Model Whirlpool KFGC500JPA07 RANGE/OVEN, GAS – Common Parts &amp; Diagrams

1

INSULATION Backorder WPL W10246087 $43.77

1

W11318831 Whirlpool Glass Frame Backorder WPL W11318831 $122.09

1

WP4450249 Whirlpool Thermostat Backorder WPL WP4450249 $81.97

1

KICKPLATE WPL W11697025 Contact Us For Availability

2

W10859573 Whirlpool Range Oven Temperature Se In Stock WPL W10859573 $68.99

2

PANEL-VENT Backorder WPL W11105221 $78.77

2

W11688507 Whirlpool Insulation In Stock WPL W11688507 $9.10

2

BACK, CHASSIS WPL W11324989 Contact Us For Availability

2

INSULATION, DOOR (30 IN) WPL W11413190 Contact Us For Availability

3

W11248652 Whirlpool Blower In Stock WPL W11248652 $120.33

3

W11318823 Whirlpool Door Glass Backorder WPL W11318823 $60.54

3

W11550107 Whirlpool Oven Rack Backorder WPL W11550107 $59.22

3

WPW10138054 Whirlpool Refrigerator Cabinet Ro In Stock WPL WPW10138054 $17.40

3

WPW10351278 Whirlpool Bumper Backorder WPL WPW10351278 $3.70

4

W11029221 Whirlpool Door Latch In Stock WPL W11029221 $116.09

4

W11496977 Whirlpool Range Rack Backorder WPL W11496977 $210.16

4

W11573760 Whirlpool Surface Igniter In Stock WPL W11573760 $8.44

4

DUCT, BOTTOM (30 IN) WPL W11109583 Contact Us For Availability

4

VENT, COOLING BOTTOM (30 IN) WPL W11091676 Contact Us For Availability

4

RETAINER, GLASS WPL W11194821 Contact Us For Availability

4A

W11628654 Whirlpool Surface Igniter Backorder WPL W11628654 $19.62

5

W11643630 Whirlpool Door Hinge Backorder WPL W11643630 $79.55

5

WP9755546 Whirlpool Locknut Backorder WPL WP9755546 $2.51

5

TUBE, VENT WPL W10145743 Contact Us For Availability

5

PLATE, COOLING LATCH WPL W11109518 Contact Us For Availability

6

RETAINER Backorder WPL W10246086 $27.52

6

W10859931 Whirlpool Foot Level Backorder WPL W10859931 $46.17

6

W11193480 Whirlpool Screw In Stock WPL W11193480 $9.59

6

W11233684 Whirlpool Range Light Assembly Backorder WPL W11233684 $36.75

6

W11662207 Whirlpool Convection Baffle Backorder WPL W11662207 $60.04

7

W10169756 Whirlpool Light Lens Backorder WPL W10169756 $27.80

7

W10794440 Whirlpool Fan Motor Backorder WPL W10794440 $146.74

7

W10908710 Whirlpool Mounting Bracket Backorder WPL W10908710 $79.35

7

W11643628 Whirlpool Screw In Stock WPL W11643628 $9.59

7

WPW10272594 Whirlpool Window Frame Backorder WPL WPW10272594 $69.70

7

SCREW WPL 7101P42660 Contact Us For Availability

8

W10819914 Whirlpool Convection Fan In Stock WPL W10819914 $35.67

8

W11712404 Whirlpool Screw Backorder WPL W11712404 $8.11

8

WP4449743 Whirlpool Screw Backorder WPL WP4449743 $2.51

8

WPW10169757 Whirlpool Light Bulb In Stock WPL WPW10169757 $29.94

8

BRACKET, BLOWER MOUNT WPL W11047754 Contact Us For Availability

9

W10261523 Whirlpool Plate Backorder WPL W10261523 $27.12

9

W10340579 Whirlpool Exhaust Vent Backorder WPL W10340579 $159.52

9

W10920281 Whirlpool Screw Backorder WPL W10920281 $2.95

9

COVER-CNTL Backorder WPL W11369237 $55.78

W10115869 Whirlpool Shaft Backorder WPL W10115869 $43.57

DUCT-AIR Backorder WPL W10145363 $51.39

W10794042 Whirlpool Nut Backorder WPL W10794042 $5.29

COVER, WIFI OUTER WPL W11205795 Contact Us For Availability

RECEIVER, HINGE (NOT SERVICED) WPL ARI085D97BB298C0C5517612CE6B83B6134 Contact Us For Availability

OUTER DOOR ASSEMBLY (INCLUDES HANDLE) WPL W11712125 Contact Us For Availability

W10115793 Whirlpool Shaft Backorder WPL W10115793 $33.69

W10115855 Whirlpool Support Bracket Backorder WPL W10115855 $27.52

W11098505 Whirlpool Element Backorder WPL W11098505 $57.97

W11380145 Whirlpool Knob Bezel Backorder WPL W11380145 $34.48

LINER, OVEN (NOT SERVICED) WPL ARI0E41E73880FF530FBBE29D9D6A419FE4 Contact Us For Availability

