Model Whirlpool RS20EKXBL00 – Common Parts &amp; Diagrams

1

Freezer, Door Panel (White) WPL 4362034 Contact Us For Availability

1

Freezer, Door Panel (Almond (Also Order Item WPL 4362035 Contact Us For Availability

1

Control Box WPL 2169147 Contact Us For Availability

1

Liner (Not A Serviceable Part) WPL ARI123856A Contact Us For Availability

1

Liner (Not A Serviceable Part) WPL ARI123855A Contact Us For Availability

1

Refrigerator Door Panel (White) WPL 4362027 Contact Us For Availability

1

Refrigerator Door Panel (Almond (Also Order I WPL 4362028 Contact Us For Availability

2

RETAINER, FAN MOTOR WPL 2155590 Contact Us For Availability

2

Fan, Blade WPL 1108179 Contact Us For Availability

2

Mounting Bracket WPL 1110629 Contact Us For Availability

2

Escutcheon, Meat Pan Control WPL 985468 Contact Us For Availability

3

Screw (2) WPL 489397 Contact Us For Availability

3

Shelf WPL 2163612 Contact Us For Availability

3

Slide, Meat Pan Control WPL 984102 Contact Us For Availability

3

Trim, Shelf (5) WPL 2173190 Contact Us For Availability

4

WP2149705 Whirlpool Refrigerator Door Switch In Stock WPL WP2149705 $23.46

4

Foam Insulation (Required When Replacing Exte WPL 876029 Contact Us For Availability

