Model Electrolux REGS37BFW1 RANGE – Common Parts & Diagrams
02 - BACKGUARD
03 - DOOR PARTS
04 - BODY PARTS
05 - COOKTOP PARTS
06 - DRAWER PARTS
07 - BROILER PARTS
Common parts from model Electrolux REGS37BFW1 RANGE
*19316
WCI 3934063 WCI 3934063 Contact Us For Availability
1
GLASS - OUTER WCI 08012546 Contact Us For Availability
1
SIDE PNL - RH (WHITE) WCI 08012527 Contact Us For Availability
1
WCI 08014244 WCI 08014244 Contact Us For Availability
1
WCI 08011051 WCI 08011051 Contact Us For Availability
1
WCI 08014249 WCI 08014249 Contact Us For Availability
1A
SURFACE UNIT LARGE WCI 08014263 Contact Us For Availability
1B
SURFACE UNIT - AUTO WCI 08014251 Contact Us For Availability
2
FRAME - DOOR WCI 08015938 Contact Us For Availability
2
PIN, HINGE (2) WCI 08012537 Contact Us For Availability
2
PANEL - WHITE WCI 08011056 Contact Us For Availability
2
WCI 08014264 WCI 08014264 Contact Us For Availability
2A
SWITCH - S/U AUTO WCI 3051682 Contact Us For Availability
2A
PAN - LARGE WCI 08014252 Contact Us For Availability
2C
WCI K005129701 WCI K005129701 Contact Us For Availability
3
WCI 08014203 WCI 08014203 Contact Us For Availability
3
STRIKE WCI 3051707 Contact Us For Availability
3
BUMPER - COOKTOP (4) WCI 08003107 Contact Us For Availability
3
WCI 08014262 WCI 08014262 Contact Us For Availability
3
HANDLE WCI K1317834 Contact Us For Availability
3
WCI 08014254 WCI 08014254 Contact Us For Availability
4
LIGHT - IND S/U WCI 08950022 Contact Us For Availability
4
WCI 3017634 WCI 3017634 Contact Us For Availability
4
RETAINER - INSUL (2) WCI 08012235 Contact Us For Availability
4
WCI 08012710 WCI 08012710 Contact Us For Availability
4
GLIDE (2) WCI 08011050 Contact Us For Availability
4A
LIGHT, IND OVEN WCI 08012515 Contact Us For Availability
4B
LIGHT - IND CLEAN WCI 08012563 Contact Us For Availability
5
LENS - IND LIGHT (3) WCI 08012578 Contact Us For Availability
5
GASKET - OVEN DOOR WCI 3051704 Contact Us For Availability
5
LEG, LEVELLER (4) WCI 3205294 Contact Us For Availability
6
SWITCH - SELECT WCI 3051684 Contact Us For Availability
6
WCI 3008673 WCI 3008673 Contact Us For Availability
6
WCI 08015746 WCI 08015746 Contact Us For Availability
6
HANGER, BROIL ELEMENT WCI 3051518 Contact Us For Availability
6A
RAIL, DRAWER LH WCI 3051652 Contact Us For Availability
7
WCI 3203186 WCI 3203186 Contact Us For Availability
7
WINDOW ASSEMBLY WCI 3205235 Contact Us For Availability
7
WCI 08003103 WCI 08003103 Contact Us For Availability
7
WCI 08016255 WCI 08016255 Contact Us For Availability
8
BULB - FLUORESCENT WCI 08012712 Contact Us For Availability
8
WCI 3051716 WCI 3051716 Contact Us For Availability
8
PLUG BUTTON-OVEN LIGHT HOLE WCI 3051784 Contact Us For Availability
9
WCI 08016520 WCI 08016520 Contact Us For Availability
9
STANCHION - HANDLE WCI 3009124 Contact Us For Availability
9
OVEN LINER WCI 3204603 Contact Us For Availability
10
WCI 3051511 WCI 3051511 Contact Us For Availability
10
BRACKET, LAMP (2) WCI 08012748 Contact Us For Availability
10
BUTTON PLUG WCI 3051807 Contact Us For Availability
11
WCI 08012577 WCI 08012577 Contact Us For Availability
11
WCI 08004957 WCI 08004957 Contact Us For Availability
12
BRACKET, CLOCK WCI 08015861 Contact Us For Availability
12
WASHER-PADDED WCI 08002847 Contact Us For Availability
13
SWITCH - FLUORESCENT WCI 08012754 Contact Us For Availability
13
WCI 3017530 WCI 3017530 Contact Us For Availability
13
WCI 08011087 WCI 08011087 Contact Us For Availability
14
