Model Whirlpool GR2FHMXPT01 REFRIGERATOR – Common Parts &amp; Diagrams

350930 Whirlpool White Spray Paint In Stock WPL 350930 $12.50

350942 Whirlpool Spray Paint Backorder WPL 350942 $32.57

4392899 Whirlpool Biscuit Touch-Up Paint In Stock WPL 4392899 $6.86

4392901 Whirlpool Biscuit Spray Paint In Stock WPL 4392901 $26.26

511873 Whirlpool Refrigerator Paint Backorder WPL 511873 $19.22

606755 Whirlpool Refrigerator Bag Backorder WPL 606755 $26.21

72017 Whirlpool Appliance Touch-Up Paint Whit In Stock WPL 72017 $3.35

72032 Whirlpool Touch Up Paint Black In Stock WPL 72032 $5.60

799344 Whirlpool Refrigerator Paint Backorder WPL 799344 $93.22

833938 Whirlpool Refrigerator Terminal Backorder WPL 833938 $3.70

WP503695 Whirlpool Refrigerator Sealer Backorder WPL WP503695 $39.18

WP505587 Whirlpool Refrigerator Sealer Backorder WPL WP505587 $57.83

WP542638 Whirlpool Refrigerator Grease In Stock WPL WP542638 $22.07

WPL 876029 WPL 876029 Contact Us For Availability

TAPE, VINYL (3/4 X 108``) WPL 479502 Contact Us For Availability

Torx Key WPL 1117510 Contact Us For Availability

1

WP488878 Whirlpool Refrigerator Tube Clamp Backorder WPL WP488878 $4.81

1

Shelf, Ladder (2) WPL 2210522 Contact Us For Availability

1

Plate, Unit Mounting WPL 2225596 Contact Us For Availability

2

W11553819 Whirlpool Refrigerator Insulation In Stock WPL W11553819 $9.59

2

Shelf, Ladder Center WPL 2300520 Contact Us For Availability

3

2163762 Whirlpool Refrigerator Cup Assembly Backorder WPL 2163762 $4.32

3

WP2166108 Whirlpool Refrigerator Cabinet Roll In Stock WPL WP2166108 $13.54

3

WP2214960 Whirlpool Refrigerator Condenser Backorder WPL WP2214960 $134.98

3

WP2254360 Whirlpool Refrigerator Gasket In Stock WPL WP2254360 $8.67

4

W10136387A Whirlpool Refrigerator Egg Contain In Stock WPL W10136387A $5.98

4

WP2315530 Whirlpool Refrigerator Heater In Stock WPL WP2315530 $56.15

4

WP489427 Whirlpool Refrigerator Screw Backorder WPL WP489427 $3.70

5

WP628379 Whirlpool Refrigerator Clip Backorder WPL WP628379 $4.61

5

Evaporator Assy. WPL 2221761 Contact Us For Availability

6

WP3400065 Whirlpool Refrigerator Screw Backorder WPL WP3400065 $2.51

6

WPW10171469 Whirlpool Refrigerator Screw In Stock WPL WPW10171469 $4.58

7

WP2212648 Whirlpool Refrigerator Hinge Sleeve Backorder WPL WP2212648 $3.70

7

WP2212651 Whirlpool Refrigerator Button Plug Backorder WPL WP2212651 $10.27

7

Drain Pan WPL 2254295 Contact Us For Availability

7

Glass, Shelf WPL 2214913 Contact Us For Availability

8

2254352A Whirlpool Refrigerator Ice Container In Stock WPL 2254352A $14.91

8

Bracket, Heater WPL 2176301 Contact Us For Availability

9

WP2314549 Whirlpool Refrigerator Cover In Stock WPL WP2314549 $103.84

10

WPW10189703 Whirlpool Refrigerator Evaporator In Stock WPL WPW10189703 $35.77

10

Shelf Assembly WPL 2214911 Contact Us For Availability

10

Extension, Air Baffle WPL 2300638 Contact Us For Availability

WP2163777 Whirlpool Refrigerator Fan Blade In Stock WPL WP2163777 $30.29

WP2176225 Whirlpool Glass Shelf Backorder WPL WP2176225 $120.79

WP3400504 Whirlpool Refrigerator Screw Backorder WPL WP3400504 $3.70

WP627018 Whirlpool Refrigerator Nut In Stock WPL WP627018 $4.59

2210495 Whirlpool Refrigerator Clip Backorder WPL 2210495 $31.90

WP2162358 Whirlpool Refrigerator Terminal Cov Backorder WPL WP2162358 $30.03

WP2183003 Whirlpool Thimble In Stock WPL WP2183003 $3.70

Control Box WPL 2212982 Contact Us For Availability

Frame Assembly, Meat Shelf WPL 2214892 Contact Us For Availability

13

W11594405 Whirlpool Axle In Stock WPL W11594405 $6.90

13

WP2214067 Whirlpool Refrigerator Overload Rel Backorder WPL WP2214067 $50.58

13

Thermostat Assembly (Includes Illus. 5 & 18) WPL 2200859 Contact Us For Availability

