Model Frigidaire FRT18KC3B0 REFRIGERATOR – Common Parts & Diagrams

*#
Hot Tube Repair Kit,Service
Hot Tube Repair Kit,Service WCI 5303918234 Contact Us For Availability
View on Model
4
Damper-fan cover
Damper-fan cover WCI 240367401 Contact Us For Availability
View on Model
6#
Wiring Harness, machine compt, w/service cord
Wiring Harness, machine compt, w/service cord WCI 240375401 Contact Us For Availability
View on Model
9
Bracket-motor mtg,front
Bracket-motor mtg,front WCI 5303292396 Contact Us For Availability
View on Model
11
Door,frzr ,white ,complete assy
Door,frzr ,white ,complete assy WCI 240412501 Contact Us For Availability
View on Model
12
Plug-ice maker harness,rectangular
Plug-ice maker harness,rectangular WCI 240366801 Contact Us For Availability
View on Model
12A
Plug-wtr inlet tube,round ,1"
Plug-wtr inlet tube,round ,1" WCI 240374401 Contact Us For Availability
View on Model
13*
Seal-diffuser
Seal-diffuser WCI 240392601 Contact Us For Availability
View on Model
15
Door,refr ,white ,complete assy
Door,refr ,white ,complete assy WCI 240412601 Contact Us For Availability
View on Model
18
Knob-control
Knob-control WCI 240360801 Contact Us For Availability
View on Model
18
Insulation Block,RH
Insulation Block,RH WCI 240362301 Contact Us For Availability
View on Model
20
Insulation Block,LH
Insulation Block,LH WCI 240362401 Contact Us For Availability
View on Model
22
Plate-compr mtg
Plate-compr mtg WCI 240330001 Contact Us For Availability
View on Model
25
Screw-compressor mtg,1/4-28 x 1.16,shoulder,t
Screw-compressor mtg,1/4-28 x 1.16,shoulder,t WCI 240491501 Contact Us For Availability
View on Model
26
Pan-crisper,white ,(2) ,no graphics
Pan-crisper,white ,(2) ,no graphics WCI 240337101 Contact Us For Availability
View on Model
26
Pan-defrost drain
Pan-defrost drain WCI 240346901 Contact Us For Availability
View on Model
27
Nut-lock,drain pan mtg
Nut-lock,drain pan mtg WCI 3161461 Contact Us For Availability
View on Model
28
Pan Retainer Kit,Service
Pan Retainer Kit,Service WCI 5303916001 Contact Us For Availability
View on Model
30#
Starter-PTC
Starter-PTC WCI 218721113 Contact Us For Availability
View on Model
72
Button-handle mtg,dovetail
Button-handle mtg,dovetail WCI 218397000 No Longer Available
View on Model
84
Tube-drain,lower
Tube-drain,lower WCI 240367101 Contact Us For Availability
View on Model
85
Tube-connector,suction
Tube-connector,suction WCI 240346202 Contact Us For Availability
View on Model
