Model Electrolux LGGF3042KFU RANGE/OVEN, GAS, FREESTANDING, 30 INCH – Common Parts &amp; Diagrams

1

316408706 Frigidaire Oven Drawer Assembly In Stock WCI 316408706 $65.66

1

SHIELD, REAR WALL WCI 316557600 Contact Us For Availability

2

5304506550 Frigidaire Oven Gas Range Valve (W Backorder WCI 5304506550 $31.63

2

5304527988 Frigidaire Liner Backorder WCI 5304527988 $15.59

2A

5304506547 Frigidaire Oven Valve In Stock WCI 5304506547 $40.11

2B

5304506549 Frigidaire Oven Valve In Stock WCI 5304506549 $41.01

2C

5304506548 Frigidaire Oven Valve In Stock WCI 5304506548 $48.06

3

5304506557 Frigidaire Oven Harness Backorder WCI 5304506557 $59.51

4

316452722 Frigidaire Oven Glass Backorder WCI 316452722 $145.79

4

5304494412 Frigidaire Oven Panel Backorder WCI 5304494412 $56.41

5

316272900 Frigidaire Oven Leg Levelling Plast In Stock WCI 316272900 $8.46

5A

5304509869 Frigidaire Oven Leveling Leg Assem In Stock WCI 5304509869 $3.55

6

316402316 Frigidaire Shield Backorder WCI 316402316 $51.57

6

316496201 Frigidaire Oven Rack In Stock WCI 316496201 $56.76

7

316403900 Frigidaire Insulation Backorder WCI 316403900 $44.97

7

316407402 Frigidaire Range Drawer Glide In Stock WCI 316407402 $5.78

7

316546300 Frigidaire Coupler Link Arm In Stock WCI 316546300 $13.35

8

316400603 Frigidaire Oven Stove Bottom Panel Backorder WCI 316400603 $105.46

8

5304503232 Frigidaire Oven Inner Door Glass In Stock WCI 5304503232 $72.74

8

808608804 Frigidaire Oven Gas Range Spark Mod In Stock WCI 808608804 $52.87

9

PAN, BROILER OPTIONAL ACCESSORY WCI 316081900 Contact Us For Availability

9

LINER, OVEN DOOR WCI 316423811 Contact Us For Availability

10

316438400 Frigidaire Range Sealed Burner, 16/ In Stock WCI 316438400 $48.50

10

SCREW, HANDLE MTG., 10-24 X 1.75", (2) WCI 316439500 Contact Us For Availability

10

INSERT, BROILER PAN OPTIONAL ACCESSORY WCI 316082000 Contact Us For Availability

10A

316438200 Frigidaire Range Sealed Burner, 5K In Stock WCI 316438200 $35.65

10B

316008401 Frigidaire Washer P-1 In Stock WCI 316008401 $7.11

10B

316438600 Frigidaire Range Sealed Burner, 14K Backorder WCI 316438600 $49.38

10C

316558300 Frigidaire Oven 9.5L Sealed Burner In Stock WCI 316558300 $32.96

11

316536622 Frigidaire Igniter Orifice Assembly In Stock WCI 316536622 $107.15

11A

316536610 Frigidaire Igniter Assembly/Orifice In Stock WCI 316536610 $57.31

11B

316536616 Frigidaire Igniter/Orifice Assembly Backorder WCI 316536616 $94.31

11C

316536602 Frigidaire Oven Igniter/Orifice Ass In Stock WCI 316536602 $77.14

11D

316536623 Frigidaire Igniter/Orifice Assembly In Stock WCI 316536623 $89.18

12

316445500 Frigidaire Oven Switch Backorder WCI 316445500 $37.48

12

316540900 Frigidaire Oven Screw In Stock WCI 316540900 $8.89

12

5304498835 Frigidaire Oven Seal In Stock WCI 5304498835 $62.59

13

316489101 Frigidaire Suppl Tube-Manifold Backorder WCI 316489101 $63.49

13

316604011 Frigidaire Panel Backorder WCI 316604011 $87.76

14

316091711 Frigidaire Regulator Assembly In Stock WCI 316091711 $60.82

14

316116400 Frigidaire Oven Light Socket In Stock WCI 316116400 $36.58

14

316572700 Frigidaire Oven Nameplate Backorder WCI 316572700 $50.69

15

316091600 Frigidaire Oven Bracket Backorder WCI 316091600 $42.77

15

316538904 Frigidaire Oven Light Lamp In Stock WCI 316538904 $10.44

15

316546710 Frigidaire Oven Cap Backorder WCI 316546710 $72.56

15A

CAP, BACKGUARD, BLACK, LH END WCI 316546703 Contact Us For Availability

16

5304507348 Frigidaire Oven Tube Backorder WCI 5304507348 $27.63

16

5304524341 Frigidaire Lens In Stock WCI 5304524341 $8.02

16

MAINTOP PANEL, BLACK WCI 316469661 Contact Us For Availability

17

316031501 Frigidaire Oven Valve In Stock WCI 316031501 $168.94

17

316087500 Frigidaire Oven Retainer Backorder WCI 316087500 $35.65

17

5304504811 Frigidaire Glass Spacer In Stock WCI 5304504811 $14.70

18

316404400 Frigidaire Oven Burner In Stock WCI 316404400 $64.80

18

316405800 Frigidaire Assembly Latch Backorder WCI 316405800 $29.00

18

LINK, DOOR, (2), AUTO RACK WCI 316547900 Contact Us For Availability

19

316572406 Frigidaire Control Panel Backorder WCI 316572406 $149.53

19

5304506545 Frigidaire Gas Oven Range Igniter In Stock WCI 5304506545 $70.07

316284100 Frigidaire Oven Spacer Assembly In Stock WCI 316284100 $9.35

