Model Electrolux REG638BNW3 RANGE – Common Parts &amp; Diagrams

*68004

5303300265 Frigidaire Oven Screw Backorder WCI 5303300265 $9.04

*68004

FOIL-ALUM BLK WCI 5303208656 Contact Us For Availability

1

316442301 Frigidaire Oven 8 Coil Element 2600 In Stock WCI 316442301 $47.77

1

SPACER-BDYSDE (8) WCI 3014099 Contact Us For Availability

1

WCI 5303013511 WCI 5303013511 Contact Us For Availability

1

FRAME-CHANNEL WCI 316013300 Contact Us For Availability

1

BRACKET-GLASS (2) WCI 5303209510 Contact Us For Availability

1

DRAWER-UTILITY WCI 316011501 Contact Us For Availability

1A

318372211 Frigidaire Oven 6" Electric Range B In Stock WCI 318372211 $31.30

2

3051163 Frigidaire Oven Range Rear Broiler Dr In Stock WCI 3051163 $2.37

2

316048413 Frigidaire Oven Range Chrome 8" Dri In Stock WCI 316048413 $6.38

2

BRACKET-HNG-LH WCI 08067746 Contact Us For Availability

2

FRAME-CHANNEL END WCI 5303290772 Contact Us For Availability

2

GLASS-HEAT BARRIER CTNG WCI 5303209513 Contact Us For Availability

2

WCI 5303293168 WCI 5303293168 Contact Us For Availability

2A

316048414 Frigidaire Oven Range Chrome 6" Dri In Stock WCI 316048414 $4.91

2A

BRACKET-HNG-RH WCI 08067747 Contact Us For Availability

2A

INSULATION-BOTTOM 1 1/2 X 13 X 221/2 (NON-ILL WCI 3015590 Contact Us For Availability

2B

INSULATION-TOP 3 X 12 1/2 X 24 (NON-ILLUSTRAT WCI 3015588 Contact Us For Availability

2C

INSULATION-BACK & SIDE 2 X 6 X 50 (NON-ILLUST WCI 3015591 Contact Us For Availability

