Model Whirlpool KTHD18KEAL01 – Common Parts &amp; Diagrams

WPL 1117510 WPL 1117510 Contact Us For Availability

WPL LIT2172667 WPL LIT2172667 Contact Us For Availability

WPL LIT2184529 WPL LIT2184529 Contact Us For Availability

WPL LIT2184595 WPL LIT2184595 Contact Us For Availability

1

Plate, Unit Mounting WPL 2182437 Contact Us For Availability

1

Cabinet (Not A Serviceable Part) WPL ARI108228A Contact Us For Availability

1

Liner (Not A Serviceable Part) WPL ARI108231A Contact Us For Availability

2

WP2189412 Whirlpool Refrigerator Door Hinge Backorder WPL WP2189412 $37.95

2

WP489478 Whirlpool Refrigerator Screw In Stock WPL WP489478 $2.51

2

Grommet (2) WPL 531933 Contact Us For Availability

3

WP2166108 Whirlpool Refrigerator Cabinet Roll In Stock WPL WP2166108 $13.54

3

Condenser WPL 2179882 Contact Us For Availability

4

WP2163835 Whirlpool Track Assembly In Stock WPL WP2163835 $11.91

4

WP2183400 Whirlpool Defrost Timer In Stock WPL WP2183400 $46.85

4

WP2315531 Whirlpool Refrigerator Heater In Stock WPL WP2315531 $55.60

4

Screw WPL 489426 Contact Us For Availability

5

520965 Whirlpool Refrigerator Support Backorder WPL 520965 $10.14

5

WP2196003 Whirlpool Refrigerator Bar Riser Backorder WPL WP2196003 $3.70

5

WP488366 Whirlpool Refrigerator Clamp Backorder WPL WP488366 $4.81

5

WP488921 Whirlpool Refrigerator Screw Backorder WPL WP488921 $2.51

5

Evaporator Assy. WPL 2176337 Contact Us For Availability

6

940014 Whirlpool Refrigerator Primary Button Backorder WPL 940014 $10.25

6

WP2183003 Whirlpool Thimble In Stock WPL WP2183003 $3.70

6

Screw WPL 489414 Contact Us For Availability

6

Screw WPL 489459 Contact Us For Availability

7

Drain Pan WPL 2172619 Contact Us For Availability

7

Screw WPL 2174650 Contact Us For Availability

7

Wire Assy. Control Box WPL 2172542 Contact Us For Availability

8

2159057 Whirlpool Refrigerator Fresh Food Doo In Stock WPL 2159057 $84.60

8

2159327 Whirlpool Refrigerator Door Gasket In Stock WPL 2159327 $78.12

8

4387478 Whirlpool Refrigerator Light Socket In Stock WPL 4387478 $30.80

8

WP4387503 Whirlpool Refrigerator Bimetal Defr In Stock WPL WP4387503 $16.40

9

Bracket, Heater WPL 2176301 Contact Us For Availability

9

Damper, Air WPL 2179858 Contact Us For Availability

10

Extension, Air Baffle WPL 2163780 Contact Us For Availability

10

Fan Motor WPL 2176298 Contact Us For Availability

11

WP2163777 Whirlpool Refrigerator Fan Blade In Stock WPL WP2163777 $30.29

11

Screw WPL 489473 Contact Us For Availability

12

549193 Whirlpool Refrigerator Power Clamp Backorder WPL 549193 $6.94

12

WP2162358 Whirlpool Refrigerator Terminal Cov Backorder WPL WP2162358 $30.03

12

Control Box WPL 2179790 Contact Us For Availability

13

4387562 Whirlpool Refrigerator Thermostat Col Backorder WPL 4387562 $116.21

13

4387913 Whirlpool Refrigerator Primary Overlo In Stock WPL 4387913 $33.47

13

Overload (Production (Includes Relay)) WPL 2169406 Contact Us For Availability

14

876811 Whirlpool Grommet Backorder WPL 876811 $3.70

14

W11661108 Whirlpool Grommet Backorder WPL W11661108 $5.51

14

WP489442 Whirlpool Refrigerator Screw Backorder WPL WP489442 $4.56

15

WP999367 Whirlpool Refrigerator Screw Backorder WPL WP999367 $2.51

15

Relay (See Overload) WPL ARI108232A Contact Us For Availability

15

Screw WPL 489412 Contact Us For Availability

16

Module WPL 2169337 Contact Us For Availability

16

Cover, Evaporator WPL 2183154 Contact Us For Availability

