JGBP28BEH3WH

Model JGBP28BEH3WH – Common Parts & Diagrams

Common parts from model JGBP28BEH3WH

WB03K10141 GE Oven Mini Valve Knob

WB03K10141 GE Oven Mini Valve Knob Out of Stock GEN WB03K10141 $23.04

WB28K10023 GE Oven Orifice

WB28K10023 GE Oven Orifice In Stock GEN WB28K10023 $8.14

WB01K10037 GE Oven Economic Nut

WB01K10037 GE Oven Economic Nut Out of Stock GEN WB01K10037 $5.00

WB01K10002 GE Oven Screw 8-32

WB01K10002 GE Oven Screw 8-32 In Stock GEN WB01K10002 $14.24

WB02K10361 GE Oven Orifice Holder

WB02K10361 GE Oven Orifice Holder In Stock GEN WB02K10361 $9.27

WB24K10025 GE Oven SW Valve Service 140 W2S

WB24K10025 GE Oven SW Valve Service 140 W2S Out of Stock GEN WB24K10025 $16.83

WB21K10081 GE Oven 140 Burner Valve

WB21K10081 GE Oven 140 Burner Valve In Stock GEN WB21K10081 $14.58

WB2K24 GE Oven Cover Valve

WB2K24 GE Oven Cover Valve Out of Stock GEN WB2K24 $24.76

WB28K10188 GE Oven Rear Orifice H R 150N 9500

WB28K10188 GE Oven Rear Orifice H R 150N 9500 Out of Stock GEN WB28K10188 $19.48

WB1K83 GE Oven Screw

WB1K83 GE Oven Screw In Stock GEN WB1K83 $5.11

WB28K10190 GE Oven Left Front Orifice

WB28K10190 GE Oven Left Front Orifice In Stock GEN WB28K10190 $17.77

WB28K10168 GE Oven Tube Burner Supply

WB28K10168 GE Oven Tube Burner Supply Out of Stock GEN WB28K10168 $27.22

WB1X1293 GE Oven Screw

WB1X1293 GE Oven Screw In Stock GEN WB1X1293 $5.11

WB34K14 GE Cover Ignitor

WB34K14 GE Cover Ignitor Out of Stock GEN WB34K14 $11.88

WB07K10193 GE Oven End Support Gloss Black

WB07K10193 GE Oven End Support Gloss Black Out of Stock GEN WB07K10193 $13.81

WB07K10194 GE Oven End Support Gloss Black

WB07K10194 GE Oven End Support Gloss Black Out of Stock GEN WB07K10194 $13.81

WB37K10003 GE Bracket Cooktop Right

WB37K10003 GE Bracket Cooktop Right Out of Stock GEN WB37K10003 $5.00

WB37K10004 GE Bracket Cooktop Left

WB37K10004 GE Bracket Cooktop Left Out of Stock GEN WB37K10004 $5.18

WB02K10074 GE Oven Bracket Control

WB02K10074 GE Oven Bracket Control Out of Stock GEN WB02K10074 $5.18

WB27K10354 GE Oven Control To9 (Gas)