WCI 08012745 WCI 08012745 Contact Us For Availability
14
WCI 3051822 WCI 3051822 Contact Us For Availability
14A
WCI 08012746 WCI 08012746 Contact Us For Availability
15
SUPT, BACKGUARD RH WCI 08015966 Contact Us For Availability
15
DOOR - SPRING WCI 08003186 Contact Us For Availability
15
WCI 08011055 WCI 08011055 Contact Us For Availability
15A
SUPT, BACKGUARD LH WCI 08015967 Contact Us For Availability
16
WCI 08012538 WCI 08012538 Contact Us For Availability
16
WCI 08012564 WCI 08012564 Contact Us For Availability
16
GRILLE, BROILER WCI 3205234 Contact Us For Availability
17
WCI 08003125 WCI 08003125 Contact Us For Availability
17
WCI 08003183 WCI 08003183 Contact Us For Availability
17
WCI 3205232 WCI 3205232 Contact Us For Availability
18
KNOB - S/U (6) WCI 08015741 Contact Us For Availability
18
WCI 3051714 WCI 3051714 Contact Us For Availability
18A
RACK-OVEN, OFFSET WCI 08014219 Contact Us For Availability
19
WCI 3016387 WCI 3016387 Contact Us For Availability
19
WCI 3051711 WCI 3051711 Contact Us For Availability
20
WCI 08012708 WCI 08012708 Contact Us For Availability
20
WCI 3051712 WCI 3051712 Contact Us For Availability
20
WCI 08003146 WCI 08003146 Contact Us For Availability
21
WCI 3205397 WCI 3205397 Contact Us For Availability
21
RIVET - SQ. HEAD (2) WCI 08012004 Contact Us For Availability
21
CHANNEL - OVEN SUPPORT LOWER WCI 3200927 Contact Us For Availability
22
WCI 3051862 WCI 3051862 Contact Us For Availability
22
PANEL - BOTTOM WCI 3203574 Contact Us For Availability
24
ROLLER - PACKAGE OVEN DOOR (2) WCI 08950070 Contact Us For Availability
25
WCI 3008677 WCI 3008677 Contact Us For Availability
25
PLUG BUTTON - THERMO BULB HOLE WCI 3051796 Contact Us For Availability
26
WCI 3051713 WCI 3051713 Contact Us For Availability
26
BRACKET - THERMO BULB WCI 3051552 Contact Us For Availability
27
WCI 3051706 WCI 3051706 Contact Us For Availability
27
CHANNEL, OVEN SUPPORT UPPER WCI 3203178 Contact Us For Availability
28
WCI 08015742 WCI 08015742 Contact Us For Availability
29
WCI 3051630 WCI 3051630 Contact Us For Availability
30
WCI 3017481 WCI 3017481 Contact Us For Availability
30A
WCI 3017482 WCI 3017482 Contact Us For Availability
31
WCI 3051856 WCI 3051856 Contact Us For Availability
32
WCI 3017575 WCI 3017575 Contact Us For Availability
33
WCI 08014247 WCI 08014247 Contact Us For Availability
33A
WCI 08002487 WCI 08002487 Contact Us For Availability
34
SWITCH - DOOR WCI 08003081 Contact Us For Availability
35
WCI 3051645 WCI 3051645 Contact Us For Availability
36
WCI 08007444 WCI 08007444 Contact Us For Availability
37
WCI 08014259 WCI 08014259 Contact Us For Availability
38
WCI 08014260 WCI 08014260 Contact Us For Availability
39
GASKET, OVEN VENT TUBE WCI 3051666 Contact Us For Availability
40
BRACKET, DR LATCH SW WCI 3051643 Contact Us For Availability
41
VENT TUBE WCI 08012752 Contact Us For Availability
42
WCI 08015743 WCI 08015743 Contact Us For Availability
46
LATCH-DOOR WCI 3051648 Contact Us For Availability
47
HOUSING, DR LATCH WCI 3051647 Contact Us For Availability
48
WCI 08003184 WCI 08003184 Contact Us For Availability
49
WCI 3051649 WCI 3051649 Contact Us For Availability
50
SWITCH - LOWER WCI 3007889 Contact Us For Availability
51
WCI 08003090 WCI 08003090 Contact Us For Availability
52
SWITCH - UPPER WCI 08003092 Contact Us For Availability
53
WCI 3009190 WCI 3009190 Contact Us For Availability
54
RETAINER-DOOR WCI 3051810 Contact Us For Availability
55
COVER, ROD END WCI 3051251 Contact Us For Availability
× ![]()
