Model Whirlpool KFIS20XVMS10 REFRIGERATOR – Common Parts &amp; Diagrams

1

WPW10300025 Whirlpool Refrigerator Ice Mold Backorder WPL WPW10300025 $90.86

1

DOOR, LEFT (STAINLESS) WPL 13107863S Contact Us For Availability

2

W10121282 Whirlpool Refrigerator Insert Backorder WPL W10121282 $10.16

2

WP12825803 Whirlpool Refrigerator Fan Blade In Stock WPL WP12825803 $35.43

2

WPW10175514 Whirlpool Refrigerator Shut-Off A Backorder WPL WPW10175514 $42.71

3

12002497 Whirlpool Refrigerator Drawer Gear K In Stock WPL 12002497 $8.86

3

W10121281 Whirlpool Refrigerator Shroud Backorder WPL W10121281 $26.21

3

W10327050 Whirlpool Refrigerator Cup Fill Backorder WPL W10327050 $33.65

3

W11727651 Whirlpool Plate Assembly Backorder WPL W11727651 $39.55

3

WP67003637 Whirlpool Dairy Door In Stock WPL WP67003637 $41.82

3

WPW10330991 Whirlpool Refrigerator Bracket In Stock WPL WPW10330991 $42.00

3

WPW10330993 Whirlpool Refrigerator Bracket Backorder WPL WPW10330993 $56.13

3

Board, L.V. WPL 13053103SP Contact Us For Availability

4

12921801 Whirlpool Refrigerator Light Cover Backorder WPL 12921801 $10.76

4

B5759655 Whirlpool Refrigerator Gasket In Stock WPL B5759655 $7.69

4

W10318914 Whirlpool Refrigerator Ejector Arm Backorder WPL W10318914 $13.89

4

WP67001279 Whirlpool Refrigerator Dairy Tray Backorder WPL WP67001279 $46.65

4

WPW10162697 Whirlpool Refrigerator Motor Backorder WPL WPW10162697 $113.74

4

SUMP-DISPENSER WPL W10448627 Contact Us For Availability

5

W11028221 Whirlpool Refrigerator Shaft In Stock WPL W11028221 $11.31

5

WP13005705 Whirlpool Refrigerator Chute Backorder WPL WP13005705 $181.70

5

WPW10119841 Whirlpool Cantilever Bin In Stock WPL WPW10119841 $44.91

5

WPW10122563 Whirlpool Refrigerator Stripper A Backorder WPL WPW10122563 $32.68

6

W11311945 Whirlpool Refrigerator Screw Backorder WPL W11311945 $9.59

6

WPW10233569 Whirlpool Refrigerator Tube Backorder WPL WPW10233569 $43.19

7

12961602 Whirlpool Refrigerator Wire Cover Backorder WPL 12961602 $39.14

7

WPW10661886 Whirlpool Refrigerator Door Handl In Stock WPL WPW10661886 $4.26

7

GROMMET, FAN WPL W10151687 Contact Us For Availability

8

12656202 Whirlpool Refrigerator Housing Backorder WPL 12656202 $52.78

8

W10356558 Whirlpool Refrigerator Divider Backorder WPL W10356558 $35.78

8

W10443023 Whirlpool Refrigerator Housing Backorder WPL W10443023 $37.83

8

W10830055 Whirlpool Refrigerator Door Gasket In Stock WPL W10830055 $124.35

8

WPW10655368 Whirlpool Refrigerator Drip Pan In Stock WPL WPW10655368 $54.66

8

FACADE, DISPENSER (APOLLO GREY) WPL W10310691 Contact Us For Availability

9

W10001240 Whirlpool Refrigerator Screw Backorder WPL W10001240 $5.65

9

W10829281 Whirlpool Refrigerator Screw Backorder WPL W10829281 $5.01

9

WPW10314517K Whirlpool Refrigerator Handle Backorder WPL WPW10314517K $120.76

W11469652 Whirlpool Refrigerator Shield Backorder WPL W11469652 $10.76

W11592374 Whirlpool Refrigerator Top Door Hin Backorder WPL W11592374 $10.07

W11671282 Whirlpool Refrigerator Ice Auger Mo In Stock WPL W11671282 $65.49

WP12729123 Whirlpool Refrigerator Heater In Stock WPL WP12729123 $75.66

WPW10351019 Whirlpool Refrigerator Extension In Stock WPL WPW10351019 $27.03

8533917 Whirlpool Refrigerator Screw In Stock WPL 8533917 $9.59

W10235358 Whirlpool Refrigerator Glide Backorder WPL W10235358 $142.79

W10275942 Whirlpool Refrigerator Water Tube Backorder WPL W10275942 $43.13

W10308421 Whirlpool Refrigerator Evaporator C Backorder WPL W10308421 $102.86

W11661170 Whirlpool Clip Backorder WPL W11661170 $4.39

