Model Whirlpool GU940SCGZ2 UNDERCOUNTER DISHWASHER – Common Parts &amp; Diagrams

350942 Whirlpool Spray Paint Backorder WPL 350942 $32.57

350956 Whirlpool Spray Assembly In Stock WPL 350956 $20.04

675679 Whirlpool Dishwasher White Tip Tines In Stock WPL 675679 $11.01

676458 Whirlpool Dishwasher Tine Tip Backorder WPL 676458 $15.56

72017 Whirlpool Appliance Touch-Up Paint Whit In Stock WPL 72017 $4.25

72032 Whirlpool Touch Up Paint Black In Stock WPL 72032 $15.46

W10840471 Whirlpool Dishwasher Touch Up In Stock WPL W10840471 $15.23

W10841140 Whirlpool Dishwasher Adhesive In Stock WPL W10841140 $8.99

WP676453 Whirlpool Dishwasher Touch-Up In Stock WPL WP676453 $16.60

WP676455 Whirlpool Dishwasher Touch-Up In Stock WPL WP676455 $16.25

WP72107 Whirlpool Touchup In Stock WPL WP72107 $6.62

1

W10311986 Whirlpool Dishwasher Lower Rack Backorder WPL W10311986 $177.46

1

DOOR SPRING KIT: (HEAVY DUTY) WPL 4318050 Contact Us For Availability

1

Seal, Tube WPL 9742953 Contact Us For Availability

1

Console (Includes Insert) (Black) WPL 8051707 Contact Us For Availability

2

WP3376961 Whirlpool Dishwasher Wheel Backorder WPL WP3376961 $31.53

2

Tub, Wheel Assembly (8) WPL 3380371 Contact Us For Availability

3

WP3385142 Whirlpool Dishwasher Bumper Backorder WPL WP3385142 $34.72

3

WP9741232 Whirlpool Dishwasher Screw In Stock WPL WP9741232 $3.33

4

W10728160 Whirlpool Tine Assembly In Stock WPL W10728160 $29.52

4

WP302710 Whirlpool Dishwasher Ring Seal Backorder WPL WP302710 $4.26

4

WP3369505 Whirlpool Dishwasher Actuator Backorder WPL WP3369505 $17.06

5

WP8052028 Whirlpool Dishwasher Dispenser Backorder WPL WP8052028 $46.99

5

Pivot, Folddown WPL 3379955 Contact Us For Availability

6

WP3379673 Whirlpool Dishwasher Seal Backorder WPL WP3379673 $5.71

6

Retainer, Tinerow WPL 3368629 Contact Us For Availability

6

Wheel (2) WPL 302819 Contact Us For Availability

7

WP719929 Whirlpool Dishwasher Check Ball Backorder WPL WP719929 $4.43

7

Silverware Basket Asembly WPL 3380872 Contact Us For Availability

7

Draw Bar, Electronic WPL 3369448 Contact Us For Availability

8

WP3368999 Whirlpool Dishwasher Spring In Stock WPL WP3368999 $3.33

8

Plate, Latch WPL 3378149 Contact Us For Availability

8

Door Frame (Black) WPL 9743028 Contact Us For Availability

8

Door, Silverware Basket WPL 3380874 Contact Us For Availability

9

WP3378138 Whirlpool Cover Assembly In Stock WPL WP3378138 $11.51

9

WP3380854 Whirlpool Door Latch Bolt In Stock WPL WP3380854 $51.51

9

Filter Assembly (Includes Items 12, 13 & 22) WPL 9742968 Contact Us For Availability

