Model RCA LEB327GS1WW Electric Range – Common Parts & Diagrams
0
1
2
3
Common parts from model RCA LEB327GS1WW Electric Range
1
GEN WB36K5324 GEN WB36K5324 Contact Us For Availability
2
GEN WB36K5322 GEN WB36K5322 Contact Us For Availability
2
GEN WB36K5323 GEN WB36K5323 Contact Us For Availability
5
GEN WB20K5030 GEN WB20K5030 Contact Us For Availability
6
GEN WB37M0005 GEN WB37M0005 Contact Us For Availability
7
BKGD SUPPORT-RT GEN WB06X0127 Contact Us For Availability
7
BACKGUARD SUPPORT LT GEN WB06X0128 Contact Us For Availability
9
GEN WB02X9415 GEN WB02X9415 Contact Us For Availability
10
COVER RACEWAY GEN WB06X0134 Contact Us For Availability
16
GEN WB27K5113 GEN WB27K5113 Contact Us For Availability
18
GEN WB57K5114 GEN WB57K5114 Contact Us For Availability
28
GEN WB02M0037 GEN WB02M0037 Contact Us For Availability
29
GEN WB03K5176 GEN WB03K5176 Contact Us For Availability
30
GEN WB03X0766 GEN WB03X0766 Contact Us For Availability
33
GEN WB25M0008 GEN WB25M0008 Contact Us For Availability
33
INDICATOR LIGHT-CLEAN GEN WB25M0012 Contact Us For Availability
34
GEN WB25M0009 GEN WB25M0009 Contact Us For Availability
35
OVEN SWITCH GEN WB22X5122 Contact Us For Availability
40
GEN WB03K5177 GEN WB03K5177 Contact Us For Availability
42
GEN WB34K5092 GEN WB34K5092 Contact Us For Availability
49
GEN WB11X0008 GEN WB11X0008 Contact Us For Availability
68
GEN WB02K5232 GEN WB02K5232 Contact Us For Availability
83
GEN WB01K5128 GEN WB01K5128 Contact Us For Availability
88
GEN WB03K5178 GEN WB03K5178 Contact Us For Availability
90
SUPPORT ROD GEN WB02X9084 Contact Us For Availability
91
MT HINGE-LT GEN WB14X0126 Contact Us For Availability
91
GEN WB14X0127 GEN WB14X0127 Contact Us For Availability
96
REINFORCEMENT PLATE GEN WB02X9418 Contact Us For Availability
102
OVEN DOOR INSULATION GEN WB35K5026 Contact Us For Availability
111
GEN WB55M0010 GEN WB55M0010 Contact Us For Availability
112
OV DOOR LINING GEN WB56M0001 Contact Us For Availability
113
OV DR INS RETAINER GEN WB02X9175 Contact Us For Availability
114
GEN WB02M0001 GEN WB02M0001 Contact Us For Availability
116
GEN WB02X9178 GEN WB02X9178 Contact Us For Availability
117
OV DR GLASS RETAINER GEN WB02X9384 Contact Us For Availability
121
OV DR OUTER GLASS GEN WB57K5036 Contact Us For Availability
122
GEN WB57K5141 GEN WB57K5141 Contact Us For Availability
123
CENTER GLASS GEN WB56X1907 Contact Us For Availability
133
FELT PAD GEN WB01K5115 Contact Us For Availability
136
GEN WB15K5058 GEN WB15K5058 Contact Us For Availability
140
GEN WB56K5066 GEN WB56K5066 Contact Us For Availability
143
FIBER WASHER GEN WB01X1138 Contact Us For Availability
146
GEN WB02X9640 GEN WB02X9640 Contact Us For Availability
147
GLASS SPACER GEN WB02X9039 Contact Us For Availability
151
GEN WB14K5011 GEN WB14K5011 Contact Us For Availability
161
GEN WB24K5069 GEN WB24K5069 Contact Us For Availability
167
LATCH HANDLE RETAINER GEN WB02X9433 Contact Us For Availability
171
SWITCH INSULATOR GEN WB02X9129 Contact Us For Availability
175
LOCK COVER ASM GEN WB02X9431 Contact Us For Availability
178
LOCK BOX INSULATION GEN WB35K5027 Contact Us For Availability
181
GEN WB02K5097 GEN WB02K5097 Contact Us For Availability
191
LATCH HANDLE GEN WB02X9434 Contact Us For Availability