W11679940 Whirlpool Refrigerator Light Bulb A In Stock WPL W11679940 $2.75

WP2176275 Whirlpool Refrigerator Wire Shelf Backorder WPL WP2176275 $69.61

Roller (2) WPL 2163782 Contact Us For Availability

Shim, Hinge Center WPL 2163757 Contact Us For Availability

18

W11594405 Whirlpool Axle In Stock WPL W11594405 $6.90

18

WP489463 Whirlpool Refrigerator Screw In Stock WPL WP489463 $2.51

18

Weight, Thermal WPL 2163802 Contact Us For Availability

19

W10856580 Whirlpool Crisper Pan In Stock WPL W10856580 $90.63

19

W11384469 Whirlpool Door Switch In Stock WPL W11384469 $12.68

19

Clip WPL 2182338 Contact Us For Availability

WP2218127K Whirlpool Meat Pan Backorder WPL WP2218127K $81.90

Protector WPL 2183183 Contact Us For Availability

Hinge, Butt WPL 2179829 Contact Us For Availability

Post, Damper WPL 2179859 Contact Us For Availability

21

Cover, Air Diffuser WPL 2176281 Contact Us For Availability

22

WP841180A Whirlpool Microwave Glass Turntable In Stock WPL WP841180A $3.92

22

Knob, Thermostat WPL 2176296 Contact Us For Availability

23

Air Tower WPL 2182340 Contact Us For Availability

23

Shim, Bottom Hinge WPL 2172745 Contact Us For Availability

24

W10854037 Whirlpool Refrigerator Crisper Pan In Stock WPL W10854037 $89.14

24

WP2189452 Whirlpool Refrigerator Diffuser Backorder WPL WP2189452 $42.62

24

Fitting, Water Tube (Not Serviced) WPL ARI108229A Contact Us For Availability

25

W10136387A Whirlpool Refrigerator Egg Contain In Stock WPL W10136387A $5.98

25

Freezer Floor WPL 2172565 Contact Us For Availability

26

Air Diffuser, Top WPL 2179877 Contact Us For Availability

WP2151652 Whirlpool Refrigerator Button Plug Backorder WPL WP2151652 $8.20

WP2217784 Whirlpool Refrigerator Cover Backorder WPL WP2217784 $15.98

Shelf, Freezer WPL 2172569 Contact Us For Availability

Hole Plug (6) (Almond) WPL 2151653 Contact Us For Availability

876765 Whirlpool Primary Mounting Kit Refrige In Stock WPL 876765 $24.72

W10309988 Whirlpool Refrigerator Compressor In Stock WPL W10309988 $284.26

WP941839 Whirlpool Refrigerator Button Plug In Stock WPL WP941839 $3.70

Installation Kit WPL 482801 Contact Us For Availability

29

2163762 Whirlpool Refrigerator Cup Assembly Backorder WPL 2163762 $4.32

29

W10843121 Whirlpool Refrigerator Tube In Stock WPL W10843121 $23.50

29

Bracket, Fan Motor WPL 2163827 Contact Us For Availability

30

WP2254360 Whirlpool Refrigerator Gasket In Stock WPL WP2254360 $8.67

30

Clamp WPL 2169464 Contact Us For Availability

31

4388450 Whirlpool Refrigerator Insert Backorder WPL 4388450 $27.03

31

Cover, Water Valve WPL 2166251 Contact Us For Availability

32

WP487996 Whirlpool Refrigerator Cap Tube Backorder WPL WP487996 $4.48

32

WPW10662129 Whirlpool Refrigerator Run Capaci In Stock WPL WPW10662129 $28.24

32

Capacitor, Run (Service) WPL 2169137 Contact Us For Availability

33

Wire Assembly, Freezer Compartment WPL 2179823 Contact Us For Availability

34

Knob, Damper WPL 2176297 Contact Us For Availability

35

WP2210509 Whirlpool Refrigerator Tub Valve Backorder WPL WP2210509 $28.80

35

WPW10283959 Whirlpool Refrigerator Filler In Stock WPL WPW10283959 $3.70

35

Corner Filler (2) (Almond) WPL 2166187 Contact Us For Availability

36

WP2205079 Whirlpool Refrigerator Seal Backorder WPL WP2205079 $4.14

36

Grille (White) WPL 2182429 Contact Us For Availability

36

Grille (Almond) WPL 2182430 Contact Us For Availability

37

Bracket, Damper Knob WPL 2163810 Contact Us For Availability

38