WPW10127427 Whirlpool Refrigerator Control In Stock WPL WPW10127427 $65.37

WPW10185233 Whirlpool Refrigerator Pad In Stock WPL WPW10185233 $34.95

WPW10235370 Whirlpool Refrigerator Glide In Stock WPL WPW10235370 $108.35

12

WPW10119846 Whirlpool Refrigerator Door Bin S In Stock WPL WPW10119846 $46.57

12

WPW10235368 Whirlpool Refrigerator Glide Backorder WPL WPW10235368 $134.64

12

WPW10448874 Whirlpool Start Device In Stock WPL WPW10448874 $64.18

W11676504 Whirlpool Insert Assembly Backorder WPL W11676504 $12.77

WP12656018 Whirlpool Drawer Support In Stock WPL WP12656018 $28.22

WP12656105 Whirlpool Drawer Support In Stock WPL WP12656105 $30.91

WP2313326 Whirlpool Refrigerator Switch Backorder WPL WP2313326 $7.94

WPW10137529 Whirlpool Refrigerator Grommet Backorder WPL WPW10137529 $3.70

WPW10287601 Whirlpool Seal In Stock WPL WPW10287601 $14.38

EDR4RXD1 Whirlpool EveryDrop„¢ Filter 4 Re In Stock WPL EDR4RXD1 $55.44

W11434460 Whirlpool Refrigerator Housing Backorder WPL W11434460 $12.39

WP12722813AP Whirlpool Refrigerator Mullion R Backorder WPL WP12722813AP $113.40

WPW10312691 Whirlpool Refrigerator Air Baffle In Stock WPL WPW10312691 $116.63

15

W10187453 Whirlpool Refrigerator Bin Backorder WPL W10187453 $33.64

15

W10312698 Whirlpool Refrigerator Wire Harness Backorder WPL W10312698 $112.21

15

WP67005149 Whirlpool Roller Backorder WPL WP67005149 $10.76

16

W11378860 Whirlpool Refrigerator Spacer In Stock WPL W11378860 $6.19

16

WP12028505AP Whirlpool Closing Cam In Stock WPL WP12028505AP $29.12

16

Screw WPL 12992101 Contact Us For Availability

17

W11703060 Whirlpool Door Stop Backorder WPL W11703060 $5.38

17

WP12587703AP Whirlpool Refrigerator Filler Backorder WPL WP12587703AP $3.70

17

WPW10169124 Whirlpool Refrigerator Grommet In Stock WPL WPW10169124 $3.70

489136 Whirlpool Refrigerator Screw Backorder WPL 489136 $4.56

W11592375 Whirlpool Door Hinge Backorder WPL W11592375 $10.07

WPW10346415 Whirlpool Refrigerator Condenser Backorder WPL WPW10346415 $152.87

BUCKET, DISPENSER (LOWER) WPL 12977501 Contact Us For Availability

12996601 Whirlpool Refrigerator Bushing Clip Backorder WPL 12996601 $6.92

W10273464 Whirlpool Refrigerator Ladder Backorder WPL W10273464 $11.03

W10281329 Whirlpool Clamp Backorder WPL W10281329 $6.59

W11395888 Whirlpool Refrigerator Bypass Filte In Stock WPL W11395888 $24.32

W11658403 Whirlpool Slide In Stock WPL W11658403 $74.88

WP628379 Whirlpool Refrigerator Clip Backorder WPL WP628379 $4.61

W10251966 Whirlpool Refrigerator Ladder Backorder WPL W10251966 $28.80

W11510594 Whirlpool Refrigerator Mat Backorder WPL W11510594 $10.43

W11547653 Whirlpool Refrigerator Drip Tray Backorder WPL W11547653 $29.39

WPW10312696 Whirlpool Water Inlet Valve In Stock WPL WPW10312696 $113.26

12999501 Whirlpool Refrigerator Hinge Shim In Stock WPL 12999501 $33.89

12999502 Whirlpool Refrigerator Hinge Shim Backorder WPL 12999502 $34.28

13033601 Whirlpool Refrigerator Wire Cover Backorder WPL 13033601 $28.80

WP33001882 Whirlpool Screw Backorder WPL WP33001882 $26.21

WP98165 Whirlpool Screw Backorder WPL WP98165 $2.51

22

W11536253 Whirlpool Refrigerator Evaporator Backorder WPL W11536253 $105.14

22

WPW10243391 Whirlpool Refrigerator Nameplate Backorder WPL WPW10243391 $26.90

12963002SP Whirlpool Refrigerator Evaporator Backorder WPL 12963002SP $30.63

12987301 Whirlpool Refrigerator Cover Backorder WPL 12987301 $7.91

W10296536 Whirlpool Refrigerator Cover Backorder WPL W10296536 $34.66

Dam (Right Side) WPL 12963102SP Contact Us For Availability