4

Cover, Wiring WPL 2160912 Contact Us For Availability

4

Pad, Foam WPL 992358 Contact Us For Availability

5

Saddle Stud (Left Side) WPL 1118134 Contact Us For Availability

6

Defrost Timer WPL 2154984 Contact Us For Availability

6

Door, Compartment WPL 2148289 Contact Us For Availability

7

489392 Whirlpool Refrigerator Screw Backorder WPL 489392 $9.59

7

Support, Stud (12) WPL 946355 Contact Us For Availability

7

Ladder, Shelf (2) WPL 1108433 Contact Us For Availability

8

2188404A Whirlpool Refrigerator Door Gasket In Stock WPL 2188404A $125.61

8

4388538 Whirlpool Refrigerator Shelf Stud Kit In Stock WPL 4388538 $11.60

8

489396 Whirlpool Refrigerator Clip Backorder WPL 489396 $4.72

8

940014 Whirlpool Refrigerator Primary Button Backorder WPL 940014 $10.25

8

WP2169142 Whirlpool Fan Blade In Stock WPL WP2169142 $13.65

8

Stud, Front (5) WPL 946356 Contact Us For Availability

9

819091 Whirlpool Refrigerator Shelf Stud In Stock WPL 819091 $13.89

9

WP2198202 Whirlpool Refrigerator Temperature In Stock WPL WP2198202 $45.43

9

Cap, Hinge Sleeve WPL 509929 Contact Us For Availability

2188405A Whirlpool Refrigerator Door Gasket Backorder WPL 2188405A $132.43

WP488488 Whirlpool Refrigerator Screw Backorder WPL WP488488 $3.70

WP965173 Whirlpool Dishwasher Screw Backorder WPL WP965173 $2.64

Handle WPL 2147526 Contact Us For Availability

Grommet (10) WPL 1110779 Contact Us For Availability

11

Shim, Handle (2) WPL 2147097 Contact Us For Availability

11

Cam Assembly WPL 2161250 Contact Us For Availability

1110560 Whirlpool Refrigerator Bearing Backorder WPL 1110560 $4.72

WP2149540 Whirlpool Shelf Support In Stock WPL WP2149540 $4.34

WP939101 Whirlpool Refrigerator Plate Backorder WPL WP939101 $3.70

Shelf (2) WPL 2163613 Contact Us For Availability

4387535 Whirlpool Refrigerator Compressor Rel In Stock WPL 4387535 $72.20

NLA:SCREW Backorder WPL WPW10141645 $3.70

Shim, Hinge (2) WPL 1123515 Contact Us For Availability

Panel, Interior Door WPL 1129241 Contact Us For Availability

Shelf, Cantilever (3) WPL 2163617 Contact Us For Availability

Reinforcement, Handle WPL 1127465 Contact Us For Availability

Trim, Shelf (5) WPL 2173191 Contact Us For Availability

Retainer, Damper WPL 938439 Contact Us For Availability

Shelf WPL 2163616 Contact Us For Availability

Pivot Arm WPL 1110559 Contact Us For Availability

Relay (See Overload) WPL ARI123857A Contact Us For Availability

Insert, Handle WPL 2147581 Contact Us For Availability

Trivet WPL 2148400 Contact Us For Availability

Wire Shelf WPL 2173056 Contact Us For Availability

16

627068 Whirlpool Refrigerator Screw Backorder WPL 627068 $7.52

16

Retainer, Gasket WPL 1117767 Contact Us For Availability

17

Panel, Interior Door WPL 1129249 Contact Us For Availability

4387478 Whirlpool Refrigerator Light Socket In Stock WPL 4387478 $32.34

W11233072 Whirlpool Screw In Stock WPL W11233072 $9.59

WP2148298 Whirlpool Refrigerator Deli Drawer Backorder WPL WP2148298 $98.03

Clip, Defrost Heater WPL 2161324 Contact Us For Availability

Tap, Plate WPL 2155335 Contact Us For Availability

8009 Whirlpool 40W 120V Light Bulb In Stock WPL 8009 $6.89

W11751592 Whirlpool Sleeve In Stock WPL W11751592 $12.17

WP489069 Whirlpool Compactor Screw In Stock WPL WP489069 $2.51

Saddle Stud (Right Side) WPL 1118133 Contact Us For Availability

20

Control Box Harness WPL 2149185 Contact Us For Availability

20

Pan, Meat WPL 2173189 Contact Us For Availability

20

Retainer, Gasket WPL 1118301 Contact Us For Availability

21

WP1115374 Whirlpool Refrigerator Clip Backorder WPL WP1115374 $2.51

21

WP488729 Whirlpool Refrigerator Door Screw In Stock WPL WP488729 $2.64

21

Retainer, Gasket WPL 1117766 Contact Us For Availability

W11566763 Whirlpool Fitting In Stock WPL W11566763 $19.82

WP2188822 Whirlpool Refrigerator Evaporator In Stock WPL WP2188822 $194.99

WP2256085 Whirlpool Refrigerator Retainer Backorder WPL WP2256085 $13.73

Grille WPL 2155476 Contact Us For Availability

CLIP, WIRING WPL 1115375 Contact Us For Availability

4318165 Whirlpool Refrigerator Door Closure C In Stock WPL 4318165 $9.42

WP489478 Whirlpool Refrigerator Screw Backorder WPL WP489478 $2.51

WP841180A Whirlpool Microwave Glass Turntable In Stock WPL WP841180A $3.92

Clip, Heater (2) WPL 2161330 Contact Us For Availability

Connecting Rod WPL 1123959 Contact Us For Availability

833697 Whirlpool Condenser Fan Motor In Stock WPL 833697 $41.18

WP999367 Whirlpool Refrigerator Screw Backorder WPL WP999367 $2.51

WPW10151374 Whirlpool Refrigerator Diffuser In Stock WPL WPW10151374 $35.08

Fastener, Push-On WPL 489285 Contact Us For Availability

Stud, Rear (5) WPL 1106982 Contact Us For Availability

2152019 Whirlpool Refrigerator Cover Backorder WPL 2152019 $34.62

WPW10614158 Whirlpool Refrigerator Evaporator In Stock WPL WPW10614158 $43.29

Bracket, Door Stop WPL 2155334 Contact Us For Availability

