Model LG LAU120CP AC – Common Parts & Diagrams
Diagram 0
Common parts from model LG LAU120CP AC
237202
Panel,Front LGE 3720A10015E Contact Us For Availability
261704
TRANSFORMER,POWER LGE 6171AQ3198G Contact Us For Availability
268711
PWB(PCB) ASSEMBLY,MAIN(OUTDOOR LGE 6871A10036S Contact Us For Availability
349480
Orifice LGE 4948A20047A Contact Us For Availability
430410
BASE ASSY,OUTDOOR LGE 3041A20008J Contact Us For Availability
435511
Cover Assembly,Control(Outdoor) LGE 3551A10005C Contact Us For Availability
437211
Panel Assembly,Front(Outdoor) LGE AGL32476440 Contact Us For Availability
437212
Panel Assembly,Rear(Outdoor) LGE 3721A20026Z Contact Us For Availability
447910
BARRIER ASSY,OUTDOOR LGE 4791A30002F Contact Us For Availability
549610
Bracket Assembly,Motor(Outdoor) LGE ABA73129801 Contact Us For Availability
552111
TUBE ASSEMBLY,CAPILLARY LGE 5211A20095J Contact Us For Availability
552203A
VALVE,SERVICE LGE 5220A20003B Contact Us For Availability
552203A
Valve,Service LGE 5220A20003F Contact Us For Availability
552203A
VALVE,SERVICE LGE 2H01890L Contact Us For Availability
552203B
VALVE,SERVICE LGE 5220A20005B Contact Us For Availability
552203B
VALVE,SERVICE LGE 2H02479H Contact Us For Availability
554031
CONDENSER ASSY,BENT LGE 5403A20019B Contact Us For Availability
554160
COMPRESSOR SET LGE 2520UKWC2HA Contact Us For Availability
649950
CONTROL BOX ASSEMBLY,OUTDOOR LGE 4995A10038J Contact Us For Availability
W0CZZ
CAPACITOR,DRAWING LGE 0CZZA20001N Contact Us For Availability
W6631
Cable & Wire,Unclassified LGE 4933AR3501G Contact Us For Availability
× ![]()