3

5303284616 Frigidaire Range Bulb Clip Thermos In Stock WCI 5303284616 $5.88

3

BULB-FLOUR WORK LIGHT WCI 3131275 Contact Us For Availability

3

WCI 5303209512 WCI 5303209512 Contact Us For Availability

3

TOP SUPT ROD (2) WCI 5303271609 Contact Us For Availability

3

GUSSETT-CORNER (2) WCI 08011727 Contact Us For Availability

3

WCI 5308067828 WCI 5308067828 Contact Us For Availability

3

PANEL-DRAWER (BLACK) WCI 3131324 Contact Us For Availability

3

WCI 5303269519 WCI 5303269519 Contact Us For Availability

3A

WCI 5303269518 WCI 5303269518 Contact Us For Availability

4

WCI 5303206607 WCI 5303206607 Contact Us For Availability

4

SPACER-GLASS (2) WCI 08011721 Contact Us For Availability

4

WCI 5303209517 WCI 5303209517 Contact Us For Availability

4

HANDLE WCI 5303280334 Contact Us For Availability

4

BOX-LIGHT WCI 5303290773 Contact Us For Availability

4

WCI 5303271658 WCI 5303271658 Contact Us For Availability

5

316075103 Frigidaire Range Bake Element In Stock WCI 316075103 $14.21

5

5303935058 Frigidaire Oven Burner Receptacle In Stock WCI 5303935058 $4.58

5

RECEPTACLE-FLUOR LIGHT (2) WCI 5303935003 Contact Us For Availability

5

WCI 3051354 WCI 3051354 Contact Us For Availability

5

WCI 5303272140 WCI 5303272140 Contact Us For Availability

5

WCI 5303209511 WCI 5303209511 Contact Us For Availability

5

WCI 3131975 WCI 3131975 Contact Us For Availability

5

WCI 08067757 WCI 08067757 Contact Us For Availability

5A

5303307010 Frigidaire Bake Element In Stock WCI 5303307010 $98.15

5A

WCI 3051355 WCI 3051355 Contact Us For Availability

6

5303051140 Frigidaire Broil Element In Stock WCI 5303051140 $121.22

6

THERMO-OVEN-UPPER WCI 5303202782 Contact Us For Availability

6

GLASS-INNER WCI 08011722 Contact Us For Availability

6

WCI 3051465 WCI 3051465 Contact Us For Availability

6

GLASS-FRONT VISULITE WCI 5303210941 Contact Us For Availability

6

FASTENER-SPACER (2) WCI 3131387 Contact Us For Availability

6

WCI 3203032 WCI 3203032 Contact Us For Availability

6A

THERMO-OVEN-LOWER WCI 5303051320 Contact Us For Availability

6A

ELEMENT-BROIL, UPPER WCI 3015187 Contact Us For Availability

7

316203400 Frigidaire Oven Support Backorder WCI 316203400 $41.86

7

GUSSET-SUPT LH WCI 3200527 Contact Us For Availability

7

STRIKE-DOOR WCI 5303935001 Contact Us For Availability

7

WCI 5303285070 WCI 5303285070 Contact Us For Availability

7

LENS-OVEN LIGHT WCI 08011668 Contact Us For Availability

7

SHIELD-LOWER WALL WCI 3203549 Contact Us For Availability

7A

GUSSET-SUPT RH WCI 3200526 Contact Us For Availability

7A

SUPT-ELMNT-UPPER WCI 3015584 Contact Us For Availability

8

HANDLE WCI 08011729 Contact Us For Availability

8

GLASS-SPLASHER O/U WCI 08067736 Contact Us For Availability

8

LINER WCI 5303209515 Contact Us For Availability

8

COVER LENS WCI 08011669 Contact Us For Availability

8

WCI 3203405 WCI 3203405 Contact Us For Availability

9

5303131601 Frigidaire Oven Seal Backorder WCI 5303131601 $203.31

9

PANEL-SPLASHER-UPPER WCI 316012900 Contact Us For Availability

9

SPACER WCI 3051302 Contact Us For Availability

9

WCI 5303934091 WCI 5303934091 Contact Us For Availability

9

COVER-FLUE WCI 3051368 Contact Us For Availability

316067902 Frigidaire Oven Rack Backorder WCI 316067902 $65.19

WCI 5303051115 WCI 5303051115 Contact Us For Availability

WCI 5303211084 WCI 5303211084 Contact Us For Availability

RACK-OVEN WCI 08011675 Contact Us For Availability

11

WCI 5303209518 WCI 5303209518 Contact Us For Availability

11

PANEL-TOP WCI 3131625 Contact Us For Availability

11

SCREW-LEVELING (4) WCI 3206285 Contact Us For Availability

WCI 5303280308 WCI 5303280308 Contact Us For Availability

COVER HNG. CUTOUT (2) WCI 3131570 Contact Us For Availability

TRIM-O/U SPL GL FILLER WCI 5303209039 Contact Us For Availability

BACK-OVEN WALL-UPR WCI 3051236 Contact Us For Availability

WCI 08067742 WCI 08067742 Contact Us For Availability

SCREW 8-18 X 1/2 BLK WCI 5303269859 Contact Us For Availability

PNL-BDYSDE-LH-WHITE WCI 5303269987 Contact Us For Availability

WCI 3200825 WCI 3200825 Contact Us For Availability

13A

PNL-BDYSDE-RH-WHTE WCI 3051263 Contact Us For Availability

CHANNEL-DOOR HNG (2) WCI 316007002 Contact Us For Availability

TRIM-LH WCI 5303269815 Contact Us For Availability

