Model Whirlpool KDRP767RSS01 36`` KITCHENAID FREE STANDING RANGE DUAL FUEL STEA – Common Parts &amp; Diagrams

3196896 Whirlpool Clip Backorder WPL 3196896 $5.14

4450800 Whirlpool Oven Screw Backorder WPL 4450800 $9.59

4453191 Whirlpool Seal Backorder WPL 4453191 $29.43

4456627 Whirlpool Wire Harness Backorder WPL 4456627 $47.14

W10138103 Whirlpool Anti-Tip Bracket Backorder WPL W10138103 $87.40

WP112432 Whirlpool Nut Assembly Backorder WPL WP112432 $2.51

WP482338 Whirlpool Refrigerator Adhesive In Stock WPL WP482338 $24.89

Harness, Wire (Ignitor 39``) WPL 4456628 Contact Us For Availability

Conv. Kit (LP) WPL 8301282 Contact Us For Availability

Bushing WPL 1129449 Contact Us For Availability

Cleaner, S.Steel WPL 2261590 Contact Us For Availability

Wire (14 Ga. 150 c Black) WPL 242820 Contact Us For Availability

Wire (14 Ga. 150 c Blue) WPL 242821 Contact Us For Availability

Wire (14 Ga. 150 c Brown) WPL 242822 Contact Us For Availability

Wire (14 Ga. 150 c Green) WPL 242823 Contact Us For Availability

Wire (14 Ga. 150 c Orange) WPL 242824 Contact Us For Availability

Wire (14 Ga. 150 c Red) WPL 242825 Contact Us For Availability

Wire (14 Ga. 150 c White) WPL 242826 Contact Us For Availability

Wire (14 Ga. 150 c Yellow) WPL 242827 Contact Us For Availability

Wire (12 Ga. 150 c Black) WPL 242828 Contact Us For Availability

Wire (12 Ga. 150 c Red) WPL 242829 Contact Us For Availability

Wire (14 Ga. 200 c Brown) WPL 242830 Contact Us For Availability

Wire (14 Ga. 200 c Yellow) WPL 242832 Contact Us For Availability

Bushing, Conduit WPL 3191506 Contact Us For Availability

Seal, Ribbon Cable WPL 4453192 Contact Us For Availability

ADHESIVE LOCTITE (1/3 OZ.) WPL 591014 Contact Us For Availability

Conduit WPL 8301668 Contact Us For Availability

Harness, Wire (Main) WPL 9758951 Contact Us For Availability

Harness, Signal WPL 9761098 Contact Us For Availability

Wire, Jumper (Oven Light) WPL 9761106 Contact Us For Availability

Harness, WPL 9762508 Contact Us For Availability

WPL 9763620 WPL 9763620 Contact Us For Availability

WPL ARI81139A3 WPL ARI81139A3 Contact Us For Availability

WPL ARI81140A5 WPL ARI81140A5 Contact Us For Availability

WPL ARI81141A6 WPL ARI81141A6 Contact Us For Availability

WPL ARI81142A8 WPL ARI81142A8 Contact Us For Availability

1

Door Liner WPL 8300152 Contact Us For Availability

1

Vent, Bottom Lower WPL 4452803 Contact Us For Availability

1

Safer Cooking Tips WPL 3191638 Contact Us For Availability

1

Installation Instructions WPL 9758978 Contact Us For Availability

1

Tech Sheet WPL 9758979 Contact Us For Availability

1

Safer Cooking Tips WPL 9759133 Contact Us For Availability

1

Conversion Instructions WPL 9759441 Contact Us For Availability

1

Cook Book WPL 9762575 Contact Us For Availability

1

Use & Care Guide WPL 9763071 Contact Us For Availability

2

9760773 Whirlpool Oven Broil Element Backorder WPL 9760773 $70.08

2

WP4455979 Whirlpool Range Small Burner Head Backorder WPL WP4455979 $34.15

2

WP9760579 Whirlpool Right Door Hinge In Stock WPL WP9760579 $39.62

2

Burner Head (Turbi (4)) WPL 4455849 Contact Us For Availability

3

WP3195996 Whirlpool Pan Grid Backorder WPL WP3195996 $41.94

3

WP3368921 Whirlpool Screw In Stock WPL WP3368921 $1.52

3

WP4449259 Whirlpool Glass Window In Stock WPL WP4449259 $79.44

3

Blower 60MM WPL 9759837 Contact Us For Availability

4

W10737569 Whirlpool Broil Pan Backorder WPL W10737569 $60.42

4

WP8284669 Whirlpool Burner Cap In Stock WPL WP8284669 $25.81

