlpool Refrigerator Screw Backorder WPL 489392 $9.59

7

W10823511 Whirlpool Refrigerator Water Tube In Stock WPL W10823511 $12.61

7

WP488729 Whirlpool Refrigerator Door Screw In Stock WPL WP488729 $2.64

7

WPW10662129 Whirlpool Refrigerator Run Capaci In Stock WPL WPW10662129 $28.24

7

Support, Stud (16) WPL 946355 Contact Us For Availability

8

4388538 Whirlpool Refrigerator Shelf Stud Kit In Stock WPL 4388538 $11.60

8

940014 Whirlpool Refrigerator Primary Button Backorder WPL 940014 $10.25

8

WP1104787 Whirlpool Refrigerator Shim Backorder WPL WP1104787 $3.70

8

WP1106508 Whirlpool Refrigerator Gasket Backorder WPL WP1106508 $4.14

8

Blade, Fan WPL 992920 Contact Us For Availability

8

Strap, Cover WPL 943322 Contact Us For Availability

8

Stud (5) WPL 946356 Contact Us For Availability

9

Stud (2) WPL 1115290 No Longer Available

9

WP2198202 Whirlpool Refrigerator Temperature In Stock WPL WP2198202 $45.43

9

Bracket, Door Stop WPL 1115906 Contact Us For Availability

9

Cover WPL 1105055 Contact Us For Availability

9

Stud (5) WPL 1106982 Contact Us For Availability

9

Ring, Compression WPL 992953 Contact Us For Availability

4318047 Whirlpool Water Valve In Stock WPL 4318047 $29.77

WP965173 Whirlpool Dishwasher Screw Backorder WPL WP965173 $2.64

Shim WPL 988421 Contact Us For Availability

Housing Plug WPL 1118850 Contact Us For Availability

Grommet (16) WPL 1110779 Contact Us For Availability

Fan Grommet (3) WPL 548268 Contact Us For Availability

WP489478 Whirlpool Refrigerator Screw Backorder WPL WP489478 $2.51

WP627018 Whirlpool Refrigerator Nut In Stock WPL WP627018 $4.59

End Cap, Handle WPL 1109189 Contact Us For Availability

Cam Assembly WPL 1110566 Contact Us For Availability

Screw, 8 x 5/8 WPL 488549 Contact Us For Availability

Overload WPL 1118862 Contact Us For Availability

Screw (Repair) WPL 488930 Contact Us For Availability

Fan, Bracket Double WPL 548263 Contact Us For Availability

1110560 Whirlpool Refrigerator Bearing Backorder WPL 1110560 $4.72

2188404A Whirlpool Refrigerator Door Gasket In Stock WPL 2188404A $125.61

W11693756 Whirlpool Screw Assembly Backorder WPL W11693756 $8.11

End Cap, Handle WPL 936930 Contact Us For Availability

Connector Wire WPL 227991 Contact Us For Availability

Shelf (2) WPL 1114608 Contact Us For Availability

Fan, Bracket Single WPL 548264 Contact Us For Availability

Shim, Hinge Top WPL 1123515 Contact Us For Availability

Screw Grommet WPL 538449 Contact Us For Availability

Tube, Water Inlet WPL 939027 Contact Us For Availability

Shelf, Cantilever (3) WPL 1114304 Contact Us For Availability

WP16123 Whirlpool Washer In Stock WPL WP16123 $2.51

Handle, Center WPL 1119757 Contact Us For Availability

Retainer, Damper WPL 938439 Contact Us For Availability

Shim, End Cap WPL 935075 Contact Us For Availability

Relay WPL 1101014 Contact Us For Availability

Shelf (2) WPL 1114609 Contact Us For Availability

Fan Motor, Harness WPL 1110749 Contact Us For Availability

Trim, Shelf (3) WPL 1124421 Contact Us For Availability

2188405A Whirlpool Refrigerator Door Gasket Backorder WPL 2188405A $132.43

WP1126289 Whirlpool Refrigerator Cover In Stock WPL WP1126289 $71.42

WP489128 Whirlpool Refrigerator Screw Backorder WPL WP489128 $4.56

Pivot Arm WPL 1110559 Contact Us For Availability

Grommet WPL 509812 Contact Us For Availability

Trivet WPL 1124424 Contact Us For Availability

Tube, Inlet Valve WPL 627854 Contact Us For Availability

16

627068 Whirlpool Refrigerator Screw Backorder WPL 627068 $7.52

16

Clamp Tube WPL 510716 Contact Us For Availability

16

Trim, Cover WPL 1119190 Contact Us For Availability

Light Socket WPL 1110690 Contact Us For Availability

Shim, End Cap WPL 935076 Contact Us For Availability

Compressor (Includes Items 51, 52, 53, 54, 55 WPL 482982 Contact Us For Availability

