  • LG LA181CNW Parts List

Model LG LA181CNW – Common Parts & Diagrams

135311A
Grille Assembly,Discharge(Indoor)
Grille Assembly,Discharge(Indoor) LGE 3531A20124K Contact Us For Availability
View on Model
135311B
Grille Assembly,Discharge(Indoor)
Grille Assembly,Discharge(Indoor) LGE 3531A20124J Contact Us For Availability
View on Model
135311C
Grille Assembly,Discharge(Indoor)
Grille Assembly,Discharge(Indoor) LGE 3531A20125G Contact Us For Availability
View on Model
135313
GRILLE ASSEMBLY,INLET
GRILLE ASSEMBLY,INLET LGE 3531A10270T Contact Us For Availability
View on Model
135316
GRILLE ASSEMBLY,FRONT(INDOOR)
GRILLE ASSEMBLY,FRONT(INDOOR) LGE 3531A10334J Contact Us For Availability
View on Model
135500A
COVER
COVER LGE 3550A20120B Contact Us For Availability
View on Model
135500B
COVER
COVER LGE 3550A20121B Contact Us For Availability
View on Model
135500C
Cover
Cover LGE 3550A20512B Contact Us For Availability
View on Model
146811A
MOTOR ASSEMBLY,STEP
MOTOR ASSEMBLY,STEP LGE 4681A20055A Contact Us For Availability
View on Model
146811A
Motor Assembly,DC,Stepping
Motor Assembly,DC,Stepping LGE 4681A20042E Contact Us For Availability
View on Model
147581
LOUVER,HORIZONTAL
LOUVER,HORIZONTAL LGE 4758A20033A Contact Us For Availability
View on Model
147582
LOUVER,VERTICAL
LOUVER,VERTICAL LGE 4758A20034A Contact Us For Availability
View on Model
152302
FILTER(MECH),A/C
FILTER(MECH),A/C LGE 5230A10011A Contact Us For Availability
View on Model
159830
AIR CLEANER ASSEMBLY
AIR CLEANER ASSEMBLY LGE 5983A20006P Contact Us For Availability
View on Model
249951
Case Assembly,Control(Indoor)
Case Assembly,Control(Indoor) LGE 4995A20825A Contact Us For Availability
View on Model
263230
THERMISTOR ASSEMBLY
THERMISTOR ASSEMBLY LGE 6323A20004N Contact Us For Availability
View on Model
267110
REMOTE CONTROLLER ASSEMBLY
REMOTE CONTROLLER ASSEMBLY LGE 6711A20083R Contact Us For Availability
View on Model
268711A
PWB(PCB) ASSEMBLY,DISPLAY
PWB(PCB) ASSEMBLY,DISPLAY LGE 6871A20462D Contact Us For Availability
View on Model
268711B
PCB Assembly,Main
PCB Assembly,Main LGE 6871A20387J Contact Us For Availability
View on Model
268711C
PCB Assembly,Main
PCB Assembly,Main LGE 6871A10184E Contact Us For Availability
View on Model
346810A
MOTOR ASSEMBLY,INDOOR
MOTOR ASSEMBLY,INDOOR LGE 4681A20047C Contact Us For Availability
View on Model
346810B
MOTOR ASSEMBLY,INDOOR
MOTOR ASSEMBLY,INDOOR LGE 4681A20047D Contact Us For Availability
View on Model
349490
Orifice Assembly
Orifice Assembly LGE 4949A20002C Contact Us For Availability
View on Model
352115
Tube Assembly,Evaporator(In)
Tube Assembly,Evaporator(In) LGE 5211A20302C Contact Us For Availability
View on Model
352116
TUBE ASSEMBLY,EVAPORATOR OUT
TUBE ASSEMBLY,EVAPORATOR OUT LGE 5211A20301F Contact Us For Availability
View on Model
352150
Hose Assembly,Drain
Hose Assembly,Drain LGE 5251A20011A Contact Us For Availability
View on Model
352380A
AIR GUIDE
AIR GUIDE LGE 5238A10009A Contact Us For Availability
View on Model
352380B
AIR GUIDE
AIR GUIDE LGE 5238A10010A Contact Us For Availability
View on Model
354210
EVAPORATOR ASSEMBLY,FIRST
EVAPORATOR ASSEMBLY,FIRST LGE 5421A20104C Contact Us For Availability
View on Model
359012A
FAN,TURBO
FAN,TURBO LGE 5900A00004A Contact Us For Availability
View on Model
359012B
FAN,TURBO
FAN,TURBO LGE 5900A00005A Contact Us For Availability
View on Model
430411
BASE ASSY,OUTDOOR
BASE ASSY,OUTDOOR LGE 3041AP2741G Contact Us For Availability
View on Model
435511
COVER ASSY,CONTROL(OUTDOOR)
COVER ASSY,CONTROL(OUTDOOR) LGE 3551AR7184T Contact Us For Availability
View on Model
435512
COVER ASSEMBLY,TOP(OUTDOOR)
COVER ASSEMBLY,TOP(OUTDOOR) LGE 3H03266P Contact Us For Availability
View on Model
437211
Panel Assembly,Front(Outdoor)
Panel Assembly,Front(Outdoor) LGE AGL36687001 Contact Us For Availability
View on Model
437212
Panel Assembly,Rear(Outdoor)
Panel Assembly,Rear(Outdoor) LGE AGL36636802 Contact Us For Availability
View on Model
447910
Barrier Assembly,Outdoor
Barrier Assembly,Outdoor LGE 4791A30004K Contact Us For Availability
View on Model
552113
Tube Assembly,Condenser(Out)
Tube Assembly,Condenser(Out) LGE 5211A25034C Contact Us For Availability
View on Model
552203B
Valve,Service
Valve,Service LGE 5220A20005C Contact Us For Availability
View on Model
554031
CONDENSER ASSEMBLY,BENT
CONDENSER ASSEMBLY,BENT LGE 5403A20058B Contact Us For Availability
View on Model
554160A
Compressor Set,Korea
Compressor Set,Korea LGE 2520UGJK2AA Contact Us For Availability
View on Model
554160B
Compressor Set,Korea
Compressor Set,Korea LGE 2520UGAK2AA Contact Us For Availability
View on Model
567480B
THERMISTOR ASSEMBLY
THERMISTOR ASSEMBLY LGE 6323A20002L Contact Us For Availability
View on Model
649950
Case Assembly,Control(Outdoor)
Case Assembly,Control(Outdoor) LGE 4995A20383W Contact Us For Availability
View on Model
W0CZZA
CAPACITOR 400/35 GA-1015LC 121
CAPACITOR 400/35 GA-1015LC 121 LGE 3A00988B Contact Us For Availability
View on Model