316499502 Frigidaire Oven Grate In Stock WCI 316499502 $160.36

5304510580 Frigidaire Oven Clock In Stock WCI 5304510580 $171.81

5304519024 Frigidaire Oven Baffle Backorder WCI 5304519024 $46.72

20A

316419339 Frigidaire Oven Overlay Backorder WCI 316419339 $30.30

20A

316551802 Frigidaire Oven Grate Backorder WCI 316551802 $175.11

21

316408000 Frigidaire Oven Clip Assembly Backorder WCI 316408000 $10.68

21

316546605 Frigidaire Oven Cap Backorder WCI 316546605 $40.99

21

5303013272 Frigidaire Oven Nut Backorder WCI 5303013272 $11.11

22

316286300 Frigidaire Bodyside Bracket Backorder WCI 316286300 $11.13

22

5304507768 Frigidaire Oven Tube Backorder WCI 5304507768 $29.41

22

5304508468 Frigidaire Oven Cap Assembly In Stock WCI 5304508468 $28.07

22A

5304508441 Frigidaire Oven Surface Burner Cap In Stock WCI 5304508441 $20.05

22B

5304508443 Frigidaire Oven Surface Burner Cap In Stock WCI 5304508443 $26.28

22C

5304508442 Frigidaire Oven Surface Burner Cap In Stock WCI 5304508442 $20.95

23

316404302 Frigidaire Oven Burner Backorder WCI 316404302 $64.78

23

316575906 Frigidaire Oven Hinge Backorder WCI 316575906 $54.22

24

5304516894 Frigidaire Oven Elbow Assembly Backorder WCI 5304516894 $50.69

25

316406200 Frigidaire Oven Shield Assembly Backorder WCI 316406200 $51.14

25

5304497666 Frigidaire Oven Baffle Backorder WCI 5304497666 $54.65

26

316489403 Frigidaire Range Bake Igniter In Stock WCI 316489403 $73.52

26A

316498200 Frigidaire Oven Bracket Backorder WCI 316498200 $30.72

29

807047102 Frigidaire Oven Front Drawer Glide In Stock WCI 807047102 $7.11

33

316405900 Frigidaire Shield Backorder WCI 316405900 $58.63

35

316542102 Frigidaire Flue Gasket Backorder WCI 316542102 $7.11

36

KNOB, TOP VALVE, BLACK, (4) WCI 316564511 Contact Us For Availability

37

316240600 Frigidaire Igniter Mounting Screw In Stock WCI 316240600 $7.11

37

316490000 Frigidaire Oven Range Temperature S In Stock WCI 316490000 $36.07

39

316554010 Frigidaire Stainless Steel Handle In Stock WCI 316554010 $88.78

39

5304515659 Frigidaire Oven Power Cord In Stock WCI 5304515659 $25.39

40

PANEL, MANIFOLD, STAINLESS STEEL WCI 316249087 Contact Us For Availability

42

316416204 Frigidaire Oven Trim Backorder WCI 316416204 $25.85

43

316282700 Frigidaire Oven Screw Backorder WCI 316282700 $6.22

44

316517600 Frigidaire Oven Spacer Backorder WCI 316517600 $7.57

44

316527509 Frigidaire Oven 18.2K Burner Orific Backorder WCI 316527509 $12.44

44A

316527504 Frigidaire Oven Orifice Assembly In Stock WCI 316527504 $14.24

44B

316527511 Frigidaire Oven Orifice Backorder WCI 316527511 $12.44

44C

316527500 Frigidaire Oven Burner Orifice Asse In Stock WCI 316527500 $13.35

47

GRLP4 Frigidaire Oven LP Conversion Kit In Stock WCI GRLP4 $32.09

55

316408300 Frigidaire Oven Bracket Backorder WCI 316408300 $12.46

56

316230708 Frigidaire Oven Shield Backorder WCI 316230708 $38.35

58A

316403700 Frigidaire Insulation Backorder WCI 316403700 $173.42

58B

INSULATION, OVEN BACK WCI 316403600 Contact Us For Availability

58G

08067973 Frigidaire 0 Insulation Backorder WCI 08067973 $32.52

60B

316021109 Frigidaire Oven Screw In Stock WCI 316021109 $8.91

82

316400801 Frigidaire Oven Shield Backorder WCI 316400801 $93.03

86

316441300 Frigidaire Receptacle Backorder WCI 316441300 $13.81

88

316232702 Frigidaire Rod Backorder WCI 316232702 $7.55

89

5304528973 Frigidaire Motor In Stock WCI 5304528973 $31.49

241853202 Frigidaire Refrigerator Screw Backorder WCI 241853202 $6.22

316021105 Frigidaire Oven Screw Backorder WCI 316021105 $7.11

316089500 Frigidaire Oven Screw In Stock WCI 316089500 $8.46

316215600 Frigidaire Oven Screw Backorder WCI 316215600 $8.89

316418901 Frigidaire Oven Screw Backorder WCI 316418901 $8.91

5303285179 Frigidaire Oven Door Screw Backorder WCI 5303285179 $8.46

5304494425 Frigidaire Oven Harness Backorder WCI 5304494425 $50.24

5304516080 Frigidaire Harness Backorder WCI 5304516080 $37.48

SCREW, CUP PT, 8-18 X 0.375, CHROME WCI 316021108 Contact Us For Availability

316001017 Frigidaire Screw Backorder WCI 316001017 $1.80

316021104 Frigidaire Oven Screw Assembly Backorder WCI 316021104 $4.89

316401500 Frigidaire Oven Cover Backorder WCI 316401500 $7.55

316418900 Frigidaire Oven Screw In Stock WCI 316418900 $8.91