4

Cap, Burner (14k (4)) WPL 4455243 Contact Us For Availability

4

Insulation, Door WPL 8300797 Contact Us For Availability

4

Retainer, Gasket WPL 9758595 Contact Us For Availability

5

8186360 Whirlpool Oven Drain Pump Backorder WPL 8186360 $135.94

5

Control, Zodiac WPL 9761103 Contact Us For Availability

5

Deflector, Center WPL 4452801 Contact Us For Availability

5

Rack, Roasting WPL 3181534 Contact Us For Availability

6

WP4450118 Whirlpool Nut Backorder WPL WP4450118 $2.51

6

Rack, Oven WPL 9759437 Contact Us For Availability

6

Vent, Center WPL 9761914 Contact Us For Availability

7

WP4449263 Whirlpool Inner Door Glass Backorder WPL WP4449263 $80.64

7

Gasket WPL 4453327 Contact Us For Availability

7

Top, Chassis WPL 9761161 Contact Us For Availability

7

Element, Hidden Bake WPL 8300204 Contact Us For Availability

8

4448520 Whirlpool Oven Bumper Backorder WPL 4448520 $10.76

8

WP3196557 Whirlpool Screw In Stock WPL WP3196557 $2.51

8

WP4456816 Whirlpool Burner Valve Backorder WPL WP4456816 $134.02

8

Valve, Burner (Turbi (4) (Bronze)) WPL 4456818 Contact Us For Availability

9

W10861715 Whirlpool Vent Tube Backorder WPL W10861715 $38.10

9

Motor Convection WPL 4451583 Contact Us For Availability

9

Bracket, Mounting Regulator WPL 9759092 Contact Us For Availability

WP4452226 Whirlpool Convection Fan Backorder WPL WP4452226 $26.94

WP9759117 Whirlpool Leveling Foot Backorder WPL WP9759117 $60.62

Burner Switch & Harness Assembly WPL 4456903 Contact Us For Availability

Lens, Light WPL 4452163 Contact Us For Availability

3400518 Whirlpool Oven Foot Mount Screw Backorder WPL 3400518 $9.13

4449748 Whirlpool Oven Screw Backorder WPL 4449748 $7.01

WP4448972 Whirlpool Oven Light Backorder WPL WP4448972 $50.93

WP9759091 Whirlpool Regulator Backorder WPL WP9759091 $128.39

WPW10160821 Whirlpool Fan Cover Backorder WPL WPW10160821 $101.81

12

WP4452164 Whirlpool 12V 5W Halogen Light Bulb In Stock WPL WP4452164 $35.14

12

Gusset WPL 4455644 Contact Us For Availability

12

Nut WPL 4452227 Contact Us For Availability

W11643125 Whirlpool Element Backorder WPL W11643125 $44.43

WP4455605 Whirlpool Left Hand Hinge In Stock WPL WP4455605 $54.02

WP4455606 Whirlpool Right Hand Hinge In Stock WPL WP4455606 $54.02

WP9782116 Whirlpool Surface Igniter In Stock WPL WP9782116 $30.07

Support, Channel WPL 4455648 Contact Us For Availability

4455115 Whirlpool Oven Knob Backorder WPL 4455115 $13.83

4455803 Whirlpool Oven Bracket Backorder WPL 4455803 $12.39

WP4449743 Whirlpool Screw Backorder WPL WP4449743 $2.51

Bracket, Handle (Left Hand) WPL 4455804 Contact Us For Availability

Brace, Rear WPL W10015720 Contact Us For Availability

Frame, Front WPL 9762238 Contact Us For Availability

Tray, Hidden Bake WPL 8300799 Contact Us For Availability

W10858111 Whirlpool Door Gasket Backorder WPL W10858111 $66.19

Plate, Simmer WPL 4455109 Contact Us For Availability

Trim, Front (Right Side) WPL 4452804 Contact Us For Availability

Trim, Front (Left Side) WPL 4453205 Contact Us For Availability

Cover, Access WPL 8300800 Contact Us For Availability

16

4452152 Whirlpool Oven Mounting Bracket Backorder WPL 4452152 $13.12

16

WP3400805 Whirlpool Screw Assembly Backorder WPL WP3400805 $2.51

16

WP3400832 Whirlpool Screw In Stock WPL WP3400832 $2.51

WP4452997 Whirlpool PB Switch Backorder WPL WP4452997 $53.03

Support, Cooktop WPL 9758987 Contact Us For Availability

Side Chassis (Left Side) WPL 9761933 Contact Us For Availability