Escutcheon, Control Box WPL 2163622 Contact Us For Availability

WP2155013 Whirlpool Refrigerator Clip In Stock WPL WP2155013 $3.70

Harness, Intermediate WPL 2153994 Contact Us For Availability

Handle, Reinforcement WPL 849445 Contact Us For Availability

Cover, Conduit WPL 2150330 Contact Us For Availability

W10759522 Whirlpool Screw Backorder WPL W10759522 $2.51

W10843121 Whirlpool Refrigerator Tube In Stock WPL W10843121 $23.50

WP2196100 Whirlpool Shelf Retainer Bar Suppor In Stock WPL WP2196100 $3.70

Knob, Air Control WPL 1116853 Contact Us For Availability

28

W10309990 Whirlpool Refrigerator Compressor In Stock WPL W10309990 $312.79

28

WP941839 Whirlpool Refrigerator Button Plug In Stock WPL WP941839 $3.70

28

Knob, Retainer WPL 837444 Contact Us For Availability

29

489203 Whirlpool Refrigerator Washer Backorder WPL 489203 $4.36

29

Trim, End Cap WPL 1110713 Contact Us For Availability

29

Seal, Hole WPL 1129056 Contact Us For Availability

30

2215823 Whirlpool Refrigerator Clip Backorder WPL 2215823 $4.61

30

Unit Mounting Frame WPL 2160498 Contact Us For Availability

32

Fan, Motor Bracket WPL 2162062 Contact Us For Availability

33

Heater, Defrost WPL 2161322 Contact Us For Availability

34

Capacitor WPL 2169137 Contact Us For Availability

35

WPW10225581 Whirlpool Refrigerator Defrost Th In Stock WPL WPW10225581 $19.51

36

Nameplate WPL 2163676 Contact Us For Availability

38

WP2172890 Whirlpool Refrigerator Wire Backorder WPL WP2172890 $2.51

39

876811 Whirlpool Grommet Backorder WPL 876811 $3.70

40

489340 Whirlpool Refrigerator Screw Backorder WPL 489340 $4.56

41

Air Baffle WPL 2155301 Contact Us For Availability

42

WP1108438 Whirlpool Refrigerator Extension Backorder WPL WP1108438 $10.07

42

Clip, Heat Shield WPL 2155547 Contact Us For Availability

48

Unit Mounting Rail WPL 2149717 Contact Us For Availability

49

Screw WPL 488624 Contact Us For Availability

50

1105612 Whirlpool Fan Guard Backorder WPL 1105612 $25.31

52

WPW10339879 Whirlpool Wire Tie In Stock WPL WPW10339879 $2.51

53

WP489427 Whirlpool Refrigerator Screw Backorder WPL WP489427 $3.70

54

Wire Connector WPL 850145 Contact Us For Availability

212643 Whirlpool Refrigerator Permagum Sealer In Stock WPL 212643 $28.53

285006 Whirlpool Spray In Stock WPL 285006 $28.82

350930 Whirlpool White Spray Paint In Stock WPL 350930 $13.12

350942 Whirlpool Spray Paint Backorder WPL 350942 $32.57

350956 Whirlpool Spray Assembly In Stock WPL 350956 $19.22

511873 Whirlpool Refrigerator Paint Backorder WPL 511873 $19.22

606755 Whirlpool Refrigerator Bag Backorder WPL 606755 $27.52

72017 Whirlpool Appliance Touch-Up Paint Whit In Stock WPL 72017 $4.41

72032 Whirlpool Touch Up Paint Black In Stock WPL 72032 $5.93

72110 Whirlpool Dryer Touch-Up Paint, Golden In Stock WPL 72110 $10.07

72113 Whirlpool Touch-Up Paint Backorder WPL 72113 $10.07

833938 Whirlpool Refrigerator Terminal Backorder WPL 833938 $3.70

876370 Whirlpool Refrigerator Insulation Backorder WPL 876370 $100.80

876764 Whirlpool Refrigerator Primary Valve In Stock WPL 876764 $23.44

978026 Whirlpool Refrigerator Primary Valve In Stock WPL 978026 $33.93

978027 Whirlpool Refrigerator Primary Valve Backorder WPL 978027 $35.65

978030 Whirlpool Refrigerator Valve Backorder WPL 978030 $37.30

W11729596 Whirlpool Ice Maker Field Install K In Stock WPL W11729596 $105.37

WP503695 Whirlpool Refrigerator Sealer Backorder WPL WP503695 $41.14

WP505587 Whirlpool Refrigerator Sealer Backorder WPL WP505587 $60.73

WP542638 Whirlpool Refrigerator Grease In Stock WPL WP542638 $23.17

WP72107 Whirlpool Touchup In Stock WPL WP72107 $6.13

WP978025 Whirlpool Refrigerator Valve In Stock WPL WP978025 $27.19

WPL 978029 WPL 978029 Contact Us For Availability

TAPE, VINYL (3/4 X 108``) WPL 479502 Contact Us For Availability

WPL 799344 WPL 799344 Contact Us For Availability

Torx Key WPL 1117510 Contact Us For Availability

Clip, Wire And Water Tube WPL 2155658 Contact Us For Availability

xEnamel, Golden Wheat (13 Oz. Spray Can) WPL 261890 Contact Us For Availability

Enamel, Golden Wheat (1 Qt. Uncut) WPL 261891 Contact Us For Availability

Paint, Spray (13 Oz.) (Toast) WPL 285365 Contact Us For Availability

Paint, Spray (13 Oz.) (Platinum) WPL 285366 Contact Us For Availability

Enamal, Toast (1 Qt. Uncut) WPL 285367 Contact Us For Availability

Enamel, Platinum (1 Qt. Uncut) WPL 285368 Contact Us For Availability

Leveler, Enamel (13 Oz. Spray Can) WPL 350941 Contact Us For Availability

WPL 515393 WPL 515393 Contact Us For Availability

WPL 542639 WPL 542639 Contact Us For Availability

WPL 72112 WPL 72112 Contact Us For Availability

WPL 799340 WPL 799340 Contact Us For Availability

WPL 799833 WPL 799833 Contact Us For Availability

WPL 978028 WPL 978028 Contact Us For Availability

WPL 978883 WPL 978883 Contact Us For Availability