9

Lid, Silverware Basket WPL 3380876 Contact Us For Availability

WP8268874 Whirlpool Dishwasher Spray Arm Backorder WPL WP8268874 $58.34

Lever, Latch (Black) WPL 3369457 Contact Us For Availability

Lever, Latch White WPL 3372231 Contact Us For Availability

Screw WPL 3400001 Contact Us For Availability

11

WP3372028 Whirlpool Hinge Pin In Stock WPL WP3372028 $5.25

11

WP3378144 Whirlpool Dishwasher Tube Backorder WPL WP3378144 $29.46

WP3371152 Whirlpool Dishwasher Screw Backorder WPL WP3371152 $3.70

WP3371710 Whirlpool Dishwasher Screen Backorder WPL WP3371710 $3.70

WP3376846 Whirlpool Seal In Stock WPL WP3376846 $12.16

WP9742945 Whirlpool Spray Arm Nut In Stock WPL WP9742945 $4.34

Pin, Switch (2) WPL 3368955 Contact Us For Availability

13

WP302711 Whirlpool Dishwasher Ring Seal In Stock WPL WP302711 $11.66

13

WP3378134 Whirlpool Dishwasher Cap In Stock WPL WP3378134 $4.70

13

WP9742946 Whirlpool Dishwasher Spray Arm Bear In Stock WPL WP9742946 $12.24

3376405 Whirlpool Dishwasher Elbow Backorder WPL 3376405 $5.33

8194582 Whirlpool Dishwasher Outlet Backorder WPL 8194582 $34.82

WP717273 Whirlpool Dishwasher Rubber Washer In Stock WPL WP717273 $3.46

Clip, Silverware Basket (Left) WPL 8051187 Contact Us For Availability

15

675238 Whirlpool Check Valve In Stock WPL 675238 $29.44

15

Clip, Silverware Basket (Right) WPL 8051188 Contact Us For Availability

16

Gasket, Pump WPL 717000 Contact Us For Availability

16

Cover, Drip WPL 3371569 Contact Us For Availability

17

Motor, Dual WPL 3374501 Contact Us For Availability

17

Stop, Track WPL 3379941 Contact Us For Availability

17

Pump & Motor Assembly (Includes Item 16) WPL 8051312 Contact Us For Availability

18

WP661566 Whirlpool High Limit Thermostat In Stock WPL WP661566 $15.26

19

WP3379674 Whirlpool Dishwasher Vent Assembly Backorder WPL WP3379674 $42.29

19

Panel Front (White) WPL 3379376 Contact Us For Availability

19

Panel Front (Black) WPL 3379375 Contact Us For Availability

22

Seal, Drain Cover WPL 302704 Contact Us For Availability

23

WP9743019 Whirlpool Dishwasher Clip In Stock WPL WP9743019 $5.27

23

Cover, Drain (Also Order Item 30) See Note A. WPL 3376845 Contact Us For Availability

24

675806 Whirlpool Dishwasher Pump Impeller and In Stock WPL 675806 $90.19

24

Tube, Feed WPL 9743958 Contact Us For Availability

25

WP3379369 Whirlpool Dishwasher Wash Assembly In Stock WPL WP3379369 $30.25

25

Base, Pump (Also Order Item 30) See Note A. WPL 3376157 Contact Us For Availability

26

WP3367197 Whirlpool Dishwasher Support Backorder WPL WP3367197 $3.51

26

WP3373234 Whirlpool Dishwasher Bearing Backorder WPL WP3373234 $4.43

27

W10909679 Whirlpool Dishwasher Slinger Backorder WPL W10909679 $8.24

28

WP3374343 Whirlpool Dishwasher Spring In Stock WPL WP3374343 $11.07

28

Motor & Fan (Assembly) (Includes Item 27) (Al WPL 3377333 Contact Us For Availability

29

Housing, Float Switch WPL 3369048 Contact Us For Availability

29

Screw (4) WPL 3369331 Contact Us For Availability

30

Pump Seal Kit (Includes Items 4, 12, 13 & 22) WPL 675505 Contact Us For Availability

31

Tool, Pump Centering WPL 303918 Contact Us For Availability

32

WP3376397 Whirlpool Dishwasher Float Assembly In Stock WPL WP3376397 $54.72

32

WP356138 Whirlpool Hose Clamp In Stock WPL WP356138 $4.52

33

WP3374077 Whirlpool Dishwasher Drain Hose In Stock WPL WP3374077 $50.93

33

Nut WPL 717488 Contact Us For Availability

34

3371748 Whirlpool Dishwasher Cap Backorder WPL 3371748 $4.41

35

Shaft, Absorber WPL 3374757 Contact Us For Availability

36

WP302868 Whirlpool Screw In Stock WPL WP302868 $3.33

36

Weight, Absorber WPL 3378202 Contact Us For Availability

37

Thermistor WPL 9743158 Contact Us For Availability

38

Seal, O-Ring WPL 3376723 Contact Us For Availability

39

WP3376358 Whirlpool Dishwasher Retainer Backorder WPL WP3376358 $4.48

40

WP9740674 Whirlpool Dishwasher Gasket Backorder WPL WP9740674 $3.70

42

COVER ASSEMBLY TERMINAL BOX WPL 300068 Contact Us For Availability

53

3379740 Whirlpool Dishwasher Heater Support Backorder WPL 3379740 $33.69

54

WP3400014 Whirlpool Dishwasher Screw Backorder WPL WP3400014 $2.51

55

WP3378128 Whirlpool Dishwasher Washer Backorder WPL WP3378128 $2.51

59

Friction Pad (Velcro) WPL 8052018 Contact Us For Availability