Socket Assembly WPL 1108630 Contact Us For Availability

Cover, Evaporator WPL 1108435 Contact Us For Availability

Nut, Valve WPL 537588 Contact Us For Availability

Glass, Shelf WPL 1124419 Contact Us For Availability

876811 Whirlpool Grommet Backorder WPL 876811 $3.70

WP2148298 Whirlpool Refrigerator Deli Drawer In Stock WPL WP2148298 $98.03

WPW10289690 Whirlpool Ice Maker Cover Backorder WPL WPW10289690 $2.64

Heat Shield WPL 1123924 Contact Us For Availability

Screw, 6-20 x 3/8 (2) WPL 489022 Contact Us For Availability

Lens, Light WPL 1108445 Contact Us For Availability

WP2148279 Whirlpool Refrigerator Crisper Pan Backorder WPL WP2148279 $101.98

WP548049 Whirlpool Refrigerator Light Bulb Backorder WPL WP548049 $27.52

Terminal Block WPL 942842 Contact Us For Availability

Gasket, Evaporator Cover (2) WPL 1110675 Contact Us For Availability

WPW10190929 Whirlpool Refrigerator Ice Maker Backorder WPL WPW10190929 $144.80

Control Box Harness WPL 1123745 Contact Us For Availability

Insert, Extension WPL 1124510 Contact Us For Availability

Strap WPL 851095 Contact Us For Availability

Cover, Wiring WPL 1114615 Contact Us For Availability

Gasket, Evaporator Cover Top (2) WPL 1110676 Contact Us For Availability

Meat Pan WPL 1124415 Contact Us For Availability

WP1115374 Whirlpool Refrigerator Clip Backorder WPL WP1115374 $2.51

WP681414 Whirlpool Screw In Stock WPL WP681414 $2.51

WPW10141625 Whirlpool Refrigerator Screw Asse Backorder WPL WPW10141625 $9.59

Insert Retainer (Top) WPL 1124569 Contact Us For Availability

Knob WPL 627992 Contact Us For Availability

WP2256085 Whirlpool Refrigerator Retainer Backorder WPL WP2256085 $13.73

WP628356 Whirlpool Refrigerator Fill Cup Backorder WPL WP628356 $16.56

CLIP, WIRING WPL 1115375 Contact Us For Availability

Insert Retainer (Bottom) WPL 1119360 Contact Us For Availability

Dampener (2) WPL 510769 Contact Us For Availability

Fitting, Drain WPL 942768 Contact Us For Availability

WP488488 Whirlpool Refrigerator Screw Backorder WPL WP488488 $3.70

WP627843 Whirlpool Refrigerator Ejector Arm In Stock WPL WP627843 $30.25

Connecting Rod WPL 1123960 Contact Us For Availability

End Cap (2) WPL 941259 Contact Us For Availability

Exchanger, Heat WPL 1106990 Contact Us For Availability

Trim, Ice Pan WPL 837122 Contact Us For Availability

WP2182124 Whirlpool Refrigerator Stripper Arm Backorder WPL WP2182124 $28.15

WP489069 Whirlpool Compactor Screw In Stock WPL WP489069 $2.51

WP944224 Whirlpool Refrigerator Support Backorder WPL WP944224 $3.70

WPW10151374 Whirlpool Refrigerator Diffuser In Stock WPL WPW10151374 $50.99

Fastener, Push-On WPL 489285 Contact Us For Availability

2152019 Whirlpool Refrigerator Cover Backorder WPL 2152019 $34.62

W11384469 Whirlpool Door Switch In Stock WPL W11384469 $13.32

WP2195914 Whirlpool Refrigerator Ice Maker Ho Backorder WPL WP2195914 $38.96

Escutcheon, Control Box WPL 1123999 Contact Us For Availability

