Model Frigidaire MEF350SFWB RANGE – Common Parts & Diagrams

*
Screw,cup pt ,#8-18 x 3/8 ,hinge ,
Screw,cup pt ,#8-18 x 3/8 ,hinge , WCI 316021108 Contact Us For Availability
View on Model
*
Screw, waf hd sdr , 10-32 x 5/16 , (2)
Screw, waf hd sdr , 10-32 x 5/16 , (2) WCI 5303280311 Contact Us For Availability
View on Model
*
Harness-wiring,surface element
Harness-wiring,surface element WCI 316001725 Contact Us For Availability
View on Model
*
Spacer-drawer,(2)
Spacer-drawer,(2) WCI 316089600 Contact Us For Availability
View on Model
*
Rivet-pop,warning-plate
Rivet-pop,warning-plate WCI 3203618 Contact Us For Availability
View on Model
*
Plate warning/caution
Plate warning/caution WCI 316065301 Contact Us For Availability
View on Model
*
Screw,cr pan hd sems ,8-32BP x 1.00
Screw,cr pan hd sems ,8-32BP x 1.00 WCI 5303212671 Contact Us For Availability
View on Model
*
Screw-switch/handle,8-32 x 5/32
Screw-switch/handle,8-32 x 5/32 WCI 5303292005 Contact Us For Availability
View on Model
1
Drawer-utility
Drawer-utility WCI 316011501 Contact Us For Availability
View on Model
2
Shield-panel
Shield-panel WCI 3131975 Contact Us For Availability
View on Model
3
Trim-oven door,black
Trim-oven door,black WCI 316067802 Contact Us For Availability
View on Model
4
Panel-drawer,almond
Panel-drawer,almond WCI 316084406 Contact Us For Availability
View on Model
4
Glass-oven door,black ,outer
Glass-oven door,black ,outer WCI 316089001 Contact Us For Availability
View on Model
4*
Screw,hex washer head ,8-18AB x 1/2
Screw,hex washer head ,8-18AB x 1/2 WCI 08067785 Contact Us For Availability
View on Model
5
Screw-leveling
Screw-leveling WCI 5303203397 Contact Us For Availability
View on Model
5*
Anti-tip Kit
Anti-tip Kit WCI 3934058 Contact Us For Availability
View on Model
6
Shield-wool
Shield-wool WCI 316091402 Contact Us For Availability
View on Model
7
Insulation,oven door
Insulation,oven door WCI 316076400 Contact Us For Availability
View on Model
7
Insulation,oven door
Insulation,oven door WCI 316076404 Contact Us For Availability
View on Model
9
Liner-oven door
Liner-oven door WCI 316066611 Contact Us For Availability
View on Model
10
Screw-handle mtg,wafer head ,10-24F x 3
Screw-handle mtg,wafer head ,10-24F x 3 WCI 5303281378 Contact Us For Availability
View on Model
16
Main Top,almond
Main Top,almond WCI 316020908 Contact Us For Availability
View on Model
18
Hinge-main top,RH
Hinge-main top,RH WCI 5303273062 Contact Us For Availability
View on Model
18A
Hinge-main top,LH
Hinge-main top,LH WCI 5303273063 Contact Us For Availability
View on Model
21
Spacer-bodyside, (8)
Spacer-bodyside, (8) WCI 3014099 Contact Us For Availability
View on Model
28
Medallion,stainless steel ,surf elem
Medallion,stainless steel ,surf elem WCI 3017801 Contact Us For Availability
View on Model
30A
Bracket-hinge,main top LH
Bracket-hinge,main top LH WCI 5303283575 Contact Us For Availability
View on Model
32
Knob-thermostat
Knob-thermostat WCI 316101301 Contact Us For Availability
View on Model
36
Knob-control,(6)
Knob-control,(6) WCI 316015203 Contact Us For Availability
View on Model
39
Handle-door,black ,oven
Handle-door,black ,oven WCI 316020204 No Longer Available
View on Model
41
Cover-hinge cutout
Cover-hinge cutout WCI 3131570 Contact Us For Availability
View on Model
52
Shield-oven door,black ,top
Shield-oven door,black ,top WCI 316081303 Contact Us For Availability
View on Model
57
Cover-access
Cover-access WCI 316081101 Contact Us For Availability
View on Model
58A
Insulation, 2" ,oven wrapper
Insulation, 2" ,oven wrapper WCI 316047708 Contact Us For Availability
View on Model
58B
Insulation, 2" ,oven back
Insulation, 2" ,oven back WCI 316054200 Contact Us For Availability
View on Model
59
Tube-oven vent
Tube-oven vent WCI 316073600 Contact Us For Availability
View on Model
63
Plate-ground strap
Plate-ground strap WCI 5301145190 Contact Us For Availability
View on Model
71
Shield-rear wall
Shield-rear wall WCI 316015805 Contact Us For Availability
View on Model
72
Cover-light rod
Cover-light rod WCI 5303285692 Contact Us For Availability
View on Model
82
Shield-insulation
Shield-insulation WCI 5303289913 Contact Us For Availability
View on Model
88
Rod-latch,auto
Rod-latch,auto WCI 316026400 Contact Us For Availability
View on Model
