Model Electrolux GCWM2767ADD WALL OVEN, MICRO COMBO, 27 INCH – Common Parts &amp; Diagrams

1

PANEL, MAIN BACK WCI 5304506959 Contact Us For Availability

2

139027805 Frigidaire Shield Backorder WCI 139027805 $40.11

2

SPACER, DOOR HANDLE WCI 330158601 Contact Us For Availability

2A

139015900 Frigidaire Shield Backorder WCI 139015900 $8.02

2B

139038901 Frigidaire Oven Housing Backorder WCI 139038901 $19.57

3

561626486 Frigidaire Door Frame Backorder WCI 561626486 $139.01

3A

5304525458 Frigidaire Trim Assembly Backorder WCI 5304525458 $23.47

4

5304531566 Frigidaire Door Assembly Backorder WCI 5304531566 $248.49

5

807625502 Frigidaire Glass Backorder WCI 807625502 $47.61

5

BRACKET, CONDUIT MTG. WCI 5304530364 Contact Us For Availability

5A

555033602 Frigidaire Glass Assembly Backorder WCI 555033602 $52.46

6

139014203 Frigidaire Oven Baffle Backorder WCI 139014203 $71.40

6

5304514984 Frigidaire Rack In Stock WCI 5304514984 $48.57

6A

5304518865 Frigidaire Rack Assembly Backorder WCI 5304518865 $163.18

7

318372017 Frigidaire Insulation Backorder WCI 318372017 $10.22

7

PANEL, SERVICE, MAIN BACK WCI 5304506960 Contact Us For Availability

7A

318372018 Frigidaire Insulation Backorder WCI 318372018 $8.89

8

139085803 Frigidaire Glass Backorder WCI 139085803 $63.04

9

316081903 Frigidaire Tray Backorder WCI 316081903 $46.89

9

LINER, OVEN DOOR WCI 139002917 Contact Us For Availability

10

5304414648 Frigidaire Oven Screw In Stock WCI 5304414648 $8.91

10A

SCREW, TRUSS, 8-32 X 17.65 WCI 5304528301 Contact Us For Availability

11

807545501 Frigidaire Oven Seal Backorder WCI 807545501 $46.30

11

A06645500 Frigidaire Cover Assembly Backorder WCI A06645500 $24.07

12

555040920 Frigidaire Inner Door Assembly Backorder WCI 555040920 $99.89

12

808136601 Frigidaire Oven Switch Backorder WCI 808136601 $24.96

13

5304525833 Frigidaire Door Assembly Backorder WCI 5304525833 $152.51

14

808082001 Frigidaire Gasket Backorder WCI 808082001 $50.69

15

5304530343 Frigidaire Lamp Assembly Backorder WCI 5304530343 $20.48

15

808140001 Frigidaire Tape Backorder WCI 808140001 $21.39

16

5304525161 Frigidaire Cover Backorder WCI 5304525161 $16.48

16

DUCT, COOLING, XFLOW WCI 139024203 Contact Us For Availability

17

318264735 Frigidaire Spacer Backorder WCI 318264735 $40.11

17

DUCT, SUCTION BYPASS, 2 CHANNEL WCI 139038501 Contact Us For Availability

18

5304531554 Frigidaire Cover Assembly In Stock WCI 5304531554 $46.82

19

5304531555 Frigidaire Cover Assembly Backorder WCI 5304531555 $46.82

20

5304525159 Frigidaire Stopper Backorder WCI 5304525159 $5.78

21

5304525160 Frigidaire Stopper In Stock WCI 5304525160 $5.78

23

808930405 Frigidaire Hinge Assembly Backorder WCI 808930405 $58.32

23

A19949501 Frigidaire Range Washer In Stock WCI A19949501 $4.89

23A

A06683602 Frigidaire Hinge Backorder WCI A06683602 $58.20

24

555023101 Frigidaire Fan Blade Backorder WCI 555023101 $17.37

25

561231207 Frigidaire Nut Backorder WCI 561231207 $10.68

26

COVER, CONVECTION FAN, BACK WCI A07296807 Contact Us For Availability

27

COVER, MICA WCI A16295701 Contact Us For Availability

28

A13805506 Frigidaire Motor In Stock WCI A13805506 $59.08