14

876811 Whirlpool Grommet Backorder WPL 876811 $3.70

14

940014 Whirlpool Refrigerator Primary Button Backorder WPL 940014 $10.25

14

WP4387558 Whirlpool Refrigerator Compressor G Backorder WPL WP4387558 $3.70

15

WP2172748 Whirlpool Drawer Support Backorder WPL WP2172748 $50.82

15

WP2225929 Whirlpool Refrigerator Start Device Backorder WPL WP2225929 $52.61

15

WP489497 Whirlpool Screw In Stock WPL WP489497 $4.58

16

Cover, Evaporator WPL 2302561 Contact Us For Availability

16

Shelf Assembly, Spillguard (2) WPL 2214909 Contact Us For Availability

8009 Whirlpool 40W 120V Light Bulb In Stock WPL 8009 $6.56

WP2183854 Whirlpool Refrigerator Shim Backorder WPL WP2183854 $4.54

WPW10475495 Whirlpool Roller Assembly In Stock WPL WPW10475495 $11.53

Trim, Door Shelf (2) WPL 2195947 Contact Us For Availability

Shelf, Freezer WPL 2184667 Contact Us For Availability

18

WP489464 Whirlpool Refrigerator Screw Backorder WPL WP489464 $3.70

18

Nameplate WPL 2220214 Contact Us For Availability

18

Weight, Thermal WPL 2200831 Contact Us For Availability

19

W10854037 Whirlpool Refrigerator Crisper Pan In Stock WPL W10854037 $89.14

19

W11384469 Whirlpool Door Switch In Stock WPL W11384469 $12.68

19

Clip, Heater WPL 2182338 Contact Us For Availability

20

WP2218132K Whirlpool Crisper Meat Pan In Stock WPL WP2218132K $102.95

20

WP2254473 Whirlpool Refrigerator Door Hinge In Stock WPL WP2254473 $3.70

20

Wire Assembly, Freezer Compartment (Includes WPL 2187992 Contact Us For Availability