HANDLE ASSEMBLY WPL W11362706 Contact Us For Availability

489504 Whirlpool Range Ring Backorder WPL 489504 $4.85

W11320145 Whirlpool Cabinet Panel Backorder WPL W11320145 $124.37

W11380146 Whirlpool Knob Bezel Backorder WPL W11380146 $33.65

WP3400805 Whirlpool Screw Assembly Backorder WPL WP3400805 $2.51

WP4449154 Whirlpool Screw In Stock WPL WP4449154 $2.51

BRACKET, HANDLE WPL W11197830 Contact Us For Availability

12A

CHASSIS, SIDE (RIGHT) WPL W11102296 Contact Us For Availability

W10839793 Whirlpool Refrigerator Nameplate In Stock WPL W10839793 $23.59

W11364214 Whirlpool Gas Tubing Backorder WPL W11364214 $39.86

W11380174 Whirlpool Burner Cap Backorder WPL W11380174 $66.75

WP9755542 Whirlpool Oven Meat Probe In Stock WPL WP9755542 $59.04

COVER, CHANNEL WPL W11106956 Contact Us For Availability

W10160858 Whirlpool Lid Cover Backorder WPL W10160858 $27.52

W10850807 Whirlpool Screw Backorder WPL W10850807 $2.51

W11175143 Whirlpool Gasket In Stock WPL W11175143 $9.68

W11344539 Whirlpool Burner Head In Stock WPL W11344539 $46.70

WPW10276043 Whirlpool Screw Backorder WPL WPW10276043 $2.51

SUPPORT, CHANNEL WPL W11087491 Contact Us For Availability

14A

W11344742 Whirlpool Burner Head In Stock WPL W11344742 $49.46

14B

W11344746 Whirlpool Burner Head Backorder WPL W11344746 $48.64

SCREW Backorder WPL W10739592 $6.28

W11233072 Whirlpool Screw In Stock WPL W11233072 $10.41

W11675844 Whirlpool Oven Gasket In Stock WPL W11675844 $44.23

MEDALLION, HANDLE WPL W11361074 Contact Us For Availability

W10162096 Whirlpool Screw Backorder WPL W10162096 $9.59

W11050145 Whirlpool HVAC Air Duct Backorder WPL W11050145 $61.68

W11548479 Whirlpool Knob Backorder WPL W11548479 $87.95

FRAME, FRONT WPL W11192755 Contact Us For Availability

W11169708 Whirlpool Screw Backorder WPL W11169708 $9.59

W11620685-includeCORE Whirlpool W11620685 Ran Backorder WPL W11620685-includeCORE $237.68