DOOR, RIGHT (STAINLESS) WPL 13107867S Contact Us For Availability

24

W10917988 Whirlpool Refrigerator Door Hinge Backorder WPL W10917988 $35.52

24

W11510593 Whirlpool Refrigerator Mat Backorder WPL W11510593 $7.80

24

W11613295 Whirlpool Condenser Motor In Stock WPL W11613295 $50.00

25

W10118193 Whirlpool Refrigerator Cover Backorder WPL W10118193 $28.80

25

W11673433 Whirlpool Clip Backorder WPL W11673433 $59.77

25

W11686675 Whirlpool Screw Backorder WPL W11686675 $8.11

26

W11666013 Whirlpool Wire Harness In Stock WPL W11666013 $37.50

27

WPW10143759 Whirlpool Dryer Filter In Stock WPL WPW10143759 $13.98

28

W10854958 Whirlpool Refrigerator Screw Backorder WPL W10854958 $2.71

28

WPW10507886 Whirlpool Refrigerator Compressor In Stock WPL WPW10507886 $433.65

29

Clip, Evaporator WPL 10623002 Contact Us For Availability

30

67006434 Whirlpool Axle Pin Backorder WPL 67006434 $3.70

30

WPW10270394 Whirlpool Refrigerator Back Cover Backorder WPL WPW10270394 $77.72

31

W11556315 Whirlpool Shroud Backorder WPL W11556315 $27.80

31

WP12227304WD Whirlpool Refrigerator Drawer Su Backorder WPL WP12227304WD $43.13

33

Fiber, Acoustic WPL 12820505 Contact Us For Availability

34

WPW10141622 Whirlpool Leveler In Stock WPL WPW10141622 $3.70

36

WP12777701 Whirlpool Refrigerator Filler Bloc Backorder WPL WP12777701 $4.15

36

WPW10334458 Whirlpool Refrigerator Connector Backorder WPL WPW10334458 $8.62

100

WPW10300024 Whirlpool Ice Maker In Stock WPL WPW10300024 $122.14

212643 Whirlpool Refrigerator Permagum Sealer In Stock WPL 212643 $27.18

285006 Whirlpool Spray In Stock WPL 285006 $27.45

350930 Whirlpool White Spray Paint In Stock WPL 350930 $12.50

350942 Whirlpool Spray Paint Backorder WPL 350942 $32.57

4392899 Whirlpool Biscuit Touch-Up Paint In Stock WPL 4392899 $6.86

4392901 Whirlpool Biscuit Spray Paint In Stock WPL 4392901 $26.26

606755 Whirlpool Refrigerator Bag Backorder WPL 606755 $26.21

72017 Whirlpool Appliance Touch-Up Paint Whit In Stock WPL 72017 $3.35

72032 Whirlpool Touch Up Paint Black In Stock WPL 72032 $5.60

799344 Whirlpool Refrigerator Paint Backorder WPL 799344 $93.22

833938 Whirlpool Refrigerator Terminal Backorder WPL 833938 $3.70

876370 Whirlpool Refrigerator Insulation Backorder WPL 876370 $96.00

876764 Whirlpool Refrigerator Primary Valve In Stock WPL 876764 $27.18

978026 Whirlpool Refrigerator Primary Valve Backorder WPL 978026 $32.32

978027 Whirlpool Refrigerator Primary Valve Backorder WPL 978027 $33.95

978030 Whirlpool Refrigerator Valve Backorder WPL 978030 $35.52

WP503695 Whirlpool Refrigerator Sealer Backorder WPL WP503695 $39.18

WP505587 Whirlpool Refrigerator Sealer Backorder WPL WP505587 $57.83

WP542638 Whirlpool Refrigerator Grease In Stock WPL WP542638 $22.07

WP978025 Whirlpool Refrigerator Valve In Stock WPL WP978025 $25.89

WPW10324088 Whirlpool Refrigerator Ice Bin Backorder WPL WPW10324088 $218.52

VALVE, ACCESS (5/8``) WPL 978029 Contact Us For Availability

KIT, FOAM SLAB (30`` X 32 1/2`` X 1 1/2``) WPL 876029 Contact Us For Availability

TAPE, VINYL (3/4 X 108``) WPL 479502 Contact Us For Availability

Torx Key WPL 1117510 Contact Us For Availability

VALVE, ACCESS (1/2``) WPL 978028 Contact Us For Availability

REFRIGERANT CHARGE (5.25 OZS. (R-134A)) WPL NP Contact Us For Availability

Cleaner, Stnls Steel Magic WPL 20000008 Contact Us For Availability

CEMENT, ALUMILASTIC (1 1/4 OZ.) WPL 542639 Contact Us For Availability

REFINISHING MATERIAL (ENAMEL, BLACK (1 QT. UN WPL 799340 Contact Us For Availability