Insert, Extension WPL 1124570 Contact Us For Availability

2182111 Whirlpool Refrigerator Thermal Knob Backorder WPL 2182111 $9.53

W11625904 Whirlpool Refrigerator Ice Pan In Stock WPL W11625904 $25.46

WP2315522 Whirlpool Refrigerator Clip Backorder WPL WP2315522 $4.59

Screw, 10-32 x 5/8 (2) WPL 489248 Contact Us For Availability

Cover, Conduit WPL 1123926 Contact Us For Availability

WP488163 Whirlpool Refrigerator Screw In Stock WPL WP488163 $3.70

WP627985 Whirlpool Icemaker Cycling Thermosta In Stock WPL WP627985 $44.03

WP939101 Whirlpool Refrigerator Plate Backorder WPL WP939101 $3.70

Knob, Air Control WPL 1110562 Contact Us For Availability

Interior, Door Panel WPL 1108461 Contact Us For Availability

Knob, Retainer WPL 837444 Contact Us For Availability

Trim, Door Shelf (5) WPL 1120852 Contact Us For Availability

Interior, Door Panel WPL 1108462 Contact Us For Availability

Screw, 10-32 x 49/64 WPL 489258 Contact Us For Availability

Cover, Wiring WPL 1123921 Contact Us For Availability

4387478 Whirlpool Refrigerator Light Socket In Stock WPL 4387478 $32.34

489203 Whirlpool Refrigerator Washer Backorder WPL 489203 $4.36

WP486692 Whirlpool Refrigerator Nut Backorder WPL WP486692 $3.70

Retainer, Door Trim (10) WPL 1124429 Contact Us For Availability

Trim, Door Shelf (5) WPL 1120856 Contact Us For Availability

2215823 Whirlpool Refrigerator Clip Backorder WPL 2215823 $4.61

WP2196100 Whirlpool Shelf Retainer Bar Suppor In Stock WPL WP2196100 $3.70

WP681249 Whirlpool Screw Assembly In Stock WPL WP681249 $2.51

Door, Compartment WPL 1124431 Contact Us For Availability

Guard, Fan WPL 1105614 Contact Us For Availability

WP627792 Whirlpool Refrigerator Shut Off Arm Backorder WPL WP627792 $37.02

Nameplate WPL 1124315 Contact Us For Availability

Evaporator WPL 1106987 Contact Us For Availability

Glass, Shelf WPL 1124422 Contact Us For Availability

WP2187464 Whirlpool Refrigerator Wire Harness Backorder WPL WP2187464 $46.02

Trim, Compartment Door WPL 1124432 Contact Us For Availability

Clamp WPL 513584 Contact Us For Availability

Retainer, Glass WPL 1123908 Contact Us For Availability

33

8009 Whirlpool 40W 120V Light Bulb In Stock WPL 8009 $6.89

33

WP4387499 Whirlpool Refrigerator Bimetallic D In Stock WPL WP4387499 $43.87

33

Shield, Heat WPL 627751 Contact Us For Availability

34

Heater, Defrost WPL 1106969 Contact Us For Availability

34

Light Lens WPL 1114624 Contact Us For Availability

35

W10190935 Whirlpool Refrigerator Icemaker Mot In Stock WPL W10190935 $54.86

37

Blade, Fan WPL 989524 Contact Us For Availability

212643 Whirlpool Refrigerator Permagum Sealer In Stock WPL 212643 $28.53

489136 Whirlpool Refrigerator Screw Backorder WPL 489136 $4.56

511873 Whirlpool Refrigerator Paint Backorder WPL 511873 $19.22

606755 Whirlpool Refrigerator Bag Backorder WPL 606755 $27.52

72017 Whirlpool Appliance Touch-Up Paint Whit In Stock WPL 72017 $3.51

72032 Whirlpool Touch Up Paint Black In Stock WPL 72032 $15.46

