Model Whirlpool JMW2427LL03 WALL OVEN, ELECTRIC, MICRO COMBO – Common Parts &amp; Diagrams

1

W11325784 Whirlpool Microwave Electronic Cont In Stock WPL W11325784 $122.93

1

W11373838 Whirlpool Glass Tray In Stock WPL W11373838 $55.73

1

W11598122 Whirlpool Broil Element Backorder WPL W11598122 $46.65

1

AIR DIVIDER ASSEMBLY WPL ARIC3DFFAB98105D2137AD531C9C75F3956 Contact Us For Availability

1

SCREW (BLACK) WPL 7101P63360 Contact Us For Availability

2

461967017511 Whirlpool Microwave Trim Backorder WPL 461967017511 $19.58

2

BRKT-MNTG Backorder WPL W10283025 $27.52

2

W11110134 Whirlpool Glass Tray Support In Stock WPL W11110134 $49.66

2

W11123146 Whirlpool Speaker Backorder WPL W11123146 $31.29

2

RACK, 27 IN OVEN WPL W11242909 Contact Us For Availability

2

SCREW WPL 7101P33860 Contact Us For Availability

3

W10318198 Whirlpool Bake Tray Backorder WPL W10318198 $69.50

3

W11044584 Whirlpool Microwave Trim In Stock WPL W11044584 $19.58

3

W11179756 Whirlpool Glass Tray Drive Coupling In Stock WPL W11179756 $13.98

3

W11320231 Whirlpool Dishwasher Nameplate Backorder WPL W11320231 $56.80

3

W11639552 Whirlpool Microwave Door Backorder WPL W11639552 $273.17

3

SCREW WPL 7101P42660 Contact Us For Availability

4

8285593 Whirlpool Oven Wire Cover Backorder WPL 8285593 $33.75

4

W10359769 Whirlpool Microwave Door Gasket Backorder WPL W10359769 $8.18

4

W10915651 Whirlpool Waveguide Cover In Stock WPL W10915651 $43.41

4

TRIM-DOOR Backorder WPL W11334717 $22.77

4

SCREW WPL 7101P43460 Contact Us For Availability

5

W11578573 Whirlpool Filter Backorder WPL W11578573 $41.05

5

W11598126 Whirlpool Support Bracket Backorder WPL W11598126 $14.20

5

W11602624 Whirlpool Oven Screw In Stock WPL W11602624 $10.41

5

W11627410 Whirlpool Mounting Rail Backorder WPL W11627410 $21.36

5

W11676353 Whirlpool Tt Motor Adapter Omi In Stock WPL W11676353 $9.02

5A

W11598127 Whirlpool Support Bracket Backorder WPL W11598127 $14.20

6

W10282957 Whirlpool Bracket Support In Stock WPL W10282957 $17.00

6

W10911403 Whirlpool Microwave Turn Motor In Stock WPL W10911403 $64.54

6

W11238401 Whirlpool Microwave Transformer In Stock WPL W11238401 $131.11

6

W11394209 Whirlpool Door Hinge Backorder WPL W11394209 $57.65

6

Backorder WPL W11602617 $395.49

6

W11627411 Whirlpool Mounting Rail Backorder WPL W11627411 $21.36

6A

W11394210 Whirlpool Door Hinge Backorder WPL W11394210 $57.65

7

W11171004 Whirlpool Rear Cover Backorder WPL W11171004 $52.01

7

W11188752 Whirlpool Microwave Fuse In Stock WPL W11188752 $6.70

7

W11545804 Whirlpool Bake Element In Stock WPL W11545804 $58.52

7

W11602615 Whirlpool Oven Door Glass Backorder WPL W11602615 $570.96

7

WPW10260060-includeCORE Whirlpool WPW10260060 Backorder WPL WPW10260060-includeCORE $192.71