ANGLE SUPT S/C THERMO WCI 3051348 Contact Us For Availability

INSULATION-WOOL WCI 5303209514 Contact Us For Availability

14A

TRIM-RH WCI 08010549 Contact Us For Availability

RECEPTACLE-STARTER WCI 5303282715 Contact Us For Availability

WCI 5303211085 WCI 5303211085 Contact Us For Availability

HINGE-TOP WCI 3131613 Contact Us For Availability

WCI 3203540 WCI 3203540 Contact Us For Availability

16

STARTER WCI 3206218 Contact Us For Availability

16

FUSE, THERMAL CUTOUT WCI 5303051385 Contact Us For Availability

16

HINGE-BOTTOM WCI 5303051166 Contact Us For Availability

17

5308015487 Frigidaire Oven Light Switch Backorder WCI 5308015487 $36.70

17

PLATE-HINGE WCI 08011665 Contact Us For Availability

17

WCI 5303013568 WCI 5303013568 Contact Us For Availability

18

SCREW 10-32 SHLDR SPECIAL (2) WCI 5308011685 Contact Us For Availability

18

WCI 5303131356 WCI 5303131356 Contact Us For Availability

19

5304409888 Frigidaire Oven Terminal Block Ass In Stock WCI 5304409888 $16.27

19

WASHER-HINGE (2) WCI 3131737 Contact Us For Availability

20

SHIELD-WOOL SIDE WCI 5303208706 Contact Us For Availability

20

WCI 5303212739 WCI 5303212739 Contact Us For Availability

21

WCI 08011680 WCI 08011680 Contact Us For Availability

21

CLIP-THERMAL BULB (2) WCI 08067754 Contact Us For Availability

22

3051162 Frigidaire Oven Range Front Broiler D In Stock WCI 3051162 $1.76

22

SEAL-DOOR-SIDES (2) WCI 316024201 Contact Us For Availability

23

SEAL-DOOR-TOP & BOTTOM (2) WCI 316024200 Contact Us For Availability

23

WCI 3051367 WCI 3051367 Contact Us For Availability

24

5304524341 Frigidaire Lens In Stock WCI 5304524341 $9.87

24

WCI 08067732 WCI 08067732 Contact Us For Availability

25

316403803 Frigidaire Insulation In Stock WCI 316403803 $28.09

25

STRIKE-DOOR WCI 316012800 Contact Us For Availability

26

5304442087 Frigidaire Range Wall Oven Broil P Backorder WCI 5304442087 $33.26

26

WCI 3051344 WCI 3051344 Contact Us For Availability

27

WIRE GLASS RETAINER WCI 3204585 Contact Us For Availability

27A

FUSE THERMAL CUTOUT (NON-ILLUSTRATED) WCI 5303203651 Contact Us For Availability

27A

INSULATION-WRAP (NON-ILLUSTRATED) WCI 3200833 Contact Us For Availability

27B

WIRING DIAGRAM (NOT FOR PURCHASE) (NON-ILLUST WCI 19100230001 Contact Us For Availability

27C

3131903 Frigidaire Door/Drawer Bumper Backorder WCI 3131903 $33.06

28

OVEN BOTTOM WCI 08016605 Contact Us For Availability

28

WCI 5303015361 WCI 5303015361 Contact Us For Availability

29

WCI 5303131357 WCI 5303131357 Contact Us For Availability

30

WCI 3203218 WCI 3203218 Contact Us For Availability

30A

WCI 08013188 WCI 08013188 Contact Us For Availability

31

SHIELD-LATCH WCI 3131593 Contact Us For Availability

32

SHIELD-BI MTL LATCH WCI 3051413 Contact Us For Availability

33

FASTNR-PUSHON (3) WCI 08067776 Contact Us For Availability

34

WCI 08067781 WCI 08067781 Contact Us For Availability

35

316116400 Frigidaire Oven Light Socket In Stock WCI 316116400 $40.25

36

316538904 Frigidaire Oven Light Lamp In Stock WCI 316538904 $10.61

37

WCI 08067810 WCI 08067810 Contact Us For Availability

38

WCI 08010606 WCI 08010606 Contact Us For Availability

39

SWITCH, DOOR WCI 5303202622 Contact Us For Availability

40

BRACKET-LT SWITCH WCI 5303131289 Contact Us For Availability

41

RODLIGHT WCI 5303269501 Contact Us For Availability

42

WCI 3200848 WCI 3200848 Contact Us For Availability

42A

SHIELD-HEAT BODYSIDE (2) (NON-ILLUSTRATED) WCI 3200834 Contact Us For Availability

42B

FASTENER-EDGE MOUNT (2) (NON-ILLUSTRATED) WCI 3200846 Contact Us For Availability

43

TRIM-VERTICAL BODYSIDE (2) WCI 5303051326 Contact Us For Availability

44

WCI 5303208642 WCI 5303208642 Contact Us For Availability

44A

TUBE-POST RH WCI 5303208643 Contact Us For Availability

44B

ANTI-TIP KIT (NON-ILLUSTRATED) WCI 3934056 Contact Us For Availability

45

WCI 3203582 WCI 3203582 Contact Us For Availability

45A

WCI 3204582 WCI 3204582 Contact Us For Availability

45B

INSULATION-TOP (NON-ILLUSTRATED) WCI 3131304 Contact Us For Availability

45C

STUD SPACER (2) (NON-ILLUSTRATED) WCI 08067978 Contact Us For Availability

45D

3203550 Frigidaire Oven Plug Backorder WCI 3203550 $9.08

46

COVER-ROD END WCI 5303285692 Contact Us For Availability