29

316517600 Frigidaire Oven Spacer Backorder WCI 316517600 $7.57

29

GASKET, DOOR, MICROWAVE WCI 807177101 Contact Us For Availability

30

SUPPORT Backorder WCI 387886701 $14.70

31

SUPPORT Backorder WCI 387886702 $14.70

32

555030400 Frigidaire Magnetron In Stock WCI 555030400 $141.00

33

555044200 Frigidaire Sensor Backorder WCI 555044200 $44.95

34

555030502 Frigidaire Transformer In Stock WCI 555030502 $165.92

35

315795903 Frigidaire Capacitor Assembly In Stock WCI 315795903 $47.12

36

555042802 Frigidaire Diode In Stock WCI 555042802 $18.72

37

5304525427 Frigidaire Probe In Stock WCI 5304525427 $22.39

39

5304525824 Frigidaire Handle Backorder WCI 5304525824 $82.78

39

A20022801 Frigidaire Filter Backorder WCI A20022801 $74.05

40

A18493801 Frigidaire PC Board Assembly In Stock WCI A18493801 $210.85

42

CLIP, PC BOARD, (4) WCI 330647300 Contact Us For Availability

43

CLIP, PC BOARD, FLAT TOP WCI 330647301 Contact Us For Availability

44

318647300 Frigidaire Microwave Fuse and Holde In Stock WCI 318647300 $105.46

45

HOLDER, CABLE, ROUND WCI 387963800 Contact Us For Availability

46

A23242801 Frigidaire Interlock In Stock WCI A23242801 $62.35

47

A23243301 Frigidaire Interlock Component In Stock WCI A23243301 $57.78

49

PLATE, SUPPORT WCI 5304531545 Contact Us For Availability

50

SUPPORT, SIDE WCI 5304531556 Contact Us For Availability

52

TRIM, VENT, BLACK WCI 5304531539 Contact Us For Availability

53

5304504202 Frigidaire Red Meat Temperature Pr Backorder WCI 5304504202 $70.09

53

5304531546 Frigidaire Spacer Backorder WCI 5304531546 $40.61

53A

5304531547 Frigidaire Spacer Backorder WCI 5304531547 $40.94

54

139017203 Frigidaire Assembly Receptacle Backorder WCI 139017203 $92.61

54

5304531550 Frigidaire Cover Assembly Backorder WCI 5304531550 $86.92

56

5304531548 Frigidaire Trim Backorder WCI 5304531548 $67.36

56

A15654501 Frigidaire Coupler Backorder WCI A15654501 $10.68

56A

5303324184 Frigidaire Wall Oven Range Screw Backorder WCI 5303324184 $8.91

56A

5304531549 Frigidaire Trim In Stock WCI 5304531549 $67.36

57

5304506949 Frigidaire Box Backorder WCI 5304506949 $67.00

57

A13881201 Frigidaire Roller Assembly Backorder WCI A13881201 $59.94

58

5304506952 Frigidaire Insulation Backorder WCI 5304506952 $42.74

58

A13804901 Frigidaire Tray Backorder WCI A13804901 $61.27

58A

139001701 Frigidaire Insulation Backorder WCI 139001701 $37.92

58C

5304506954 Frigidaire Insulation Backorder WCI 5304506954 $22.28

58D

5304506965 Frigidaire Insulation Backorder WCI 5304506965 $7.13

58E

5304506966 Frigidaire Insulation Backorder WCI 5304506966 $8.02

59

139015700 Frigidaire Duct Backorder WCI 139015700 $27.61

59

A18994801 Frigidaire Range Accessory Kit Backorder WCI A18994801 $102.94

60

WCI 5304531540 WCI 5304531540 Contact Us For Availability

62

5304409888 Frigidaire Oven Terminal Block Ass In Stock WCI 5304409888 $16.01

66

5304514924 Frigidaire Element Backorder WCI 5304514924 $70.97

67

5304506946 Frigidaire Oven Element Backorder WCI 5304506946 $69.66

70

139000601 Frigidaire Oven Shield Backorder WCI 139000601 $41.86

71