WP2156006 Whirlpool Refrigerator Shelf Trim E In Stock WPL WP2156006 $4.10

38

WP2172890 Whirlpool Refrigerator Wire Backorder WPL WP2172890 $2.51

38

WP487576 Whirlpool Washer In Stock WPL WP487576 $4.58

39

WP2156007 Whirlpool Refrigerator Endcap Trim In Stock WPL WP2156007 $3.70

39

Air Baffle WPL 2182395 Contact Us For Availability

39

Shim WPL 1123517 Contact Us For Availability

W10822259 Whirlpool Refrigerator Condenser Fa In Stock WPL W10822259 $131.83

WP2213360 Whirlpool Refrigerator Cover Backorder WPL WP2213360 $11.95

Cover, Hinge (Almond) WPL 2160404 Contact Us For Availability

Clip, Defrost Timer WPL 2176341 Contact Us For Availability

41

Rail Center (Not Serviced) WPL ARI108230A Contact Us For Availability

42

Wire Assy. Unit WPL 2184587 Contact Us For Availability

42

Corner Filler, Grille (White) WPL 2166156 Contact Us For Availability

42

Corner Filler, Grille (Almond) WPL 2166204 Contact Us For Availability

43

WP2254618 Whirlpool Center Door Hinge In Stock WPL WP2254618 $25.07

43

Fan, Blade WPL 851732 Contact Us For Availability

44

WP486692 Whirlpool Refrigerator Nut Backorder WPL WP486692 $3.70

44

Cover, Unit WPL 2183158 Contact Us For Availability

46

Tube, Discharge WPL 2184451 Contact Us For Availability

47

Tube, Suction WPL 2182475 Contact Us For Availability

48

2154109 Whirlpool Refrigerator Tube Backorder WPL 2154109 $33.89

49

Tube, Condenser To Heat Loop WPL 2174670 Contact Us For Availability

56

WP489128 Whirlpool Refrigerator Screw Backorder WPL WP489128 $4.56

212643 Whirlpool Refrigerator Permagum Sealer In Stock WPL 212643 $27.18

285006 Whirlpool Spray In Stock WPL 285006 $27.45

350930 Whirlpool White Spray Paint In Stock WPL 350930 $12.50

350942 Whirlpool Spray Paint Backorder WPL 350942 $32.57

350956 Whirlpool Spray Assembly In Stock WPL 350956 $19.22

511873 Whirlpool Refrigerator Paint Backorder WPL 511873 $19.22

606755 Whirlpool Refrigerator Bag Backorder WPL 606755 $26.21

72017 Whirlpool Appliance Touch-Up Paint Whit In Stock WPL 72017 $3.35

72032 Whirlpool Touch Up Paint Black In Stock WPL 72032 $5.60

799344 Whirlpool Refrigerator Paint Backorder WPL 799344 $93.22

833938 Whirlpool Refrigerator Terminal Backorder WPL 833938 $3.70

876370 Whirlpool Refrigerator Insulation Backorder WPL 876370 $96.00

876764 Whirlpool Refrigerator Primary Valve In Stock WPL 876764 $27.18

978026 Whirlpool Refrigerator Primary Valve Backorder WPL 978026 $32.32

978027 Whirlpool Refrigerator Primary Valve Backorder WPL 978027 $33.95

978030 Whirlpool Refrigerator Valve Backorder WPL 978030 $35.52

WP503695 Whirlpool Refrigerator Sealer Backorder WPL WP503695 $39.18

WP505587 Whirlpool Refrigerator Sealer Backorder WPL WP505587 $57.83

WP542638 Whirlpool Refrigerator Grease In Stock WPL WP542638 $22.07

WP72107 Whirlpool Touchup In Stock WPL WP72107 $5.80

WP978025 Whirlpool Refrigerator Valve In Stock WPL WP978025 $25.89

WPL 978029 WPL 978029 Contact Us For Availability

WPL 876029 WPL 876029 Contact Us For Availability

TAPE, VINYL (3/4 X 108``) WPL 479502 Contact Us For Availability

Evap. Tray WPL 2163795 Contact Us For Availability

Door Reversal Instructions WPL 2176379 Contact Us For Availability

Start Kit WPL 482278 Contact Us For Availability

WPL 542639 WPL 542639 Contact Us For Availability

WPL 799832 WPL 799832 Contact Us For Availability

WPL 799833 WPL 799833 Contact Us For Availability

WPL 978028 WPL 978028 Contact Us For Availability

WPL 978883 WPL 978883 Contact Us For Availability
