Model Whirlpool KECT305VWH0 – Common Parts & Diagrams
03 - SECTION
04 - SECTION
01 - SECTION
02 - SECTION
Common parts from model Whirlpool KECT305VWH0
1
ring, intermediate (1.5 KW-black) WPL 3179150 Contact Us For Availability
1
ring, intermediate (2.0 KW-white) WPL 3179151 Contact Us For Availability
1
ring, intermediate (2.0 KW-almond) WPL 3179152 Contact Us For Availability
1
ring, intermediate (2.0 KW-black) WPL 3179153 Contact Us For Availability
2
indicator light (4) WPL 3179236 Contact Us For Availability
3
gasket, ring (1.5 KW) WPL 3147187 Contact Us For Availability
3
gasket, ring (2.0 KW) WPL 3147188 Contact Us For Availability
3
limit control (4) WPL 3179158 Contact Us For Availability
3
seal (4) control switch grommet WPL 3179128 Contact Us For Availability
4
seal, element WPL 3179361 Contact Us For Availability
4
Block, Terminal WPL 4164332 Contact Us For Availability
4
Nut, Infinite Switch (4) WPL 4159114 Contact Us For Availability
5
bracket, element (1.5 KW) WPL 3147703 Contact Us For Availability
5
bracket, element (2.0 KW) WPL 3147704 Contact Us For Availability
5
bracket, conduit mounting WPL 3179160 Contact Us For Availability
5
control knob (4) WPL 3179203 Contact Us For Availability
6
Spring, Leaf WPL 3147191 Contact Us For Availability
6
cooktop, glass (white) WPL 3179141 Contact Us For Availability
6
cooktop, glass (almond) WPL 3179142 Contact Us For Availability
6
cooktop, glass (black) WPL 3179143 Contact Us For Availability
7
hex nut (8) WPL 3147189 Contact Us For Availability
7
Conduit, Flex WPL 4167898 Contact Us For Availability
7
dressing, element WPL 3147861 Contact Us For Availability
7
burner box WPL 3179129 Contact Us For Availability
7
cover, burner box WPL 3179161 Contact Us For Availability
7
seal, foam tape WPL 3179164 Contact Us For Availability
7
Hardware, Mounting WPL 3179804 Contact Us For Availability
7
adhesive WPL 3179828 Contact Us For Availability
7
insert, avdel (4) WPL 4164131 Contact Us For Availability
8
bracket, front indicator light mounting WPL 3179137 Contact Us For Availability
9
bracket, rear indicator light mounting WPL 3179138 Contact Us For Availability
10
bracket, terminal block WPL 3179140 Contact Us For Availability
11
screw, No.10-16 x 3/4 WPL 3179829 Contact Us For Availability
12
enclosure, switch wiring WPL 3179134 Contact Us For Availability
13
speed nut (3) WPL 3179168 Contact Us For Availability
14
bracket, indicator light support WPL 3179136 Contact Us For Availability
14
limiter-RF burner WPL 3179334 Contact Us For Availability
14
terminal block-RF infinite switch WPL 3179335 Contact Us For Availability
14
limiter-LF burner WPL 3179336 Contact Us For Availability
14
terminal block-LR & RR infinite switch (2) WPL 3179337 Contact Us For Availability
14
limiter-RF & LF infinite switch (2) WPL 3179339 Contact Us For Availability
14
limiter-LR burner WPL 3179342 Contact Us For Availability
14
limiter-RR burner WPL 3179344 Contact Us For Availability
14
limiter-LR infinite switch WPL 3179345 Contact Us For Availability
14
limiter-RR infinite switch WPL 3179346 Contact Us For Availability
14
indicator light-infinite switch & terminal bl WPL 3179348 Contact Us For Availability
14
terminal block-RF, RR, & LR WPL 3179349 Contact Us For Availability
14
RF infinite switch-RF burner WPL 3179350 Contact Us For Availability
14
LF infinite switch-LF burner WPL 3179353 Contact Us For Availability
14
LR infinite switch-LR burner WPL 3179354 Contact Us For Availability
14
RR infinite switch-RR burner WPL 3179356 Contact Us For Availability
14
pilot light assy WPL 3179367 Contact Us For Availability
× ![]()