192
GEN WB03K5152 GEN WB03K5152 Contact Us For Availability
193
KNOB CLIP GEN WB02X9404 Contact Us For Availability
194
LEVER SWITCH GEN WB02X9432 Contact Us For Availability
195
LOCK SPRING GEN WB09X0251 Contact Us For Availability
201
GEN WB63K5109 GEN WB63K5109 Contact Us For Availability
202
GEN WB63K5161 GEN WB63K5161 Contact Us For Availability
203
GEN WB63K5134 GEN WB63K5134 Contact Us For Availability
204
GEN WB58X0065 GEN WB58X0065 Contact Us For Availability
211
GEN WB02M0038 GEN WB02M0038 Contact Us For Availability
212
INS RETAINER-LO GEN WB02K5093 Contact Us For Availability
216
WIRE COVER-REAR-UPP GEN WB34M0020 Contact Us For Availability
217
UPPER WIRE COVER GEN WB34K5093 Contact Us For Availability
221
BODY SIDE-WHITE GEN WB63X0351 Contact Us For Availability
222
LOWER FRONT PANEL-WHITE GEN WB56K5059 Contact Us For Availability
231
INSULATION TOP &SIDES GEN WB35M0022 Contact Us For Availability
232
INSULATION-OV BTM/BACK GEN WB35K5029 Contact Us For Availability
233
INSULATION TOP & SIDES GEN WB02X9718 Contact Us For Availability
241
GEN WB48X0208 GEN WB48X0208 Contact Us For Availability
256
GEN WB08K5042 GEN WB08K5042 Contact Us For Availability
257
GEN BUY LOCAL GEN BUY LOCAL Contact Us For Availability
259
OVEN LAMP LENS GEN WB25M0010 Contact Us For Availability
261
SWITCH GEN WB24K5030 Contact Us For Availability
266
GEN WB02K5274 GEN WB02K5274 Contact Us For Availability
267
GEN WB56M0003 GEN WB56M0003 Contact Us For Availability
269
SERVICE RANGE MTG PLATE GEN WB02X9427 Contact Us For Availability
282
GEN WB38M0007 GEN WB38M0007 Contact Us For Availability
286
OV DR SPRING GEN WB09X0273 Contact Us For Availability
291
GEN WB02X9152 GEN WB02X9152 Contact Us For Availability
292
GEN WB02X9146 GEN WB02X9146 Contact Us For Availability
293
GEN WB02X9148 GEN WB02X9148 Contact Us For Availability
296
GEN WB02X9188 GEN WB02X9188 Contact Us For Availability
802
GEN WB01K5123 GEN WB01K5123 Contact Us For Availability
803
GEN WB01X1176 GEN WB01X1176 Contact Us For Availability
811
GEN WB01X1172 GEN WB01X1172 Contact Us For Availability
824
GEN WB01X1291 GEN WB01X1291 Contact Us For Availability
856
GEN WB01X1170 GEN WB01X1170 Contact Us For Availability
857
GEN WB01X1324 GEN WB01X1324 Contact Us For Availability
874
GEN WB01X1162 GEN WB01X1162 Contact Us For Availability
926
GROUND WASHER GEN WB01X1260 Contact Us For Availability
930
GEN WB01M0022 GEN WB01M0022 Contact Us For Availability
951
GEN WB02X9443 GEN WB02X9443 Contact Us For Availability
954
THERMOSTAT BULB RET CLIP GEN WB02X9105 Contact Us For Availability
974
GEN WB01X1264 GEN WB01X1264 Contact Us For Availability
976
GEN WB01X1251 GEN WB01X1251 Contact Us For Availability
979
SPACER GEN WB01X1177 Contact Us For Availability
999
GEN 31-10059 GEN 31-10059 Contact Us For Availability
999
GEN 31-13008 GEN 31-13008 Contact Us For Availability
999
GEN 79-4073 GEN 79-4073 Contact Us For Availability
999
LIGHT SWITCH W HARNESS GEN WB18K5232 Contact Us For Availability
999
GEN WB18K5350 GEN WB18K5350 Contact Us For Availability
999
GEN WB18K5414 GEN WB18K5414 Contact Us For Availability
999
GEN WB18K5419 GEN WB18K5419 Contact Us For Availability
999
CLOCK JUMPER W HARNESS GEN WB18M0068 Contact Us For Availability
× ![]()