8

W10245194 Whirlpool Microwave Fuse Block Backorder WPL W10245194 $29.77

8

W10650497 Whirlpool Spacer Backorder WPL W10650497 $9.08

8

W11256306 Whirlpool Rack Backorder WPL W11256306 $207.89

8

W11724411 Whirlpool Support In Stock WPL W11724411 $33.75

8

SIDE, COMBO CHASSIS (LEFT) WPL W11171909 Contact Us For Availability

8A

SIDE, COMBO CHASSIS (RIGHT) WPL W11244451 Contact Us For Availability

9

W10283023 Whirlpool Support Backorder WPL W10283023 $27.52

9

W10904163 Whirlpool Vent Deflector Backorder WPL W10904163 $64.16

9

W11175831 Whirlpool Microwave Rack Backorder WPL W11175831 $15.99

9

W11233913 Whirlpool Microwave Sensor In Stock WPL W11233913 $59.35

9

W11602631 Whirlpool Door Glass Backorder WPL W11602631 $305.32

9

CONVECT MOTOR ASSEMBLY WPL W11244895 Contact Us For Availability

W10748280 Whirlpool Microwave Rack Backorder WPL W10748280 $44.94

W11349396 Whirlpool Door Handle Backorder WPL W11349396 $184.66

W11548753 Whirlpool Convection Fan Backorder WPL W11548753 $55.82

W11578959 Whirlpool Magnetron In Stock WPL W11578959 $71.24

WP3196183 Whirlpool Screw In Stock WPL WP3196183 $3.33

W10465869 Whirlpool Microwave Spring Backorder WPL W10465869 $38.50

W11548755 Whirlpool Nut Backorder WPL W11548755 $9.59

W11676355 Whirlpool Washer Backorder WPL W11676355 $8.11

WPW10387651 Whirlpool Microwave Element In Stock WPL WPW10387651 $152.39

12

W10521808 Whirlpool Baffle Convect Backorder WPL W10521808 $121.61

12

W11598130 Whirlpool Oven Support Bracket Backorder WPL W11598130 $24.47

12

WPW10490593 Whirlpool Microwave Lamp Housing In Stock WPL WPW10490593 $28.40

W10886919 Whirlpool Light Bulb In Stock WPL W10886919 $13.85

W11165274 Whirlpool Side Panel Backorder WPL W11165274 $45.33

W11252826 Whirlpool Probe Jack Backorder WPL W11252826 $41.07

W11598128 Whirlpool Oven Support Bracket Backorder WPL W11598128 $24.47

461967754821 Whirlpool Microwave Magnetic Duc Backorder WPL 461967754821 $37.77

W11231343 Whirlpool Lock Nut In Stock WPL W11231343 $9.59

W11598131 Whirlpool Oven Clip In Stock WPL W11598131 $5.44

BACK, CHASSIS (NOT SERVICED) WPL ARI6655B8C91FC6F816F7982F80F561FE0E Contact Us For Availability

W10211972 Whirlpool Microwave Switch In Stock WPL W10211972 $32.67

WPW10517428 Whirlpool Spacer Backorder WPL WPW10517428 $4.30

LINER, OVEN (NOT SERVICEABLE) WPL ARI221486ECAEC93F8B8C6C8EF9CFFD9E68 Contact Us For Availability

