Model Electrolux LGBD2432LB0A DISHWASHER – Common Parts &amp; Diagrams

1

WCI 154729401 WCI 154729401 Contact Us For Availability

1A

154325201 Frigidaire Linkage Spring In Stock WCI 154325201 $25.37

2

154093301 Frigidaire Dishwasher ARM Assembly In Stock WCI 154093301 $1.35

2

154465101 Frigidaire Dishwasher Heating Eleme Backorder WCI 154465101 $7.25

2

5304532796 Frigidaire Dishwasher Strike In Stock WCI 5304532796 $7.23

2

5304535382 Frigidaire Basket Assembly In Stock WCI 5304535382 $12.89

2

WCI 154778003 WCI 154778003 Contact Us For Availability

3

154637401 Frigidaire Dishwasher Fill Valve Wa In Stock WCI 154637401 $22.19

3

5304535250 Frigidaire Dishwasher Upper Rack A In Stock WCI 5304535250 $80.85

3A

5304513274 Frigidaire Dishwasher Counterbalan In Stock WCI 5304513274 $43.03

4

154718801 Frigidaire Dishwasher Cover Backorder WCI 154718801 $20.38

4

5304535381 Frigidaire Dishwasher Dishrack Whe In Stock WCI 5304535381 $1.94

4

WCI 154200602 WCI 154200602 Contact Us For Availability

4

WCI 154669301 WCI 154669301 Contact Us For Availability

5

5304506510 Frigidaire Dishrack Slide Rail Sto In Stock WCI 5304506510 $4.51

5

5304506916 Frigidaire Dishwasher Assembly-Rol In Stock WCI 5304506916 $10.87

5

WCI 154734301 WCI 154734301 Contact Us For Availability

6

154597801 Frigidaire Dishwasher Upper Rack Sl In Stock WCI 154597801 $5.68

6

5303943103 Frigidaire Dishwasher P-1 Screw Ki In Stock WCI 5303943103 $11.32

7

5304532229 Frigidaire Dishwasher Lower Rack W In Stock WCI 5304532229 $3.18

7

WCI 154494603 WCI 154494603 Contact Us For Availability

8

154745503 Frigidaire Dishwasher Toe Panel In Stock WCI 154745503 $10.41

9

5304501484 Frigidaire Dishwasher Assembly Toe In Stock WCI 5304501484 $32.62

154103702 Frigidaire Dishwasher Screw Backorder WCI 154103702 $8.60

154294701 Frigidaire Dishwasher Screw Backorder WCI 154294701 $5.86

154724001 Frigidaire Lower Arm Support In Stock WCI 154724001 $6.32

154754801 Frigidaire Dishwasher Screw Backorder WCI 154754801 $1.35

13

154246801 Frigidaire Dishwasher Primary Gaske In Stock WCI 154246801 $31.71

13

WCI 154755801 No Longer Available

13

5304534829 Frigidaire Dishwasher Guard In Stock WCI 5304534829 $8.36

13A

154740304 Frigidaire Dishwasher Fold-Down Tin In Stock WCI 154740304 $20.84

14

154723801 Frigidaire Dishwasher SUMP Assembly In Stock WCI 154723801 $38.55

14

WCI 154784401 WCI 154784401 Contact Us For Availability

14A

5304506508 Frigidaire Bracket Support In Stock WCI 5304506508 $3.59

15

5304506540 Frigidaire Dishwasher Leg Assembly In Stock WCI 5304506540 $6.79

16

154246502 Frigidaire Dishwasher Bracket In Stock WCI 154246502 $25.79

20

154758501 Frigidaire Power Cord Cover Backorder WCI 154758501 $12.67

20

5304506509 Frigidaire Dishwasher Handle Backorder WCI 5304506509 $8.58

20

WCI 154741003 WCI 154741003 Contact Us For Availability

21

154754701 Frigidaire Dishwasher Screw Backorder WCI 154754701 $2.26

21

5304504913 Frigidaire Dishwasher Handle Backorder WCI 5304504913 $8.60

22

5304523457 Frigidaire Inlet Hose In Stock WCI 5304523457 $8.15

23

5304538466 Frigidaire Hose Clamp Backorder WCI 5304538466 $0.92

24

5304517203 Frigidaire Dishwasher Lower Wash A In Stock WCI 5304517203 $22.11

24B

5304506516 Frigidaire Dishwasher Upper Spray In Stock WCI 5304506516 $14.48

25

5304506520 Frigidaire Dishwasher Float Assemb In Stock WCI 5304506520 $4.31

28

154773201 Frigidaire Dishwasher Switch Assemb In Stock WCI 154773201 $35.33

29

154290204 Frigidaire Dishwasher Thermostat In Stock WCI 154290204 $40.78

30

154241101 Frigidaire Dishwasher Retainer Backorder WCI 154241101 $2.26

30

A01986801 Frigidaire Upper Rack Assembly In Stock WCI A01986801 $109.03

32A

154406401 Frigidaire Delivery Tube Gasket In Stock WCI 154406401 $6.99

33

154478901 Frigidaire Dishwasher Gasket Backorder WCI 154478901 $39.00

49

809006501 Frigidaire Bottom Seal/Gasket Door In Stock WCI 809006501 $15.31

51

WCI 154320301 WCI 154320301 Contact Us For Availability

55

5304534830 Frigidaire Dishwasher Bracket In Stock WCI 5304534830 $3.46

58

154246402 Frigidaire Dishwasher P-1 Ball Asse Backorder WCI 154246402 $35.78

59

154246901 Frigidaire Dishwasher Rear O-Ring f In Stock WCI 154246901 $36.24

59A

154247001 Frigidaire Dishwasher Pump Gasket S Backorder WCI 154247001 $36.24

61

5304506517 Frigidaire Dishwasher Grommet Asse In Stock WCI 5304506517 $9.95

62

5304518968 Frigidaire Lower Spray Arm Support In Stock WCI 5304518968 $7.25

65

154283005 Frigidaire Dishwasher Filter Assemb In Stock WCI 154283005 $151.31

66

5304532206 Frigidaire Trap In Stock WCI 5304532206 $4.73

71

154762601 Frigidaire Dishwasher Turbidity Sen In Stock WCI 154762601 $49.31

154106202 Frigidaire Dishwasher Heater Nut In Stock WCI 154106202 $4.88

154200701 Frigidaire Dishwasher Screw Backorder WCI 154200701 $8.60

154289801 Frigidaire Dishwasher Shield Backorder WCI 154289801 $4.97

154297701 Frigidaire Dishwasher Screw Backorder WCI 154297701 $8.60

154380601 Frigidaire Dishwasher Clamp Assembl In Stock WCI 154380601 $46.60

154388801 Frigidaire Dishwasher Rinse Aid Dis In Stock WCI 154388801 $15.85

154491101 Frigidaire Dishwasher Screw Backorder WCI 154491101 $2.26

154647101 Frigidaire Dishwasher Pin Hinge Backorder WCI 154647101 $9.06

154686401 Frigidaire Dishwasher Bearing Backorder WCI 154686401 $6.79

154741501 Frigidaire Dishwasher Screw Backorder WCI 154741501 $8.60

154754901 Frigidaire Dishwasher Screw In Stock WCI 154754901 $2.70

5304538695 Frigidaire Door Insulation Backorder WCI 5304538695 $0.92

808690701 Frigidaire Dishwasher Screw Backorder WCI 808690701 $2.26

WCI 154200601 WCI 154200601 Contact Us For Availability

WCI 5303316032 WCI 5303316032 Contact Us For Availability