833938 Whirlpool Refrigerator Terminal Backorder WPL 833938 $3.70

876370 Whirlpool Refrigerator Insulation Backorder WPL 876370 $100.80

WP503695 Whirlpool Refrigerator Sealer Backorder WPL WP503695 $41.14

WP505587 Whirlpool Refrigerator Sealer Backorder WPL WP505587 $60.73

WP542638 Whirlpool Refrigerator Grease In Stock WPL WP542638 $23.17

WP72107 Whirlpool Touchup In Stock WPL WP72107 $5.80

WPL 876029 WPL 876029 Contact Us For Availability

TAPE, VINYL (3/4 X 108``) WPL 479502 Contact Us For Availability

PAINT WPL 799344 Contact Us For Availability

Transformer (115-230 Volt) WPL 515393 Contact Us For Availability

CEMENT, ALUMILASTIC (1 1/4 OZ.) WPL 542639 Contact Us For Availability

Enamel, Black (1 Qt. Uncut) WPL 799340 Contact Us For Availability

WPL 799833 WPL 799833 Contact Us For Availability

WPL 799908 WPL 799908 Contact Us For Availability

WPL 978883 WPL 978883 Contact Us For Availability

39

Receptacle, Housing WPL 943647 Contact Us For Availability

40

681390 Whirlpool Refrigerator Screw Backorder WPL 681390 $9.13

42

2304903 Whirlpool Refrigerator Frame Backorder WPL 2304903 $100.60

42

WP1108438 Whirlpool Refrigerator Extension Backorder WPL WP1108438 $10.07

44

833697 Whirlpool Condenser Fan Motor In Stock WPL 833697 $41.18

45

Rail, Front WPL 1105525 Contact Us For Availability

46

489340 Whirlpool Refrigerator Screw Backorder WPL 489340 $4.56

47

Screw, 8 x 3/8 WPL 488624 Contact Us For Availability

48

Bracket, Fan Motor WPL 548695 Contact Us For Availability

49

Baffle, Air WPL 1105530 Contact Us For Availability

51

WP2262181 Whirlpool Refrigerator Start Relay In Stock WPL WP2262181 $53.03

52

Overload WPL 483054 Contact Us For Availability

53

Cover, Terminal WPL 1105015 Contact Us For Availability

54

WP2187501 Whirlpool Refrigerator Wire Harness Backorder WPL WP2187501 $55.06

54

Terminal Strap WPL 938384 Contact Us For Availability

55

Capacitor WPL 482996 Contact Us For Availability

56

Screw, 1/4-28 x 1/2 (2) WPL 488454 Contact Us For Availability

57

Nut WPL 489142 Contact Us For Availability

59

Washer WPL 489143 Contact Us For Availability

60

W10843121 Whirlpool Refrigerator Tube In Stock WPL W10843121 $38.32

61

Overload Spring WPL 1114190 Contact Us For Availability

68

Tray, Evaporator WPL 1105524 Contact Us For Availability

81

Screw, 8-32 x 1/2 WPL 489050 Contact Us For Availability

83

Clamp, Drier WPL 548508 Contact Us For Availability

876764 Whirlpool Refrigerator Primary Valve In Stock WPL 876764 $23.44

978026 Whirlpool Refrigerator Primary Valve In Stock WPL 978026 $33.93

978027 Whirlpool Refrigerator Primary Valve Backorder WPL 978027 $35.65

978030 Whirlpool Refrigerator Valve Backorder WPL 978030 $37.30

WP978025 Whirlpool Refrigerator Valve In Stock WPL WP978025 $27.19

VALVE, ACCESS (5/8``) WPL 978029 Contact Us For Availability

Clamp (4) WPL 1108431 Contact Us For Availability

VALVE, ACCESS (1/2``) WPL 978028 Contact Us For Availability