W11643898 Whirlpool Door Hinge Backorder WPL W11643898 $48.57

CHANNEL, WIRE WPL W11368831 Contact Us For Availability

18

W10308051 Whirlpool Burner Box Backorder WPL W10308051 $137.68

18

W11344755 Whirlpool Cooktop Backorder WPL W11344755 $63.10

18

W11362015 Whirlpool Retainer Backorder WPL W11362015 $60.35

18A

W11380180 Whirlpool Cooktop Backorder WPL W11380180 $171.65

19

W11318855 Whirlpool Antenna Backorder WPL W11318855 $113.37

19

TOP-OVEN Backorder WPL W11324986 $98.61

19

SCREW WPL 7101P43460 Contact Us For Availability

20

W10271524 Whirlpool Trim Top Backorder WPL W10271524 $88.85

20

W11355920 Whirlpool Surface Igniter Backorder WPL W11355920 $23.46

20

CHASSIS, BOTTOM WPL W11040802 Contact Us For Availability

21

W10130760 Whirlpool Bracket Mounting Backorder WPL W10130760 $27.52

21

W11355922 Whirlpool Surface Igniter In Stock WPL W11355922 $23.46

21

PANEL, BACK TOP WPL W11103334 Contact Us For Availability

21A

W10130759 Whirlpool Mounting Bracket Backorder WPL W10130759 $27.52

22

W11509770 Whirlpool Screw In Stock WPL W11509770 $10.41

22

WPW10145744 Whirlpool Support Backorder WPL WPW10145744 $75.75

22

PANEL, BACK BOTTOM WPL W11034134 Contact Us For Availability

23

W11320155 Whirlpool Mounting Bracket Backorder WPL W11320155 $41.34

23

WP12992902 Whirlpool Refrigerator Screw Backorder WPL WP12992902 $4.58

23

WPL W11700784 WPL W11700784 Contact Us For Availability

24

W10317437 Whirlpool Support Assembly Backorder WPL W10317437 $10.25

24

W11193822 Whirlpool Regulator Backorder WPL W11193822 $111.93

24

W11380561 Whirlpool Knob Backorder WPL W11380561 $43.37

25

W11318207 Whirlpool Clip Assembly Backorder WPL W11318207 $4.61

25

W11380562 Whirlpool Knob Assembly Backorder WPL W11380562 $43.37

25

W11643161 Whirlpool Range Burner Backorder WPL W11643161 $67.01

26

W10896366 Whirlpool Light Indicator Backorder WPL W10896366 $41.49

26

W11661180 Whirlpool Burner Broiler Backorder WPL W11661180 $63.21

26

DRAWER, APPLIANCE MANAGER WPL W11106341 Contact Us For Availability

27

W10308040 Whirlpool Pan Bracket Backorder WPL W10308040 $27.52

27

W11199181 Whirlpool Foot Cover Backorder WPL W11199181 $57.09

27

WPL W11500871 WPL W11500871 Contact Us For Availability

27A

W11199178 Whirlpool Foot Cover Assembly Backorder WPL W11199178 $57.09

28

W11190223 Whirlpool Bracket Assembly Backorder WPL W11190223 $41.34

28

W11548477 Whirlpool Knob Backorder WPL W11548477 $87.95

28

INSULATION, BROIL COVER WPL W10311009 Contact Us For Availability

29

W10310985 Whirlpool Access Cover Backorder WPL W10310985 $27.52

29

W11239228 Whirlpool Gas Valve Backorder WPL W11239228 $121.52

29

WPL W11205794 WPL W11205794 Contact Us For Availability

30

W11241511 Whirlpool Push Button Backorder WPL W11241511 $25.36

30

W11355244 Whirlpool Gas Tubing Backorder WPL W11355244 $66.79

31

W11355919 Whirlpool Range Gas Tubing Backorder WPL W11355919 $66.79

31

W11477029 Whirlpool Top Trim Backorder WPL W11477029 $187.33

32

W10323248 Whirlpool Top Trim Backorder WPL W10323248 $106.88

32

TUBE, GAS WPL W11109167 Contact Us For Availability

33

W10145362 Whirlpool Control Bracket Backorder WPL W10145362 $30.25

34

W11241510 Whirlpool Push Button Backorder WPL W11241510 $26.66

34

WPW10511278 Whirlpool Spark Module In Stock WPL WPW10511278 $108.08

35

W11661576 Whirlpool Range Bottom Pan Backorder WPL W11661576 $59.55

35

WP3400814 Whirlpool Screw Backorder WPL WP3400814 $2.91

36

W11380566 Whirlpool Burner Grate Backorder WPL W11380566 $123.76

37

W11550692 Whirlpool Bumper In Stock WPL W11550692 $11.72

38

W11234290 Whirlpool Electronic Control Board Backorder WPL W11234290 $75.33

39

WPL 7101P62460 WPL 7101P62460 Contact Us For Availability

40

W11123146 Whirlpool Speaker Backorder WPL W11123146 $31.29

4396096RB Whirlpool Griddle Backorder WPL 4396096RB $157.87

4396923 Whirlpool Broil Pan Set Gray Porcelai In Stock WPL 4396923 $36.18

W10285447 Whirlpool 30" Stainless Steel Range Backorder WPL W10285447 $431.20

ACCESSORY PARTS, CLEANER, COOKTOP WPL W10355051 No Longer Available

W10624584 Whirlpool Power Cord Backorder WPL W10624584 $74.77

W11368841BN Whirlpool Medallion Backorder WPL W11368841BN $88.69

W11368841CF Whirlpool Range Medallion Backorder WPL W11368841CF $88.69

MEDALLION Backorder WPL W11368841MP $75.12

W11368841NE Whirlpool Medallion Backorder WPL W11368841NE $131.86

W11368841RE Whirlpool Range Commercial-Style Backorder WPL W11368841RE $83.26

W11502161 Whirlpool Conversion Kit In Stock WPL W11502161 $26.97

W11544575 Whirlpool Anti-Tip Bracket Backorder WPL W11544575 $19.47

WP3400968 Whirlpool Nut Backorder WPL WP3400968 $3.70

FOLLOWING PARTS NOT ILLUSTRATED WPL ARI7C4B781E09F4C135E8A56A812FBF5A4D Contact Us For Availability

INSULATION, WRAP (30 IN) WPL W10282810 Contact Us For Availability

INSULATION, BOTTOM WPL W10299354 Contact Us For Availability

INSULATION, BACK (30 IN) WPL W11109145 Contact Us For Availability

ACCESSORY PARTS, GAS RANGE CONNECTOR KIT WPL 3048KITRC Contact Us For Availability

ACCESSORY PARTS, MEDALLION, HANDLE (BLACK ANO WPL W11368841BO Contact Us For Availability

ACCESSORY PARTS, MEDALLION, HANDLE (DARK BLUE WPL W11368841DD Contact Us For Availability
