  • LG LA141CP Parts List

Model LG LA141CP – Common Parts & Diagrams

135080-2
Decor
Decor LGE 3508A20034E Contact Us For Availability
View on Model
135311
GRILLE ASSEMBLY,DISCHARGE(INDO
GRILLE ASSEMBLY,DISCHARGE(INDO LGE 3531A10137E Contact Us For Availability
View on Model
135312
GRILLE ASSEMBLY,FRONT(INDOOR)
GRILLE ASSEMBLY,FRONT(INDOOR) LGE 3531A20284S Contact Us For Availability
View on Model
135314
GRILLE ASSEMBLY,INLET
GRILLE ASSEMBLY,INLET LGE 3531A20285E Contact Us For Availability
View on Model
135516
Cover Assembly,Motor
Cover Assembly,Motor LGE 3551A20050C Contact Us For Availability
View on Model
145200
LINK
LINK LGE 4520A20008A Contact Us For Availability
View on Model
146811
MOTOR ASSEMBLY,STEP
MOTOR ASSEMBLY,STEP LGE 4681A20055B Contact Us For Availability
View on Model
146811-1
MOTOR ASSEMBLY,STEP
MOTOR ASSEMBLY,STEP LGE 4681A20055A Contact Us For Availability
View on Model
152302
FILTER(MECH),A/C
FILTER(MECH),A/C LGE 5230A20022A Contact Us For Availability
View on Model
159830
Filter Assembly,Air Cleaner
Filter Assembly,Air Cleaner LGE 5983A25003R Contact Us For Availability
View on Model
159901
VANE,HORIZONTAL
VANE,HORIZONTAL LGE 5990A20015B Contact Us For Availability
View on Model
249951
CONTROL BOX ASSEMBLY,INDOOR
CONTROL BOX ASSEMBLY,INDOOR LGE 4995A10138B Contact Us For Availability
View on Model
266090
H.V ASSEMBLY
H.V ASSEMBLY LGE 6609A10005D Contact Us For Availability
View on Model
267110
REMOTE CONTROLLER ASSEMBLY
REMOTE CONTROLLER ASSEMBLY LGE 6711A20083Q Contact Us For Availability
View on Model
268712
Window,Display
Window,Display LGE 3790A20046E Contact Us For Availability
View on Model
268714
PWB(PCB) ASSEMBLY,MAIN(DC)
PWB(PCB) ASSEMBLY,MAIN(DC) LGE 6871A20535B Contact Us For Availability
View on Model
346810
MOTOR ASSEMBLY,INDOOR
MOTOR ASSEMBLY,INDOOR LGE 4681AR2295K Contact Us For Availability
View on Model
352150
HOSE ASSEMBLY,DRAIN
HOSE ASSEMBLY,DRAIN LGE 5251AR1222R Contact Us For Availability
View on Model
354212
EVAPORATOR ASSEMBLY,FINAL
EVAPORATOR ASSEMBLY,FINAL LGE 5421A20086D Contact Us For Availability
View on Model
430410
BASE ASSY,OUTDOOR
BASE ASSY,OUTDOOR LGE 3041A20008J Contact Us For Availability
View on Model
435301
GRILLE,DISCHARGE
GRILLE,DISCHARGE LGE 3530A20006G Contact Us For Availability
View on Model
437210
PANEL ASSEMBLY,FRONT(OUTDOOR)
PANEL ASSEMBLY,FRONT(OUTDOOR) LGE 3721A20027P Contact Us For Availability
View on Model
437212
PANEL ASSEMBLY,REAR(OUTDOOR)
PANEL ASSEMBLY,REAR(OUTDOOR) LGE 3721A20026K Contact Us For Availability
View on Model
447910
BARRIER ASSY,OUTDOOR
BARRIER ASSY,OUTDOOR LGE 4791A30002F Contact Us For Availability
View on Model
552102
Tube,Capillary Bending
Tube,Capillary Bending LGE 5210A30041U Contact Us For Availability
View on Model
552111
TUBE ASSEMBLY,CAPILLARY
TUBE ASSEMBLY,CAPILLARY LGE 5211A21143H Contact Us For Availability
View on Model
552203-1
VALVE,SERVICE
VALVE,SERVICE LGE 5220A20005B Contact Us For Availability
View on Model
552203-2
VALVE,SERVICE
VALVE,SERVICE LGE 5220A20003B Contact Us For Availability
View on Model
554031
CONDENSER ASSY,BENT
CONDENSER ASSY,BENT LGE 5403A20019B Contact Us For Availability
View on Model
554160
COMPRESSOR SET
COMPRESSOR SET LGE 2520UKJC2AA Contact Us For Availability
View on Model
567502
O.L.P
O.L.P LGE 6750U-L046A Contact Us For Availability
View on Model
649950
CONTROL BOX ASSEMBLY,OUTDOOR
CONTROL BOX ASSEMBLY,OUTDOOR LGE 4995A10038K Contact Us For Availability
View on Model
733010
PLATE INSTALLATION
PLATE INSTALLATION LGE 1H00843A Contact Us For Availability
View on Model