WB27K10354 GE Oven Control To9 (Gas) In Stock GEN WB27K10354 $84.72

WB34K10003 GE Oven Cover Back Upper

WB34K10003 GE Oven Cover Back Upper Out of Stock GEN WB34K10003 $32.71

WB01T10016 GE Oven Screw 8-18 AB HXW 5/8 S

WB01T10016 GE Oven Screw 8-18 AB HXW 5/8 S Out of Stock GEN WB01T10016 $5.11

WB1X5364 GE Oven Screw Mounting

WB1X5364 GE Oven Screw Mounting Out of Stock GEN WB1X5364 $5.11

WB18K10035 GE Oven Wire Harness

WB18K10035 GE Oven Wire Harness In Stock GEN WB18K10035 $26.66

WB31K10033 GE Oven Burner Grate

WB31K10033 GE Oven Burner Grate In Stock GEN WB31K10033 $74.60

WB2K91 GE Oven Support Top

WB2K91 GE Oven Support Top Out of Stock GEN WB2K91 $4.86

WB14K5 GE Oven Pin Hinge

WB14K5 GE Oven Pin Hinge Out of Stock GEN WB14K5 $5.00

WB1K45 GE Oven Screw & Washer Assembly

WB1K45 GE Oven Screw & Washer Assembly Out of Stock GEN WB1K45 $5.11

WB1K5119 GE Oven Screw

WB1K5119 GE Oven Screw Out of Stock GEN WB1K5119 $5.00

WB01K10008 GE Oven Mounting Screw

WB01K10008 GE Oven Mounting Screw Out of Stock GEN WB01K10008 $5.11

WB29K10001 GE Oven Burner Cap

WB29K10001 GE Oven Burner Cap In Stock GEN WB29K10001 $45.40

WB16K10055 GE Oven Burner Base

WB16K10055 GE Oven Burner Base In Stock GEN WB16K10055 $28.40

WB01K10112 GE Range Stove Oven Electrode Clip

WB01K10112 GE Range Stove Oven Electrode Clip In Stock GEN WB01K10112 $5.11

WB48T10095 GE Oven Rack

WB48T10095 GE Oven Rack In Stock GEN WB48T10095 $52.97

WB48X10056 GE Large Porcelain Broil Pan Set

WB48X10056 GE Large Porcelain Broil Pan Set In Stock GEN WB48X10056 $21.29

WB1K5062 GE Oven Screw

WB1K5062 GE Oven Screw In Stock GEN WB1K5062 $5.11

WB1X536 GE Oven Screw

WB1X536 GE Oven Screw Out of Stock GEN WB1X536 $6.25

WZ4X345D GE Screw Package 12 C92

WZ4X345D GE Screw Package 12 C92 Out of Stock GEN WZ4X345D $15.53

WR01X10065 GE Screw

WR01X10065 GE Screw Out of Stock GEN WR01X10065 $5.11

WB35X37973 GE Bottom Oven and Deflector Assem

WB35X37973 GE Bottom Oven and Deflector Assem In Stock GEN WB35X37973 $59.17

WB19K10051 GE Oven Valve Control Assembly SIC

WB19K10051 GE Oven Valve Control Assembly SIC In Stock GEN WB19K10051 $130.90

WB2X9154 GE Oven Ignitor 8" Leads

WB2X9154 GE Oven Ignitor 8" Leads In Stock GEN WB2X9154 $80.55

WB08T10026 GE Range Receptacle Push-In

WB08T10026 GE Range Receptacle Push-In In Stock GEN WB08T10026 $5.11

WB28X24772 GE Oven Gas Tube or Connector

WB28X24772 GE Oven Gas Tube or Connector Out of Stock GEN WB28X24772 $28.78

WB02X10521 GE Oven Levelling Leg

WB02X10521 GE Oven Levelling Leg In Stock GEN WB02X10521 $8.89

WB38K10001 GE Oven Vent Assembly

WB38K10001 GE Oven Vent Assembly Out of Stock GEN WB38K10001 $36.49

WB34K10 GE Oven Shield Broil

WB34K10 GE Oven Shield Broil Out of Stock GEN WB34K10 $13.61

WB2K27 GE Oven Bail

WB2K27 GE Oven Bail Out of Stock GEN WB2K27 $38.00

WB02X21679 GE Oven Clip Wire

WB02X21679 GE Oven Clip Wire Out of Stock GEN WB02X21679 $5.11

WB2K32 GE Oven BCKT Support

WB2K32 GE Oven BCKT Support Out of Stock GEN WB2K32 $4.86

WB34K10086 GE Oven Lower Heat Shield

WB34K10086 GE Oven Lower Heat Shield Out of Stock GEN WB34K10086 $99.12

WB63K16 GE Oven Guard Bottom

WB63K16 GE Oven Guard Bottom Out of Stock GEN WB63K16 $83.25

WB34K13 GE Oven Cover B Panel SP

WB34K13 GE Oven Cover B Panel SP Out of Stock GEN WB34K13 $9.18

GE Range Washer

GE Range Washer Out of Stock GEN WB1X119D $9.27

WB57K2 GE Oven Outer Glass Door Black

WB57K2 GE Oven Outer Glass Door Black Out of Stock GEN WB57K2 $166.09

WB7K403 GE Oven Trim Top Door

WB7K403 GE Oven Trim Top Door Out of Stock GEN WB7K403 $35.62

WB4K1 GE Oven Door Gasket

WB4K1 GE Oven Door Gasket In Stock GEN WB4K1 $35.15

WB1X558D GE Oven Screw Package 12

WB1X558D GE Oven Screw Package 12 Out of Stock GEN WB1X558D $14.61

WB02K10061 GE Oven Drawer Glide

WB02K10061 GE Oven Drawer Glide In Stock GEN WB02K10061 $5.11

WB02K10062 GE Oven Drawer Glide

WB02K10062 GE Oven Drawer Glide Out of Stock GEN WB02K10062 $5.11

WB39K20 GE Oven Bracket Mounting DRW

WB39K20 GE Oven Bracket Mounting DRW Out of Stock GEN WB39K20 $5.11

WB1K63 GE Oven Screw

WB1K63 GE Oven Screw Out of Stock GEN WB1K63 $28.35

WB1K67 GE Oven Screw 8-22

WB1K67 GE Oven Screw 8-22 Out of Stock GEN WB1K67 $5.00

WB1K62 GE Oven WB01K0041

WB1K62 GE Oven WB01K0041 Out of Stock GEN WB1K62 $5.00

WB07K10232 GE Oven Trim Bottom Assembly

WB07K10232 GE Oven Trim Bottom Assembly Out of Stock GEN WB07K10232 $9.36

WB36K10033 GE Oven Panel Drawer (White)

WB36K10033 GE Oven Panel Drawer (White) Out of Stock GEN WB36K10033 $79.26

WB35K10040 GE Oven Insulation Control

WB35K10040 GE Oven Insulation Control Out of Stock GEN WB35K10040 $7.00
