Model Frigidaire FRT18KC3B2 REFRIGERATOR – Common Parts & Diagrams
Common parts from model Frigidaire FRT18KC3B2 REFRIGERATOR
*#
Hot Tube Repair Kit,Service WCI 5303918234 Contact Us For Availability
4
Damper-fan cover WCI 240367401 Contact Us For Availability
6#
Wiring Harness, machine compt, w/service cord WCI 240375401 Contact Us For Availability
6*#
Wiring Harness,freezer section WCI 240385401 Contact Us For Availability
9
Bracket-motor mtg,front WCI 5303292396 Contact Us For Availability
11
Door,frzr ,white ,complete assy WCI 240412501 Contact Us For Availability
12
Plug-ice maker harness,rectangular WCI 240366801 Contact Us For Availability
12A
Plug-wtr inlet tube,round ,1" WCI 240374401 Contact Us For Availability
13*
Seal-diffuser WCI 240392601 Contact Us For Availability
15
Door,refr ,white ,complete assy WCI 240412601 Contact Us For Availability
18
Knob-control WCI 240360801 Contact Us For Availability
18
Insulation Block,RH WCI 240362301 Contact Us For Availability
20
Insulation Block,LH WCI 240362401 Contact Us For Availability
22
Plate-compr mtg WCI 240330001 Contact Us For Availability
25
Screw-compressor mtg,1/4-28 x 1.16,shoulder,t WCI 240491501 Contact Us For Availability
26
Pan-crisper,white ,(2) ,no graphics WCI 240337101 Contact Us For Availability
41
Screw,hex washer head ,8-32 x 1/4 WCI 218897001 Contact Us For Availability
85
Tube-connector,suction WCI 240493101 Contact Us For Availability
× ![]()