21

WP489128 Whirlpool Refrigerator Screw Backorder WPL WP489128 $4.56

21

Cover, Air Diffuser WPL 2176281 Contact Us For Availability

W10829461 Whirlpool Refrigerator Thermal Knob Backorder WPL W10829461 $12.08

WP2218109 Whirlpool Refrigerator Door Compres Backorder WPL WP2218109 $42.64

WP628356 Whirlpool Refrigerator Fill Cup In Stock WPL WP628356 $15.77

Support Block WPL 2201185 Contact Us For Availability

23

3400518 Whirlpool Oven Foot Mount Screw Backorder WPL 3400518 $9.13

23

WP2254354 Whirlpool Refrigerator Air Tower Backorder WPL WP2254354 $51.48

23

Trim, Door Shelf WPL 2159306 Contact Us For Availability

24

WP2182124 Whirlpool Refrigerator Stripper Arm Backorder WPL WP2182124 $26.81

24

WP2189452 Whirlpool Refrigerator Diffuser Backorder WPL WP2189452 $42.62

26

2212996 Whirlpool Refrigerator Retainer Backorder WPL 2212996 $7.52

26

Air Separator Assembly WPL 2212439 Contact Us For Availability

27

WP2172890 Whirlpool Refrigerator Wire Backorder WPL WP2172890 $2.51

27

WP627985 Whirlpool Icemaker Cycling Thermosta In Stock WPL WP627985 $41.93

28

8533917 Whirlpool Refrigerator Screw In Stock WPL 8533917 $9.59

28

W10309988 Whirlpool Refrigerator Compressor In Stock WPL W10309988 $284.26

28

Screw WPL 8534009 Contact Us For Availability

29

W10843121 Whirlpool Refrigerator Tube In Stock WPL W10843121 $23.50

29

BRACKET, FAN MOTOR WPL 2254453 Contact Us For Availability

30

WPW10339879 Whirlpool Wire Tie In Stock WPL WPW10339879 $2.51

31

2254454 Whirlpool Refrigerator Bracket Backorder WPL 2254454 $31.79

31

W10920279 Whirlpool Refrigerator Start Relay In Stock WPL W10920279 $40.48

31

WP627792 Whirlpool Refrigerator Shut Off Arm Backorder WPL WP627792 $35.26

32

WP2176222 Whirlpool Refrigerator Slide In Stock WPL WP2176222 $9.97

32

WPW10662129 Whirlpool Refrigerator Run Capaci In Stock WPL WPW10662129 $28.24

33

W11500948 Whirlpool Refrigerator Bracket In Stock WPL W11500948 $12.32

34

Knob, Damper WPL 2302536 Contact Us For Availability

35

WPW10283959 Whirlpool Refrigerator Filler In Stock WPL WPW10283959 $3.70

WP2205079 Whirlpool Refrigerator Seal Backorder WPL WP2205079 $4.14

WP2212446 Whirlpool Refrigerator Control Body In Stock WPL WP2212446 $30.98

WP489478 Whirlpool Refrigerator Screw In Stock WPL WP489478 $2.51

Grille (Includes Illus. 39) (White) WPL 2254313 Contact Us For Availability

Grille (Includes Illus. 39) (Biscuit) WPL 2254316 Contact Us For Availability

37

WP2210509 Whirlpool Refrigerator Tub Valve Backorder WPL WP2210509 $28.80

38

489136 Whirlpool Refrigerator Screw Backorder WPL 489136 $4.56

38

WP487576 Whirlpool Washer In Stock WPL WP487576 $4.58

WP2156006 Whirlpool Refrigerator Shelf Trim E In Stock WPL WP2156006 $4.10

CLIP, GRILLE (2) WPL 2189356 Contact Us For Availability

Housing Base WPL 2300418 Contact Us For Availability

Air Baffle WPL 2302249 Contact Us For Availability

2213364 Whirlpool Refrigerator Cover Backorder WPL 2213364 $9.48

WP2188874 Whirlpool Refrigerator Condenser Mo In Stock WPL WP2188874 $59.32

WP2213360 Whirlpool Refrigerator Cover Backorder WPL WP2213360 $11.95

WP489442 Whirlpool Refrigerator Screw Backorder WPL WP489442 $4.56

41

Wiring Harness, Freezer Light WPL 2187601 Contact Us For Availability

42

2187382 Whirlpool Refrigerator Wire Harness Backorder WPL 2187382 $110.47

42

Electrical Shield, Freezer Light WPL 2193491 Contact Us For Availability

43

4396822 Whirlpool Refrigerator Light Bulb In Stock WPL 4396822 $5.98

43

W11458267 Whirlpool Refrigerator Fan Blade In Stock WPL W11458267 $7.16

43

WP2195341 Whirlpool Refrigerator Pan Trim Backorder WPL WP2195341 $27.12

44

Trim, Meat Pan WPL 2176357 Contact Us For Availability

45

Shield, heat WPL 2204639 Contact Us For Availability

46

Post, Damper WPL 2179859 Contact Us For Availability

46

Tube, Discharge WPL 2205384 Contact Us For Availability

47

Bracket, Damper Knob WPL 2163810 Contact Us For Availability

47

Tube, Suction WPL 2225237 Contact Us For Availability

48

2154109 Whirlpool Refrigerator Tube Backorder WPL 2154109 $33.89

48

Gasket, Rear WPL 2166284 Contact Us For Availability

54

WP4387503 Whirlpool Refrigerator Bimetal Defr In Stock WPL WP4387503 $16.40

8201826 Whirlpool Refrigerator Evaporator Tra In Stock WPL 8201826 $45.05

876764 Whirlpool Refrigerator Primary Valve In Stock WPL 876764 $27.18

978026 Whirlpool Refrigerator Primary Valve Backorder WPL 978026 $32.32

978027 Whirlpool Refrigerator Primary Valve Backorder WPL 978027 $33.95

978030 Whirlpool Refrigerator Valve Backorder WPL 978030 $35.52

WP978025 Whirlpool Refrigerator Valve In Stock WPL WP978025 $25.89

VALVE, ACCESS (5/8``) WPL 978029 Contact Us For Availability

VALVE, ACCESS (1/2``) WPL 978028 Contact Us For Availability

Following Parts Not Illustrated and Optional WPL ARI67409A5 Contact Us For Availability

REFRIGERANT CHARGE 4.0 Ozs. (R134A) WPL ARI67410A1 Contact Us For Availability

100

4317943 Whirlpool Refrigerator Ice Maker Asse In Stock WPL 4317943 $88.85