Side Chassis (Right Side) WPL 9761934 Contact Us For Availability

Spacer, Foam WPL 4452260 Contact Us For Availability

18

8186352 Whirlpool Boiler Backorder WPL 8186352 $207.38

18

WP9759118 Whirlpool Mounting Plate Backorder WPL WP9759118 $29.99

18

Bracket, Burner WPL 3192811 Contact Us For Availability

19

WP3177991 Whirlpool Screw Backorder WPL WP3177991 $2.51

19

Tray, Drip WPL 9762143 Contact Us For Availability

19

Support, Insulation WPL 8300184 Contact Us For Availability

20

WP4449809 Whirlpool Screw In Stock WPL WP4449809 $2.51

20

Bracket, Valve WPL 9758964 Contact Us For Availability

20

Reservoir (Includes Clamps) WPL 9761145 Contact Us For Availability

21

Switch, Cancel (Drain Pump) WPL 4457218 Contact Us For Availability

21

Tube, Manifold WPL 8301252 Contact Us For Availability

21

Bracket, Support WPL 4455510 Contact Us For Availability

22

Cover, Manifold WPL 9762133 Contact Us For Availability

22

Gasket, Sensor WPL 9762243 Contact Us For Availability

23

4453115 Whirlpool Oven Adapter Backorder WPL 4453115 $43.39

23

4453116 Whirlpool Oven Adapter Backorder WPL 4453116 $68.92

23

Sensor, Level WPL 9761107 Contact Us For Availability

24

WP9760889 Whirlpool Door Latch In Stock WPL WP9760889 $218.57

24

Control, Taurus (Appliance Mngr) WPL 9761156 Contact Us For Availability

24

Cover, Burner Box WPL 8284964 Contact Us For Availability

W10782197 Whirlpool Side Panel Backorder WPL W10782197 $54.63

WP4452842 Whirlpool Light Switch Backorder WPL WP4452842 $35.47

WPW10110486 Whirlpool Spark Module In Stock WPL WPW10110486 $140.34

SUPPRESSOR WPL 8302143 Contact Us For Availability

26

8186361 Whirlpool Oven Valve Assembly Backorder WPL 8186361 $143.61

26

Control, Steam WPL 9758985 Contact Us For Availability

26

Back, Chassis WPL 9761160 Contact Us For Availability

27

WPW10132940 Whirlpool Dishwasher Screw In Stock WPL WPW10132940 $3.13

27

Liner, Oven (Not serviceable) WPL ARI81137A2 Contact Us For Availability

28

8186363 Whirlpool Oven Hose Backorder WPL 8186363 $26.92

29

WPW10131825 Whirlpool Oven Temperature Sensor In Stock WPL WPW10131825 $54.84

30

WP3188425 Whirlpool Seal Switch In Stock WPL WP3188425 $28.80

30

WP4449154 Whirlpool Screw Backorder WPL WP4449154 $2.51

31

Screw, 8-18 x 3/8 WPL 4449040 Contact Us For Availability

32

W11233072 Whirlpool Screw In Stock WPL W11233072 $9.59

32

Nut (2) WPL 4167077 Contact Us For Availability

33

Bracket, Panel Support WPL 8300216 Contact Us For Availability

33

Orifice, Boiler WPL 9758597 Contact Us For Availability

34

Plug, Manifold WPL 8284796 Contact Us For Availability

34

Cover, Orifice Boiler WPL 9758596 Contact Us For Availability

35

8186365 Whirlpool Oven Hose Backorder WPL 8186365 $35.79

35

Tubing, Gas Burner - CR WPL 8300232 Contact Us For Availability

36

8186366 Whirlpool Oven Hose Backorder WPL 8186366 $68.83

36

Rail, Support WPL 4454974 Contact Us For Availability

37

WP4450249 Whirlpool Thermostat Backorder WPL WP4450249 $77.29

38

8186367 Whirlpool Oven Hose Assembly Backorder WPL 8186367 $26.21

40

WP489503 Whirlpool Refrigerator Clamp Backorder WPL WP489503 $4.81

41

Screw WPL 9762844 Contact Us For Availability

43

Base, Chassis WPL 8300965 Contact Us For Availability

Insulation, Wrap WPL 8300158 Contact Us For Availability

Insulation, Back WPL 8300159 Contact Us For Availability

Cover, Back WPL 9758583 Contact Us For Availability

FOLLOWING PARTS NOT ILLUSTRATED INSULATION WPL ARI81138A4 Contact Us For Availability