139022000 Frigidaire Oven Shield Backorder WCI 139022000 $38.35

77A

316114100 Frigidaire Oven Spacer Backorder WCI 316114100 $37.90

80

139021101 Frigidaire Bracket Assembly Backorder WCI 139021101 $9.35

82

5304506947 Frigidaire Shield Backorder WCI 5304506947 $59.49

83

5304506951 Frigidaire Shield Appliance Backorder WCI 5304506951 $44.07

86

808930503 Frigidaire Receptacle Backorder WCI 808930503 $10.79

87

BRACKET, CABLE MTG. WCI 139021901 Contact Us For Availability

89

5304528835 Frigidaire Motor Backorder WCI 5304528835 $44.09

90

5304531544 Frigidaire Trim Backorder WCI 5304531544 $56.13

99

318256201 Frigidaire Oven Bracket Backorder WCI 318256201 $35.63

107

5304527949 Frigidaire Cover Backorder WCI 5304527949 $115.06

108

139038303 Frigidaire Blower Assembly Backorder WCI 139038303 $69.03

109

5304525455 Frigidaire Blade Backorder WCI 5304525455 $8.46

111

316136600 Frigidaire Oven Range Lock Nut Backorder WCI 316136600 $12.01

119

318578509 Frigidaire Range/Wall Oven Thermost Backorder WCI 318578509 $8.71

125

139008507 Frigidaire Motor Assembly Backorder WCI 139008507 $57.78

127

139042600 Frigidaire Tube Assembly Backorder WCI 139042600 $27.18

142

WCI 5304506953 WCI 5304506953 Contact Us For Availability

161

139006500 Frigidaire Oven Element Backorder WCI 139006500 $56.86

185

318531800 Frigidaire Oven Spacer Backorder WCI 318531800 $8.00

272

139021700 Frigidaire Oven Tube Backorder WCI 139021700 $11.13

316021109 Frigidaire Oven Screw In Stock WCI 316021109 $8.91

387856311 Frigidaire Screw Backorder WCI 387856311 $1.80

405522329 Frigidaire Screw Kit Backorder WCI 405522329 $13.81

5304470882 Frigidaire Oven Screw Backorder WCI 5304470882 $8.46

5304526533 Frigidaire Screw Backorder WCI 5304526533 $1.35

5304531552 Frigidaire Harness Assembly Backorder WCI 5304531552 $79.19

5304531553 Frigidaire Harness Backorder WCI 5304531553 $44.29

5304531557 Frigidaire Harness Assembly Backorder WCI 5304531557 $28.25

5304531567 Frigidaire Harness Assembly In Stock WCI 5304531567 $67.01

5304535368 Frigidaire Harness Backorder WCI 5304535368 $83.07

A17118003 Frigidaire Harness Assembly Backorder WCI A17118003 $78.93

A17118006 Frigidaire Harness Backorder WCI A17118006 $78.93

A17118014 Frigidaire Harness Backorder WCI A17118014 $78.93

A17118016 Frigidaire Harness Assembly Backorder WCI A17118016 $78.93

A17118021 Frigidaire Harness Backorder WCI A17118021 $78.93

WCI 349475501 WCI 349475501 Contact Us For Availability

WCI 5029617300 WCI 5029617300 Contact Us For Availability

WCI 5304528293 WCI 5304528293 Contact Us For Availability

WCI 5304531542 WCI 5304531542 Contact Us For Availability

SCREW, PT T20, 4 X 10, (8) WCI 349479701 Contact Us For Availability

139022101 Frigidaire Insulation Backorder WCI 139022101 $10.24

316001017 Frigidaire Screw Backorder WCI 316001017 $1.80

316205500 Frigidaire Oven Nut Backorder WCI 316205500 $7.13

316418900 Frigidaire Oven Screw In Stock WCI 316418900 $8.91

5304525451 Frigidaire Harness Backorder WCI 5304525451 $25.36

555031101 Frigidaire Sensor Backorder WCI 555031101 $78.93

WCI 561045004 WCI 561045004 Contact Us For Availability

WCI 387872717 WCI 387872717 Contact Us For Availability