BAFFLE, BOW TIE WPL W11192519 Contact Us For Availability

W11214928 Whirlpool Microwave Interlock Backorder WPL W11214928 $13.49

W11598120 Whirlpool Thermostat In Stock WPL W11598120 $15.08

WP9755542 Whirlpool Oven Meat Probe In Stock WPL WP9755542 $59.04

TOP VENT TRIM ASSEMBLY WPL W11671365 Contact Us For Availability

423107022541 Whirlpool Microwave Reflector Backorder WPL 423107022541 $34.44

Backorder WPL W10588737 $41.82

WP694091 Whirlpool Screw Backorder WPL WP694091 $2.51

WPW10472384 Whirlpool Light Bulb In Stock WPL WPW10472384 $57.37

W10566973 Whirlpool Wire Harness In Stock WPL W10566973 $31.46

W11193483 Whirlpool Microwave Lamp Lens In Stock WPL W11193483 $39.07

W11617225 Whirlpool Oven Screw Backorder WPL W11617225 $9.59

W11678579 Whirlpool Element Backorder WPL W11678579 $44.05

WP4449751 Whirlpool Range Oven Thermostat Fix In Stock WPL WP4449751 $76.71

W10443110 Whirlpool Screw Backorder WPL W10443110 $5.38

W10850807 Whirlpool Screw Backorder WPL W10850807 $2.51

W11440819 Whirlpool Clip Backorder WPL W11440819 $10.76

BASE, CHASSIS WPL W11244454 Contact Us For Availability

W10575307 Whirlpool Wire Harness Backorder WPL W10575307 $72.82

SCREW Backorder WPL W10739592 $6.28

W11033422 Whirlpool Microwave Interlock In Stock WPL W11033422 $108.21

W11369891 Whirlpool Heat Deflector Backorder WPL W11369891 $41.07

8205707 Whirlpool Microwave Support Backorder WPL 8205707 $29.43

W10668510 Whirlpool Housing Backorder WPL W10668510 $42.51

W11244446 Whirlpool Cover Access Backorder WPL W11244446 $49.01

W11598121 Whirlpool Top-Cabnt Backorder WPL W11598121 $29.81

22

W10283020 Whirlpool Support Backorder WPL W10283020 $28.26

22

COVER, CONVECT PLATE WPL W11235449 Contact Us For Availability

22

HINGE, DOOR WPL W11681073 Contact Us For Availability

23

SUPPORT Backorder WPL W11135135 $19.95

23

W11344874 Whirlpool Microwave Fan Motor In Stock WPL W11344874 $78.66

23

PLATE, CONVECT MOTOR WPL W11251715 Contact Us For Availability

24

W11578579 Whirlpool Inverter In Stock WPL W11578579 $99.63

24

SPACER, BOTTOM CHASSIS DUCT WPL W11135125 Contact Us For Availability

24

INSULATION, CONVECT MOTOR WPL W11251716 Contact Us For Availability

25

461967825971 Whirlpool Oven Screw Backorder WPL 461967825971 $7.58

25

W11598125 Whirlpool Bumper Backorder WPL W11598125 $10.76

26

WPW10120235 Whirlpool Microwave Relief Rod In Stock WPL WPW10120235 $5.12

26

WPW10519866 Whirlpool Light Backorder WPL WPW10519866 $61.34

28

TUBE-VENT Backorder WPL W11256423 $20.39

28

W11700292 Whirlpool Spring Backorder WPL W11700292 $28.11

29

W11684510 Whirlpool Support In Stock WPL W11684510 $5.38

29

DEFLECTOR, CHASSIS (LEFT) WPL W11186391 Contact Us For Availability

29A

DEFLCTR-VT Backorder WPL W11186398 $19.65

30

W11598150 Whirlpool Side Cover Backorder WPL W11598150 $27.45

30

W11607070 Whirlpool Arm Backorder WPL W11607070 $10.23

30A

W11598151 Whirlpool Side Cover Backorder WPL W11598151 $27.45

31

W11134657 Whirlpool Rear Cover Backorder WPL W11134657 $52.01

31

W11699906 Whirlpool Sensor In Stock WPL W11699906 $53.62

32

W11235457 Whirlpool Trim Backorder WPL W11235457 $29.54

32

WPW10128850 Whirlpool Microwave Arm In Stock WPL WPW10128850 $45.68

32A

W11235458 Whirlpool Trim Backorder WPL W11235458 $29.54

33

W11607085 Whirlpool Microwave Thermostat Fix In Stock WPL W11607085 $17.68

33

WPY706189 Whirlpool Stove Screw In Stock WPL WPY706189 $3.33

34

W11512064 Whirlpool Microwave Fan In Stock WPL W11512064 $63.89

34

WPW10254050 Whirlpool Screw Backorder WPL WPW10254050 $2.51

35

WPW10493735 Whirlpool Microwave Heater Backorder WPL WPW10493735 $47.16

35

RIVET (BLACK) WPL W11696855 Contact Us For Availability

36

W11534564 Whirlpool Microwave Convection Moto Backorder WPL W11534564 $37.95

36

W11712432 Whirlpool Trim Assembly In Stock WPL W11712432 $32.98

37

W11208292 Whirlpool Microwave Sensor Backorder WPL W11208292 $62.86

37

W11598170 Whirlpool Level Foot Backorder WPL W11598170 $12.59

38

461967842541 Whirlpool Microwave Actuator Backorder WPL 461967842541 $29.26

38

W11598169 Whirlpool Foot Level Assembly Backorder WPL W11598169 $12.59

39

W10769147 Whirlpool Microwave Foam Seal Backorder WPL W10769147 $14.44

40

W11715912 Whirlpool Spring Assembly Backorder WPL W11715912 $2.29

41

461967825321 Whirlpool Microwave Screw Backorder WPL 461967825321 $7.47

42

W11690594 Whirlpool Screw Backorder WPL W11690594 $8.11

43

HOUSING, UPPER INVERTER WPL W11591019 Contact Us For Availability

44

HOUSING, LOWER INVERTER WPL W11591018 Contact Us For Availability

46

461967825601 Whirlpool Screw Backorder WPL 461967825601 $9.13

W10123240 Whirlpool Broil Pan and Roasting Ra Backorder WPL W10123240 $72.40

W11369893 Whirlpool Heat Deflector Backorder WPL W11369893 $41.07

W11598168 Whirlpool Leveling Foot Backorder WPL W11598168 $12.52

INSULATION (NOT ILLUSTRATED) WPL ARIC3896A09BBAECADB12C59FB914B3A715 Contact Us For Availability

INSULATION, WRAP WPL W11244474 Contact Us For Availability

INSULATION, BACK WPL W11244475 Contact Us For Availability
